C&H Technologies AM100 User manual

C&H Technologies, Inc. •445 Round Rock West Drive •Round Rock, TX 78681-5012
[phone] •FAX [phone] •www.chtech.com
Ordering Information
Description
AM100 Buffer IP Accessory
Part Number 11027840-0001
AM100 Buffer IP Accessory:
Th e AM10 0 p r ovid es d u al o ut put si gna l b u fferi ng f or o ther C &H
IP source mod ul es. T he mod ule attache s adja cen t to othe r
spe cially d esig n ed C &H I P m od u le s th r ou g h a 1 0- pi n si de
co n ne cto r . On e o r tw o ou tp u t sig n a ls f or m th e so ur c e IP
mo d ule ar e bu ff ere d to pr ovid e up to
+
3 00 m a d ri ve c ap a bi li ty
th a t w il l n ot o scil la te w hi l e d r ivi ng l a rg e c ap aci tive lo a ds. Th e
buf fe rs sle w at 800V/ µs an d have a smal l sign a l ban d width of
50 Mhz whil e d rivi ng a 5 0Ωl oa d . Th e y fe at ur e b u ilt- in cu rr e nt
lim it in g an d th e rm al s hu td o wn . O utp u t i mp ed a nc e is ty pi ca ll y
3Ω.
