Campvalley 30658 User manual

STITCH LINE
PARTIALLY EXTEND FRAME
With two people pulling from opposite corners,
partially extend the frame.
10’ X 10’ SIMPLE PUSH STRAIGHT LEG CANOPY
1
(See other side for Take Down Instructions)
VSN: WMT-1010112P
Model No. 30658
6
(1) Canopy
(8) Steel Stakes
(1) Carry Bag
SET UP
2
DRAPE CANOPY OVER FRAME
Press the hook and loop pads located at each corner
onto frame.
UNDERSIDE
OF CANOPY
HOOK & LOOP
FASTENERS
STEEL
SHELTER LEG
5
SECURE CANOPY TO FRAME
Wrap hook & loop fasteners on underside of
canopy around metal braces to secure.
HOOK & LOOP
FASTENER
METAL
BRACE
LOCKING
BUTTON
3
3-Stage Height
Adjustability
LOWEST
MEDIUM
HIGHEST
EXTEND LEG POLES TO DESIRED HEIGHT
Grasp and extend telescoping leg poles until the
silver locking buttons “click” into locked position.
STAKE SHELTER & GUYLINES
Drive stake through hole in each leg pole foot.
Stake each guyline then tighten and adjust with slider.
FOOT
SLIDER
(1) Stake Bag
For more in-depth videos, setup demonstrations and product information,
please visit www.Walmart.com
Before you begin
Read all instructions thoroughly before beginning set up.
• Select a level site clear of rocks, branches and other hard or sharp objects, to set up your shelter.
WARNING: Keep clear of overhead power lines.
• Do not set up your shelter under trees because of potential lightning strikes or falling tree limbs in
inclement weather.
• Secure with all stakes and guylines provided to prevent property damage or personal injury.
• Two people can easily setup this shelter in minutes.
4
RAISING ROOF SUPPORT BRACKETS WITH
SIMPLE PUSH
Push Simple Push handle up until support brackets
lock into place.
SUPPORT
BRACKETS
(1) Simple Push
Frame
SIMPLE PUSH
HANDLE

IMPORTANT FACTS:
• Never store shelter, even for a short period of time, without drying it thoroughly and brushing off caked dirt.
Do not pack stakes inside your shelter. Use a separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE ITSELF. NEVER PULL ON THE SHELTER TO
REMOVE STAKE.
• Do not leave your shelter set-up for weeks at a time. Be aware that exposure to ultraviolet rays from the sun
can seriously damage material and/or cause it to become discolored.
Storing the Shelter
• Remove stakes and place in their storage bag.
• All stakes must be placed in their own storage bag before placing in shelter carrying case to prevent
damage to the shelter fabric.
• Store in a clean, dry area.
IMPORTANT:
THE ORIGINAL FIRE RETARDANT AND WATER REPELLENT PROTEC-
TIVE COATINGS MAY BE COMPROMISED IF SPRAYS OR OTHER
CHEMICAL TREATMENTS ARE USED ON THE TENT. FABRIC HAS
BEEN FACTORY TREATED. IT IS HIGHLY WATER-REPELLENT; HOW-
EVER, IT IS NOT WATERPROOF. ALL TENTS CAN EXPERIENCE SEAM
LEAKAGE DURING WET WEATHER. IF YOU WANT ADDITIONAL
MOISTURE PROTECTION, TRY A SEAM SEALING COMPOUND ONLY;
STRICTLY FOLLOW THE MANUFACTURER’S DIRECTIONS. IT IS REC-
OMMENDED THAT YOU SEAL THE TENT DURING THE INITIAL SET-
UP AS WELL AS PRIOR TO EACH CAMPING SEASON. SEAM SEALER
COMPOUNDS CAN BE PURCHASED AT YOUR LOCAL CAMPING
PRODUCTS OUTLET. FOR MISSING PARTS CALL 1-888-774-5840.
PLEASE DO NOT RETURN THIS PRODUCT TO THE RETAIL STORE.
Part Number Description
91575 Canopy Top
91576 Apex Support Pole
91577 Roof Joint
91578 Scissor Joint
91579 Scissor Bar
91580 Upper Roof Pole
91581 Lower Roof Pole
91582 Scissor Endcap
91583 Gazebo Leg
91593 Simple Push Center Hub
91594 Simple Push Supporting Pole
91595 Simple Push Handle
REPAIR PARTS LIST
6 Month Limited Warranty
Campvalley (Xiamen) Co., Ltd. warrants for a period of
six months from the original date of purchase, this product
against any defects in materials or workmanship. At its
discretion, Campvalley may provide replacement parts to
original purchaser. Original receipt or proof of purchase as
well as proof of defect is required. Campvalley will not be re-
sponsible for shipping costs incurred outside the continental
USA. Warranty is valid for the original purchaser six months
from the date of purchase and is not transferable. This
warranty does not cover any product purchased through
non-authorized dealers and/or online auction websites.
This Warranty Does Not Cover
This 6 Month Limited Warranty does NOT cover normal
wear and tear, abuse or misuse of this product includ-
ing damage from inclement weather conditions, such as
wind, rain or hail. In case of inclement weather remove all
valuables and persons and seek appropriate shelter. Under
no circumstances will Campvalley (Xiamen) Co., Ltd. be
liable or responsible for any incidental or consequential
damages.
This product is designed and intended for recreational
use only. Prolonged exposure to UV rays will cause any
fabric to fade and deteriorate and is NOT covered by this 6
Month Limited Warranty.
All replacement products or parts will assume the
remaining warranty of the original product. This warranty
gives you specific legal rights. You may also have other
rights which vary from state to state.
To Obtain Warranty Service
Call Toll Free 1-888-774-5840 for warranty service, repair
parts or product questions. Please have model number
30658 available for reference when calling customer service.
Mon-Fri, 8:00 a.m. – 5:00 p.m. Central Time.
NOTICE: DO NOT RETURN PRODUCT TO RETAIL STORE.
Campvalley (Xiamen) Co., Ltd.
No.18th, West Road 3, Jinyuan, Jimei District, Xiamen, Fujian 361022 (China)
Made in China • Printed in China
STITCH LINE
PULL DOWN SIMPLE PUSH
HANDLE TO UNLOCK
SUPPORT BRACKETS &
COLLAPSE FRAME
1
TEAR DOWN
REMOVE CANOPY FROM FRAME
34
FOLD & STORE CANOPY & FRAME
UNDERSIDE
OF CANOPY
HOOK & LOOP
FASTENERS
STEEL
SHELTER LEG
HOOK & LOOP
FASTENER
METAL
BRACE
2
LOWER LEG
POLES
LOCKING
BUTTON
SUPPORT
BRACKETS
SIMPLE PUSH
HANDLE
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS
SHELTER FABRIC
This shelter is made of flame-resistant fabric which meets CPAI-84 specifications. IT IS NOT FIRE-PROOF. The
fabric will burn if left in continuous contact with any flame source. The application of any foreign substance to the
product fabric may render the flame-resistant properties ineffective.
DO NOT use fuel burning devices inside or near tent materials.
DO NOT permit children to light matches, operate burning appliances or handle any flame sources in or near the
shelter.
• Do not smoke, use matches, candles or open flames of any kind in or near the shelter.
• Do not refuel lanterns, stoves or heaters inside shelter.
• Do not cook inside shelter.
• Do not store flammable liquids inside shelter.
