1.1 Overview
The VCO-6000-ADL Series Machine Vision Systems provide powerful computing and excellent graphic
performance, which are suitable for graphic-intensive and computing-oriented applications including
image and vision measurement, machine automation. Delivering high quality, durability and compact
construction, the systems leverages a reliable fanless and cable-free configuration, optimal thermal
dissipation, and easy installation for flexible and user-friendly system development and application
implementation in harsh environments.
11
Chapter 1: Product Introductions
Machine Vision Computer
VCO-6000-ADL-3E
Series
VCO-6000-ADL-4E
Series

VCO-6000-ADL l User’s Manual
12
Chapter 1: Product Introductions
Model No. Front Panel
•VCO-6000-ADL-3E
1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3)
•VCO-6000-ADL-3E-2PWR
1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3),
2x Power input
•VCO-6000-ADL-3E-4B7M
1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3), 6x HDD
•VCO-6000-ADL-3E-4B7M-2PWR
1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3), 6x HDD,
2x Power input
•VCO-6000-ADL-3E-2B15M
1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3), 4x HDD
•VCO-6000-ADL-3E-2B15M-2PWR
1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3), 4x HDD,
2x Power input
•VCO-6000-ADL-3E-2N15M
1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3), 2x 15mm NVMe
•VCO-6000-ADL-3E-2N15M-2PWR
1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3), 2x 15mm NVMe,
2x Power input
VCO-6000-ADL-3E Series

VCO-6000-ADL l User’s Manual
13
Chapter 1: Product Introductions
Model No. Front Panel
•VCO-6000-ADL-4E
2x PCIe x16 Slot (x8 Lane, Gen 4),
1x PCIe x4 (x1 Lane, Gen 3)
•VCO-6000-ADL-4E-2PWR
2x PCIe x16 Slot (x8 Lane, Gen 4),
1x PCIe x4 (x1 Lane, Gen 3),
2x Power input
•VCO-6000-ADL-4E-4B7M
2x PCIe x16 Slot (x8 Lane, Gen 4),
1x PCIe x4 (x1 Lane, Gen 3),
6x HDD
•VCO-6000-ADL-4E-4B7M-2PWR
2x PCIe x16 Slot (x8 Lane, Gen 4),
1x PCIe x4 (x1 Lane, Gen 3),
6x HDD,
2x Power input
•VCO-6000-ADL-4E-2B15M
2x PCIe x16 Slot (x8 Lane, Gen 4),
1x PCIe x4 (x1 Lane, Gen 3),
4x HDD
•VCO-6000-ADL-4E-2B15M-2PWR
2x PCIe x16 Slot (x8 Lane, Gen 4),
1x PCIe x4 (x1 Lane, Gen 3),
4x HDD,
2x Power input
•VCO-6000-ADL-4E-2N15M
2x PCIe x16 Slot (x8 Lane, Gen 4),
1x PCIe x4 (x1 Lane, Gen 3),
2x 15mm NVMe
•VCO-6000-ADL-4E-2N15M-2PWR
2x PCIe x16 Slot (x8 Lane, Gen 4),
1x PCIe x4 (x1 Lane, Gen 3),
2x 15mm NVMe,
2x Power input
VCO-6000-ADL-4E Series

VCO-6000-ADL l User’s Manual
14
1.1.1 Key Features
⚫LGA 1700 socket for 12/13th Gen. Intel® ADL-S & RPL-S Processor (65W/35W TDP)
⚫Intel® R680E chipset
⚫2x DDR5 4800/5600MHz SODIMM. Max. up to 64GB
⚫Triple Independent Display by 1x DVI-I and 2x DisplayPort
⚫2x Intel® 2.5GbE supporting Wake-on-LAN and PXE
⚫2x Full-size Mini PCIe (1x shared by 1x mSATA), 2x SIM socket
⚫2x 2.5” SATA HDD Bay (1x Internal) and with RAID 0, 1 support
⚫1x M.2 (E Key, PCIe x1, USB 2.0, 2230, Support CNVi)
⚫6x RS-232/422/485 (4x internal), 4x USB 3.2 Gen 2, 5x USB 3.2 Gen 1 (internal)
⚫8x DI + 8x DO with isolation
⚫9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
⚫Wide Operating Temperature -25°C to 70°C (35W CPU); -25°C to 60°C (65W CPU)
⚫TPM 2.0 Supported
Chapter 1: Product Introductions
PCIe Expansion Model No.
1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3) •VCO-6000-ADL-3E
2x PCIe x16 Slot (x8 Lane, Gen 4), 1x PCIe x4 (x1 Lane, Gen 3) •VCO-6000-ADL-4E
SSD/HDD Features Model No.
1x Internal 2.5" SATA/SSD HDD Bay (support H=9mm)
1x Removable 2.5" SATA HDD Bay (support H=7mm, Hot-swappable)
•VCO-6000-ADL-3E
•VCO-6000-ADL-4E
1x Internal 2.5" SATA/SSD HDD Bay (support H=9mm)
5x Removable 2.5" SATA HDD Bay (support H=7mm, Hot-swappable)
•VCO-6000-ADL-3E-4B7M
•VCO-6000-ADL-4E-4B7M
1x Internal 2.5" SATA/SSD HDD Bay (support H=9mm)
1x Removable 2.5“ SATA HDD Bay (support H=7mm, Hot-swappable)
2x Removable 2.5” SATA HDD Bay (support H=15mm, Hot-swappable)
•VCO-6000-ADL-3E-2B15M
•VCO-6000-ADL-4E-2B15M
1x Internal 2.5" SATA/SSD HDD Bay (support H=9mm)
1x Removable 2.5“ SATA HDD Bay (support H=7mm, Hot-swappable)
2x Removable 2.5” U.2 NVMe Bay (support H=15mm, Hot-swappable)
•VCO-6000-ADL-3E-2N15M
•VCO-6000-ADL-4E-2N15M
2x Power input Model No.
9~48VDC
12~48VDC
(For GPU/Card Expansion)
•VCO-6000-ADL-3E-2PWR
•VCO-6000-ADL-3E-4B7M-2PWR
•VCO-6000-ADL-3E-2B15M-2PWR
•VCO-6000-ADL-3E-2N15M-2PWR
•VCO-6000-ADL-4E-2PWR
•VCO-6000-ADL-4E-4B7M-2PWR
•VCO-6000-ADL-4E-2B15M-2PWR
•VCO-6000-ADL-4E-2N15M-2PWR

VCO-6000-ADL l User’s Manual
15
1.2 Hardware Specification
Chapter 1: Product Introductions
System
Processor
Support 12/13th Gen Intel® ADL-S & RPL-S Processor (LGA 1700, 65W/35W TDP)
•Intel® Core™i9-13900TE/i9-12900TE, up to 24 Cores, 36MB Cache, up to 5 GHz, 35W
•Intel® Core™i7-13700E/i7-12700E, up to 16 Core, 30MB Cache, up to 5.1 GHz, 65W
•Intel® Core™i7-13700TE/i7-12700TE, up to 16 Cores, 30MB cache, up to 4.8 GHz, 35W
•Intel® Core™i5-13500E/i5-12500E, up to 14 Cores, 24MB Cache, up to 4.6 GHz, 65 W
•Intel® Core™i5-13500TE/i5-12500TE, up to 14 Core, 24MB Cache, up to 4.5 GHz, 35W
•Intel® Core™i3-13100E/i3-12100E, up to 8 Cores, 12MB cache, up to 4.4 GHz, 60W
•Intel® Core™i3-12100TE/i3-12100TE, up to 4 Cores, 12MB Cache, up to 4.1 GHz, 35W
•Intel® Pentium® G7400E,2 Cores, 6MB Cache, 3.6 GHz, 46W
•Intel® Pentium® G7400TE, 2 Cores, 6MB Cache, 3.0 GHz, 35W
•Intel® Celeron® G6900E, 2 Cores, 4MB Cache, 3.0 GHz, 46W
•Intel® Celeron® G6900TE, 2 Cores, 4MB Cache, 2.4 GHz, 35W
System Chipset Intel® R680E Express Chipset
LAN Chipset 2.5 GbE1: Intel I226, Support Wake-on-LAN and PXE, Support TSN
2.5 GbE2: Intel I226, Support Wake-on-LAN and PXE, Support TSN
Audio Codec Realtek ALC888S
System Memory 2x 262-Pin DDR5 4800/5600MHz SODIMM.
Max. up to 64GB (ECC and Non-ECC)
Graphics Intel® UHD Graphics 770/710
BIOS AMI 256Mbit SPI BIOS
Watchdog Software Programmable Supports 1~255 sec. System Reset
TPM TPM 2.0
Display
DisplayPort 2x DisplayPort, Support resolution 5120 x 3200,
Up to 7680 x 4320
DVI 1x DVI-I, support resolution 1920 x 1200
Multiple Display Triple Display
VGA Yes (by optional split cable)

VCO-6000-ADL l User’s Manual
16
Chapter 1: Product Introductions
Storage M.2 SIM Socket
VCO-6000-ADL-3E-4B7M
VCO-6000-ADL-3E-4B7M-2PWR
VCO-6000-ADL-4E-4B7M
VCO-6000-ADL-4E-4B7M-2PWR
1x M.2 B Key,
2242/3042/3052
(PCIe x2, Support AI
Module/NVMe Storage)
(PCIe x1 & USB 3.2
Gen1, Support 4G/5G)
2x External SIM
socket
(Mini PCIE attached)
1x Internal 2.5" SATA/SSD HDD Bay (support
H=9mm)
5x Removable 2.5“ SATA HDD Bay (support
H=7mm, Hot-swappable)
VCO-6000-ADL-3E-2B15M
VCO-6000-ADL-3E-2B15M-2PWR
VCO-6000-ADL-4E-2B15M
VCO-6000-ADL-4E-2B15M-2PWR
1x Internal 2.5" SATA/SSD HDD Bay (support
H=9mm)
1x Removable 2.5“ SATA HDD Bay (support
H=7mm, Hot-swappable)
2x Removable 2.5” SATA HDD Bay (support
H=15mm, Hot-swappable,)
VCO-6000-ADL-3E-2N15M
VCO-6000-ADL-3E-2N15M-2PWR
VCO-6000-ADL-4E-2N15M
VCO-6000-ADL-4E-2N15M-2PWR
1x Internal 2.5" SATA/SSD HDD Bay (support
H=9mm)
1x Removable 2.5“ SATA HDD Bay (support
H=7mm, Hot-swappable)
2x Removable 2.5” U.2 NVMe Bay (support
H=15mm, Hot-swappable)
Expansion
Mini PCIe 1x Full-size Mini PCIe (1x shared by 1x mSATA)
PCIe
•1x PCIe x16 (Gen4), 2x PCIe x1 (Gen3) ：
Model No：
VCO-6000-ADL-3E
VCO-6000-ADL-3E-4B7M
VCO-6000-ADL-3E-2B15M
VCO-6000-ADL-3E-2N15M
VCO-6000-ADL-3E-2PWR
VCO-6000-ADL-3E-4B7M-2PWR
VCO-6000-ADL-3E-2B15M-2PWR
VCO-6000-ADL-3E-2N15M-2PWR
•2x PCIe x16 Slot (x8 Lane, Gen 4),
1x PCIe x4 (x1 Lane, Gen 3)：
Model No：
VCO-6000-ADL-4E
VCO-6000-ADL-4E-4B7M
VCO-6000-ADL-4E-2B15M
VCO-6000-ADL-4E-2N15M
VCO-6000-ADL-4E-2PWR
VCO-6000-ADL-4E-4B7M-2PWR
VCO-6000-ADL-4E-2B15M-2PWR
VCO-6000-ADL-4E-2N15M-2PWR
I/O
COM 2x RS-232/422/485 ; 6x RS-232/422/485 (internal)
DIO 8 in / 8 out (Isolated)
LAN 2x RJ45
Universal I/O Bracket 2x Universal I/O Bracket (By mini PCIe interface)
USB 4x USB 3.2 Gen 2 (10 Gbps)
5x USB 3.2 Gen 1 (5 Gbps, Internal)
1x USB 3.2 Gen 1 header (5 Gbps, internal)
Others 4x WiFi Antenna Holes
1x Power Switch, 1x AT/ATX Switch, 1x Remote Power On/Off
1x PC/Car Mode Switch, 1x Delay Time Switch
1x Removable CMOS Battery (internal)
1x 6CM FAN Module (Optional)

VCO-6000-ADL l User’s Manual
17
Chapter 1: Product Introductions
Power
Power Adapter
Optional AC/DC 24V/9.2A, 220W
Optional AC/DC 24V/11.67A, 280W (GPU/Card Expansion)
Optional AC/DC 24V/15A, 360W (i7/i9 CPU/GPU/Card Expansion)
Power Mode AT, ATX
Power Ignition Sensing Power Ignition Management
Power Supply Voltage 9~48VDC
12~48VDC (Optional, For GPU/Card Expansion) (optional)
Power Connector 5-pin Terminal Block
4-pin Terminal Block (optional)
Power Protection
OVP (Over Voltage Protection);
OCP (Over Current Protection)
Reserve Protection
Environment
Operating Temp. -25°C to 70°C (35W CPU)
-25°C to 60°C (65W CPU)
Storage Temp. -30°C to 85°C
Relative Humidity 10% to 95% (non-condensing)
Standards / Certification CE, FCC Class A
Vibration With SSD: 3 Grms, 5 - 500 Hz, 0.5 hr/axis
With HDD: 1 Grms, 5 - 500 Hz, 0.5 hr/axis
Shock With SSD: 20G, half sine, 11ms
Physical
Construction Extruded Aluminum with Heavy Duty Metal
Dimension •VCO-6000-ADL-3E Series：
157 (W) x 340 (D) x 240 (H) mm
•VCO-6000-ADL-4E Series：
177 (W) x 340 (D) x 240 (H) mm
Mounting Wall Mounting
Operating System
Windows Windows 10/11
Linux Linux kernel

VCO-6000-ADL l User’s Manual
18
1.3 System I/O
1.3.1 VCO-6000-ADL-3E
Chapter 1: Product Introductions
ATX power on/off switch
Press to power-on or power-off the system
DC IN
Used to plug a DC power input with terminal
Block
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
Removable HDD
Removable 2.5" SATA HDD Bay
(support H=7mm, hot-swappable)
DisplayPort
Used to connect a DisplayPort monitor
LAN Port
Used to connect the system to a local area
network
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
COM port
COM1 & COM2 support RS232/422/485 serial
device
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal
block
2x Universal I/O Bracket
Hot-Swappable Fan
Easily removed for replacements or quick
maintenance in the field.

VCO-6000-ADL l User’s Manual
19
VCO-6000-ADL-3E Series Expansion
VCO-6000-ADL-3E / VCO-6000-ADL-3E-4B7M / VCO-6000-ADL-3E-2B15M / VCO-6000-ADL-3E-2N15M /
VCO-6000-ADL-3E-2PWR / VCO-6000-ADL-3E-4B7M-2PWR / VCO-6000-ADL-3E-2B15M-2PWR /
VCO-6000-ADL-3E-2N15M-2PWR
Chapter 1: Product Introductions
Storage (optional)
•4B7M:
4x Removable 2.5" SATA HDD Bay
•2B15M:
2x Removable 2.5" SATA HDD Bay
•2N15M:
2x Removable 2.5" U.2 NVMe Bay
DC IN 12 ~ 48VDC (optional)
•12 ~ 48VDC (For GPU/Card Expansion)
FAN (optional)
•Internal 6 CM FAN (Optional)
Front Panel
Rear Panel

VCO-6000-ADL l User’s Manual
20
1.3.2 VCO-6000-ADL-4E
Chapter 1: Product Introductions
ATX power on/off switch
Press to power-on or power-off the system
DC IN
Used to plug a DC power input with terminal
Block
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
Removable HDD
Removable 2.5" SATA HDD Bay
(support H=7mm, hot-swappable)
DisplayPort
Used to connect a DisplayPort monitor
LAN Port
Used to connect the system to a local area
network
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
COM port
COM1 & COM2 support RS232/422/485 serial
device
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal
block
2x Universal I/O Bracket
Hot-Swappable Fan
Easily removed for replacements or quick
maintenance in the field.
