Camec COMPACT RV II User manual

1 | P a g e
Version 1.0
COMPACT RV II
TOP LOADING WASHING MACHINE 3.5KG
USER MANUAL
(Part No. 051879)
NOTE: Please read this manual carefully before installing
and/or using this appliance.
More information https://www.caravansplus.com.au

2 | P a g e
Version 1.0
1
General
Safety Instructions……………………………
……………………………………
…
3
2
Installation Instructions
…………………………………………
…………………….
……
…
.
4
3
Operation Instructions
……………………………………….……
…...………….
………….
5
4
Maintenance and Cleaning I
nstructions
……………
………
….
……………………….
6
5
Troubleshooting Instructions
………………
………………………………
….
…………….
7
6
Product Data and Specifications
………………………………………
…………
.
.
………
8
7
Product Warranty
…………………………………
………………………
.
…………
………
…
…
9
Contents
More information https://www.caravansplus.com.au

3 | P a g e
Version 1.0
Please read this manual carefully before installing and/or using this appliance.
Perform all installation, maintenance and operation of this appliance with caution
and care. Proper operation, handling, use and care will ensure effective use through
the service life of this appliance. Camec will not be liable for any damages and/or
claims resulting from incorrect installation and/or improper use of this appliance.
This appliance is intended to be used in household and similar applications
such as: staff laundry areas in shops, offices and other working
environments, farmhouses, hotels, motels and other residential type
environments, bed and breakfast type environments, areas for communal
use in blocks of flats or in launderettes.
Young children should be supervised to ensure that they do not play with
the appliance. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
Installation and Operations Risk
 DO NOT install the appliance in a location where it cannot be drained normally
 DO NOT install the appliance in a humid place i.e. bathroom
 DO NOT install this appliance in a location where the sun is shining direct or near
the heating source.
 DO NOT reuse old hose sets for connection to the water mains. New
hose-sets supplied with the appliance are to be used.
 DO NOT obstruct the ventilation holes at the bottom of this appliance. Check
and ensure that it is not obstructed by carpet, the packaging items, and/or any
other foreign objects
 DO NOT spray water on this appliance
 DO NOT disassemble, repair or modify this appliance
 DO NOT use hot water above 50 degrees Celsius. This appliance is to be used with
cold water only
 DO NOT wash waterproof clothing e.g. rain clothes to avoid abnormal vibration
or damage to clothing. Follow washing instruction on the clothing label
 DO NOT wash clothes that are dyed with volatile substances (such as diluents,
gasoline, etc.)
 DO NOT place any hot or heavy items on this appliance
 DO NOT put your hands into the appliance, at all time, during operation
General Safety Instructions
More information https://www.caravansplus.com.au

4 | P a g e
Version 1.0
1. Adjust the levelling leg – Raise the front side of the
washing machine and adjust the foot on the front left
and right hand sides to ensure that the washing
machine is stable.
2. Install the bottom cover – Insert the
bottom cover from front to rear.
Tighten the cover with a screw.
Installation Instructions
Electrical Risks
 DO NOT bend, pull, entangle, tie or place
heavy object on the power chord
 DO NOT use the appliance when the
power chord and/or plug is faulty. If the
supply cord is damaged, it must be
replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
 DO NOT switch off the power or pull the
power plug when appliance is in operation
 DO NOT connect the power plug with wet
hands
 Disconnect the power plug and water supply
when appliance is under maintenance or
when not in use for prolonged period
 Use a dedicated approved AS/NZS wall type
220V-240V AC power outlet with reliable
grounding
 Use a leakage protection device, whenever
possible
More information https://www.caravansplus.com.au

5 | P a g e
Version 1.0
3. Connect the inlet water pipe joint – Remove the inlet water
pipe joint from the hose. Install the inlet water pipe joint
to the tap. Connect the hose after installation.
4. Connect the water hose – Screw the new water hose
(supplied with the appliance) to the water inlet valve on the
washing machine. After installation, turn on the tap to check
for any leakage.
Operation Instructions
1.
Press Power button to turn ON/OFF
2. Press Select button to select wash
program
3. Press Water Level button to select
required water level
4. Press Start/Pause button to commence
washing
5. Time display shows remaining time to
complete washing.
More information https://www.caravansplus.com.au

6 | P a g e
Version 1.0
Washing Load
Recommended
Water
L
evel
2.8
to
3.5
KG
4L
2.0
to
2.8
KG
3L
1.0
to
2.0
KG
2L
<
1.0
KG
1L
Wash Program
Approx. Cycle Time (min)
Standard
60
Soft 40
Quick
25
Baby clothes
6
0
Wash
15
Spin
10
Drum Self Clean
25
Air Dry
30
NOTE: If this appliance is used in an environment with 0 degree Celsius and below,
it must be moved to a room temperature environment for 2 to 4 hours before use to
avoid damages to the water inlet and drainage system.
1. Use a soft clean cloth to wipe the external surface and
washing machine tub.
2. Open the top cover to dry and air the tub after every wash.
3. Remove and clean the filter cover periodically.
4. Drain residual water in the washing machine if not in use for
prolonged period.
Maintenance and Cleaning Instructions
More information https://www.caravansplus.com.au

7 | P a g e
Version 1.0
NOTE: Before carrying out any maintenance and/or cleaning, always remove the
power plug from the AC wall power outlet and turn off the water tap.
Observation / Fault Recommended Solution
Unable to operate

Check power
supply
 Check power plug is connected
properly
 Check water tap is turned on
 Check if time delay setting is ON
 Check if the top cover is closed
properly
 Check if drain hose is installed
properly
Selected program unable to start

Check if Child Lock or
Time Delay
setting is ON

Restart the washing machine
Water tap leakage

Check if the inlet water pipe joint
size fits the tap
 Check inlet water pipe joint and
water hose are
tightened
properly
Water drains when filling

Check if there are any
foreign
objects causing obstruction at the
drain valve
Abnormal noise

Check if washing machine
installation is stable
 Check if there are any foreign
objects in the tub
 Check if the filter cover is not
installed properly
Clothes are not washed properly

Check washing load is not above the
washing capacity
 Check washing detergent and water
level is enough for washing load
Clothes are not rinsed dry

Clothes are not put properly
in the
tub for rinse. Washing machine will
auto adjust and start rinse again. If
fail after 2 repeat cycles, alarm will
sound,
and rinse operation will stop
Top cover is open during rinse
operation

Do not open top cover during rinse
cycle. Alarm will sound and error
code E3 display
Troubleshooting Instructions
More information https://www.caravansplus.com.au

8 | P a g e
Version 1.0
Error
Code
Observation / Fault Recommended Solution
E1
Wa
ter fill operation more than
20mins

Check inlet water pressure

C
heck and clean filter
E2 Water drain operation more than
5mins

Lower the drain hose
 Check if there are any foreign
objects causing obstruction
E3 Top cover open during rinse cycle  Close the top cover properly
E4
During rinse cycle, tub
got hit
more than 3 times
 Adjust the clothes properly
E6  Water level exceed limit
 Water level sensor faulty

Control unit will auto adjust
water level
 Remove and replace water level
sensor
E7
Top cover open during Child Lock
mode
 Close the top cover properly
Type Fully Automatic Washing Machine
Rated Voltage and Frequency 220 – 240V / 50Hz
Rated Wash / Spin Capacity 3.5KG
Rated Power 280W
Water Pressure 0.1MPa to 0.6MPa
WELS Water Consumption 44L per standard wash cycle
Dimensions 445 (W) x 460 (D) x 730 (H)mm
Net Weight 16KG
Product Data and Specifications
More information https://www.caravansplus.com.au

9 | P a g e
Version 1.0
This product is covered under a 12 months warranty period. Kindly refer to the
warranty policy terms and conditions available on Camec website.
For further information or assistance, please contact our National Customer Support
Team or visit Camec website.
1. Australia on 1300 422 632 or camec.com.au
2. New Zealand on 09 257 2419 or camec.co.nz
For any retail or trade enquiries, please contact our Sales office.
CAMEC VICTORIA
47-63 Remington Drive
Dandenong South VIC 3175
23-27 Freight Drive
Somerton VIC 3062
Phone: [phone]
CAMEC NEW ZEALAND
44 Montgomerie Road
Mangere Auckland 2022
Phone: [phone]
CAMEC NEW SOUTH WALES
Units 2 & 3 No. 1 Koonya Circuit
Caringbah NSW 2229
Phone: [phone]
CAMEC QUEENSLAND
Building 3 Archerfield Industrial Park
Cnr Kerry & Beaudesert Road
Archerfield QLD 4108
Phone: [phone]
CAMEC WESTERN AUSTRALIA
190 Welshpool Road
Welshpool WA 6106
Phone: [phone]
