Camera User Guide
Advanced
DIGITAL CAMERA Advanced Camera User Guide
This guide explains camera features and procedures in detail.
CDI-E211-010 © 2006 CANON INC.
ENGLISH
PRINTED IN CHINA
Before Using the Camera
Shooting
Playback/Erasing
Print/Transfer Settings
Customizing the Camera
Appendix
Troubleshooting
Shooting/Viewing Images on a TV Set
List of Messages

Main Features
This guide uses illustrations of the PowerShot A430.
Playback
zPlays movies ( with audio)
zAuto Play
Editing
zEdits movies
zRecords sound memos for
still images.
Printing
zMakes printing easy with the Print/Share button
z
Also supports non-Canon brand PictBridge
compliant printers
Uses of Recorded Images
zEffortlessly transfer them to a computer with the Print/
Share button
Shooting
zAutomatically adjusts
shooting settings to match
particular conditions
(Special Scene mode)
zChanges image colors to
create special effects
(Color Accent, Color Swap
modes)
z
Automatically detects
camera orientation with an
Intelligent Orientation sensor
.

1
Conventions Used in this Guide
Icons appearing below titles indicate the modes in which the
procedure can be used. In the example below, the mode dial can
be used in the following shooting modes.
•(Manual) •(Special Scene)
•* (Manual) •* (Super Macro)
•* (Color Accent) •* (Color Swap)
* Black square icons are modes in the FUNC. menu.
•See Functions Available in Each Shooting Mode (p. 112).
In this guide, the Basic Camera User Guide is referred to as the
Basic Guide, and the Advanced Camera User Guide is referred to
as the Advanced Guide.
Switching between Focusing Modes
Shooting Mode
This mark denotes issues that may affect the camera’s operation.
This mark denotes additional topics that complement the basic
operating procedures.
This icon appears for functions and notes that apply only to the
PowerShot A430.
You can use SD* memory cards and MultiMediaCards with this camera.
These cards are collectively called memory cards in this guide.
* SD stands for Secure Digital, a copyright protection system.
Use of genuine Canon accessories is recommended.
This product is designed to achieve excellent performance when
used with genuine Canon accessories. Canon shall not be liable
for any damage to this product and/or accidents such as fire, etc.,
caused by the malfunction of non-genuine Canon accessories
(e.g., a leakage and/or explosion of a battery pack). Please note
that this warranty does not apply to repairs arising out of the
malfunction of non-genuine Canon accessories, although you
may request such repairs on a chargeable basis.

2
Table of Contents
Items marked with a are lists or charts that summarize camera
functions or procedures.
Please Read. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Preventing Malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using the LCD Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Information Displayed on the LCD Monitor . . . . . . . . . . . . . . 16
Using the Viewfinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Power Saving Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Menus and Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Menu List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Resetting Settings to Their Default Values. . . . . . . . . . . . . . . 28
Formatting Memory Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Changing the Recording Pixels and Compression (Still Images) 30
Magnified Close-Up Shooting (Super Macro). . . . . . . . . . . . . 31
Using the Digital Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Continuous Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Postcard Date Imprint Mode. . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using the Self-Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Movie Shooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Shooting Panoramic Images (Stitch Assist) . . . . . . . . . . . . . . . . 40
Changing the Colors and Shooting . . . . . . . . . . . . . . . . . . . . 42
Switching between Focusing Modes . . . . . . . . . . . . . . . . . . . 46
Shooting Hard-to-Focus Subjects (Focus Lock). . . . . . . . . . . 47
Switching between Metering Modes. . . . . . . . . . . . . . . . . . . . 47
Adjusting the Exposure Compensation . . . . . . . . . . . . . . . . . 48
Adjusting the Tone (White Balance) . . . . . . . . . . . . . . . . . . . . . 49
Conventions Used in this Guide . . . . . . . . . . . . . . . . . . . . . . .1
Handling Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Before Using the Camera—The Components Guide . . . . . .12
Before Using the Camera—Basic Operations . . . . . . . . . . .15
Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

3
Shooting in a My Colors Mode . . . . . . . . . . . . . . . . . . . . . . . . .51
Adjusting the ISO Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Setting the Auto Rotate Function . . . . . . . . . . . . . . . . . . .54
Creating an Image Destination (Folder) . . . . . . . . . . . . . . . . .55
Resetting the File Number . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Magnifying Images. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Viewing Images in Sets of Nine (Index Playback) . . . . . . . . . . . .59
Viewing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Editing Movies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Rotating Images in the Display . . . . . . . . . . . . . . . . . . . . . . . .62
Attaching Sound Memos to Images. . . . . . . . . . . . . . . .62
Automated Playback (Auto Play) . . . . . . . . . . . . . . . . . . . . . .64
Protecting Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Erasing All Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Setting the DPOF Print Settings . . . . . . . . . . . . . . . . . . . . . . .66
Setting the DPOF Transfer Settings . . . . . . . . . . . . . . . . . . . .69
Changing My Camera Settings . . . . . . . . . . . . . . . . . . . . . . . . .72
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
When the power is turned on . . . . . . . . . . . . . . . . . . . . . . . . .74
LCD monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Shooting Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
TV monitor output . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
Direct print compatible printers . . . . . . . . . . . . . . . . . . . . . . . .81
Playback/Erasing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Print Settings/Transfer Settings. . . . . . . . . . . . . . . . . . . . . . 66
Shooting/Viewing Images on a TV set . . . . . . . . . . . . 71
Customizing the Camera (My Camera Settings) . . . . 72
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
List of Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

4
Battery Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Handling the Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Replacing the Date Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Using an AC Adapter Kit (Sold Separately) . . . . . . . . . . . . . . 90
Using Rechargeable Batteries (Sold Separately) . . . . . . . . . 91
Using an Externally Mounted Flash (Sold Separately). . . . . . 93
Camera Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . 95
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
INDEX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Functions Available in Each Shooting Mode . . . . . . . . . . .112

5
Handling Precautions
Test Shots
Before you try to photograph important subjects, we highly
recommend that you shoot several trial images to confirm that the
camera is operating and being operated correctly.
Please note that Canon Inc., its subsidiaries and affiliates, and its
distributors are not liable for any consequential damages arising
from any malfunction of a camera or accessory, including memory
cards, that results in the failure of an image to be recorded or to be
recorded in a way that is machine readable.
Warning Against Copyright Infringement
Please note that Canon digital cameras are intended for personal
use and should never be used in a manner that infringes upon or
contravenes international or domestic copyright laws and
regulations. Please be advised that in certain cases the copying of
images from performances, exhibitions, or commercial properties
by means of a camera or other device may contravene copyright or
other legal rights even if the image was shot for personal use.
Warranty Limitations
This camera’s warranty is only effective in the country of sale. If a
problem arises while the camera is in use abroad, please convey it
back to the country of sale before proceeding with a warranty claim
to a Canon Customer Support Help Desk.
For Canon Customer Support contacts, please see the Canon
Limited Warranty supplied with your camera.
Please Read

6
Language Setting
Please see the Basic Guide (p. 3) to change the language setting.
zBefore using the camera, please ensure that you read and
understand the safety precautions described below. Always
ensure that the camera is operated correctly.
zThe safety precautions noted on the following pages are intended
to instruct you in the safe and correct operation of the camera and
its accessories to prevent injuries or damage to yourself, other
persons and equipment.
zEquipment refers to the camera, battery, battery charger or
separately sold compact power adapter.
Camera Body Temperature
If your camera is used for prolonged periods, the camera body
may become warm. Please be aware of this and take care when
operating the camera for an extended period.
About the LCD Monitor
The LCD monitor is produced with extremely high-precision
manufacturing techniques. More than 99.99% of the pixels
operate to specification. Less than 0.01% of the pixels may
occasionally misfire or appear as red or black dots. This has no
effect on the recorded image and does not constitute a
malfunction.
Safety Precautions

7
Warnings
Equipment
zDo not aim the camera directly into the sun or at other
intense light sources that could damage your eyesight.
z
Store this equipment out of the reach of children and infants.
Accidental damage by a child could result in serious injury.
• Wrist strap: Placement of the strap around the child's neck could
result in asphyxiation.
• Memory card: It may be swallowed accidentally. If this occurs,
contact a doctor immediately.
zDo not attempt to disassemble or alter any part of the
equipment that is not expressly described in this guide.
z
To avoid the risk of high-voltage electrical shock, do not
touch the flash portion of the camera if it has been damaged.
zStop operating the equipment immediately if it emits smoke
or noxious fumes.
zDo not allow the equipment to come into contact with, or
become immersed in, water or other liquids. If the exterior
comes into contact with liquids or salt air, wipe it dry with a
soft, absorbent cloth.
Continued use of the equipment may result in fire or electrical
shock. Immediately turn the camera power off and remove the
camera battery or unplug the power cord from the power outlet.
Please consult your camera distributor or the closest Canon
Customer Support Help Desk.
zDo not use substances containing alcohol, benzine,
thinners or other flammable substances to clean or
maintain the equipment.
z
Do not cut, damage, alter or place heavy items on the power cord.
zUse only recommended power accessories.
zRemove the power cord on a regular periodic basis and
wipe away the dust and dirt that collects on the plug, the
exterior of the power outlet and the surrounding area.
zDo not handle the power cord if your hands are wet.
Continued use of the equipment may result in fire or electrical
shock.

8
Battery
zDo not place the battery near a heat source or expose it to
direct flame or heat.
zThe battery should not be immersed in water or sea water.
zDo not attempt to disassemble, alter or apply heat to the
battery.
zAvoid dropping or subjecting the batteries to severe
impacts that could damage the casing.
zUse only recommended batteries and accessories.
Use of batteries not expressly recommended for this equipment
may cause explosions or leaks, resulting in fire, injury and
damage to the surroundings. In the event that a battery leaks and
the eyes, mouth, skin or clothing contact these substances,
immediately flush with water and seek medical assistance.
zDisconnect the battery charger and compact power adapter
from both the camera and the power outlet after recharging
or when they are not in use to avoid fire and other hazards.
zDo not place anything, such as tablecloths, carpets,
bedding or cushions, on top of the battery charger while it
is charging.
Continued use over a long period may cause the units to overheat
and distort, resulting in fire.
zPlease use Canon AA-size NiMH batteries and charger
recommended for use with these batteries.
zThe compact power adapter are designed for exclusive use
with your camera. Do not use it with other products or
batteries.
There is a risk of overheating and distortion which could result in
fire or electrical shock.
zBefore you discard a battery, cover the terminals with tape
or other insulators to prevent direct contact with other
objects.
Contact with the metallic components of other materials in waste
containers may lead to fire or explosions.

9
Others
zDo not trigger the flash in close proximity to human or
animal eyes. Exposure to the intense light produced by the
flash may damage eyesight.
In particular, remain at least one meter (39 inches) away from
infants when using the flash.
zKeep objects that are sensitive to magnetic fields (such as
credit cards) away from the speaker of the camera
(PowerShot A430 only).
Such items may lose data or stop working.

10
Cautions
Equipment
zBe careful not to bang the camera or subject it to strong
impacts or shocks that could lead to injury or damage the
equipment when wearing or holding it by the strap.
zDo not store the equipment in humid or dusty areas.
zDo not allow metal objects (such as pins or keys) or dirt to
contact the charger terminals or plug.
Such conditions could lead to fire, electrical shock or other
damage.
zAvoid using, placing or storing the equipment in places
subject to strong sunlight or high temperatures, such as the
dashboard or trunk (boot) of a car.
zEnsure that the battery charger is plugged into a power
outlet of the specified rating, not over the specified rating.
Do not use if the power cord or plug are damaged, or if not
fully plugged into the outlet.
zDo not use in locations with poor ventilation.
The above-mentioned can cause leakage, overheating or
explosion, resulting in fire, burns or other injuries. High
temperatures may also cause deformation of the casing.
zWhen not using the camera for extended periods of time,
remove the battery from the camera or battery charger and
store the equipment in a safe place.
Storing the camera for extended periods with batteries installed
will cause battery leakage and damage the camera.
Flash
zDo not operate the flash with dirt, dust or other items stuck
to the surface of the flash.
zBe careful not to cover the flash with your fingers or
clothing when shooting.
The flash may be damaged and emit smoke or noise. The
resulting heat build-up could damage the flash.
zDo not touch the surface of the flash after taking several
pictures in rapid succession.
Doing so could result in burns.

11
Preventing Malfunctions
Avoid Strong Magnetic Fields
zNever place the camera in close proximity to electric motors
or other equipment generating strong electromagnetic
fields.
Exposure to strong magnetic fields may cause malfunctions or
corrupt image data.
Avoid Condensation Related Problems
zWhen moving the equipment rapidly between hot and cold
temperatures, you can avoid condensation by placing the
equipment in an airtight, resealable plastic bag and letting it
adjust to temperature changes slowly before removing it
from the bag.
Moving the equipment rapidly between hot and cold temperatures
may cause condensation (water droplets) to form on its external
and internal surfaces.
If Condensation Forms Inside the Camera
zStop using the camera immediately.
Continued use may damage the equipment. Remove the memory
card and battery or compact power adapter from the camera and
wait until the moisture evaporates completely before resuming
use.

12
Before Using the Camera—The Components Guide
Front View
Power Button (Basic Guide p. 2)
Shutter Button (Basic Guide p. 4)
Speaker
Flash (Basic Guide p. 8)
Microphone (p. 62)
Viewfinder Window (p. 19)
A/V OUT (Audio/Video output) Terminal (p. 71)
Wrist Strap Mount
AF-assist Beam (p. 24)
Red-Eye Reduction Lamp (Basic Guide p. 8)
Self-Timer Lamp (p. 35)
Lens
Attaching the Wrist Strap

13
Before Using the Camera—The Components Guide
Back View
LCD Monitor (p. 15)
Viewfinder (p. 19)
DIGITAL Terminal (Basic Guide p. 17)
DC Coupler Terminal (p. 90)
Terminal Cover
Coin Battery Holder (p. 89)
Tripod Socket
Memory Card Slot/Battery Cover (Basic Guide p. 1)

14
Operation Panel
Indicator (p. 19)
DISP. (Display) Button (p. 15)
Mode Dial (Basic Guide p. 5)
MENU Button (p. 22)
FUNC./SET (Function/Set) Button (p. 21)
(Print/Share) Button (Basic Guide p. 13)
(Telephoto) (when shooting)/ (Magnify) (when playing)/
Sbutton (Basic Guide p. 8/pp. 32, 58)
(Macro)/ (Infinity)/ Wbutton (Basic Guide p. 9)
(Flash)/ Xbutton (Basic Guide p. 8)
(Wide Angle) (when shooting)/ (Single Image Erase)
(when playing)/ Tbutton (Basic Guide pp. 8, 10, p. 32)

15
Before Using the Camera—Basic Operations
Before Using the Camera—Basic Operations
zThe LCD monitor on or off setting is remembered even after
the camera power is turned off.
zThe LCD monitor does not shut off in the (Super Macro),
(Color Accent), (Color Swap), (Stitch Assist) or
(Movie) mode.
zThe LCD monitor will not switch to the detailed display in
the index playback mode (p. 59).
LCD Monitor Brightness
The brightness of the LCD monitor can be adjusted to better suit the
shooting conditions.
You can change the brightness of the LCD monitor using the Set up
menu (p. 25).
Night Display
When shooting in dark conditions, the camera automatically
brightens the LCD monitor to suit the brightness of the subject*,
making it easier to frame the subject.
* The movements of the subject will appear irregular in the LCD monitor. The
recorded image, however, will not be affected. The brightness of the image
displayed in the monitor, and the brightness of the actual image recorded
will be different.
Using the LCD Monitor
1Press the DISP. button.
zThe display mode changes as follows with each press.
z
In the shooting modes, the shooting information displays for
approximately 6 sec. when changing modes, or when the or
/ button is pressed, regardless of the selected display mode.
Shooting Mode Playback Mode
( , , or ) ( )
Standard Standard
(No Information)
Detailed Detailed
(Information View)
Off No Information

16
Shooting mode
* Appears even if the LCD monitor is set to Standard (No Information)
Information Displayed on the LCD Monitor
Exposure Compensation (p. 48)
Shooting Method (pp. 33, 35)
Recording Pixels (p. 30)
Low Battery (p. 85)
Macro/Infinity (Basic Guide p. 9)
Shooting Mode (Basic Guide
p. 5/pp. 31, 37, 40, 51)
Spot Frame
Camera Shake Warning (p. 74)
*
(Red)
Movie Recording (p. 37)
*
Zoom Magnification (p. 32)*
• Stills: Recordable Shots
• Movies: Remaining Time/
Elapsed Time
*
*
Flash (Basic Guide p. 8)
AF Frame (p. 46)
Recording Pixels/
Frame Rate (Movie) (p. 39)
My Colors (p. 51)
*
White Balance
(p. 49)
Grid Lines* (p. 24)
*
**
ISO Speed (p. 53)
Folder Creation (p. 55)
Auto Rotate (p. 54)
Compression (p. 30)
*
*

17
Before Using the Camera—Basic Operations
zIf the indicator blinks orange and the camera shake icon
displays, it may indicate slow shutter speed due to
insufficient lighting. Increase the ISO speed (p. 53), select a
setting other than (Flash off), or attach the camera to a
tripod or other device.
zDuring shooting, you can display a grid to help you
determine if your camera is level (p. 24).
Playback Mode
Standard
Protection Status (p. 64)
Folder Number-File Number
Shooting Date/Time
Displayed image number
Total number of images
Recording Pixels (Still image) (p. 30)
Movie (p. 37)
WAVE Format Sound (p. 18)
Compression (Still image) (p. 30)

18
Detailed
The following information may also be displayed with some images.
Information for images shot on other cameras may not display
correctly.
A sound file in a format other than the WAVE format is attached, or the
file format is not recognized.
JPEG image not conforming to Design rule for Camera File System
Standards
RAW image
Unrecognized data type
Exposure Compensation (p. 48)
White Balance (p. 49)
ISO Speed (p. 53)
Recording Pixels/
Frame Rate (Movies) (p. 39)
Flash (Basic Guide p. 8)
Metering Mode (p. 47)
My Colors (p. 51)
Shooting Mode (Basic Guide p. 6/
pp. 31, 37, 40, 51)
Macro/Infinity (Basic Guide p. 9)
Recording Time (Movie) (p. 37)
