Canon PowerShot A2600 Service manual

Camera User Guide
English
©CANON INC. 2013 CDJ-E523-010
Switching Between Pages
Click buttons on the top of the screen.
 Contents
: return to the Contents.
Chapter Contents
: return to the Chapter Contents page.
•
Make sure you read this guide, including the “Safety Precautions”
section, before using the camera.
•
Reading this guide will help you learn to use the camera properly.
•
Store this guide safely so that you can use it in the future.

2
Contents
Package Contents
Before use, make sure the following items are included in the
package.
If anything is missing, contact your camera retailer.
Camera Wrist Strap
WS-800
Getting Started Warranty Card
Battery Pack
NB-11L
Battery Charger
CB-2LF/CB-2LFE
A2600
AA Alkaline Batteries
(x2)
A1400
•A memory card is not included.

3
Contents
Compatible Memory Cards
The following memory cards (sold separately) can be used,
regardless of capacity.
• SD memory cards*
• SDHC memory cards*
• SDXC memory cards*
• Eye-Fi cards
* Cards conforming to SD standards. However, not all memory cards have
beenveriedtoworkwiththecamera.
About Eye-Fi Cards
This product is not guaranteed to support Eye-Fi card functions
(including wireless transfer). In case of an issue with an Eye-Fi
card, please check with the card manufacturer.
Also note that an approval is required to use Eye-Fi cards in many
countries or regions. Without approval, use of the card is not
permitted. If it is unclear whether the card has been approved for
use in the area, please check with the card manufacturer.

4
Contents
Preliminary Notes and Legal
Information
• Take and review some test shots initially to make sure the
images were recorded correctly. Please note that Canon Inc., its
subsidiariesandafliates,anditsdistributorsarenotliablefor
any consequential damages arising from any malfunction of a
camera or accessory, including memory cards, that result in the
failure of an image to be recorded or to be recorded in a way
that is machine readable.
• Images recorded by the camera are intended for personal use.
Refrain from unauthorized recording that infringes on copyright
law, and note that even for personal use, photography may
contravene copyright or other legal rights at some performances
or exhibitions, or in some commercial settings.
• The camera warranty is valid only in the area of purchase. In
case of camera problems while abroad, return to the area of
purchase before contacting a Canon Customer Support Help
Desk.
• Although the LCD monitor is produced under extremely high-
precision manufacturing conditions and more than 99.99% of
thepixelsmeetdesignspecications,inrarecasessomepixels
may be defective or may appear as red or black dots. This does
not indicate camera damage or affect recorded images.
• TheLCDmonitormaybecoveredwithathinplasticlmfor
protection against scratches during shipment. If covered,
removethelmbeforeusingthecamera.
• When the camera is used over an extended period, it may
become warm. This does not indicate damage.

5
Contents
Part Names and Conventions in
This Guide
A2600
Speaker
Zoom lever
Shooting:<
i
(telephoto)>/
< j (wide angle)>
Playback:< k (magnify)>/ < g (index)>
Lens
Shutter button
Lamp
Power button
Microphone
Flash
Tripod socket
Memory card/battery cover
Indicator
DC coupler cable port
Strap mount
AV OUT (Audio/video output) /
DIGITAL terminal
Screen (LCD monitor)
Movie button
<A(Auto)> / < a (Single-
image erase)> / Up button
< > / Left button
<1(Playback)> button
< (Help)> button
FUNC./SET button
<h(Flash)> / Right button
<l(Display)> / Down button
<n> button

6
Contents
A1400
Zoom lever
Shooting:<
i (telephoto)>/
<
j
(wide angle)>
Playback:< k
(magnify)>/<
g
(index)>
Lamp
Microphone
Lens
Shutter button
Power button
Flash
Tripod socket
Memory card/battery cover
DC coupler cable port
Strap mount
AV OUT (Audio/video output) /
DIGITAL terminal
Screen (LCD monitor)
Movie button
<A(Auto)> / < a (Single-
image erase)> / Up button
< > / Left button
<1(Playback)> button
< (Help)> button
FUNC./SET button
<h(Flash)> / Right button
<l(Display)> / Down button
<n> button
Speaker
 Viewnder
Indicator

7
Contents
• In this guide, icons are used to represent the corresponding
camera buttons on which they appear, or which they resemble.
• The following camera buttons and controls are represented by
icons.
<o> Up button on back
<q> Left button on back
<r> Right button on back
<p> Down button on back
• Shooting modes and on-screen icons and text are indicated in
brackets.
• : Important information you should know
• : Notes and tips for expert camera use
• =xx: Pages with related information (in this example, “xx”
represents a page number)
• Instructions in this guide apply to the camera under default
settings.
• For convenience, all supported memory cards are simply
referred to as the “memory card”.
• The tabs shown above titles indicate whether the function is
used for still images, movies, or both.
Still Images : Indicates that the function is used when
shooting or viewing still images.
Movies : Indicates that the function is used when
shooting or viewing movies.
• The following icons are used to indicate functions that differ
depending on the camera model:
A2600
: Functions and precautions for the PowerShot A2600 only
A1400
: Functions and precautions for the PowerShot A1400 only
• This guide uses PowerShot A2600 illustrations and screenshots
for all explanations.

8
Contents
Table of Contents
Package Contents .................2
Compatible Memory Cards ....3
Preliminary Notes and Legal
Information.............................4
Part Names and Conventions in
This Guide..............................5
Table of Contents...................8
Contents: Basic
Operations ...........................10
Safety Precautions...............12
Basic Guide.............. 17
Initial Preparations ...............18
Trying the Camera Out ........30
Using the Software ..............37
System Map.........................45
Advanced Guide....... 47
1 Camera Basics............. 47
On/Off ..................................48
Shutter Button......................50
OpticalViewnder................51
Shooting Display Options ....52
FUNC. Menu........................53
MENU Menu ........................55
Indicator Display ..................57
2 Smart Auto Mode......... 58
Shooting (Smart Auto) .........59
Common, Convenient
Features...............................69
Image Customization
Features...............................77
Helpful Shooting Features ...80
Customizing Camera
Operation .............................81
3 Other Shooting
Modes ........................... 82
SpecicScenes ...................83
Applying Special Effects ......87
Special Modes for Other
Purposes..............................93
4 P Mode.......................... 96
Shooting in Program AE
(<P> Mode)..........................97
Image Brightness
(Exposure Compensation) ...98
Color and Continuous
Shooting.............................103
Shooting Range and
Focusing ............................106
Flash .................................. 114
Using Eco Mode ................ 116
Other Settings.................... 117

9
Contents
5 Playback Mode .......... 122
Viewing ..............................123
Browsing and Filtering
Images ...............................126
Image Viewing Options......129
Protecting Images..............132
Erasing Images..................135
Rotating Images.................138
Editing Still Images ............141
6 Setting Menu.............. 146
Adjusting Basic Camera
Functions ...........................147
7 Accessories ............... 159
Optional Accessories .........160
Using Optional
Accessories........................164
Printing Images..................170
Using an Eye-Fi Card.........186
8 Appendix .................... 189
Troubleshooting .................190
On-Screen Messages ........196
On-Screen Information ......199
Functions and Menu
Tables.................................203
Handling Precautions.........215
Specications.....................216
Index ..................................222

10
Contents
Contents: Basic Operations
4 Shoot
 Use camera-determined settings (Auto Mode) ..................... 59
Shooting people well
I
Portraits
(=
83)
P
Against Snow
(=
84)
Matchingspecicscenes
Low Light
(=
83)
t
Fireworks
(=
84)
Applying special effects
Vivid Colors
(=
87)
Poster Effect
(=
87)
Fish-Eye Effect
(=
88)
Miniature Effect
(=
89)
Toy Camera Effect
(=
91)
Monochrome
(=
92)

11
Contents
 While adjusting image settings (Live View Control) .............. 85
 Focus on faces........................................................ 59, 83, 108
 Withoutusingtheash(FlashOff)........................................ 74
 Include yourself in the shot (Self-Timer) ......................... 71, 93
 Add a date stamp.................................................................. 75
1 View
 View images (Playback Mode)............................................ 123
 Automatic playback (Slideshow) ......................................... 130
 On a TV............................................................................... 164
 On a computer ...................................................................... 38
 Browse through images quickly .................................. 126, 127
 Erase images ...................................................................... 135
E Shoot/View Movies
 Shoot movies ........................................................................ 59
 View movies (Playback Mode)............................................ 123
c Print
 Print pictures ....................................................................... 170
Save
 Save images to a computer .................................................. 42

12
Contents
Safety Precautions
• Before using the product, please ensure that you read the safety
precautions described below. Always ensure that the product is
used correctly.
• The safety precautions noted on the following pages are
intended to prevent injuries to yourself and other persons, or
damage to the equipment.
• Be sure to also check the guides included with any separately
sold accessories you use.
Warning
Denotes the possibility of serious injury or death.
• Donottriggertheashincloseproximitytopeople’seyes.
Exposuretotheintenselightproducedbytheashcoulddamage
eyesight. In particular, remain at least 1 meter (39 inches) away
frominfantswhenusingtheash.
•
Store this equipment out of the reach of children and infants.
Strap: Putting the strap around a child’s neck could result in
asphyxiation.
• Use only recommended power sources.
•
Do not attempt to disassemble, alter or apply heat to the product.
• Avoid dropping or subjecting the product to severe impacts.
• To avoid the risk of injury, do not touch the interior of the
product if it has been dropped or otherwise damaged.
• Stop using the product immediately if it emits smoke, a
strange smell, or otherwise behaves abnormally.
• Do not use organic solvents such as alcohol, benzine, or
thinner to clean the product.
• Do not let the product come into contact with water (e.g. sea
water) or other liquids.

13
Contents
• Do not allow liquids or foreign objects to enter the camera.
Thiscouldresultinelectricalshockorre.
If liquids or foreign objects come into contact with the camera
interior, immediately turn the camera off and remove the battery/
batteries.
A2600
If the battery charger becomes wet, unplug it from the outlet and
consult your camera retailer or a Canon Customer Support Help
Desk.
A1400
• Donotlookthroughtheviewnderatbrightlightsources
(such as the sun on a clear day).
This could damage your eyesight.
• Use only the recommended battery/batteries.
• Donotplacethebattery/batteriesnearorindirectame.
A2600
• Unplug the power cord periodically, and using a dry cloth,
wipe away any dust and dirt that has collected on the plug,
the exterior of the power outlet, and the surrounding area.
• Do not handle the power cord with wet hands.
• Do not use the equipment in a manner that exceeds the rated
capacity of the electrical outlet or wiring accessories. Do
not use if the power cord or plug are damaged, or not fully
plugged into the outlet.
• Do not allow dirt or metal objects (such as pins or keys) to
contact the terminals or plug.
The battery/batteries may explode or leak, resulting in
electricalshockorre.Thiscouldcauseinjuryanddamagethe
surroundings. In the event that a battery leaks and the battery
electrolyte contacts eyes, mouth, skin or clothing, immediately
ushwithwater.

14
Contents
• Turn the camera off in places where camera use is prohibited.
The electromagnetic waves emitted by the camera may interfere
with the operation of electronic instruments and other devices.
Exercise adequate caution when using the camera in places
where use of electronic devices is restricted, such as inside
airplanes and medical facilities.
Caution
Denotes the possibility of injury.
• When holding the camera by the strap, be careful not to
bang it, subject it to strong impacts or shocks, or let it get
caught on other objects.
• Be careful not to bump or push strongly on the lens.
This could lead to injury or damage the camera.
• Be careful not to subject the screen to strong impacts.
If the screen cracks, injury may result from the broken fragments.
• Whenusingtheash,becarefulnottocoveritwithyour
ngersorclothing.
Thiscouldresultinburnsordamagetotheash.
• Avoid using, placing or storing the product in the following
places:
- Places subject to direct sunlight
- Places subject to temperatures above 40 °C (104 °F)
- Humid or dusty areas
These could cause leakage, overheating or an explosion of the
battery/batteries,resultinginelectricalshock,re,burnsorother
injuries.
High temperatures may cause deformation of the camera or
battery charger casing.

15
Contents
Caution
Denotes the possibility of damage to the equipment.
• Do not aim the camera at bright light sources (such as the
sun on a clear day).
Doing so may damage the image sensor.
• When using the camera on a beach or at a windy location,
be careful not to allow dust or sand to enter the camera.
This may cause the product to malfunction.
• In regular use, small amounts of smoke may be emitted
fromtheash.
Thisisduetothehighintensityoftheashburningdustand
foreign materials stuck to the front of the unit. Please use a cotton
swabtoremovedirt,dustorotherforeignmatterfromtheashto
prevent heat build-up and damage to the unit.
• Remove and store the battery/batteries when you are not
using the camera.
If the battery or batteries are left inside the camera, damage
caused by leakage may occur.
• Before you discard the battery/batteries, cover the terminals
with tape or other insulators.
Contactingothermetalmaterialsmayleadtoreorexplosions.
A2600
• Unplug the battery charger from the power outlet after
charging is complete, or when you are not using it.
• Do not place anything, such as cloth, on top of the battery
charger while it is charging.
Leaving the unit plugged in for a long period of time may cause it
tooverheatanddistort,resultinginre.

16
Contents
A2600
• Do not place the battery near pets.
Pets biting the battery could cause leakage, overheating or
explosion,resultinginreordamage.
A1400
• Do not charge batteries of different types at the same time,
or use older batteries together with newer batteries.
• Do not insert the batteries with the + and – terminals reversed.
This may cause the product to malfunction.
• Do not sit down with the camera in your pocket.
Doing so may cause malfunctions or damage the screen.
• When putting the camera in your bag, ensure that hard
objects do not come into contact with the screen.
• Do not attach any hard objects to the camera.
Doing so may cause malfunctions or damage the screen.

Contents
17
Gives basic instructions, from initial preparations
to shooting, playback, and saving on a computer
Basic Guide
Initial Preparations .............18
Trying the Camera Out .......30
Using the Software.............37
System Map.........................45

18
Contents Chapter Contents
Initial Preparations
Prepare for shooting as follows.
Attaching the Strap
 Thread the end of the strap
through the strap hole ( ), and
then pull the other end of the
strap through the loop on the
threaded end ( ).
Holding the Camera
 Place the strap around your
wrist.
 When shooting, keep your arms
close to your body and hold the
camera securely to prevent it
from moving. Do not rest your
ngersontheash.

19
Contents Chapter Contents
A2600
Charging the Battery
Before use, charge the battery with the included charger. Be sure
to charge the battery initially, because the camera is not sold with
the battery charged.
1Insert the battery.
 After aligning the marks on
the battery and charger, insert
the battery by pushing it in ( )
and down ( ).
2Charge the battery.
 CB-2LF: Flip out the plug
() and plug the charger into a
power outlet ( ).
 CB-2LFE: Plug the power cord
into the charger, then plug the
other end into a power outlet.
 The charging lamp turns orange
and charging begins.
 Whenchargingisnished,the
lamp turns green.
3Remove the battery.
 After unplugging the battery
charger, remove the battery by
pushing it in ( ) and up ( ).
CB-2LF
CB-2LFE

20
Contents Chapter Contents
• To protect the battery and keep it in optimal condition, do
not charge it continuously for more than 24 hours.
• For battery chargers that use a power cord, do not attach
the charger or cord to other objects. Doing so could result
in malfunction or damage to the product.
• For details on charging time and the number of shots and recording
time possible with a fully charged battery, see “Number of Shots/
Recording Time, Playback Time” (=
217).
• Charged batteries gradually lose their charge, even when they are
not used. Charge the battery on (or immediately before) the day of
use.
• The charger can be used in areas with 100 – 240 V AC power
(50/60 Hz). For power outlets in a different format, use a
commercially available adapter for the plug. Never use an electrical
transformer designed for traveling, which may damage the battery.
