Candy GVH 9913NA2 User manual

INSTRUCTION BOOK
GVH 9913NA2
Heat Pump Tumble Dryer
English 2
Deutsch 16
Español
Deutsch
Français
Italiano
44
30
58
Polish 72
Deutsch
Deutsch
Deutsch
Deutsch
86
100
114
128
Suomi
Dansk
Norsk
Svenska
Porteguese 142

EN 2
Introduction
Delivery Information
Safety Reminders
Use
Installation
The Laundry
Ventilation
Environmental Issues
Gias Service
Electrical Requirements
Adjusting the Feet
Drain Hose Kit: Fitting Instructions
Preparing the Load
Clothes Preparation
Do Not Tumble Dry
Energy Saving
Sorting the Load
Drying Guide
Controls and Indicators
Selecting the Programme
Door and Filter
Opening the Door
Filter
Filter Care Indicator
Water Container
To Remove the Container
Condenser
To Remove the Condenser
Operation
Delay Start Function
Cancelling and Resetting the Programme
Cleaning and Routine Maintenance
Cleaning the Dryer
Technical Specifications
Troubleshooting
Customer Service
Spares
Gias Service
INDEX
3
3
3
4
5
5
6
7
7
7
7
8
9
9
9
9
9
9
10
11
12
12
12
12
13
13
13
13
14
14
14
14
14
14
15
15
15
15

INTRODUCTION
Use
Please check that the following items are
delivered with the appliance:
● Instruction manual
● Guarantee card
● Energy label
Please read and follow these instructions carefully and operate the machine accordingly. This
booklet provides important guidelines for safe use, installation, maintenance and some useful
advice for best results when using your machine.
Keep all documentation in a safe place for future reference or for any future owners.
Delivery Information
EN 3
SAFETY REMINDERS
●
and persons with reduced physical,sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.Children of less than 3 years should be kept away unless
continuously supervised.
● WARNING Misuse of a tumble dryer may create a fire hazard.
●This appliances is intended to be used in household and similar
applications such as:
- Staff kitchen areas in shops , offices and other working environments;
- Farm houses
- By clients in hotels, motels and other residential type environments;
- Bed and breakfast type environments.
A different use of this appliance from household environment or from
typical housekeeping functions,as commercial use by expert or trained
users, is excluded even in the above applications.
If the appliance is used in a manner inconsistent with this it may reduce the
life of the appliance and may void the manufacturer’s warranty. Any
damage to the appliance or other damage or loss arising through use that
is not consistent with domestic or household use ( even if located in a
domestic or household environment) shall not be accepted by the
manufacturer to the fullest extent permitted by law.''
This appliance can be used by children aged from 8 years and above
Failure to comply with the above can
compromise the safety of the appliance. You
may be charged for a service call if a problem
with your machine is caused by misuse.
Check that no damage has occurred to the
machine during transit. If it has, call for service
by GIAS.

INTRODUCTION
●This machine should only be used for its intended purpose as described
in this manual. Ensure that the instructions for installation and use are
fully understood before operating the appliance.
● Do not touch the appliance when hands or feet are damp or wet.
● Do not lean on the door when loading the machine or use the door to lift
or move the machine.
●Do not allow children to play with the machine or its controls.
● WARNING Do not use the product if the fluff filter is not in position or is
damaged; fluff could be ignited.
●WARNING Where the hot surface symbol is located the
temperature rise during operation of the tumble dryer may be in excess of
60 degrees C.
●Remove the plug from the electricity supply. Always remove the plug
before cleaning the appliance.
● Do not continue to use this machine if it appears to be faulty.
● Lint and fluff must not be allowed to collect on the floor around the
outside of the machine.
●The final part of a tumble dryer cycle occurs without heat (cool down
cycle) to ensure that the items are left at a temperature that ensures that
the items will not be damaged.
● Maximum load drying weight : 9 kg
●The tumble dryer is not to be used if industrial chemicals have been used
for cleaning.
● WARNING: Never stop a tumble dryer before the end of the drying cycle
unless all items are quickly removed and spread out so that the heat is
dissipated.
Use
SAFETY REMINDERS
EN 4

●Do not dry unwashed items in the
tumble dryer.
●WARNING Do not tumble dry
fabrics treated with dry cleaning
fluids.
●WARNING Foam rubber
materials can, under certain
circumstances, when heated
become ignited by spontaneous
combustion. Items such as foam
rubber (latex foam), shower caps,
waterproof textiles, rubber backed
articles and clothes or pillows fitted
with foam rubber pads MUST NOT
be dried in the tumble dryer.
●Always refer to the laundry care
labels for directions on suitability for
drying.
●Clothes should be spin dried or
thoroughly wrung before they are
put into the tumble dryer. Clothes
that are dripping wet should not be
put into the dryer.
● Lighters and matches must not
be left in pockets and NEVER use
flammable liquids near the
machine.
●Glass fibre curtains should
NEVER be put in this machine.
Skin irritation may occur if other
garments are contaminated with the
glass fibres.
● Items that have been soiled with
substances such as cooking oil,
acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes
and wax removers should be
washed in hot water with an extra
amount of detergent before being
dried in the tumble dryer.
●Fabric softeners, or similar
products, should be used as
specified by the fabric softener
instructions.
The Laundry
● Check that the product has no
visible signs of damage before use.
If damaged do not use and please
call GIAS Service.
●Do not use adapters, multiple
connectors and/or extensions.
●Never install the dryer against
curtains and be sure to prevent
items from falling or collecting
behind the dryer.
●The appliance must not be
installed behind a lockable door, a
sliding door or a door with a hinge
on the opposite side to that of the
tumble dryer.
Installation
INTRODUCTION
SAFETY REMINDERS
EN 5

The instructions for installation and
any fixing attachments, are provided
with the staking kit.
Ventilation
INTRODUCTION
SAFETY REMINDERS
● Adequate ventilation must be
provided in the room where the
tumble dryer is located to prevent
gases from appliances burning other
fuels, including open fires, being
drawn into the room during operation
of the tumble dryer.
● Installing the rear of the appliance
close to a wall or vertical surface.
●There should be a gap of at least 12
mm between the machine and any
obstrubtions.The inlet and outlet
should be kept clear of obstruction.To
ensure adequate ventilation the
space between the bottom of the
machine and the floor must not be
obstructed.
●Check regularly that the air flowing
through the dryer is not restricted.
●Check frequently the fluff filter after
use, and clean, if necessary.
●Prevent items from falling or
collecting behind the dryer as these
may obstruct the air inlet and outlet
●NEVER install the dryer up against
curtains.
●In cases where the dryer is installed
on top of a washing machine, a
suitable stacking kit must be used
according to the follow configuration.
-Stacking kit Mod 35100019: for
minimum washing machine depth
49 cm
-Stacking kit Mod 35900120: for
minimum washing machine depth
51 cm
The stacking kit shall be one of that
above, obtainable from our spare
service.
Air Outlets in the Base
Important: During transport ensure that the
dryer is in an upright position, if it's necessary
you can only flip in the side shown;
Caution: If the product is in different side, wait
at least 4 hours before switching on so that the
oil can flow back into the compressor. Failure
to do this could result in damage to the
compressor.
EN 6

SAFETY REMINDERS
This appliance is marked according
t o th e Eu r o p e a n di r e c t i v e
2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product.
The symbol on the product indicates that this
product may not be treated as household waste.
Instead it shall be handed over to the applicable
collection point for the recycling of electrical and
electronic equipment.
For more detailed information about treatment,
recovery and recycling of this product, please
contact your local city office,your household
waste disposal service or the shop where you
purchased the product. Disposal must be
carried out in accordance with local
environmental regulations for waste disposal.
European Directive 2002/96/EC
● To ensure the continued safe and efficient
operation of this appliance we recommend that
any servicing or repairs are only carried out by
an authorised GIAS service engineer.
GIAS Service
If the appliance is not running properly or
breaks down, switch it off and disconnect the
plug from the socket. Consult GIAS Service for
possible repair.
● All packaging materials used are
environmentally-friendly and recyclable.
Please help dispose of the packaging via
environmentally-friendly means. Your local
council will be able to give you details of current
means of disposal.
● To ensure safety when disposing of an old
tumble dryer disconnect the mains plug from
the socket, cut the mains power cable and
destroy this together with the plug. To prevent
children shutting themselves in the machine
break the door hinges or the door lock.
Environmental Issues
Tumble dryers are supplied to operate at a
voltage of 220-240V, 50 Hz single phase. Check
that the supply circuit is rated to at least 6A.
Electricity can be extremely dangerous.
This appliance must be earthed.
The socket outlet and the plug on the
appliance must be of the same type.
Do not use multiple adapters and/or
extension leads.
The plug should be accessible for
disconnection after the appliance has been
installed.
CE Appliance complies with European Directive
2004/108/EC, 2006/95/EC and subsequent
amendments.
Electrical Requirements
If the mains cord on this appliance is
damaged, it must be replaced by a special cord
which is ONLY obtainable from the spares
service. It must be installed by a competent
person.
You may be charged for a service call if a
problem with your machine is caused by
incorrect installation.
Once the machine is in
place the feet should
be adjusted to ensure
that the machine is
level.
Adjusting the Feet
Do not plug the machine in and switch it
on at the mains until the installation is
completed.For your safety, this dryer must be
correctly installed. If there is any doubt about
installation, call GIAS Service for advice.
EN 7

DRAIN HOSE : FITTING INSTRUCTIONS
WARNING! Switch off and remove the
tumble dryer plug from the electricity supply
before carrying out any work.
Fit the Hose as Follows:
1.Flip the machine
slowly to the right side.
2. The waste water
pipe is situated at the
right-hand side of the
machine (see the
picture). A grey hose
connects to the bridge
at the left hand side of
the machine. Using
pliers, remove the pipe
retaining clip from the
bridge.
3. Pull the hose off the
bridge connection.
4. Attach the black
hose from the kit,
(using the connector
a n d p i p e c l i p s
supplied), to the hose
removed from the
bridge connection.
5. Once the machine is
in place, check the
bottom to ensure that
the new hose does not
kink when pushing the
tumble dryer into
position.
6. Connect the new
drain hose to the waste
Water pipe.
7. Connect to the
m a i n s e l e c t r i c i t y
supply.
Caution: If the product
is in different side, wait
at least 4 hours before
switching on so that the
oil can flow back into
t h e c o m p r e s s o r.
Failure to do this could
result in damage to the
compressor.
To avoid emptying the water container after
each drying cycle, the water can be
discharged directly to a waste water drain pipe
(the same drainage system as household
sinks). Water Bye-Laws prohibit connection to
a surface water drain. The waste water drain
pipe should be located adjacent to the tumble
dryer.
The kit consists of:1 hose and 1 tap.
DRAIN HOSE KIT: FITTING INSTRUCTIONS
Do not install the product in a low temperature room or
in a room where there is a risk of frost occurring. At
temperature around freezing point the product may not be
able to operate properly: there is a risk of damage if the
water is allowed to freeze in the hydraulic circuit (valves,
hoses, pumps). For a better product performance the
ambient room temperature must be between +2°C and
+35°C. Please note that operating in cold condition
(between +2 and +15°C) might imply some water
condensation and water drops on floor.
EN 8

PREPARING THE LOAD
Before using the tumble dryer for the first time:
● Please read this instruction book thoroughly.
● Remove all items packed inside drum.
●Wipe the inside of the drum and door with a damp
cloth to remove any dust which may have settled in
transit.
Make sure that the laundry you are going to dry is
suitable for drying in a tumble dryer, as shown by the
care symbols on each item.
Check that all fastenings are closed and that
pockets are empty. Turn the articles inside out. Place
clothes loosely in the drum to make sure that they
don't get tangled.
Clothes Preparation
● Cottons Max. 9 kg
● Synthetics Max. 4 kg
Maximum Drying Weight
Sort the Load as Follows
. .
.
● By care symbols
These can be found on the collar or inside seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
Do not tumble dry.
If the item does not have a care label it must be
assumed that it is not suitable for tumble drying.
● By amount and thickness
Whenever the load is bigger than the dryer
capacity, separate clothes according to
thickness (e.g. towels from thin underwear).
● By type of fabric
Cottons/linen: Towels, cotton jersey, bed and
table linen.
Synthetics: Blouses, shirts, overalls, etc. made
of polyester or polyamid, as well as for
cotton/synthetic mixes.
● By drying level
Sort into: iron dry, cupboard dry, etc. For delicate
articles press the button to select low drying
temperature.
Woollens, silk, delicate fabrics, nylon stockings,
delicate embroidery, fabrics with metallic decorations,
garments with PVC or leather trimmings, training
shoes, bulky items such as sleeping bags, etc.
Do Not Tumble Dry:
IMPORTANT: Do not dry articles which
have been treated with a dry cleaning fluid or
rubber clothes (danger of fire or explosion).
Only put into the tumble dryer laundry which
has been thoroughly wrung or spin-dried. The
drier the laundry the shorter the drying time thus
saving electricity.
ALWAYS
● Try to dry the maximum weight of laundry, this
will save time and electricity.
● Check that the filter is clean before every
drying cycle.
NEVER
● Exceed the maximum weight, this will waste
time and electricity.
● Put dripping wet items into the tumble dryer,
this may damage the appliance.
Energy Saving
During the last 15 minutes (roughly) the
load is always tumbled in cool air
Do not overload the drum, large items when
wet can exceed the maximum admissible clothes
load (for example: sleeping bags, duvets).
Drying Guide
Power consumption of "left on-mode"
Power consumption of "off-mode" 0,20 W
0,75 W
CYCLE LOAD ENERGY TIME
(kWh) (Min)
FULL
FULL
FULL
FULL
2,75 330
2,40 300
2,18 260
1,15 149
1,74 210
HALF
The standard cycle HANG DRY ( ) is the most
energy efficient and best suited for drying normal wet
cotton laundry.
The table below shows the approximate time and
energy consumption of the main drying programmes.
Perfect Home
Store Dry
Hang Dry
Hang Dry
Iron Dry
EN 9

CONTROLS AND INDICATORS
Control Panel and Indicator Lights
SELECTING THE PROGRAMME
Knob: You can turn it in both directions to choose the required programme.
Time selection :To modify the drying timing of required programme; it works only with certain
programmes.
Delay start :To delay the start of the drying cycle and to dry your laundry when electricity costs
less (please see dedicated section)
Delicate fabrics : When pulled, this indicator turns off and this new one turns on; with this
special function, the drying temperature is lower to better protect your delicate clothes.
Anti- Crease Button – Select the anti-crease function at the end of drying cycle. The drum
keeps moving at regular phases to refresh the laundry.
Cool down : This indicator turns on during the final cool phase of the cycle.
Start/Pause : To start the programme required or to pause the cycle.
Automatic programmes: Depending on desired programme, specific indicators turn on (please
see “programme list”); ECO indicator turns on when you select a low consumption programme.
Filter care : When on, please clean the filters.
Full water tank : When on, please empty the water tank.
This machine has a special Sensor Dry to help you
choose your preferred programme simply by selecting
the level of dryness wanted.
For small loads and pre-dried clothes, please use a
Timing programme and select “Delicate fabrics” button
to lower the temperature inside the drum.
If the Sensor does not detect any item, this Dryer will
work for only 10 minutes before starting the Cool down
phase.
If the load is too big or too wet, this Dryer will
automatically work for 3 hours and then start the Cool
down phase.
At the end of each programme, there is always the Cool
Down phase: it is a cool-air refresh phase of around 15
minutes.
Filter Care
Indicator
Program
Display
Empty Water
Indicator Programme
Selector
Start/Pause
Button
Delay Start
Button
Time Selection
Button Acrylic Synthetic
Button
Anti-Crease
Button
EN 10

SELECTING THE PROGRAMME
PROGRAMME
Wool
Mix & Dry
Rapid 40 Min.
Shirts
Time
Jeans
No Crease
Iron Dry
Perfect Home
Store Dry
Hang Dry
IDEAL FOR
Leave clothes slightly damp to allow easier ironing. Time: around 1h and
50 min.
Clothes you don’t need to iron, but just hang after the drying cycle. Time:
around 2h and 30 min.
Clothes you want to fold and store without ironing, e.g. shirts in mixed
fabrics, socks, baby clothes. Time: around 2h and 45 min.
Clothes you want completely dryed, e.g. towels, bathrobes, table clothes
or sheet. Time: around 3h.
To soften your woollen clothes or to simply refresh them after a long time in
the wardrobe. Time: 12 min.
To dry mixed cotton and synthetic clothes: save time and no need to
separate the washing and dry them in different cycles. Time: around 2h
(max 4 kg).
To dry shirts both cotton and synthetic fabrics. Time: 1h for 2kg of synthetic
shirts (around 10 shirts); 1h and 20 min for 3 kg of cotton shirts (around 10
shirts).
If you want to choose drying times, from 30 to 180 minutes. By selecting “20
min” you choose a “cool programme”, ideal to refresh clothes and to remove
eventual smells.
To dry up to 4 kg of Jeans (around 5 pairs). The programme works for around
2h, but timing can change according to the load and washing spin speed.
Jeans programme can only be used for 100% cotton items, please do not
mix colours nor dry jeans with embroideries or accessories.
Clothes you just need to refresh. Good for items of clothing which have been
left prior to ironing or if they have been dried outside or on radiators. This
programme has a specific Anti-Crease function that relaxes fibres and
makes easier ironing. Time: 9 min + 3 min cool down.
For dry, refreshed and ready to dress clothes in onyl 40 minutes. Sensor
system keeps under control the temperature to have always the best result.
Max 2 kg.
EN 11

DOOR and FILTER
Opening the Door
Pull on handle to open
the door.
To restart the dryer,
close the door and
press .
WARNING! When the tumble dryer is in
use the drum and door may be VERY HOT.
Never stop a tumble dryer before the end of the
drying cycle unless all items are quickly
removed and spread out so that the heat is
dissipated.
Filter Care Indicator
Lights when the filter
needs cleaning.
Check and clean the
main filter in the door
and the condenser
filters allocated in the
bottom of the dryer,If
the laundry is not
drying check that the
filter is not clogged. DO NOT USE WATER TO CLEAN THE FILTER.
Filter
IMPORTANT: To maintain the efficiency of the
dryer check that the fluff filter is clean before
each drying cycle.
Do not operate the dryer without the filters.
Clogged filters can increase the drying time
and cause damage which may result in
expensive repair costs.
1 . P u l l t h e f i l t e r
upwards.
2. Open filter as shown.
3.Gently remove lint
using a soft brush or
your fingertips.
4. S n a p th e f i l t e r
together and push
back into place.
To Clean the Condenser Filter
1 . R e m o v e t h e
kickplate.
2. Turn the two locking
levers anti-clockwise
and pull out the front
cover.
3. Gently remove the
filter frame and clean
any dust or fluff with a
cloth from the filter. Do
not use water to clean
the filter.
4. Remove the sponge
gently from its place
and then wash the
sponge by holding it
under a running tap
turning it so to remove
any dust or fluff.
5. Refit the front cover
ensuring it is in the
c o r r e c t w a y ( a s
indicated by the arrow)
and pushed firmly into
place. Lock the two
levers by turning them
clockwise.
6. Refit the kickplate.
EN 12

WATER CONTAINER
OPERATION
1. Open the door and load the drum with
laundry. Ensure that garments do not hinder
closure of the door.
2. Gently close the door pushing it slowly until
you hear the door 'click' shut.
3. Turn the Programme Selector dial to select
the required drying programme (see
Programme Guide).
4. If drying synthetics, acrylics or delicate items,
press the button to reduce the heat level.
The indicator will light up when the machine is in
low heat setting. To deselect in the first few
minutes of the programme, press the button
, after this time reset the machine to change the
setting.
5. Press the button. The dryer will start
automatically and the indicator above the
button will be continuously lit.
6. If the door is opened during the programme to
check the laundry, it is necessary to press to
recommence drying after the door has been
closed.
7. When the cycle is nearing completion the
machine will enter the cool down phase, the
clothes will be tumbled in cool air allowing the
load to cool down.
8. Following the completion of the cycle the
drum will rotate intermittently to minimize
creasing. This will continue until the machine is
switched OFF or the door is opened.
Do not open the door during the automatic
programs in order to obtain a proper drying.
The water removed from the laundry during
the drying cycle is collected in a container
inside the door of the dryer. When the
container is full the indicator on the control
panel will light, and the container MUST be
emptied. However, we recommend that the
container is emptied after each drying cycle.
NOTE: Very little water will collect during the
first few cycles of a new machine as an internal
reservoir is filled first.
To Remove the Container
1. Gently pull out the
w a t e r c o n t a i n e r
holding the handle.
When it is full the
water container will
weigh about 6 kg.
2. Tilt the water
container to empty the
water out through the
spout.
When empty, replace
the water container
back as shown; first
insert the base of the
container into position
as shown then gentle
push the top into
position.
3. Press Button to
restart the cycle.
NOTE: If you have the
option of drainage
near to the dryer you
can use the discharge
k i t to p r o v i d e a
permanent drainage
for the water collected
in the container of the
dryer. This means that
you don't have to
em pt y th e wat er
container.
1
WARNING! If you open the door mid cycle,
before the cool-down cycle has completed,the
handle may be hot. Please use extreme caution
when attempting to empty the water reservoir
during the cycle.
EN 13

IMPORTANT Always switch off and
remove the plug from the electricity supply
before cleaning this appliance.
For electrical data refer to the rating label
on the front of the dryer cabinet (with the door
open).
Technical Specifications
Cleaning the Dryer
Drum capacity 115 litres
Maximum load 9 kg
Height 85 cm
Width 60 cm
Depth 60 cm
Energy Label Band A ++
OPERATION
● Clean the filter and empty the water
container after every drying cycle.
● Regularly clean the filters.
● After each period of use, wipe the inside of
the drum and leave the door open for a while to
allow circulation of air to dry it.
● Wipe the outside of the machine and the
door with a soft cloth.
● DO NOT use abrasive pads or cleaning
agents.
● To prevent the door sticking or the build up
of fluff clean the inner door and gasket with a
damp cloth after every drying cycle.
WARNING! The Drum, door and load may
be very hot.
CLEANING AND ROUTINE MAINTENANCE
Delay Start Function
The Delay Start Function allows the user to delay the start of the drying cycle by 1 to 24 hours.
When the function is first selected the display will show a delay of 1 hour, subsequent presses of
the button will increase the delay with 1 hour steps.
To commence the programme press and the appliance will complete the drying cycle at the
end of this time. The indicator light will flash to indicate that the start delay is in progress.
Cancelling and Resetting the Programme
To cancel a programme press the button for 3 seconds. In the TIME CONTROL display 0:00
Light will flash to indicate that it has been reset.
Information for Test Laboratory
EN 61121 Programme Programme To Use
-DRY COTTON -HANG DRY
-IRON DRY
-HANG DRY + SYNTHETIC
-IRON DRY COTTON
-EASY-CARE TEXTILE
EN 14

TROUBLESHOOTING
What Might be the Cause of...
Defects you can remedy yourself
Before calling GIAS Service for technical
advice please run through the following
checklist. A charge will be made if the machine
is found to be working or has been installed
incorrectly or used incorrectly.
If the problem persists after completing the
recommended checks, please call GIAS
Service, they may be able to assist you over the
telephone.
Time display to end could change during
drying cycle. The time to end is
continuously checked during the drying
cycle and the time is adjusted to give the
best estimation time. The displayed time
may increase or decrease during the cycle
and this is normal.
Drying time is too long/clothes are not dry
enough…
●Have you selected the correct drying
time/programme?
● Were the clothes too wet? Were the clothes
thoroughly wrung or spindried?
● Does the filter need cleaning?
● Is the dryer overloaded?
●Has the option been selected from a
previous cycle?
The dryer does not operate…
● Is there a working electricity supply to the
dryer? Check using another appliance such as
a table lamp.
● Is the plug properly connected to the mains
supply?
● Is there a power failure?
● Has the fuse blown?
● Is the door fully closed?
● Is the dryer switched on, both at the mains
supply and at the machine?
● Has the drying time or the programme been
selected?
● Has the machine been switched on again after
opening the door?
CUSTOMER SERVICE
Spares
GIAS Service
Should there still be a problem with your dryer
after completing all the recommended checks,
please call GIAS Service for advice.
They may be able to assist you over the
telephone or arrange for a suitable appointment
for an engineer to call under the terms of your
guarantee. However, a charge may be made if
any of the following applies to your machine:
● Is found to be in working order.
● Has not been installed in accordance with the
installation instructions.
● Has been used incorrectly.
Always use genuine spares, available direct
from GIAS Service.
For service and repairs call your local GIAS
Service engineer.
The dryer is noisy…
● Switch off the dryer and contact GIAS Service
for advice.
The Indicator is on…
● Does the filter need cleaning?
The Indicator is on…
● Does the water container need emptying?
The manufacturer declines all responsibility
in the event of any printing mistakes in this
booklet. The manufacturer also reserves the
right to make appropriate modifications to
its products without changing the essential
characteristics.
EN 15

Introducción
Información de entrega
Advertencias sobre seguridad
Uso
Instalación
La colada
Ventilación
Instalación
Temas medioambientales
Servicio técnico de GIAS
Requisitos eléctricos
Ajuste de las patas
Desagüe: Instrucciones de Colocación
Preparación del material para secar
Preparación de la ropa
Clasificación del material para secar
No secar en secadora
Ahorro de energía
Guía de secado
Controles e indicadores
Selección del programa
Puerta y filtro
Modo de abrir la puerta
Filtro
Control de mantenimiento del filtro
Depósito del agua
Modo de sacar el recipiente
Condensador
Modo de sacar el condensador
Operación
Inicio diferido
Modo de cancelar y restablecer el programa
Limpieza y mantenimiento de rutina
Limpieza de la secadora
Especificaciones técnicas
Resolución de problemas
Servicio de atención al cliente
Servicio de recambios
Servicio técnico de GIAS
ÍNDICE
ES 16
17
17
17
18
19
19
20
21
21
21
21
21
22
23
23
23
23
23
23
24
25
26
27
27
27
27
28
28
28
28
28
28
29
29
29
29
26
26
26

SL 6
INTRODUCCIÓN
Por favor verifique que los siguientes artículos
hayan sido entregados con el electrodoméstico:
● Manual de instrucciones
● Tarjeta de garantía
● Etiqueta de energía
Por favor lea cuidadosamente estas instrucciones y utilice la máquina según sus indicaciones. Este
folleto presenta directrices importantes para el seguro, la instalación y el mantenimiento seguros y
algunos consejos útiles para obtener los mejores resultados de su secadora.
.Conserve toda la documentación en un lugar seguro para referencia futura o para los dueños futuros
Información de Entrega
El incumplimiento de lo anterior puede
perjudicar a la seguridad del electrodoméstico. Es
posible que se le cobre una llamada al servicio
técnico si el problema con el electrodoméstico es
el resultado de un uso incorrecto.
Verifique que no se hayan producido daños al
electrodoméstico durante el transporte. De
haberlos, llame al Servicio técnico de GIAS.
ADVERTENCIAS SOBRE SEGURIDAD
Uso
ADVERTENCIAS SOBRE SEGURIDAD
Uso
ES 17
● Este electrodoméstico puede ser utilizado por niños mayores de 8 años
y por personas con capacidades físicas, sensoriales o mentales
limitadas o que carezcan de la experiencia y el conocimiento necesarios,
siempre y cuando estén supervisadas por una persona encargada de
velar por su seguridad o hayan sido instruidas en su utilización de
manera segura.
●ADVERTENCIA El uso incorrecto de una secadora puede provocar
riesgo de incendio.
●Este producto es exclusivamente para uso doméstico o similar:
Los niños no deben jugar con el electrodoméstico. Los niños no deben
ocuparse del mantenimiento ni de la limpieza del electrodoméstico, salvo
que estén supervisados una persona encargada de velar por su
seguridad.
-zona de cocina para el personal de tiendas, oficinas y otros entornos
laborales;
-granjas;
-pasajeros de hoteles, moteles u otros entornos residenciales;
-hostales (B&B).
No se recomienda el uso de este producto con fines diferentes del
doméstico o similar, por ejemplo, con fines comerciales o profesionales.

El empleo de la lavadora con fines no recomendados puede reducir la
vida útil del artefacto e invalidar la garantía. Todos los daños, averías o
pérdidas ocasionados por un uso diferente del doméstico o similar
(aunque ese uso se realice en un entorno doméstico) no serán
reconocidos por el fabricante en la medida en que lo permita la ley.
,
●Esta máquina debe usarse solamente para el propósito para el cual
fue diseñada tal y como se describe en este manual. Asegúrese de que
entiende todas las instrucciones de instalación antes de utilizar el
electrodoméstico.
●No toque el electrodoméstico cuando tenga las manos o los pies
mojados o húmedos.
● No se apoye en la puerta al cargar la secadora ni utilice la puerta para
levantar o mover la máquina.
● No permita a los niños jugar con la máquina ni los mandos.
● ADVERTENCIA No use el producto si el filtro de pelusa no está en su
lugar o si está dañado, ya que la pelusa podría arder.
● ADVERTENCIA En el lugar donde aparezca el símbolo de superficie
caliente ,el incremento de temperatura durante la operación de la
secadora puede exceder los 60 grados centígrados.
● Desconecte el enchufe de la red del suministro eléctrico. Siempre debe
desenchufar la máquina antes de limpiarla.
● No siga usando esta máquina si pareciera tener algún desperfecto.
●No hay que dejar que se acumulen lanilla y pelusas en el suelo
alrededor de la máquina.
● El tambor interior puede calentarse mucho. Antes de retirar la ropa de la
máquina, siempre deje que ésta termine de enfriarse.
●La última parte del ciclo de secado se realiza sin calor (ciclo frío) para
lograr una temperatura final que no dañe los tejidos.
●Máxima capacidad de secado: ver tarjeta de eficiencia energética 9 kg
●La secadora no debe ser usada si se han empleado agentes químicos
en el lavado.
●ATENCIÓN: Nunca detenga la secadora antes del fin de ciclo sin que
los tejidos hayan sido removidos velozmente y separados de manera que
el calor se disperse.
INTRODUCCIÓN
ADVERTENCIAS SOBRE SEGURIDAD
Uso
ADVERTENCIAS SOBRE SEGURIDAD
Uso
ES 18

INTRODUCCIÓN
ADVERTENCIAS SOBRE SEGURIDADADVERTENCIAS SOBRE SEGURIDAD
● Verifique que el producto no
muestre daños visibles antes de
usarlo. En caso de presentar algún
daño, no lo use y póngase en
contacto con el Servicio técnico de
GIAS.
●No utilice adaptadores,
c o n e c t o r e s m ú l t i p l e s y / o
alargaderas.
● Nunca instale la secadora junto
a cortinas, y procure que no caigan
objetos ni se acumule nada detrás
de la secadora.
● El electrodoméstico no debe
instalarse detrás de una puerta
con cierre, de una puerta
corredera ni de puertas cuyas
bisagras se encuentren en el lado
opuesto del lugar donde se
encuentra la secadora.
Instalación
NO DEBEN secarse en la
secadora.
● Consulte siempre las etiquetas
sobre lavado de las prendas para
conocer si se pueden secar en
secadora.
● Antes de introducir ropa en la
secadora, aquélla debe
centrifugarse o escurrirse bien.
Las prendas que escurren agua
NO deben introducirse en la
secadora.
● Deben sacarse de los bolsillos
encendedores y cerillas y no se
deben NUNCA usar líquidos
inflamables cerca de la máquina.
● No se deben introducir NUNCA
cortinas de fibra de vidrio en esta
máquina. Puede producirse
irritación de la piel si otras prendas
se contaminan con fibras de vidrio.
● Las prendas que se hayan
ensuciado con sustancias como
aceite de cocina, acetona,
alcohol,gasolina, queroseno,
limpiamanchas, trementina, ceras
y limpiadores de ceras deben
lavarse en agua caliente con una
cantidad extra de detergente
antes de introducirse en la
secadora.
● Los suavizantes de tejidos y los
productos similares pueden
utilizarse siguiendo las
instrucciones del suavizante.
La oladaC
●No utilice la secadora con
prendas que no haya lavado.
● ADVERTENCIA No debe
usarse para secar tejidos
tratados con líquidos para
limpieza en seco.
●ADVERTENCIA Los materiales
de gomaespuma, en algunas
circunstancias, pueden arder
por combustión espontánea si se
calientan. Los artículos como
gomaespuma (espuma de látex),
los gorros de ducha, los tejidos
impermeables a base de goma,
así como las almohadas o las SL 27
ES 19

SU 20
INTRODUCCIÓN
ADVERTENCIAS SOBRE SEGURIDADADVERTENCIAS SOBRE SEGURIDAD
Debe asegurarse una ventilación
adecuada en la sala donde esté
ubicada la secadora para evitar que
los gases de aparatos que quemen
otros combustibles, incluyendo
llamas abiertas, entren en la sala
cuando se está usando la secadora.
í
conducto
que sea utilizado para expulsar
humos de aparatos que quemen
gas u otros combustibles.
el paso de la corriente de aire a
través de la secadora.
Tiene que dejarse almenos un
espacio de 12 mm entre la secadora
y cualquier obstrucción. La
válvulade entrada y de salida tienen
que estar lejos de obstáculos. Para
asegurarse de una adecuada
ventilación el espacio entre la parte
inferior de la máquina y el
pavimento no debe ser obstruido.
●El aire extra do no debe
descargarse dentro de un
●Compruebe periódicamente que
no esté obstruido
●Después de usar la máquina,
revise el filtro de pelusas y límpielo
si es necesario.
●Installar la parte trasera del
aparato cerca de un muro o pared
vertical.
●
●Procure que no caigan objetos ni
se acumulen detrás de la máquina,
ya que éstos pueden obstruir la
entrada y salida de aire.
VENTILACIÓN
●
● NUNCA instale la secadora
junto a cortinas.
● En el caso de que la secadora se
instale encima de una lavadora, se
debe instalar el kit accesorio
columna correspondiente de
acuerdo con la siguiente
configuración.
Controlar frecuentemente el fitro
despues del uso y limpiarlo, si
fuera necesario.
-Kit Mod 35100019: para una
lavadora de profundidad de al
menos 49 cm.
-Kit Mod 35100120: para una
lavadora de profundidad de al
menos 51 cm.
El kit debe ser uno de los indicados
arriba, disponibles en los centros
se asistencia técnica. Las
intrucciones de montaje en la
secadora y de todos los
accesorios están en el própio kit.
ES 20
SALIDAS DE AIRE
SALIDAS DE AIRE EN LA BASE
TOMAS DE AIRE
Important: During transport ensure that the dryer is in an
upright position, if it's necessary you can only flip in the side
shown;
Caution: If the product is in different side, wait at least 4
hours before switching on so that the oil can flow back into
the compressor. Failure to do this could result in damage to
the compressor.
