CanCom BLUE-X User manual

CanCom Sales Inc.
[email protected]
tel [phone] fax [phone]
toll free 855.533.5677
CanCom XBX portable radio adapters fit
many types of radios and are powered by
the radio so no battery or charger is re-
quired. The unit is compatible with many
aftermarket Bluetooth headsets.
Portable Radio Compatibility: Motorola,
ICOM, Kenwood, Hytera, Vertex Standard,
Sepura, Harris, Simoco, etc.
Type: Bluetooth Dongle for Portable Radio
Temp: -20℃±2℃~ 50℃±2℃Approx.
Weight: 30g
 Fully Qualified Bluetooth v2.1+EDR
Chip Set
 Chip Audio Line Input : 350mV rms
(max)
 Audio Output : 20 mV rms
 Transmitted Power : 1 dBm (typ.)
 Receiver Sensitivity : -82 dBm (typ.)
 PTT function built-in, Power switch is
embedded on some models
 Display : Two Color LED
 HSP / HFP / A2DP / AVRCP/ PBAP /
SPP / MAP profile supports
 DC Input : 3.3-9V based on portable
radio
 DC Current : 13 mA (avg.)
 DC Current : 20 mA (transmit)

1. Attached Bluetooth
Adapter to the Radio
2. Fasten the thumb
screw
4. Press and HOLD the
pairing button.
5. Turn on the Radio
3. Power off the radio
before pairing

3 Progress Drive, Unit 8B
Orillia, Ontario L3V 0T7
www.cancomradioaccessories.com
© CanCom Sales Inc. 2020
6. Check LED Indicator.
If 2 flashes per second
unit is in pairing mode.
7. PAIR your Bluetooth device of choice.
STATUS LED FLASHING PATTERN
Power OFF No LED
Power ON, but no pair and link to accessory Flashing once per second
Pairing mode for Bluetooth accessory Flashing twice per second
Pairing mode for Bluetooth remote PTT Flashing three times per second
Paired Successfully One continuous LED light for three seconds
Standby Mode One flash per seconds
