Cannon imageRUNNER 2230 User manual

Corporate Solutions

Your growing business is unique. You need greater produc-
tivity as well as the flexibility to shape office solutions
around your specific needs. That’s why you need the Canon
imageRUNNER 3530/2830/2230 digital multifunction office
systems.
Take command of your office productivity, starting with a
standard copier configuration, and build a system to meet
your printing, scanning, faxing, and document storage needs
as your business dictates. Canon’s ImagePlatform architec-
ture ensuresconcurrent processing of each task for maxi-
mum productivity every time, for every job.
And when the imageRUNNER 3530/2830/2230 devices are
fully connected to your network, all users can leverage sys-
tem capabilities directly from their desktops through intu-
itively designed drivers–complete with finishing and paper
supply functions. All this in an extremely compact, cost-
effective system your business can count on.
Corporate Solutions
ACHIEVE MORE WITHOUT EXHAUSTING
YOUR BUDGET.
A powerful lineup of Canon multifunction office systems
that can take your business to a higher level.

PRODUCE HIGH-QUALITY DIGITAL COPIES WITH CONFIDENCE
The imageRUNNER 3530/2830/2230 models are designed
to make your documents look their best. These systems can
capture images at true 600 x 600 dpi resolution and produce
high-quality output for both text and images–equivalent to
1200 x600 dpi for copying and 2400 x 600 dpi for printing, with
256 gradations. Each model hosts a number of productivity-
enhancing copy features that save time and money. Standard
Automatic Duplexing provides two-sided printing to conserve
time and paper. Also, with Canon’s RAPID Fusing System™,
warm-up times and energy consumption costs are kept to a
minimum.
A MULTIFUNCTIONAL DELIGHT
The imageRUNNER system, when equipped with an optional
printer kit, is transformed into a productive multifunction device
that can greatly improve your workflow. As networked printers,
the imageRUNNER 3530/2830/2230 devices support Canon’s
Ultra Fast Rendering II (UFR II) technology for fast document
processing, and available support for popular PCL 5e/6 page
description languages. And with the Canon Network ScanGear
utility* you can easily integrate scanned images with your docu-
ments using TWAIN-compatible software.
Innovative Mail Box features* provide the ability to store
scanned documents and printed files directly into device
memory for later use. Each Mail Box can be customized and
password-protected for complete confidentiality.
POWERFUL DOCUMENT DISTRIBUTION
The imageRUNNER 3530/2830/2230 systems can handle all
your heavy-duty faxing needs when equipped with the optional
Super G3 Fax Board*. Time-saving features include a high-
capacity address book and auto-dialing to speed operation, as
well as PC Fax capabilities that allow you to transmit fax docu-
ments easily from a networked computer. For even greater docu-
ment distribution needs, you may configure the system with the
powerful eCopy suite* of products that link the device to your
company’s e-mail and networked enterprise applications for
secure, paperless distribution and management of data.
Make your business stand out from all the others.
A FIRST IMPRESSION ALWAYS LASTS.
UFR II Print Driver
eCopy ShareScanTM
Mail Box Main Menu
* Requires UFR II Printer Kit-E3 or UFR II/PCL Printer Kit-E2.

COMPACT, DURABLE DESIGN
The incredibly compact imageRUNNER 3530/2830/2230 models
are built to accommodate busy office environments with limited
space. High-yielding supplies and consumables keep running
costs and downtime to a minimum for top-notch efficiency. And
thanksto an easy-to-load bottle design, toner replenishment is
quickand clean.
An optional 50-sheet Duplexing Automatic Document
Feeder easily handles multiple-page originals so you can
focus on other tasks. The system handles various paper
formats, from Statement-R to Ledger, with a maximum paper
capacity of 2,250 sheets to keep your business moving. The
imageRUNNER 3530/2830/2230 devices also support a range
of output options to increase productivity, including an inno-
vative built-in finishing option that offers full sorting, sta-
pling, and optional hole-punching, without taking up any
extra space.
EASE-OF-USE
The imageRUNNER 3530/2830/2230 models are designed for
easy operation at the device through an intuitive touch-screen
panel or at a desktop using a Remote UI*(User Interface) that
allows users to control operations via their Web browser. Canon
also provides a complete set of device management and moni-
toring utilities. As an ENERGY STAR®qualified system, the
imageRUNNER 3530/2830/2230 systems are designed with the
environment in mind.
IMAGE OF A LEADER
Canon continues to set new standards for quality, performance,
and reliability. That’s why you can trust Canon to provide you
with solutions to make your business more productive and com-
petitive.
In addition to enhancing productivity, the imageRUNNER 3530/2830/2230
devices save space and reduce costs.
A SINGLE DEVICE THAT CAN
DO THE WORK OF MANY
* Requires UFR II Printer Kit-E3 or UFR II/PCL Printer Kit-E2.
Remote UI
Control Panel

imageRUNNER 2830/2230
With the ability to deliver output at 28 and 22
pages per minute, respectively, the compact
imageRUNNER 2830/2230 models are perfect
for small businesses and workgroups.
imageRUNNER 3530
At 35 pages per minute, the imageRUNNER 3530
device is an ideal solution for busier, medium-size
offices and departments within larger corporations.
Feature Standard Configuration Available with Optional
Hard Disk
Memory Capacity 256MB RAM 256MB RAM
20GB Hard Disk
Copy Standard Standard
Mail Box Optional* Standard
Network Print Optional* Standard
(UFR II or UFR II/PCL 5e/6)
Network Scan Optional* Standard
Fax Optional*†Optional†
eCopy Suite Optional* Optional
* Requires additional 20GB Hard Disk (ships with the UFR II Printer Kit-E3 and UFR II/PCL Printer Kit-E2).
† Requires the Super G3 Fax Board-Q1 with optional 20GB Hard Disk to be installed.
imageRUNNER 3530/2830/2230

MAIN UNIT
Type: Monochrome Digital, Multifunction
Imaging System
Imaging System: Laser Dry Electrostatic Transfer
Developing System: Dry Mono Component Developing System
Fixing System: RAPID Fusing System
Memory
Standard: 256MB RAM
Optional: 20GB HDD
First-Copy Time
imageRUNNER 3530: 3.9 Seconds from Platen Glass
5.9 Seconds from Feeder
imageRUNNER 2830/2230: 4.9 Seconds from Platen Glass
6.9 Seconds from Feeder
Warm-Up Time: 10 Seconds or Less from Sleep Mode
15 Seconds or Less from Main Power Off
30 Seconds or Less from Main Power Off
When Configured with Either Printer Kit
Copy/Print Speed: 35/28/22 ppm (Letter)
Max. Copy Reservation: 5 Jobs
Actual Resolution: 600 dpi x 600 dpi
Interpolated Resolution: 1200 dpi x 600 dpi (Copy)
2400 dpi x 600 dpi (Print)
Halftone: 256 Gradations of Gray
Duplexing: Standard Automatic Trayless Duplexing
Magnification Reduction/
Enlargement: 25% to 400% (Platen)
25% to 200% (Feeder)
(In 1% Increments)
Exposure Control: Automatic or Manual (9 Levels)
Paper Sources
Standard: Dual 550-Sheet Paper Cassettes
(1,100 Sheets)
Stack Bypass (50 Sheets)
Optional: Dual 550-Sheet Cassette Feeding Unit
(2,250 Sheets Max.)
Multiple Copies: 1 to 999
Paper Weights: 17 lb. to 20 lb. Bond (Cassette)
17 lb. to 32 lb. Bond (Stack Bypass)
Network Interface
Connections: 10/100 Base-TX(RJ-45)
Dimensions (H x W x D): 29-7/8" x 22-1/4" x 27-5/8"
(761mm x 565mm x 700mm)
Installation Space (W x D): 34" x 27-5/8"
Weight: 152 lb. (69kg)
Power Requirements: 120V AC, 60Hz, 10A (3570)
120V AC, 60Hz, 8A (2870/2270)
Power Consumption: 1.35kW (Max.)
Drum: Organic Photo Conductor (OPC)
Estimated Yield: 85,000 Impressions (3530)
75,000 Impressions (2830/2230)
Toner Yield: 24,000 @ 6% Coverage (3530)
21,000 @ 6% Coverage (2830/2230)
OPTIONAL ACCESSORIES
Duplexing Automatic Document Feeder-N1
Acceptable Originals: Statement to 11" x 17"
Capacity: 50 Sheets (20 lb. Bond/Letter)
Max. Paper Weight: 13 lb. to 32 lb. Bond
Cassette Feeding Unit-Y2
Paper Capacity: Dual 550-Sheet Paper Cassettes
(1,100 Sheets/20 lb. Bond)
Acceptable Paper Sizes: Statement-R to 11" x 17"
Acceptable Paper Weights: 17 lb. to 20 lb. Bond
Inner 2-Way Tray-D1*
Number of Trays: 2 Trays
Tray Capacity
Lower Output Tray: 250 Sheets (Letter)
100 Sheets (Other Sizes)
Upper Output Tray: 100 Sheets (Letter)
50 Sheets (Other Sizes)
Acceptable Paper Sizes: Statement to 11" x 17"
Attachable Accessories: Copy Tray-J1
Finisher-S1*
Number of Trays: 1 Tray (Second Tray Optional)
Tray Capacity
Non-Collate, Collate,
Group Mode: 1,000 Sheets (Letter, Statement)
Staple Mode: 1,000 Sheets/30 Sets
Tray Capacity (With Additional Finisher Tray-B1)
Non-Collate, Collate,
Group Mode: 300 Sheets per Tray (Letter,Statement)
Staple Mode: 300 Sheets/30 Sets per Tray (Letter)
150 Sheets/30 Sets (Legal, 11" x 17")
Staple Position/Size
Top Left Corner: 11" x 17" (Landscape),
Legal (Landscape), Letter, Letter-R
Top Right Corner: 11" x 17" (Portrait), Legal (Portrait)
Max. Stapling Capacity
(Up to 20 lb. Bond): 50 Sheets (Letter)
Attachable Accessories: Additional Finisher Tray-B1
Puncher Unit-R1
Copy Tray-J1
Copy Tray-J1 (option for Inner 2-Way Tray and Finisher-S1)
Tray Capacity: 150 Sheets (Letter)
75 Sheets (All Other Sizes)
Super G3 Fax Board-Q1
Applicable Line: Public Switched Telephone Network (PSTN)
Connection Lines: One
Sending/Original Sizes: Statement to 11" x 17"
(from Document Feeder)
Recording/Printing Sizes: Statement to 11" x 17"
UFR II Printer Kit-E3, UFR II/PCL Printer Kit-E2
Processor: Canon Custom Processor—Shared
RAM: 256MB—Shared
Hard Disk: 20GB—Shared
PDL Support
UFR II Printer Kit-E3: UFR II
UFR II/PCL Printer Kit-E2: UFR II/PCL
Interface Connections
Standard: 10/100 Base-TX (RJ-45), USB 2.0
High-Speed
Network OS: Windows
®
98
▲
/Me
▲
Windows 2000/XP
WindowsNT
®
4.0
▲
/Server 2003
Macintosh
®
OS 10.1.5 or Later (PPD)
Solaris™ 1.1x, 2.5x, or Later
Novell
®
NetWare
®
v3.2, 4.1, 4.11,
4.2, 5, 5.1, 6, 6.5 (IPX/SPX™)
Additional Optional Accessories and Utilities
Accessibility Handle-A1
Braille Label Kit-A1
Cabinet
Card Reader-C1
Card Sets
Document Tray-J1
eCopy Suite
Envelope Feeder Attachment-C1
imageRUNNER Security Kit-A2
Platen Cover Type H
Puncher Unit-R1
* Requires 3-way unit.
▲
UFR II not supported.
Main Unit
Cassette Feeding
Unit-Y2
Inner 2-Way
Tray-D1 Finisher-S1
Additional
Finisher Tray-B1
Cabinet
Copy Tray-J1
DADF-N1
Platen Cover Type H
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
0706R-35/28/22-PDF-LC
As an ENERGY STAR®Partner, Canon U.S.A., Inc. has determined that these products meet the
ENERGY STAR guidelines for energy efficiency. ENERGY STAR and the ENERGY STAR mark are regis-
tered U.S. marks. Windows and Windows NT are registered trademarks of Microsoft Corporation in
the United States and/or other countries. Macintosh is a registered trademark of Apple Computer,
Inc. Solaris is a trademark of Sun Microsystems, Inc. in the United States and other countries. Novell
and NetWare are registered trademarks of Novell, Inc. in the United States and other countries.
IPX/SPX is a trademark of Novell, Inc. CANON and IMAGERUNNER are registered trademarks, and
RAPID FUSING SYSTEM is a trademark of Canon Inc. in the United States and may also be registered
trademarks or trademarks in other countries. IMAGEANYWARE is a trademark of Canon. All referenced
product namesand other marks are trademarks of their respective owners.
Specifications subject to change without notice.
Machine shown with optional accessories/equipment.
©2006 Canon U.S.A., Inc. All rights reserved.
Specifications
