CAMPARK T80 User manual

UserManual
T80TrailCamera

V190921

YouhavepurchasedaCamparkWildlifeCamerawithexcellenttechnical
featuresandrespectiveaccessorythatisparticularlyeasytooperate.Please
studyallnoticescarefullyanddiligently.Pleasestudythisinformationin
detailobserving,inparticular,thesafetyinstructions.
Dearcustomer,congratulationsonpurchasinga
highqualityproduct.
1.Contentsofbox
Carefullyunpackcameraandcheckthatallofthefollowingcomponentsare
containedinthe box:
1.WildlifeCamera 2.Mountingbelt 3.USBcable
4.Instructionmanual 5.RemoteController
Removetheprotectivefoilfromthecameralensbypullingtheprotrudingtab.
Caution!Keepplasticfoilandbagsawayfrombabiesandsmallchildren,as
otherwisedangerofsuocation.
Note:
1

2.Contents
1.CONTENTSOFBOX.............................................................................................
2.CONTENTS...........................................................................................................
3.HAZARD,SAFETYANDWARNINGNOTICES....................................................
4.INTRODUCTION..................................................................................................
5.YOURCAMERA.....................................................................................................
5.1.Frontview..........................................................................................................
5.2.Insideviews.......................................................................................................
6.PREPARINGTHECAMERA..................................................................................
6.1.Openingandclosingthecamera........................................................................
6.2.Insertingthebatteries........................................................................................
6.3.Insertingthememorycard.................................................................................
6.4.Externalpowersupply........................................................................................
6.5.Assemblywithstrap...........................................................................................
7.USINGTHECAMERA...........................................................................................
7.1.Modeswitch......................................................................................................
7.2.Operatingbuttons..............................................................................................
7.3.Settings.............................................................................................................
7.4.WIFIAPPconnection..........................................................................................
7.5.Nightrecording..................................................................................................
7.6.SettinguptheLivemode...................................................................................
7.7.Aligningthecamera...........................................................................................
7.8.Fileformat.........................................................................................................
8.CONNECTINGTOCOMPUTER..........................................................................
9.TECHNICALSPECIFICATION..............................................................................
10.SIMPLETROUBLESHOOTING........................................................................
11.SYSTEMINFORMATION,MAINTENANCEANDDISPOSAL............................
11.1.Care.................................................................................................................
11.2.Storage............................................................................................................
11.3.Disposal..........................................................................................................
2
3
5
6
6
7
8
8
9
10
11
11
12
12
12
14
19
24
25
26
26
27
28
30
31
31
32
32
1
2

3.HAZARD,SAFETYANDWARNINGNOTICES
Incorrectuseofthecameraandaccessoriescanbedangerousforyouand
othersandcandamageordestroythecamera.Wethereforeaskyoutoread
andstrictlyobservethefollowingHazard,safetyandwarningnotices.
Intendeduse
Thiscameraisintendedfortakingdigitalphotosandvideoclips.Ithas
beendesignedforprivateuseandisnotsuitableforcommercialpurposes.
Hazardsforchildrenandpersonswithlimitedabilitytooperate
electronicequipment
Thecamera,accessoryandpackagingarenottoysforchildren.These
shouldthereforealwaysbekeptawayfromchildren.Dangerof
electrocution,poisoningandsuffocation.
Thecameraandaccessorymaynotbeusedbychildrenandpersonswith
limitedabilities.Thecameramayonlybeoperatedbypersonsphysically
andmentallyabletooperateitsafely.
Electricalhazard
Switchoffthecameraandremovethebatteriesifaforeignbodyorliquid
hasenteredthecamera.Letallpartsdrythoroughly.Otherwisedangerof
fireorelectrocution
Switchoffthecameraandremovethebatteriesifthecamerahasbeen
droppedorthehousingisdamaged.Otherwisedangeroffireandelectrocution.
Thecameramaynotbedismantled,modifiedorrepaired.Dangeroffire
andelectrocution.
Onlyuseapoweradaptor(notsupplied)withthemainsvoltagespecifiedon
theratingplate(6V).Otherwisedangeroffireorelectrocution.Disconnectthe
powerbypullingthepoweradaptoroutofthesocket.
Apluggedinpoweradaptor(notsupplied)cancontinuetousepowerandthe
reforerepresentsahazardsource.
Thepowersupplymaynotbeusedduringthunderstorms.Otherwisedanger
ofelectrocution.
3

DAMAGEFROMHEAT-FIREHAZARD
Donotleavethecamerainplacesthataresusceptibletoconsiderablein
creasesintemperature(e.g.avehicle).Thehousingandinternalparts
maybedamaged,whichinturncouldcauseafire.
Donotwrapupcameraorplaceontextiles.Thiscouldproduceabuild
upofheatinthecamerathatcancausedeformationofthehousingand
mayrepresentafirehazard.
INJURIESANDMATERIALDAMAGE
Onlyplacethecameraonsturdysurfaces.Thecameracouldotherwise
fallortoppleover,causingdamageorinjury.
Donotoperatethecamerawhilstrunningordriving.Youcouldfallor
causeatrafficaccident.
Onlyuseamainsadaptor(notsupplied)forthecamera,havingthein
putvoltagespecifiedontheratingplate(6V).Wedonotacceptany
liabilityfordamagecausedbytheuseofanincorrectmainsadaptor.
The230Vsocketusedforthemainsadaptor(notsupplied)mustnotbe
coveredandaccessibleatalltimessothatthemainsadaptorcanbe
quicklydisconnectedfromthemains,whenrequired.
Ensureadequateventilationanddonotcoverthemainsadaptor
(notsupplied)toavoidoverheating.
Donotplaceanyopenignitionsources,suchaslitcandlesontoor
closetothedevice.
DonotsubjecttheLCDmonitortoimpactorpressure.Thiscould
damagetheglassofthemonitorortheliquidcouldleakfromtheinside.
Incaseofcontactwitheyesorskin,rinseimmediatelywithclearwater.
Incaseofcontactwitheyescontactadoctorimmediately.
Damagetotheelectronics,themonitororthelenscausedbyexternal
influencessuchasimpacts,fallsorotherarenotcoveredbythewarranty
andmustbepaidfor.
Donotdroporbumpthecameraandalwayshandleitcarefully.
Otherwisethecameracanbedamaged.
4

4.INTRODUCTION
TheT80Cameraisawildlifeandsurveillancecamerawitha3zoneinfrared
sensor.Thesensorcandetectsuddenchangestotheambienttemperature
withinanevaluationarea.Thesignalsofthehighlysensitiveinfraredsensor
(PIR,passiveinfraredsensor)switchonthecamera,activatingpictureor
videomode.
FeaturesofWildlifeCamera:
20MegapixelsCMOSsensor.
20Megapixelphotoand1296PHDvideo.
Theuniquesensordesignoffersa120°widerangleofdetectionand
improvestheresponsetimeofthecamera.
Duringday,sharpandclearcolorimagesandduringnighttimeclearblack
andwhiteimages.
Impressivelyquickshutterreleasetime(0.3seconds).
SpraywaterprotectedaccordingtostandardIP66.
Lockableandpasswordprotection.
Date,time,temperatureandmoonphasecanbedisplayedontheimages.
Usingtheserialnumberfunction,locationscanbeencodedonphotos.
Whereseveralcamerasareused,thisfunctionallowseasieridentificationof
locationswhenviewingphotos.
Possibleuseunderextremetemperaturesofbetween-20°Cto60°C.
Extremelylowpowerconsumptioninstandbyoperationproviding
extremelylongoperatingtimes.
(instandbymodeupto6monthswith8AAbatteries).
Areasofapplication
Cameratrapforhunting.
Animalorincidentobservation.
Motiontriggeredsecuritycamerafordomestic,officeorpublicuse.
Anyinternalandexternalsurveillance,whereevidenceofaninfringement
hastobeprovided.
5

5.YOURCAMERA
5.1.Frontview
LEDinfraredlight
Lightsensor
Lens
Centralsensorzone
Sidesensorzones
Lockingholeforlock
Lockingholeforlock
Motionindicator
blue/redLED
Microphone
6

5.2.Insideviews
ThemonitorisonlyswitchedonintheSETUPmodeforchangingmenu
settingsorviewingexistingphotos.
AnSDorSDHCmemorycardmusthavebeeninsertedintothememorycard
slotinordertosavephotos.
UsingtheminiUSBconnection(USB2.0),thecameracanbeconnectedto
acomputer.
UsingthemodeswitchthethreeoperatingmodesOFF,SETUPandONcan
beselected.
Screen
Shot/zoominbutton
Video/zoomoutbutton
Modeswitch
(OFF/SETUP/ON)
WIFI/UP
Menubutton
OKbutton
Replaybutton
Speaker
Memorycardslot MiniUSBconnection
7

Sealring
1/4Tripodthread
DCconnection
Batterycompartment
6.PREPARINGTHECAMERA
6.1.Openingandclosingthecamera
Operatingbuttons,connectionsandbatteriesarelocatedinsidethe
WildlifeCamera.
Afixingforapadlockisprovidedbetweenthetwolockingbrackets,
allowingthecameratobesecurelylocked.
8

6.2.Insertingthebatteries
Openthecameraasdescribedinsection6.1toinsertthebatteries.Thebattery
compartmentishousedintheright,rearpartofthecamera.Nowopenthe
protectivecoverofthebatterycompartmentbypullingtheclampingclosureat
thetopslightlyinwardsbeforeliftingoffthecover.
Firstremoveanyexistingbatteriesfromthebatterycompartment.Insert8
fullychargebatteriesasshowninthebelowfigure.Wheninsertigbatteries
ensurecorrectpositionasmarkedforeachbatteryinthebatterycompartment.
Note:
Werecommendusing8xalkalineAAbatteriestoensurethecamera's
normalfunction.
Analarmissoundedifbatterychargeistoolow.
9

6.3.Insertingthememorycard
Amemorycardmusthavebeeninsertedinordertosavephotosandvideos.
InsertaSD/SDHCmemorycardinthememorycardcompartmentbefore
switchingonthecamera.
Switchoffthecameraandopenasdescribedinsection6.1.
Priortoinsertingthememorycardensurethatthelateralwriteprotectionon
thememorycardhasnotbeenactivated(seefigure).
Ifthecameradisplays"Cardprotected",removethememorycardandchange
thepositionofthememoryprotection.
Insertthememorycardasshownintheadjacentillustration.Pushthe
memorycardintocompartmentuntilitclicksintoplace.
Toremovethememorycardpushcardinagainuntilitispartlyejected.
Note:
SD/SDHCmemorycardsuptoacapacityof32GBaresupported.
10

6.4.Externalpowersupply
Thecameracanbeoperatedusing
powerfromanexternalpowersupply.
A6Vpowersupplywithatleast
1.5Aisrequiredcontaininga
connectorwitha3.5mmexternal
and1.35mminternaldiameter
(internalpisitivepole,externalnegativepole).
6.5.Assemblywithstrap
UsethesecuringstrapsuppliedtoattachtheWildlifeCameratoatreeor
anotherobject.Theillustrationsbelowdemonstratehowtofastenthe
securingstrap.
PositiontheWildlifeCameraasdesiredandpullthelooseendofthesecuring
straptightuntilthecameraisfirmlysecured.
Toreleasethesecuringstrapagain,pullatthetabofthesecuringstrap.
11

7.USINGTHECAMERA
7.1.Modeswitch
Priortosettingupthecameraforsurveillance,itmustbesetupforthe
respectivepurpose.Forthispurpose,thereisasetupmodeavailable.In
additiontochangingsettings,photosandvideoscanbetakenandexisting
photoscanbeviewedinthismode.
Openthecameraasdescribedinsection6.1.TheModeswitchislocatedat
thebottomedgeontheleftinside.3operatingmodescanbeselected:
OFF:Thecameraiscompletelyswitched
offintheOFFmode.
SelectSETUPmodetoadjustSETUP:
settingsandmakeorplaybackphotosandvideos.
ThecameraisactivatedtotakephotosON:
automatically(Livemode).
7.2.Operatingbuttons
SetthemodeswitchtoSETUPandthecameraandmonitorareswitchedon.
Usingtheoperatingbuttonsdifferentfunctionscannowbeactivatedand
settingscanbechanged.Forthispurpose,thefollowingoperatingbuttons
areprovidedonthedisplaypanel:
12

FUNCTIONSOFOPERATINGBUTTONSINRECORDINGMODE
Below,theoperatingbuttonsaredescribedintherecordingmodewithnon
activatedmenu.
FUNCTIONSOFOPERATINGBUTTONSINREPLAYMODE
Below,theoperatingbuttonsaredescribedinthereplaymodewithnon
activatedmenu.
OpentheSettingsmenuusingtheMENUbutton.
Pressthisbuttontostartthereplaymode.
Changetothemanualrecordingmodeandrecordavideo.
Changetothemanualrecordingmodeandtakeaphoto.
Nofunction(inrecordingmode).
SelecttheReplaymenuusingtheMENUbutton.
Pressthebuttontoreturntorecordingmode.
Viewexistingpicturesbackwardsanddragupwardstoviewphotoand
increasethevideoplayvolume.
Viewexistingpicturesforwardsanddragdownwardstoviewphotoand
decreasethevideoplayvolume.
Dragrighttoviewandskipaheadthevideo.
Draglefttoviewandskipbackthevideo.
Startandendreplayofvideos/imagecutsaveafterzoom.
Zoomoutthephotosanddecreasethevideoplayvolume.
Zoominthephotosandincreasethevideoplayvolume.
13

FUNCTIONSOFOPERATINGBUTTONSINMENU
Below,theoperatingbuttonsaredescribedinthereplaymodewithactivated
menu.(RecordingandReplaymode).
ClosetheMainmenuoranysubmenubypressingtheMENUbutton.
Moveuponemenupointorincrementvalueby1.
Movedownonemenupointordecreasevalueby1.
Moveforwardlytothedatasetting.
Movebackwardlytothedatasetting.
Openselectedoptionsoracceptselectedsettings.
ConfirmeachchangetoasettingbypressingOK.Ifthechangeisnot
confirmedbypressingtheOKbutton,thenewsettingarelostwhen
leavingthemenu.
Nofunction(inMENUmode).
7.3.Settings
PriortousingtheT80Camera,changethesettingsasrequired.Slidethemodeswitchofthe
T80CameratotheSETUPpositiontostartthesetupmode.InthePhotoorVideomode
presstheMENUbuttontocallupthemenu.AllmenuoptionsoftheT80Cameraand
possiblesettingvaluesfortherecordingmodearelistedbelow.Thestandardsettingis
alwayshighlightedinbold.
14

Mode:Photo,Video,Photo+VideoSelectwhetherphotosorvideosshould
betakenwhenmotionisdetected.Wheninthe"Photo+Video"mode,the
camerafirsttakesasetnumberofphotospriortorecordingavideo.
Defaulted30seconds,optionalfrom5seconds~60minutesPIRInterval:
Selecttheshorsetupperiodforthecameratowaitbeforeitreactstothe
successivetriggeringofthemainsensorafterananimalhasfirstbeen
detected.Thecameradoesnotrecordanyimagesorvideosduringthe
selectedinterval.Thispreventsthememorycardfrombeingfilledwith
unnecessaryshots.
Note:
Theintervaltimeisshort,thecamerashootingfrequencywouldbehigh,
andtherewouldbehighconsumptionofbatteries.Itwouldeffectthe
usagedaysofthebatteries.Itisjustontheopposite,theintervaltimeis
long,wouldbealowerconsumptionofbatteriestoguaranteealong
timeusage.
PIRSensitivity:High/Medium/Low
Off/OnWhen“ on”hasbeenTimelapse:
selected,thecamerawouldautomaticallytakesphotosintheselectedtime
interval,irrespectiveofwhetherornotthePIRsensorhasdetectedamotion
ornot.Thisisusefulforobservingcoldbloodedanimalse.g.snakesorplan
tsopeningup,etc.Assoonasthe"On"settinghasbeenconfirmedby
pressingtheOKbutton,youcanentertheintervaltimeafterwhichphotos
aretobetaken.
Note:
Inthismode,thePIRfunctionwouldstopworking,andthecamerawould
takephotosinthesettingintervaltime.
15

IRLED:Auto/SuperFine/EconomySettheinfraredLEDsbrightness.
Off/OnSettimerto"On"ifcamerashouldonlybeactiveMonitoringPeriod:
withinacertaintime.Once"On"hasbeenconfirmedwiththeOKbutton,
thestartandendtimecanbeset.Ifthestarttimeis,forinstancesetto
18:35hrsandtheendtimeto8:25hrs,thecamerawillbeoperationalfrom
6:35pmofthecurrentdayuntil8:25amofthefollowingday.Thecamera
willnotbetriggeredandwillnottakeanyphotosorvideosoutside
ofthisperiod.
Off/OnThetwosidePIRsensorzonesprovideawideSidePIRSetup:
detectionangleanddetectmorepotentialtriggers.Sometimesyouonly
wishtoobserveacertainpoint.Toomanyirrelevanttriggersfromtheside
sensorzonesoutsideofthispointcontinuouslyswitchthecameraonand
off,considerablyaffectingbatterylife.Insomesituationsitmaybedifficult
toremoveinterferingbranchesoravoidsunlight.Inthesesituationsyou
canswitchoffthesidesensorzones.
Imagesize:20M(5120x3840),16M(4608x3456),12M(4032x3024),8M
(3264x2448),5M(2592x1944),3M(2048x1536),2M(1600x1200)Select
thedesiredresolutionforphotos.Werecommendtheresolution5M.A
higherresolutionproducesasomewhatbetterphotoqualitybutresultsin
largerfilesrequiringmorespaceonthememorycard..
1P,2P,3P,4P,5P,6P,7P,8P,9P,10P.SelectthenumberofPictureNO:
photostobetakeninsuccessionwhenthecameraistriggeredinthePhoto
mode.PleasealsoobservetheparameterInterval!
1/15,1/20,1/30Shutterspeed:
16
