Candy CITT642C/E1 User manual

PN:16166000A24991
Candy-MC-IF7251J1-A（IF7251J1-A）
CITT642C/E1
80G双胶纸
20210301
1、印刷颜色：钉装，单黑；

Thank you for purchasing the CANDY induction hob. Please read this instruction manual
carefully before using the hob and keep it in a safe place for future reference.
CITT642C/E1
Instructions Manual For Induction Hob
ENGLISH
Manuale di istruzioni per il piano cottura a induzione
ITALIANO

EN-2

EN-3

EN-4

59cm 52cm
6.2cm 5.8cm
EN-5

1. Max. 1300/1500W zone
2. Max. 2300/2600W zone
3. Max. 1800/2000W zone
4. Max. 1800/2000W zone
5. Glass plate
6. Control panel
1. On/Off control
2. Timer control
3. Boost
4. Heating zone selection controls
5. Power / Timer regulating key
6. Keylock control
four
2
1
3
4
5
3
2 1
4 5 6
EN-6

EN-7

How to use
Start cooking
Touch the ON/OFF control for three seconds. After power
on, the buzzer beeps once, all displays show “–” or “– –”,
indicating that the induction hob has entered the state of
standby mode.
Place a suitable pan on the cooking zone that you wish to
use.
• Make sure the bottom of the pan and the surface of the
cooking zone are clean and dry.
Touching the heating zone selection control ,and an
indicator next to the key will flash
Select a heat setting by touching the “-”or “+” control.
•If you don’t choose a heat setting within 1 minute, the
Induction hob will automatically switch off. You will need to
start again at step 1.
•You can modify the heat setting at any time during
cooking.
If the display flashes alternately with the heat setting
This means that:
•you have not placed a pan on the correct cooking zone or,
•the pan you’re using is not suitable for induction cooking or,
•the pan is too small or not properly centered on the cooking zone.
No heating takes place unless there is a suitable pan on the cooking zone.
The display will automatically turn off after 1 minute if no suitable pan is placed on it.
EN-8

Finish cooking
Using the Boost function
Touching the heating zone selection control that you
wish to switch off
Turn the cooking zone off by scrolling down to “0” or
touching “-” and “+” control together. Make sure the
display shows “0”.
Turn the whole cooktop off by touching the ON/OFF
control.
Beware of hot surfaces
H will show which cooking zone is hot to touch. It
will disappear when the surface has cooled down to
a safe temperature. It can also be used as an energy
saving function if you want to heat further pans, use
the hotplate that is still hot.
OR
Activate the boost function
Touching the heating zone selection control.
Touching the boost control , the zone indicator show
“P” and the power reach Max.
EN-9

•The cooking zone returns to its original setting after 5 minutes.
•If the original heat setting equals 0, it will return to 9 after 5 minutes.
Locking the Controls
•You can lock the controls to prevent unintended use (for example children accidentally turning the
cooking zones on).
•When the controls are locked, all the controls except the ON/OFF control are disabled.
To lock the controls
Touch the lock control The timer indicator will show “ Lo“
To unlock the controls
Touch and hold the lock control for a while.
When the hob is in the lock mode, all the controls are disable except the ON/OFF , you can always
turn the induction hob off with the ON/OFF control in an emergency, but you shall unlock the hob first
in the next operation.
Cancel the Boost function
Touching the "Boost" control or the “-” button to cancel
the Boost function, then the cooking zone will revert to
its original setting.
Touching “-” and “+” control together. The cooking zone
switch off and the boost function cancel automatically
OR
EN-10

Timer control
You can use the timer in two different ways:
a) You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when
the set time is up.
b) You can set it to turn one or more cooking zones off after the set time is up.
The timer of maximum is 99 min.
a) Using the Timer as a Minute Minder
Make sure the cooktop is turned on, if you are selecting a
cooking zone
Note: you can use the minute minder at least one zone shall
be active.
Select the zone by touching the heating zone selection
control.
When the zone is confirmed, touch the control of the timer.
The minder indicator will start flashing and “10” will show in
the timer display.
Set the time by touching the “-” or “+” control of the timer
Hint: Touch the “-” or “+” control of the timer once to
decrease or increase by 1 minute.
Touch and hold the “-” or “+” control of the timer to decrease
or increase by 10 minutes.
To cancel the minute minder
Select the zone by touching the heating zone selection
control. In a short time, touch the timer control.
Touching the “-” and “+” together, the timer
is cancelled, and the “00” will show in the minute
display.
When the time is set, it will begin to count down
immediately. The display will show the remaining
time and the timer indicator will flash for 5 seconds.
Buzzer will beep for 30 seconds and the timer
indicator shows “- -” when the setting time finished.
EN-11

b) Setting the timer to turn one cooking zone off
Set one zone
When cooking timer expires, the corresponding cooking zone
will be switched off automatically.
Other cooking zone will keep operating if they are turned on previously.
The pictures shown above are for reference only, and the final product shall prevail.
Touching the heating zone selection control that you want to set
the timer for. (e.g. zone 3#)
In short time, before the display stops flashing, touch the timer
control. The minder indicator will start flashing and “10” will show
in the timer display.
Set the time by touching the ”–“ or “+” control of the timer
Hint: Touch the “-” or “+” control of the timer once will decrease
or increase by 1 minute.
Touch and hold the “-” or “+” control of the timer will decrease or
increase by 10 minutes.
To cancel the timer
Select the zone by touching the heating zone selection control. In
a short time, touch the timer control.
Touching the “-” and “+” together, the timer is cancelled, and the
“00” will show in the minute display.
When the time is set, it will begin to count down immediately. The
display will show the remaining time and the timer indicator flash
for 5 seconds.
NOTE: The red dot next to power level indicator will illuminate
indicating that zone is selected.
EN-12

Power Management Function
it is possible to set a maximum power absorption level for the induction hob, choosing up to different
power ranges.
induction hobs are able to limit themselves automatically in order to work at lower power, to avoid
the risk of overloading.
It is not necessary to put any pots on the heating zones. We suggest to start setting within 5
seconds after connecting the power. You need to enter the power setting mode within 60
seconds to enter Power Management Function.
To enter Power Management Function
1. Please be noted that do not turn on the
hob. At this stage, press “Boost” and “Lock” at the
same time.
The “S” symbol will be displayed on zone #1.
2. Press “Lock” key.
The symbol “S” will be displayed on zone #1 and
symbol “E” will be displayed on zone #2.
3. Press “Boost” and “Lock” keys at the same
time again.
The symbol “S” will be displayed on zone #1, “E”
will be displayed on zone #2, and “t” will be
displayed on zone #3. At the same time, the
current maximum power mode (7.2) will be
displayed on the timer indicator.
To switch to another level
short press the “Boost” key
Confirmation Power Management Function
There are 6 power levels, from “7.2”to “2.5”. The
timer indicator will show one of them.
“7.2”: the maximum power is 7.2Kw.
“6.5”: the maximum power is 6.5Kw.
“5.5”: the maximum power is 5.5Kw.
“4.5”: the maximum power is 4.5Kw.
“3.5”: the maximum power is 3.5Kw.
“2.5”: the maximum power is 2.5Kw.
EN-13

After the desired power setting mode is selected,
please press “Lock” key
When the timer indicator stops flickering, the power
mode is set successfully.
Exit Power Management Function
After the setting, make sure to dis-connect the
power and connect it again.
Then the hob will be turned off.
EN-14

You may have a number of different cooking vessels
1. This induction hob can identify a variety of cooking vessels, which you can test by
one of the following methods:
Place the vessel on the cooking zone. If the corresponding cooking zone displays a
power level, then the vessel is suitable. If “U” flashes, then the vessel is not
suitable for use with the induction hob.
2. Hold a magnet to the vessel. If the magnet is attracted to the vessel is suitable for
use with the induction hob.
NB: The base of the vessel must contain magnetic material.
It must have flat bottom with a diameter according to the table 1 below.
3. Use only ferromagnetic cookwares made from enameled steel, cast iron or stainless
steel but compatible with induction
4. Use pans whose diameter of the ferromagnetic area (base of the pan) is in the range
of dimensions in the table below. (Table 1)
- If you use smaller pots, performance could be affected
- If you use pot with a diameter smaller than the one indicated in the table 1, pots
may not be detected
According to the dimension of the zone you can use pots of different diameters as picture
below:
Iron oil frying Stainless steel Iron pan Iron kettle
Enamel
stainless steel
kettle
Enamel cooking
utesil
Iron plate
EN-15

5. If the ferromagnetic part covers only partially the base of the pan, only the
ferromagnetic area will heat up, the rest of the base may not heat up a sufficient
temperature for cooking.
6. If the ferromagnetic area is not homogeneous, but presents others material such as
aluminum this may affect the heating up and the pan detection.
If the base of the pan is similar to the pictures below the pan could be not detected.
The base diameter of induction cookware
Cooking zone
1 120
160
160
210
3 & 4
Minimum Maximum
The above may vary according to the size of the pan and the material it is made from.
2
140 180
EN-16

EN-17

EN-18

EN-19
