Cameron CA-555DVD Quick start guide
Cameron CA-555DVD
Part
(Код ЗЧД=Номер ЗЧД)
1CD-7511 ORNAMENT 1 483-7511A00-10000
2CMPV-9002 {VOL } -KNOB 1428-9002A00-1NL00
3CD-7511 WINDOW 1 413-7511A00-2CR00
4CD-7511 NOSE-PLIECE 1 402-7511B00-1BK00
5CD-7511 {RELEASE }-KNOB 1 439-7511A00-10000
6CD-1188 RELEASE SPRING 1 209-1188000-K0000
7CD-7511 {BAND }-KNOB 1 423-7511A00-CCR00
8CD-7511 {AF-TA }-KNOB 1 446-7511A00-2BE00
9CD-7511 {AF-TA}-KNOB BASE 1 460-7511B00-CCR00
10 AF-TA-KN0B-REFLECT0R-CD7511 1 446-7511A00-2BE00
11 LCD DISPLAY TB1439BMTTN 1 008-TB14391-TN0RB
12 CD-7607 LCD-FILTER-{BIG}72.2X29 1 245-7607100-A0100
13 CD-7607 LCD RREFLECTOR PAPER 1 246-7607A02-WE010
14 CD-7607 LCD-REFLECTOR 1 414-7607500-2CR00
15 CD-7500 {LEFT}RELEASE-SHAFT-BASE 1 462-7500C00-9BK00
16 RELEASE-SPING (BLACK) CD-7500 1 209-7500000-K0000
17 SCREWPA 2.0x8.0MM BLACK 3 234-PA02000-08B00
18 CD-7511 NOSE-PIECE-BACK 1 402-7511C00-1BK00
19 CD-7500 {RIGHT}-RELEASE-SHAFT-BASE 1 462-7500D00-9BK00
20 FRONT-PCB 1 CA-555DVD-20
21 CD-7607 LCD BRACKET-PASTER 1 246-7607A01-BK010
22 CD-7511 {CIRCLE}-REFLECTOR 1 414-7511A00-2BE00
23 CD-7511 {TRK-UP-DN}-KN0B BASE 1 460-7511A00-CCR00
24 CD-7511 {MUTE }-KNOB 1 436-7511A00-2BE00
25 CD-7511 {TRK-UP/DN}-KNOB 1 418-7511A00-2BE00
26 CD-7511 {POWER-SEL}-KNOB 1 427-7511A00-2BE00
27 CD-7511 {MODE }-KNOB 1 445-7511A00-2BE00
28 CD-7511 {TRACK-UP-KNOB}-ORNAMENT 1 483-7511B00-10000
29 CD-7511 {ORNAMENT}-KNOB 1 454-7511A00-2BE00
30 CD-7511 {PTY }-KNOB 1 446-7511B00-2BE00
31 CD-7507 TRIM-COVER 1 441-7507A00-1BK00
32 CD-7500 BASE-PANEL 1 402-7500A00-3BK00
33 FLAT-WASHER-AA ID2.0XOD5.0W/OPEN CUTTING 1 212-2005000-03P00
34 CD-7500 REL-BRACKET-SHAFT-(LEFT) 1 219-7500000-L0000
35 CD-7500 STOP SHAFT 1 219-7500000-A0000
36 CD-7500 RELEASE-GEAR-SHAFT 1 219-7500000-B0000
37 CD-7500 FRONT-BRACKET-{LEFT } 1 218-7500F00-E1000
38 MICRO DAMPER ASS'Y DPP0l 14TQ (19-24) RED COLOR 1 462-2001A00-3BK00
39 MACHINE SCREWPM 2.0x3.0MM 2 234-PM02000-03000
40 SCREWPB 2.0X 4.0MM TS NICKLE 4 234-PB02000-04000
41 CD-7500 RELEASE-GEAR-B 1 462-7500B00-9BK00
SparePartsList (CA-555DVD)
DescriptionItem QTY
42 RELEASE-SPRING(BLACK) CD-7500 D5.2XL3.0X0.5T 1 209-7500000-K0000
43 CD-7500 RELEASE-GEAR 1 462-7500A00-9BK00
44 CD-7500 HOOK 1 440-7500A00-3BK00
45 HOOK-SPRING CD-7500 D4.BXL2.8X0.35T 1 209-7500000-L0000
46 CD-7600 DETECTING SWITCH SPRING-PLATE 1 217-7600A00-00000
47 CD-7500 PANEL DETECTING KNOB 1 456-7500A00-1BK00
48 SCREW: MS 3.0X 4.0(5.5x1x4) 3 234-MS03000-04000
49 CD-7500 REL-BRACKET-SHAFT-(RIGHT) 1 219-7500000-R0000
50 CD-7500 FRONT-BRACKET-{RIGHT } 1 218-7500G00-E1000
51 CD-7500 EJ-KNOB 1 430-7500A00-3CR00
52 CD-3888 CD SLOT FELT 1 228-3888A00-00000
53 CD-3888 CD-GUIDE PLATE 1 243-3888000-A0000
54 CONNECTOR PCB 1 H0B-7505S00-C00000-000
55 CD-7500 CD-GUILD-REFLECTOR 1 414-7500100-2CR00
56 SCREWPB 2.0x5.0MM TS NICKLE 234-PB02000-05000
57 CD-3987 DECK-BRACKET-"FRONT" 1 218-3987C00-E1000
58 SCREWTTP 3.0x5TAP TYPE (B) 6 234-PTT3000-05000
59
CARDVD DECK DL-C28D1 W/HOP1200W PICK UP (without Servo Board)
1203-DLC28D1-1200W
59 SERVO BOARD (for CD Deck) 1D02-DVD7505-7500DD-200
59 SERVO BOARD WITH DVD DECK ASSY 1CA-555DVD-92
60 SCREW: TS 2.6x4 TAP TYPE WHITE 5 234-PT02600-04000
61 DVD-7505 DECK-BRACKET - (RIGHT) 1 218-7505X00-E1000
62 DVD-7505 DUSTPROOF-FABRIC 1 228-7505A00-00000
63 DVD-7505 TOP-COVER 1 222-7505J00-E0600
64 DVD-7505 DECK-BRACKET - (LEFT) 1 218-7505Y00-E1000
65 DVD-7505 SIDE-CHASSIS - (RIGHT) 1 218-7505R00-E1000
66 MAIN-PCB-BOARD 1CA-555DVD-66
67 TAP TYPE SCREWTTP M3.0x5.0MM 7 234-PT03000-05000
68 CD-3988 BACK CHASSIS FOR ISO-CON 1 218-3988B00-E1000
69 HEAT-SINK-S CD-3300 1 216-3300B00-C0000
70 TAP TYPE"C"SCREWTTP M3.0x8.0MM 1 234-PT03000-0B000
71 SCREWTTP 3.0x5TAP TYPE (B) 6 234-PTT3000-05000
72 CD-3896 SLEEVE-CASE 1 222-3896S00-E0600
73 SPRING WASHER ID =5.2x9.0xl.4T 1 212-5209000-14S00
74 HEX BOLT D5xl2mm DOUBLE HEAD 1 234-HEX5000-12000
75 MACHINE SCREWPM 3.0x13.0MM 2 234-PM03000-13000
76 CD-3300 FIXED-ISO-CONNECTOR 4 485-3300A00-8BK00
77 HEX NUT: M3 1 233-N030W00-H0000
78 DVD-7505 SIDE-CHASSIS - (LEFT) 2 218-7505L00-E1000
79 MACHINE SCREWPM 3.0x6.0MM 1 234-PM03000-06000
80 DVD-7505 MAIN-FIBRE 1 214-7505000-05F00
81 DVD-7505 BOTTOM-COVER 1 218-7505K00-E0600
FRONT PANEL ASSY 1CA-555DVD-90
REMOTE CONTROL 1 CA-555DVD-91
Product Code K02-DVD7511-270158-00A
Report Date 17/01/2007 10:08:43
Item Material Code Brief Description Qty Remarks
DVD-7511 RDS CAR DVD[CAMERON CA-555
DVD]-RU-64104T 1
RDS/MW/FM/OIRT,DVD,40WX4,2N/2O,BISO,CAS'
G1
1 010-351MT22-2600A
AMORPHOUS TOROID 350uH 6A 20% D22x14 H-
TYPE L=4MM 1 L801
2 022-C101000-10000 PLUG TYPE FUSE 10A 32V RED COLOUR 1
3 029-B000100-00000
ANTENNA JACK DOUBLE SCREW ANGLE
SOLDER PLATE 1
4 031-0050U00-15000
FFC 15PIN 1.25PT L=(3+50+3) 2896 ROHS FOR
CD-7500 1
5 037-G032000-101B1
RCA 1xSH 320mm YELLOW W/CLIP FOR
DVD3000 1 YELLOW
6 037-G030000-201A0
2xRCA SKT W/O HOUS'G 3PIN 300mm BLK
W/CLIP DVD7505 1 LINE-IN RCA
7 037-G030000-203A0
2xRCA SKT W/O HOUS'G 3PIN 300mm GRY
W/CLIP DVD7505 1 REAR LINE-OUT RCA
8 209-7500000-K0000
RELEASE-SPRING(BLACK) CD-7500
D5.2XL3.0X0.5T 1
9 209-7500000-L0000 HOOK-SPRING CD-7500 D4.8XL2.8X0.35T 1
10 217-7600A00-00000 CD-7600 DETECTING SWITCH SPRING-PLATE 1
11 212-2005000-03P00
FLAT-WASHER-AA ID2.0XOD5.0 W/OPEN
CUTTING 1
12 212-5209000-14S00 SPRING WASHER ID=5.2x9.0x1.4T 1 SET:1
13 214-7505000-05F00 DVD-7505 MAIN-FIBRE [T=0.5mm] 1
14 216-7505B00-C0000
DVD-7505 HEAT-SINK W/SAND BLOWING [AL DIE
CASTING] 1
15 218-3988B00-E1000 CD-3988 BACK CHASSIS FOR ISO-CON [EGI-1.0] 1
16 218-7500F00-E1000 CD-7500 FRONT-BRACKET-{ LEFT } [EGI-1.0] 1
17 218-7500G00-E1000 CD-7500 FRONT-BRACKET-{ RIGHT } [EGI-1.0] 1
18 218-7505K00-E0600 DVD-7505 BOTTOM-COVER [EGI-0.6] 1
19 218-7505L00-E1000 DVD-7505 SIDE-CHASSIS - (LEFT) [EGI T=1.0] 1
20 218-7505R00-E1000 DVD-7505 SIDE-CHASSIS - (RIGHT) [EGI T=1.0] 1
21 219-7500000-A0000 CD-7500 STOP SHAFT [BRASS] 1
22 219-7500000-B0000 CD-7500 RELEASE-GEAR-SHAFT [BRASS D.Ni] 1
23 219-7500000-L0000 CD-7500 REL-BRACKET-SHAFT-(LEFT) [BRASS] 1
24 219-7500000-R0000 CD-7500 REL-BRACKET-SHAFT-(RIGHT) [BRASS] 1
WIWI INDUSTRIES LIMITED
K02-DVD7511-270158-00A
C02-DVD7500-64104T-EU1
CA-555 (DVD7511) CAMERON BOM PAGE 1 OF 13
Item Material Code Brief Description Qty Remarks
25 222-7505J00-E0600 DVD-7505 TOP-COVER [EGI T=0.6] 1
26 225-0900700-40000 PAD CORK 9x7x4mm W/ADHESIVE 3
27 227-8500A00-00000
CD-8500 EMI-CONDUCTIVE SPONGE
20X10X10MM 1
28 228-3888A00-00000
CD-3888 CD SLOT FELT [60g/m2 NON WOVEN
CLOTH] 1
29 228-7505A00-00000 DVD-7505 DUSTPROOF-FABRIC 1
30 233-N030W00-H0000 HEX NUT: M3 4 IC:2
31 234-HEX5000-12000
HEX BOLT D5x12mm DOUBLE HEAD [CARBON ST
D.Zn] 1
32 234-MS03000-04000 SCREW: MS 3.0 X 4.0 (5.5x1x4) 3 BASE PANEL:3
33 234-PB02000-04000 SCREW PB 2.0 x 4.0 MM TS NICKLE 4 RELEASE BRACKET:4
34 234-PB02000-05000 SCREW PB 2.0 x 5.0 MM TS NICKLE 2 CONNECTOR PCB:2
35 234-PM02000-03000
MACHINE SCREW PM 2.0 x 3.0 MM NICKLE
ROUND HEAD 2 DAMPER:2
36 234-PM03000-06000
MACHINE SCREW PM 3.0 x 6.0 MM NICKLE
ROUND HEAD 2 IC:2
37 234-PM03000-08000
MACHINE SCREW PM 3.0 x 8.0 MM NICKLE
ROUND HEAD 2 IC:2
38 234-PM03000-13000
MACHINE SCREW PM 3.0 x 13.0 MM NICKLE
ROUND HEAD 2 IC:2
39 234-PT03000-05000
TAP TYPE SCREW TTP M3.0 x 5.0 MM NICKLE
ROUND HEAD 7
BRACKET+CHA:3 BET+MAIN
PCB:1
40 234-PT03000-08000
TAP TYPE"C" SCREW TTP M3.0 x 8.0 MM NICKLE
ROUND H 4
BRACKET:1 HEAT SINK+SIDE
SHASSIS:2
41 234-PTT3000-05000 SCREW TTP 3.0 x 5 TAP TYPE (B) 6
COVER+HEAT SINK;3 ANT+HEAT
SINK:2 DECK BKT+HEAT SINK:1
42 243-3099000-M0000 FF/REW COVER 1
43 243-3888000-A0000 CD-3888 CD-GUIDE PLATE [PVC-0.5T BLACK] 1
44 402-7500A00-3BK00 CD-7500 BASE-PANEL [PC BLACK] 1
45 414-7500100-2CR00 CD-7500 CD-GUILD-REFLECTOR [PMMA CLEAR] 1
46 430-7500A00-3CR00 CD-7500 EJ-KNOB [PC CLEAR] 1
47 440-7500A00-3BK00 CD-7500 HOOK [PC BLACK] 1
48 456-7500A00-1BK00 CD-7500 PANEL DETECTING KNOB [ABS] BLACK 1
49 462-2001A00-3BK00
MICRO DAMPER ASS'Y DPP01 14TQ (19-24) RED
COLOR 1
50 462-7500A00-9BK00 CD-7500 RELEASE-GEAR [POM BLACK] 1
51 462-7500B00-9BK00 CD-7500 RELEASE-GEAR-B [POM BLACK] 1
52 802-0703E00-WE000 SILICONE GLUE 45grm 0.03
DVD-7500 DVD SERVO [ZORAN] SHINWA DECK
ASSY 1
D02-DVD7505-7500DD-200
CA-555 (DVD7511) CAMERON BOM PAGE 2 OF 13
Item Material Code Brief Description Qty Remarks
53 203-DLC28D1-1200W
CAR DVD DECK DL-C28D1 W/HOP1200W PICKUP
[SHINWA] 1
54 212-3006000-05F00 FIBER WASHER ID3.0 x OD6.0 x 0.5T 4
55 214-3300000-B0000
CD-3300 DECK MOTOR-COVER-FIBRE [10x27mm]
0.5T 1
56 214-DECK000-A0000 DECK FIBER 105x95x0.5mm 1
57 216-3300B00-C0000 HEAT-SINK-S CD-3300 [IRON PLATE] 1 FOR MOTOR DRIVER IC
58 218-3987C00-E1000 CD-3987 DECK-BRACKET-"FRONT" [EGI T=1.0] 1
59 218-7505X00-E1000 DVD-7505 DECK-BRACKET - (RIGHT) [EGI T=1.0] 1
60 218-7505Y00-E1000 DVD-7505 DECK-BRACKET - (LEFT) [EGI T=1.0] 1
61 234-BMT2000-05000 SCREW TTP 2.0 x 5.0 BM TAP TYPE 4 SUB PCB:4
62 234-PT02600-04000 SCREW: TS 2.6x4 TAP TYPE WHITE 5 DECK BRACKET:5
DVD-7500 DVD SERVO BOARD [ZORAN] SHINWA
HISEM 1
63 002-S111718-F003A
IC S1117-18PI 1.8V 1A LDO REGULATOR
[TO220F] 1 U502
64 004-SR23G00-00000
INFRARED EMITTING DIODE SR-23G/OSE-
23G/OSE-23F 2 LD1,LD2
65 006-2700000-40000 CRYSTAL 27.000MHZ HC-49U/S 20P 30PPM 1 Y101
66 012-4226C00-30000 MINI E-CAP [4X5] 22uF 16V 20% 85C 1 C217.
67 012-4476C00-30000 MINI E-CAP [5X5] 47uF 16V 20% 85C 7 C324.229.228.209.159.158.319
68 012-5107C00-30000 MINI E-CAP [6x5] 100uF 16V 20% 85C 3 C201.504.503.
69 012-5227B00-30000 MINI E-CAP [6x5] 220uF 10V 20% 85C 5 C505.529.508.C244.17.
70 025-TA02000-33000 SWITCH 2P 3.3mm SW-111 HC-49S 1 SW1
71 031-F150100-22531
22PIN FFC CABLE L=150 PT=1.0 (5MM+3MM) UL
W/TAPE 1 CN7
72 037-C609000-3B000 H'ING 3PIN P=2.5mm 1X28 2XSH 90mm 1
DVD-7500 DVD SERVO BOARD [ZORAN] SMTSEM 1
73 001-7500D00-D2000
PCB DVD-7500 DVD SERVO BOARD W/MP3 [REV-
5] 1
74 002-0111700-U3300 IC S1117-33Q 3.3V 1A LDO [SOT223] AUK 2 U501.503.
75 002-0455800-G0000 IC TJM4558-C DUAL OP-AMP [SO8] 1 U303
76 002-9VF1601-U048D
IC SST39VF1601-70-4C-EK 16Mb FLASH ROM
[TSOP48] 1 U106
77 002-BA5888F-D028A
IC BA5888FP BTL DRIVER FOR CD/CD-ROM FOR
DVD-7505 1 U202.
78 002-K4S6416-U050D
IC 64M(4MX16) SDRAM K4S641632H-TC(L)70
[TSOP50] 1 U102
79 002-ZR36882-R208D
IC ZR36882ELCG DVD SERVO MCU [LQFP208]
ZORAN 1 U101
H05-7500D00-D20000-000
S05-7500D00-D20000-000
CA-555 (DVD7511) CAMERON BOM PAGE 3 OF 13
Item Material Code Brief Description Qty Remarks
80 003-0390400-S0000 SMD TR-NPN UTC MMBT3904/2N3904 [SOT23] 3 Q312.313.303.
81 003-0390600-S0000 SMD TR-PNP UTC MMBT3906/2N3906 [SOT23] 2 Q304.305
82 003-STN2907-S0000
SMT TR-PNP STN2907S -60V,0.6A,HFE-
75,MK"GA"[SOT23] 2 Q204.205.
83 004-0414800-S0000 CHIP-DIODE [0805] CD4148 3 D301.302.1.
84 004-SDB310W-SKD00
SMD 2XSCH-DIODE BAT54S OR SDB310WM 30V
0.2A[SOT23] 3 D501.204.104.
85 010-1R0KS08-00000
CHIP INDUCTOR [0805] 1uH 10% 50mA
DCR<=0.4R 1 L501.
86 010-H010600-00000 CHIP-INDUCTOR [0805] 10uH 5% (15mA MAX) 2 L201.1
87 011-S000A00-20000 CHIP RES [0805] 0 OHM 5% 15
R239.160.164.166.275.272.259.252.
2.133.11.10.1.FB110.FB106.
88 011-S010A00-20000 CHIP RES [0805] 1 OHM 5% 4 R274.273.256.255.
89 011-S100A00-20000 CHIP RES [0805] 10 OHM 5% 3 R224.221.202
90 011-S102A00-20000 CHIP RES [0805] 1K OHM 5% 9
R185.264.265.277.334.325.3.276.27
7
91 011-S103A00-20000 CHIP RES [0805] 10K OHM 5% 13
R501.503.502.247.237.236.254.267.
3861.3832.311.281.2A0
92 011-S104A00-20000 CHIP RES [0805] 100K OHM 5% 2 R312.115
93 011-S121A00-20000 CHIP RES [0805] 120 OHM 5% 1 R203.
94 011-S151A00-20000 CHIP RES [0805] 150 OHM ㊣5% 1 R9
95 011-S153A00-20000 CHIP RES [0805] 15K OHM ㊣5% 1 R104
96 011-S202A00-20000 CHIP RES [0805] 2.0K OHM 5% 2 R299.R314
97 011-S203A00-20000 CHIP RES [0805] 20K OHM ㊣5% 5 R101.3852.3851.12.3812
98 011-S221A00-20000 CHIP RES [0805] 220 OHM ㊣5% 3 R533.222.223.
99 011-S223A00-20000 CHIP RES [0805] 22K OHM ㊣5% 1 R292.
100 011-S224A00-20000 CHIP RES [0805] 220K OHM ㊣5% 1 R112.
101 011-S273A00-20000 CHIP RES [0805] 27K OHM ㊣5% 2 R127.128
102 011-S330A00-20000 CHIP RES [0805] 33 OHM ㊣5% 2 R382.217.
103 011-S331A00-20000 CHIP RES [0805] 330 OHM ㊣5% 1 R532.
104 011-S332A00-20000 CHIP RES [0805] 3.3K OHM ㊣5% 1 R318
105 011-S333A00-20000 CHIP RES [0805] 33K OHM ㊣5% 2 R278.R105
106 011-S390A00-20000 CHIP RES [0805] 39 OHM 5% 1 R279.
107 011-S391A00-20000 CHIP RES [0805] 390 OHM ㊣5% 1 R106.
CA-555 (DVD7511) CAMERON BOM PAGE 4 OF 13
Item Material Code Brief Description Qty Remarks
108 011-S472A00-20000 CHIP RES [0805] 4.7K OHM ㊣5% 19
R338.337.330.339.333.384.324.
380.320.329.327.328.119.120.
126.168.125.308.103.
109 011-S473A00-20000 CHIP RES [0805] 47K OHM ㊣5% 5 R313.540.539.244.139.
110 011-S560A00-20000 CHIP RES [0805] 56 OHM 5% 1 R123.
111 011-S682A00-20000 CHIP RES [0805] 6.8K OHM 5% 1 R248
112 011-S750A00-20000 CHIP RES [0805] 75 OHM 5% 3 R110.129.113.
113 011-S910A00-20000 CHIP RES [0805] 91 OHM 5% 2 R283.270.
114 013-D106L00-50A00 TAN CHIP CAP 10uF 10V ㊣20% [A SIZE] 1 C317
115 013-D106M06-S2012
CHIP TAN CAP 10uF 6.3V 20% [2012] (0805) SIZE
REEL 2 C2.3
116 013-D107J00-50C00 TAN CHIP CAP 100uF 6.3V 20% [B/C SIZE] 1 C122.
117 013-D226J00-50A00 TAN CHIP CAP 22uF 6.3V 20% [A SIZE] 1 C108.
118 013-D227J00-50C00 TAN CHIP CAP 220uF 6.3V 20% "C-Size" 2 C120.C318.
119 013-D476J00-50A00 CHIP TAN CAP 20% 47uF 6.3V [A-SIZE] 2 C16.124
120 014-S100C00-200NP CHIP CAP [0805] 10PF 50V +/-0.5P NPO 1 C520
121 014-S101C00-400NP CHIP CAP [0805] 100PF 50V +/-5% NPO 2 C218.247
122 014-S102C00-50000 CHIP CAP [0805] 102P (0.001uF) 50V ㊣10% 13
C166.167.179.165.105.104.102.212.
168.110.109.178.9
123 014-S103C00-50000 CHIP CAP [0805] 103P (0.01uF) 50V +/-10% 28
C556.154.152.141.149.155.140.139.
150.142.136.162.130.554.553.18.13
5.137.138.146.123.196.121.555.147.
12.119.163.
124 014-S104B00-80000 CHIP CAP [0805] 104P (0.1uF) 25V +80-20% 16
C343.246.245.274.103.270.208.8.
207.204.203.560.530.125.242.241.
125 014-S151C00-50000 CHIP CAP [0805] 151P (150PF) 50V 10% 2 C511.C521.
126 014-S181C00-50000 CHIP CAP [0805] 180PF 50V 10% 2 C331.321.
127 014-S201C00-50000 CHIP CAP [0805] 201P (200PF) 50V 10% 2 C335.325
128 014-S220C00-400NP CHIP CAP [0805] 22PF 50V +/-5% NPO 2 C114.115.
129 014-S221C00-50000 CHIP CAP [0805] 221P (220PF) 50V 10% 1 C544.
130 014-S223C00-80000 CHIP CAP [0805] 223P (0.022uF) 50V +80-20% 2 C251.C1.
131 014-S273C00-50000 CHIP CAP [0805] 0.027UF 50V 10% 1 C101.
132 014-S330C00-400NP CHIP CAP [0805] 33PF 50V +/-5% NPO 16
C197.107.195.194.192.193.190.191.
189.186.187.188.336.332.326.322
133 014-S471C00-50000 CHIP CAP [0805] 471P (470PF) 50V 10% 2 C205.216
134 036-G00500A-242L0
SMT 24P FFC CONN PT=0.5 H-TYPE UPPER
CONTACT 1 CN3
CA-555 (DVD7511) CAMERON BOM PAGE 5 OF 13
Item Material Code Brief Description Qty Remarks
135 057-121T000-S0200
CHIP BEAD [0603] R=120R/100MHz DCR=0.25,
0.5A(MAX) 9
FB502.111.112.105.102.FB101.501.
503.505.
DVD-7511
RDS/MW/FM/OIRT,DVD,40WX4,2N/2O,BISO M.HIS 1
136 002-0078L15-T003A IC LM78L15 15V 0.1A [TO92] 3PIN REGULATOR 1 IC802.
137 002-0455800-G0000 IC TJM4558-C DUAL OP-AMP [SO8] 2 IC902.901
138 002-0729100-A0000 IC TA7291S (SIP-9) BRIDGE MOTOR DRIVER 1 IC603
139 002-1923F00-G0700 IC BU1923F RDS DECODER 1 IC2
140 002-2313L00-B0000 IC PT2313L AUDIO PROCESSOR [SOP28] 1 IC401
141 002-72F321A-H064D
IC 72F321R9T6 MCU W/SOFTWARE [QFP64]
DVD7508/RDS 1 U1
142 002-78L0500-F0000 IC KIA78L05 5V 0.1A REGULATOR [TO92] KEC 1 U2
143 002-9256F00-G0200 IC KIC9256F FM PLL [SOP16] 1 IC101
144 002-LM2576T-F005A
IC LM2576T-ADJ 3A STEP-DN POWER REG 5PIN
[TO220] 1 Q6
145 002-TDA7454-W025A
IC TDA7454 4X35W CAR AUDIO AMP
[FLEXIWATT25] ST 1 C801
146 003-0130300-D0300
TR-NPN KTD-1303 [TO-92M] AUDIO MUTING (25V
0.3A) 4 Q4.3.2.1
147 003-0136800-C0000 TR-PNP KTB1368-O -80V -4A 25W [TO-220IS] 1 Q804.
148 003-1267Y00-A0000
TR-PNP KTA1267-Y [TO-92M] GENERAL USE (-
50V 0.15A) 1 Q104
149 003-3199Y00-A0000
TR-NPN KTC3199-Y [TO-92M] GENERAL USE (50V
0.15A) 3 Q401.811.110.
150 003-B1243Q0-J0700
TR-PNP 2SB1243-Q POWER -60V,3A,1W [ATV-
ROHM] 4 Q109.814.812.806.
151 003-D1859Q0-J0700
TR-NPN 2SD1859-Q MED.POWER 80V,0.7A,1W
[ATV-ROHM] 2 Q5.809.
152 004-0400100-00000 DIODE 1N4001 50V 1A 2 D802.807.
153 004-0414800-00000 DIODE 1N4148 11
D805.721.702.402.401.808.710.708.
704.806.709.
154 004-0581800-00000 SCHOTTKY DIODE 1N5818 30V 1A 1 D1
155 005-0004700-A0000 ZENER DIODE 4.7V 1/2W +/-5% 1
156 005-0005100-A0000 ZENER DIODE 5.1V 1/2W +/-5% 1
157 005-0005600-A0000 ZENER DIODE 5.6V 1/2W +/-5% 1 ZD804.
158 005-0006200-A0000 ZENER DIODE 6.2V 1/2W +/-5% 4 ZD705.706.704.703.
159 005-0006800-A0000 ZENER DIODE 6.8V 1/2W +/-5% 1 ZD831
160 005-0008200-A0000 ZENER DIODE 8.2V 1/2W +/-5% 2 ZD1.ZD401
161 005-0009100-A0000 ZENER DIODE 1/2W 9.1V 2 ZD701.803.
162 006-0433200-40000 CRYSTAL 4.332MHz HC49US 30PPM CL=16PF 1 X702
H01-7500S00-DM1000-EU4
CA-555 (DVD7511) CAMERON BOM PAGE 6 OF 13
Item Material Code Brief Description Qty Remarks
163 006-0450000-40000 CRYSTAL 4.5MHz HC-49US 30P 30PPM H=3.5 1 X101
164 006-0800000-40000 CRYSTAL 8.0MHz [HC-49U/S] +/-30PPM CL=16PF 1 X701.
165 009-0702000-A0200 TUNER CET-7020YC/E AM/FM OIRT [TAEBONG] 1 TUNER
166 010-220KRAE-22200
POWER INDUCTOR 22uH 20% 2.2A [D10x14.5MM]
LEADFREE 1 L1
167 010-221KT15-20500
TOROID 227uH 10% 2PIN D16x10mm (WIRE
0.5x70.5Ts) 1 L3
168 010-330KA24-20000 INDUCTOR [EC24] 33uH 10% Q=50 AXIAL 2 L802.L103
169 010-3R3KA22-20000 INDUCTOR [EC22] 3.3uH 10% AXIAL TYPE 1 L101.
170 011-A100D00-20000 RES 1/4W ㊣5% 10 OHM 1 R815
171 011-A103A00-20000 RES 1/16W ㊣5% 10K OHM 2 R810.813.
172 011-A151A00-20000 RES 1/16W ㊣5% 150 OHM 1 R405
173 011-A222A00-20000 RES 1/16W ㊣5% 2.2K OHM 2 R842.812.
174 011-A229A00-20000 RES 1/16W 5% 2.2 OHM 1 R37
175 011-A471A00-20000 RES 1/16W ㊣5% 470 OHM 1 R5
176 011-A474A00-20000 RES 1/16W ㊣5% 470K OHM 2 R807.808.
177 011-A479A00-20000 RES 1/16 W ㊣5% 4.7 OHM 1 R623
178 011-A479F00-20000 CF-RES 1/2 W 5% 4.7 OHM 1 R825B
179 011-A562A00-20000 RES 1/16W ㊣5% 5.6K OHM 2 R29.28.
180 012-1107C00-30000 MINI E-CAP [5x7] 100uF 16V 20% 85C 18
C828.825.832.824.8.120.121.117.83
7.836.902.410.137.901.1.16.2.703
181 012-1476C00-30000 MINI E-CAP [5x7] 47uF 16V 20% 85C 2 C409.810.
182 012-5227B00-30000 MINI E-CAP [6x5] 220uF 10V 20% 85C 1 C604.
183 012-B105F00-30000 MINI E-CAP [4x7] 1uF 50V 20% 85C 23
C904.424.838.531.532.802.803.416.
414.903.906.412.905.413.411.804.
138.719.801.811.132.425.CE203.
184 012-B106D00-30000 MINI E-CAP [4x7] 10uF 25V 20% 85C 5 C842.829.426.721.812.
185 012-B225F00-30000 MINI E-CAP [4x7] 2.2uF 50V 20% 85C 3 C821.108.107.
186 012-B475F00-30000 MINI E-CAP [4x7] 4.7uF 50V 20% 85C 4 C10.3.128.4.
187 012-R228D00-30000 E-CAP [13x26] 2200uF 25V 20% 85C 1 C813
188 014-A103C00-60000 CER CAP 103P (0.01uF) 50V ㊣20% 1 C106.
189 023-A005000-RD000 LED RED DIA=5mm 2V/20mA 25-40mcd 1 D2
190 025-LF1120B-00000
MICRO DETECTOR SWITCH [1P1T] 1120B FOR
CD7600 1 Q8
CA-555 (DVD7511) CAMERON BOM PAGE 7 OF 13
Item Material Code Brief Description Qty Remarks
191 025-TA04000-38500 4P TACT SW H=3.85 169G/F 1 JP1
192 033-S100000-BN000 S.SHIELD WIRE #28 100MM(3+94+3) BROWN 1
193 035-E080000-RD100 JUMPER WIRE AWG#26 80mm RED (3+80+3) 2
194 036-D01000A-2220A
22P FFC CONN PT=1.0 L-DIP TYPE-A UPPER
CONTACT 1
195 221-S004000-04000 BARE WIRE D=0.4x40mm 130
RDS/MW/FM/OIRT,DVD,40WX4,2N/2O,BISO
M.SMT 1
196 001-7500S00-DM100 PCB DVD-7500 RDS MAIN BOARD [REV-C] 1
197 003-0011400-S0700 SMT TR-NPN DTC-114TUA [SOT-23] 1 Q16.
198 003-0150400-B0300
SMT TR-PNP KTA1504S-GR/A1980S/F [SOT-23]
50V 0.15A 1 Q15.
199 003-0387500-G0000
SMT TR-NPN KTC3875S/2SC-5343S/F [SOT-23]
50V 0.15A 14
Q803.813.808.102.103.106.108.101.
802.703.7.606.605.105.
200 004-0414800-S0000 CHIP-DIODE [0805] CD4148 2 D804.101.
201 011-S000A00-20000 CHIP RES [0805] 0 OHM 5% 13
R4.3.2.10.36.35.34.6.RJ5.RJ9.R622.
190.C101
202 011-S101A00-20000 CHIP RES [0805] 100 OHM 5% 3 R140.915.129
203 011-S102A00-20000 CHIP RES [0805] 1K OHM 5% 14
R111.117A.411.729.727.726.38.
725.120.119A.121.249.41.9
204 011-S103A00-20000 CHIP RES [0805] 10K OHM 5% 41
R25.24.23.853.134.840.839.721.707
.138.137.117.132.122.139.20.126.12
5.124.827.830.831.811.805.802.13.1
2.716.714.713.712.711.115.705.40.7
.750.751.752.39.624
205 011-S104A00-20000 CHIP RES [0805] 100K OHM 5% 4 R131.814.119.412.
206 011-S122A00-20000 CHIP RES [0805] 1.2K OHM 5% 4 R27.26.851.852.
207 011-S151A00-20000 CHIP RES [0805] 150 OHM ㊣5% 1 R723
208 011-S153A00-20000 CHIP RES [0805] 15K OHM ㊣5% 2 R11.14
209 011-S220A00-20000 CHIP RES [0805] 22 OHM 5% 1 R142.
210 011-S222A00-20000 CHIP RES [0805] 2.2K OHM 5% 16
R108.107.133.113.112.404.403.103.
101.128.829.409.127.102.114.133.
211 011-S223A00-20000 CHIP RES [0805] 22K OHM ㊣5% 5 R724.701.819.722.913.
212 011-S224A00-20000 CHIP RES [0805] 220K OHM ㊣5% 3 R818.720.719.
213 011-S273A00-20000 CHIP RES [0805] 27K OHM ㊣5% 2 R837.914.
214 011-S331A00-20000 CHIP RES [0805] 330 OHM ㊣5% 4 R615.616.141.143.
215 011-S332A00-20000 CHIP RES [0805] 3.3K OHM ㊣5% 8 R519.518.135.136.8.109.17.601
216 011-S333A00-20000 CHIP RES [0805] 33K OHM ㊣5% 1 R806.
S01-7500S00-DM1000-EU4
CA-555 (DVD7511) CAMERON BOM PAGE 8 OF 13
Item Material Code Brief Description Qty Remarks
217 011-S472A00-20000 CHIP RES [0805] 4.7K OHM ㊣5% 9
R841.838.617.710.709.626.820.621.
708.
218 011-S473A00-20000 CHIP RES [0805] 47K OHM ㊣5% 17
R130.809.408.407.904.903.902.19.1
8.901.905.906.907.908.801.16.118
219 011-S474A00-20000 CHIP RES [0805] 470K OHM ㊣5% 2 R33.32.
220 011-S562A00-20000 CHIP RES [0805] 5.6K OHM ㊣5% 11
R31.30.116.824.823.822.821.401.40
2.516.517
221 011-S681A00-20000 CHIP RES [0805] 680 OHM +/-5% 2 R110.826.
222 011-S682A00-20000 CHIP RES [0805] 6.8K OHM 5% 4 R912.911.910.909.
223 011-S684A00-20000 CHIP RES [0805] 680K OHM ㊣5% 1 R410
224 011-S753A00-20000 CHIP RES [0805] 75K OHM 5% 2 R1.731.
225 014-S101C00-400NP CHIP CAP [0805] 100PF 50V +/-5% NPO 4 C20.19.18.17.
226 014-S102C00-50000 CHIP CAP [0805] 102P (0.001uF) 50V ㊣10% 10
C808.136.534.533.135.113.112.805.
806.807.
227 014-S103C00-50000 CHIP CAP [0805] 103P (0.01uF) 50V +/-10% 6 C114.725.726.123.124.122.
228 014-S104B00-80000 CHIP CAP [0805] 104P (0.1uF) 25V +80-20% 16
C7.422.421.405.730.822.208.621.72
2.406.835.403. 404.402.401.814.
229 014-S105A00-80000 CHIP CAP [0805] 105P (1uF) 16V +80-20% 2 C423.417.
230 014-S200C00-400NP CHIP CAP [0805] 20PF 50V +/-5% NPO 2 C708.709
231 014-S220C00-400NP CHIP CAP [0805] 22PF 50V +/-5% NPO 1 C701.
232 014-S222C00-50000 CHIP CAP [0805] 222P (0.0022uF) 50V 10% 2 C408.407.
233 014-S223C00-80000 CHIP CAP [0805] 223P (0.022uF) 50V +80-20% 25
C831.705.111.826.827.415.126.728.
729.603.830.602.118.139.127.840.1
31.133.110.103.704.134.104.109.10
5.
234 014-S270C00-400NP CHIP CAP [0805] 27PF 50V +/-5% NPO 1 C702.
235 014-S271C00-50000 CHIP CAP [0805] 271P (270PF) 50V 10% 1 C706
236 014-S300C00-400NP CHIP CAP [0805] 30PF 50V +/-5% NPO 2 C116.115.
237 014-S472C00-50000 CHIP CAP [0805] 472P (0.0047uF) 50V 10% 2 C11.9
238 014-S561C00-50000 CHIP CAP [0805] 561P (560PF) 50V 10% 1 C707.
CD-3300 ISO BOARD (W/POWER ANT) HISEM 1
239 001-3300D00-A9000 P.C.B ISO BOARD 1
240 004-1N5404A-00000
DIODE-RECTIFIER 1N5404, 400V 3A [DO-201AD]
PACKING 1
241 036-K025000-12000 12Pin P=2.5mm PCB Connector Right Angle 1
242 263-3300000-A0000 TERMINAL-FUSE 2
243 263-3300000-B0000
CD-3300 ISO SOCKET - TERMINAL-CONTACT
[COPPER] 11
H04-3300D00-A90000-000
CA-555 (DVD7511) CAMERON BOM PAGE 9 OF 13
Item Material Code Brief Description Qty Remarks
244 263-3300001-C0000
CD-3300 ISO SOCKET-TERMINAL -{ 1 } [COPPER]
0.6MM 1
245 485-3300A00-8BK00
CD-3300 FIXED-ISO-CONNECTOR-NYLON 66
(BLACK) 1
DVD-7505 CONNECTOR BOARD HAND INSERT 1
246 001-7505S00-C0000 PCB DVD-7505 CONNECTOR BOARD [REV-1] 1
247 011-S561A00-20000 CHIP RES [0805] 560 OHM 5% 1 R1
248 023-A003000-RD300
LED D=1.8 RED(660nm)H.BRIGHT 220mcd
1.9V20MA 52DEG 1 D1
249 025-TA02000-26000
TACT-SW 2P TP-1126C 3X6MM H=2.6MM DIP
TYPE 1
250 036-J020000-18000 DETACHABLE CON 18P P=2.0mm SOCKET 1
DVD-7511 FRONT W/TB1439B LCD(WE/BL )
REMOTE PANEL 1
251 209-1188000-K0000 CD-1188 RELEASE SPRING 1
252 227-7608G00-A0000 CD-7608 SENSOR-SPONGE [BLACK] 1
253 234-PA02000-08B00 SCREW PA 2.0 x 8.0 MM BLACK 3 N/BACK:3
254 402-7511B00-1BK00 CD-7511 NOSE-PLIECE [ABS] BLACK 1
255 402-7511C00-1BK00 CD-7511 NOSE-PIECE-BACK [ABS] BLACK 1
256 413-7511A00-2CR00 CD-7511 WINDOW [PMMA CLEAR] 1
257 418-7511A00-2BE00 CD-7511 {TRK-UP/DN}-KNOB [PMMA] SKYBLUE 1
258 423-7511A00-CCR00 CD-7511 { BAND }-KNOB [RUBBER] CLEAR 1
259 427-7511A00-2BE00 CD-7511 {POWER-SEL}-KNOB [PMMA] SKYBLUE 1
260 428-9002A00-1NL00 CMP-9002 { VOL } -KNOB [ABS NATURAL] 1
261 436-7511A00-2BE00 CD-7511 { MUTE }-KNOB [PMMA] SKYBLUE 1
262 439-7511A00-10000 CD-7511 { RELEASE } -KNOB [ABS] 1
263 445-7511A00-2BE00 CD-7511 { MODE } -KNOB [PMMA] SKYBLUE 1
264 446-7511A00-2BE00 CD-7511 { AF-TA } -KNOB [PMMA] SKYBLUE 1
265 446-7511B00-2BE00 CD-7511 { PTY } -KNOB [PMMA] SKYBLUE 1
266 454-7511A00-2BE00 CD-7511 {ORNAMENT} -KNOB [PMMA] SKY BLUE 1
267 460-7511A00-CCR00
CD-7511 {TRK-UP-DN}-KNOB BASE [RUBBER]
CLEAR 1
268 460-7511B00-CCR00
CD-7511 {AF-TA}-KNOB BASE [RUBBER] CLEAR
SPY WHITE 1
269 462-7500C00-9BK00
CD-7500 {LEFT} RELEASE-SHAFT-BASE [POM]
BLACK 1
270 462-7500D00-9BK00
CD-7500 {RIGHT}-RELEASE-SHAFT-BASE [POM]
BLACK 1
H0B-7505S00-C00000-000
F02-DVD7511-000000-000
CA-555 (DVD7511) CAMERON BOM PAGE 10 OF 13
Item Material Code Brief Description Qty Remarks
271 483-7511A00-10000 CD-7511 ORNAMENT [ABS] 1
272 483-7511B00-10000
CD-7511 {TRACK-UP-KNOB} --ORNAMENT
[ABS]CHROME PLA 1
DVD-7511 FRONT W/TB1439B LCD(WE/BL ILL)
REMO HISEM 1
273 008-TB14391-TN0RB LCD DISPLAY TB1439BMTTN FOR DVD-7511 1 LCD
274 025-TA02000-43130
TACT SW TA-02 2P 6.5X3.5 H=4.3MM 130G CD-
7608BT 16
275 025-TA02S00-43130
SMT TACT SW 2PIN 6X3.5 H=4.3mm 130g CD-
7608BT 3
276 036-H020000-18000 DETACHABLE CON 18P P=2.0mm PLUG 1
277 038-6792400-65000
ZERBA CONNECTOR 67.9X2.4 H=6.5 PT=0.1 FOR
CD-7607 1
278 044-RMS0380-30000
IR RECIVER 3PIN MINI L-TYPE H=3.6 FOR
CD7608/7609 1
279 049-EN2412A-F1750
ENCODER VOL 24DET/12PULSE H=17.5MM PCB
TYPE{NOBLE} 1
280 218-7607A01-J0250 CD-7607 LCD BRACKET [IRON 0.4T] 1
281 245-1198000-BBK00 1198 CONNECTOR COVER SHEET 1
282 245-3300000-D0000
LED FILTER-"T-SHAPE" 20x12MM [0.1T/TRACING
FILM] 2
283 245-7607100-A0100 CD-7607 LCD-FILTER-{BIG} 72.2X29 [FILM 0.1T] 1
284 246-7607A01-BK010
CD-7607 LCD BRACKET-PASTER-2 20X7.5X
0.1MM 1
285 246-7607A01-WE010 CD-7607 LED REFLECTOR PLATE 29X5.7X0.1T 1
286 246-7607A02-WE010 CD-7607 LCD RREFLECTOR [PET] 72.2X29X0.1T 1
287 414-7511A00-2BE00
CD-7511 {CIRCLE}-REFLECTOR [PMMA
SKYBLUE] 1
288 414-7511B00-2BE00
CD-7511 {AF-TA-KNOB}-REFLECTOR [PMMA]
SKYBLUE 1 BACK SIDE SILK SCREEN WHITE
289 414-7607500-2CR00 CD-7607 LCD-REFLECTOR [PMMA] CLEAR 1
DVD-7511 FRONT PCB (WHE/BLU ILL) REMOTE
SMT ASSY 1
290 001-7511D00-D5000 PCB DVD-7511 RDS FRONT BOARD [REV-0] 1 FRONT PCB
291 001-7607D00-A6000 PCB CD-7607 LED BOARD REV-0 [0.6T FR-4] 1
292 002-0652300-H0000 IC PT6523LQ LCD DRIVER [LQFP64] 1
293 011-C181D00-20000 CHIP RES [1206] 180 OHM 5% 1/4W 1 R27.
294 011-C221A00-20000 CHIP RES [1206] 220 OHM ㊣5% 1 R25.
295 011-S000A00-20000 CHIP RES [0805] 0 OHM 5% 1 R23.
296 011-S101A00-20000 CHIP RES [0805] 100 OHM 5% 1 R30.
297 011-S102A00-20000 CHIP RES [0805] 1K OHM 5% 2 R26.9.
S03-7511D00-D50000-000
H03-7511D00-D50000-000
CA-555 (DVD7511) CAMERON BOM PAGE 11 OF 13
Item Material Code Brief Description Qty Remarks
298 011-S103A00-20000 CHIP RES [0805] 10K OHM 5% 1 R24.
299 011-S122A00-20000 CHIP RES [0805] 1.2K OHM 5% 1 R29.
300 011-S123A00-20000 CHIP RES [0805] 12K OHM 5% 1 R33.
301 011-S152A00-20000 CHIP RES [0805] 1.5K OHM ㊣5% 1 R1.
302 011-S221A00-20000 CHIP RES [0805] 220 OHM ㊣5% 1 R21.
303 011-S222A00-20000 CHIP RES [0805] 2.2K OHM 5% 1 R2
304 011-S332A00-20000 CHIP RES [0805] 3.3K OHM ㊣5% 1 R3.
305 011-S333A00-20000 CHIP RES [0805] 33K OHM ㊣5% 1 R34.
306 011-S391A00-20000 CHIP RES [0805] 390 OHM ㊣5% 2 R4.6.
307 011-S471A00-20000 CHIP RES [0805] 470 OHM 5% 2 R5.7.
308 011-S513A00-20000 CHIP RES [0805] 51K OHM ㊣5% 1 R11.
309 011-S561A00-20000 CHIP RES [0805] 560 OHM 5% 2 R16.8.
310 011-S562A00-20000 CHIP RES [0805] 5.6K OHM ㊣5% 1 R32.
311 011-S681A00-20000 CHIP RES [0805] 680 OHM +/-5% 8 R19.10.22.28.20.17.18.12.
312 011-S821A00-20000 CHIP RES [0805] 820 OHM ㊣5% 2 R13.31.
313 014-S104B00-80000 CHIP CAP [0805] 104P (0.1uF) 25V +80-20% 2 C2.3.
314 014-S331C00-50000 CHIP CAP [0805] 331P (330PF) 50V 10% 2 C5.4.
315 014-S681C00-50000 CHIP CAP [0805] 681P (680PF) 50V 10% 1 C1.
316 023-D000000-BE000
SMT LED [0603] BLUE (470nm) 50mcd 3.2V 20MA
130DEG 13
317 023-F283500-WE200
SMT LED (2.8x3.5x1.9) WHITE 800-1000mcd 3.2V
20mA 2
DVD-7511 MP3[CAMERON CA-555 DVD]-RU-
64104T PACKING 1
318 034-H020200-M15BK
RCA TO RCA VIDEO CORD SET L=1.5M BLACK
W/YEL PLUG 1
319 060-7511036-270158A
REMOTE DVD-7511 RDS MP3[CAMERON CA-555
DVD] 1
320 061-CR20250-B0000 BUTTON LITHIUM BATTERY CR2025 3.0V 1
321 212-5209000-14S00 SPRING WASHER ID=5.2x9.0x1.4T 2
322 212-5210000-05P00 PLATE WASHER (φ5.2) 2
323 217-1001E00-E1200 MOUNTING STRIP 1
324 222-3896S00-E0600 CD-3896 SLEEVE-CASE [EGI-0.6] 1
325 227-7803000-EA500
CD-7803 CASE CUSHION (BLACK W/ ADHESIVE
TAPE) 1
P02-DVD7511-270158-00A
CA-555 (DVD7511) CAMERON BOM PAGE 12 OF 13
Item Material Code Brief Description Qty Remarks
326 230-100BK00-10000 PLASTIC TIE l=100mm 1
327 233-N050W00-H0000 HEX NUT：M5 1
328 234-PA05000-16000 SCREW TS 5.0 x 16.0 MM PA NICKLE TYPE-A TIP 1
329 235-3896000-E1000 SET KEY 2
330 301-0C02500-08000 POLY BAG OPEN 2.5"x8"XT0.04 1
331 301-0C04000-09000 POLYBAG 4"X9"XT0.04 1 FOR VIDEO WIRE
332 301-0C06600-10500 POLY BAG 6-5/8" X 10-1/2" X 0.04MM THK [PE] 1
333 301-0C11000-14000 POLY BAG 11"x14"XT0.04 1
334 303-MR30000-PS060 POLYFOAM MR-300 264x79.5x57 FOR CAR AUDIO 2
335 304-7511036-270158A
GIFT BOX DVD-7511 MP3 RDS MW FM[CAMERON
CA-555 DVD 1
336 305-7511036-270158A
I/M(EN/RU/PO/UK) DVD-7511 MW FM[CAMERON
CA-555 DVD 1
337 306-7511036-270158A
CARTON BOX 6PCS DVD-7511 MW FM[CAMERON
CA-555 DVD] 0.17
338 307-250X012-SCR002A
SCREW CARD 250X12 RED/WHE (EN) S.HOLE
ROADSTAR 2
339 308-7511036-270158A
TOP LABEL DVD-7511 MW FM[CAMERON CA-555
DVD] 1
340 311-210X148-036000A
WARRANTY CARD 210X148 [CAMERON CA-535
FLASH]
341 315-029X025-LSB001A
LASER BEAM LABEL 29X25 YEL/BLK [LASER
SYMBOL] 1
342 315-050X025-CAS003A CLASS1 LABEL 50X25 YEL/BLK(6-LANG) 1
343 315-050X030-CAU001A LASER CAUTION LB 50x30 YEL/BLK(6-LANG) 1
344 315-058X015-WRG017A WIRING LABEL WHE/BLK [ CD IN (L)] 1
345 315-058X015-WRG018A WIRING LABEL RED/BLK [ CD IN (R)] 1
346 315-058X015-WRG019A WIRING LABEL WHE/BLK [LINE OUT(L)] 1
347 315-058X015-WRG020A WIRING LABEL RED/BLK [LINE OUT(R)] 1
348 315-058X015-WRG025A WIRING LABEL YEL/BLK [ VIDEO OUT ] 1
349 315-134X030-WAR001A
WARRANTY LABEL 134X30 GOLD W/BLK (5-
LANG) 1
350 402-7803S00-4BK00 CD-7803 NOSE PIECE CASE [PP] 1
351 441-7507A00-1BK00 CD-7507 TRIM-COVER [ABS] BLACK 1
*** [End of Report] ***
CA-555 (DVD7511) CAMERON BOM PAGE 13 OF 13
Table of contents
