Canon F-1 User manual

CODE #
C12-0751-881
C12-0751-861
C12-0751-841
C12-0751-211
Specifications
ITEM
Canon New F-1 inclIEye-Level
Finder FN, Focusing Screen
FN-PE w/lens FD 50mm 11.8
Canon New F-1 incl/Eye-Level
Finder FN, Focusing Screen
FN-PE w/lens FD 50mm 11.4
Canon New F-1 incllEye-Level
Finder FN, Focusing Screen
FN-PE w/lens FD 50mm 11 .2
Canon New F-1 incl/Eye-Level
Finder FN, Focusing Screen
FN-PE body only
Type: 35mm single-lens reflex camera with a metal focal plane
shutter.
Format: 24 x 36mm
Exposure Modes: Match-needle and stopped-down (fixed-'index)
manual exposure; aperture-priority AE or stopped-down AE
with AE Finder FN; shutter priority AE with AE Motor Drive FN
or AE Power Winder FN; AE flash photography with Canon
dedicated Speedlites. .
Usable Lenses: FD lenses: full aperture or stopped-down meter-
ing
coupled with automatic diaphragm; FL lenses: stopped-
down metering .
Lens Mount: Canon breech-lock mount
Viewfinder: Removable Eye-Level Finder FN or AE Finder FN ,
with hot shoe. Interchangeable with Speed Finder FN, Waist
Level Finder FN and Waist Level Finder FN-6X.
Field-of-View: 97% vert. and 97% hor. of actual picture area; 0.8
magnification at infinity with standard 50mm lens.
Finder Information: To the right, outside finder field, information
applicable for manual mode: aperture scale in full f/stops
with meter needle and follow-up aperture needle linked to
shutter and aperture
controls (either of which pre-selected
and setting control altered to match the needles); under- and
overexposure warnings;
stopped-down/battery check index
mark;
selected shutter speed below the scale. In shutter
priority
AE using AE Motor Drive FN or AE Power Winder FN ,
follow-up aperture needle stays outside the aperture scale. In
aperture priority and stopped-down AE using AE Finder FN ,
finder information moves from the right to directly below the
screen; shutter speed
scale with indicator needle, and aper-
ture
direct read out window (using the new FD lenses) to the
right of the scale appear.
Mirror: Instant return with shock absorber.
Focusing Screens: Camera equipped with Eye-Level Finder FN:
C12-0752-861
C12-0752-841
Canon New F-1 inci/AE Finder
FN, Focusing Screen FN-AE
w/lens FD 50mm 11.8
Canon New F-1 incl/AE Finder
FN, Focusing Screen FN-AE
w/lens FD 50mm 11.4
Canon New F-1 incl/AE Finder
FN, Focusing Screen FN-AE
w/lens FD 50mm 11.2
Canon New F-1 incl/AE Finder
FN , Focusing Screen FN-AE
body only
Supplied with Focusing Screen E (new split-image range-
finder with a
microprism collar) for selective area metering.
Camera equipped with AE Finder FN: Supplied with Focusing
Screen E for center-weighted average metering. Twelve other
types for both selective area metering and center-weighted
average metering user-interchangeable . Six types (including
type E) user-intercha ngeable for 3 degree spot metering.
Dioptric Adjustment: Built-in eyepiece adjusted to standard
-1.0 diopter. I nterchangeable with ten other strengths.
Shutter: Metal titanium focal plane shutter with speeds electron-
ically controlled (electro-magnetic shutter release) from 8 to
1/60 sec. and mechanically controlled (mechanical shutter
release) from
1/125 to 1/2000 sec., B, and X (flash) syn-
chronization at 1/90 sec. In aperture-priority AE, speeds from
8 to 1/1
OOOsec. usable and electronically controlled. X (flash
sync
and B mechanically controlled . With battery removal in
manual and shutter priority AE, back-up mechanical shutter
for
B, X (flash) sync and speeds from 1/125 to 1/2000 sec.
usable.
Shutter Dial: Adjacent to film transport lever; B, 7 (X sync), 8 to
1/2000 sec. and A (setting for aperture-priority AE with AE
Finder FN)
Self-Timer: Electronically controlled for a 10 sec. delay. Elec-
tronic
"beep-beep" sound to indicate operation; shorter
"beep-beep" intervals .two sec. before shutter release. Can-
ce11.ation possible by pressing battery check button.
Meter Coupling Range: EV -1 (4 sec. at f/14) to EV 20 (1 / 2000
sec. at f/22) with ASA/ISO:100/21 0 film and FD 50mm f/14
lens in manual and snutter priority AE modes. In aperture
priority
AE, EV -1 to EV19 (1/1000 sec. at f/22) with the same
film speed and
f/14 lens.
Auto Exposure Compensation (in all modes): Range of ±2
f/stops compensation, with calibration in 1/3 stops.
SG1-A1

SELLING POINTS
The new F-1 is Canon's top-of-the-line
professional camera. It
is introduced
as the successor to the original F-1
which, since its introduction in 1971,
has become the mainstay system
camera for growing numbers of profes-
sional photographers in all fields.
Continuing the unmatched tradition of
durability and reliability established
by its predecessor, the new
F-1 will
function perfectly for a minimum of
100,000 exposures. It has successfully
undergone a demanding series of
vibration, shock and operation tests
as
well as temperature testing between
-30°C (-22 ° F) and +60°C (140°F).
vent entry of dust and moisture from
locations such as the shutter release
button and dial to protect interior
parts. And the shutter curtain control
magnets are Silver-plated to ensure
better contacts and longer life cycle.
Elastic connectors instead of solder
connectors are used to connect the
main
PC board to the resistor board
and other flexible circuit boards pro-
vide extra shock protection.
ASA settings and the other a digital
control circuit which controls the shut-
ter speed, electromagnetic release,
self-timer and exposure meter. These
circuits also monitor the control status
of both the camera and its accesso-
ries. The "Check and Go" system of
electro-mechanical sequences checks
each camera operation and function to
determine whether it was normal or
not before passing
to the next stage.
"Check and Go" is executed in three
steps: prior to shutter button release,
prior to making exposure after first
press of the shutter button and prior
to
winding the film to next frame in con-
tinuous shooting.
The new F-1 has two IC's, one for the
photometry circuit with
an analog op-
erational amplifier to perform exposure
calculations based on the subject il-
lumination, shutter speed, aperture and
ANALOG
AM PL if i ER
AE FINDER FN
Q
I 8 ' ~ \ 2 , I r.i XI 60175 150 ~D \000 I
AE FIN DE R FN
EVE·l EV EL FIN DE R FN
SPEED FINDER fN
SP EE DLITE
g
W
BAT TER Y CH ECK BUTTON
VI EWFIN DER
,---+(""') INf ORMA TION
ILLUMIN
ATOR
Contributing to this impressive record
are several revolutionary advances
in
production technology. These include
the computer-controlled NC (Numer-
ical Control) machine which performs
a variety of grinding, milling and drill-
ing functions, primarily on the die-cast
body and
AE Finder FN. The machine
is also used for precision milling of in-
dividual parts. Other advances include
the use of laser welding instead of
conventional rivets, and burnishing of
the inner surface of shafts by forcing
ball bearings through under high
pneumatic pressure.
MAX I M~T U "
SHU
0_'0_
+-_-+-+'--I
FIRST CURTAIN
- RE LEASE MAGN ET
SECOND CUR TAIN
r-r- , ,--,,- RElE AS E MAGN ET
Special measures are taken to protect
the new F-1's sophisticated electronic
circuitry inside, against vibration and
moisture. Plastic and rubber seals pre-
A PE~_ U' _t==~==== :::::j
Metering Circuit: Slight pressure on the shutter button turns on
the metering circuit that remains on until finger pressure is
released. When the metering switch is moved over to HOLD
or LIGHT pOSition , slight pressure on the shutter button turns
on the circuit and metering remains on for 16 sec ., without
maintaining pressure
on the shutter button, and then turns
itself off,
or turns off earlier with shutter release.
Metering Information Illumination : Moving the metering switch
over
to LIGHT position turns on the lamp to illuminate aper-
ture scale and shutter speed, for manual and shutter priority
AE.
Meter Sensitivity Pattern: Stress on central area (12%) with
supplied focusing screen,
by SPC (Si lic on Photo Cell) for
camera equipped with Eye-Level Finder
FN . Reading 50 % of
screen area with centerweighting with supplied focusing
screen for camera equipped with
AE Finder FN, by SPC . Spot
metering (3 % ), reading center spot of screen area, by SPC,
with user-interchangeable set of focusing screens.
Depth-of-Field Preview : Possible by releasing the stop-down
lever away from the lens.
Stop-Down Slide Lever: For depth-of-field preview or stopped-
down metering.
Battery Check: By pushing in the battery check button on the
front of the camera. Battery check information available for
viewfinder with aperture scale.
Power Source: One 6V lithium (Ouracell PX28L) battery,
alkaline-manganese (Eveready [UCAR]
No. A544), or silver
oxide (Eveready [UCAR]
No . 544) battery. Battery lasts about
one year under normal
use.
Flash: Built-in flash hot shoe on Eye-Level Finder FN or AE
Finder FN equipped to camera, for dedicated Canon Speed-
lites. Conventional
PC socket in front of camera body.
SG1-A2
Flash Synchronization: X synchronization at 1/90 sec. or below.
Exclusive Flash Circuit : Automatically adjusts shutter speed (to
1/90 sec., regardless of the speed selected on shutter dial)
with dedicated Canon Speedlites; meter needle
in the finder
indicates the choice of one of auto-flash apertures set
on
flash. Using AE Motor Drive FN or AE Power Winder FN for
shutter priority
AE, shutter speed as well as aperture will be
automatically adjusted.
Winding Lever: Single or multiple strokes, 139° throw, 30 °
standoff.
Rewinding: With film rewind mini lever atop the camera and
re -
wind knob. Motorized film rewinding with
AE Motor Drive FN .
Frame
Counter: Additive type; automatically resets when back
cover
is opened.
Film Loading : Easy film loading with multi-slot take-up spool for
regular winding
in normal direction.
Coupler for Automatic Winding: Coupling covers at the bottom
of the camera unthread for attaching motor-drive-section-
and-power-source-in-one
AE Power Winder FN or AE Motor
Drive
FN (motor section which couples to one of the power
packs). Possible
to use camera/motor drive or power winder
combination remotely for sequence shooting
or single opera-
tion; provision for time-lapse photography with Interval Timer
TM-1 Quartz.
Back Cover : With film box reminder holder. Removable to ac-
commodate the Data Back
FN or bulk film back, the Film
Chamber FN-1 00.
Size: 146.7mm(W) x 48.3mm(O) x 96 .6mm(H); 5-11 /16"(W) x 1-
15 / 16 "(0) x 3-13/16"(H)
Weight: 795g (28-3/8 ozs.) body only; 1,030g (36-5/16 ozs.)
with
FD 50mm f/1.4 lens. Subject
to change without notice.

SELLING POINTS
Multiple AE Modes Plus Manual
Versatility comes in the form of system accessories
which, besides fulfilling their basic functions, also provide
additional AE modes. Thus, attaching the AE Motor Drive
FN not only permits powered film advance but gives you
shutter-priority
AE, as well. Similarly, replacing the stand-
ard Eye-level Finder
FN with the AE Finder FN makes
possible aperture-priority and stopped-down AE.
1. Manual
The mode which puts you in total creative control.
Your customer has a choice of either full-aperture
metering or stopped-down metering. The meter is acti-
vated by gently depressing the shutter release button.
Turn the aperture ring
so that the aperture needle
matches the meter needle (or meter needle cuts the fixed
index
in case of stopped-down metering) for correct ex-
posure.
2. Shutter-priority AE
The ideal mode for action photography. This kind of
photography also calls for rapid film advance, so
Canon decided to combine the two. Shutter-priority
AE is
attained by attaching either the AE Motor Drive FN or AE
Power Winder FN . For this mode select a shutter speed
and set the lens aperture ring to "A
". Shutter-priority AE is
possible with any of the 5 interchpngeable viewfinders in-
stalled.
3. Aperture-priority AE
Aperture-priority AE is provided by installing the AE
Finder FN . Set the shutter dial to " A" and select the
desired aperture. The exposure information display shifts
from the right side
to below the image. The AE Finder FN
also makes feasible stopped-down AE which is a conve-
nience
in close-up work.
4. Multiple Exposure Modes
For the photographer who demands maximum ex-
posure mode flexibility, the new F-1
is the perfect
system camera. Attaching either of the two power drives
and the
AE Finder FN gives three AE Modes (shutter-
priority
AE , aperture-priority AE and stopped-down AE)
plus manual. For others, such as sports or news photo-
graphers who are more concerned wi
th capturing fast
action scenes, the power drives' shutter-priority
AE capa-
bility will usually suffice.
1
A
II
Manual
A
2
A
II
Manual
3 4
• •
ilL;.
Manual,
Aperture-priority
AE,
&
Stopped-down
AE
II
&
Shutter-priority AE
Manual,
Shutter-priority AE
&
Aperture-priority AE
New F-1 Body
Eye-Level Finder FN
•
AE Finder FN
L.
AE Motor Drive FN
or
AE Power Winder FN
Reliable Electromechanical Hybrid
Shutter
The new F-1 has an electromechanical hybrid shutter.
The fast speeds from
1/2000 - 1/125 , 7. (1/90) and B
are mechanically controlled, whereas eleCtronic circuitry
controls the slower speeds from 1/60 to 8 secs. With the
AE Finder FN set for aperture-priority and stopped-down
AE, all shutter speeds become electronic, although in this
case the fastest speed
is 1/1000 sec. Battery failure, the
bane of the professional photographer, thus poses
no
problem. The battery must be removed for mechanically-
controlled speeds
in case of battery failure.
~~e~: ~~~a \ 1¢ ====== =:::::::tJ¢=~
Co ntrol
SG1-A3

SELLING POINTS
Microprism Rangefinder
Laser
Mrte Screen
New Split Rangefinder Aperture Scale
Meter Needle
Overexposure
Warning Mark
Meter Needle
Battery Checkl
Stopped-down
Metering Index
Aperture Needle
Meter Mode Selector
Underexposure Warning Mark
Overexposure Warning Mark
125
I Underexposure
Warning Mark
Set at NORMAL, the meter only
functions while the shutter button
is depressed, as a power-saving
measure.
At HOLD , the meter op-
erates for 16 seconds, freeing
both hands
to adjust the camera
or lighting.
The same happens on
LIGHT ; but in addition the view-
finder display
is illuminated for
shooting in low-light co nditions.
Touching
the battery check but-
ton or releasing the shutter can-
cels the 16-second delay in either
HOLD or LIGHT modes.
Shutter Speed Scale
Expanded Metering Range
The metering range is a wide EV-1 to EV20
(ASA 100; 50mm f/14), permitting shutter
speeds
of down to 4 seco nds . Th e film
speed range is also wider: ASA 6 to ASA
6400.
Interchangeable Viewfinders
., Eye-Level Finder FN
Standard finder with the new F-1.
Features include built-in X-sync hot
shoe with special contacts for Speed-
lite flash AE and a handy eyepiece
shutter to prevent entry of extraneous
light during time exposures at night,
etc.
• AE Finder FN
This is also a standard finder for
the new F-1 . Photographers who re-
quire maximum control over the depth
of field (e.g. in close-up work) will find
this finder a great advantage, as it pro-
vides aperture-priority AE and stop-
ped - down AE .
SG1-A4
Shutter Speed Display
ODO~ ------------ D ~i re - c~t~A-p - e ~ rtu - r - e'R ~ e - a~do - u~t
7 8 9 10 11 12 13 14 15 16 17 18 19 20 EV
"""" "" "" "" "" - ,,
F NO
32
,,'"
"
I"
1"-
I"I"
I"-, I"-,
" "" "" "
'"
"
" I"
"
"-
"- "-
"
"-
"-
"-
""
"
""
"'"
"-
I"
1"-
"-
I"
1"-
I"-,
"-
"""" "
""
",, '
"'"
"
'"'"'"
f'.,
I" ~ '\
I"
"" "
""
",, '
22
"'"
"
'"'"'" """" '"
I"
""
""
""
"'"
"
'"'"'"'" """ '"'" "
I'-: ~
5.6
"I'-."
"""""" "" '" "" ""
""
"
'"
~
"
I'-.
" """""""" """ ""
r"-.
"-
~
""
28
,"
I'-.. I'-..
"" ""
""
"-
r"-. r"-.
"-
'"
""
" """"""
'"
""
"
KI" "
""
",,'
,
SHUTTER 8 4 2 1 1/2 11 4 1/8 1/ 30 1/125 1f500 1/ 2000
SPEED 1/15 1/60 1/ 250 lflOOO
6) Speed Finder FN
The Speed Finder FN swivels
round a full 180
0
in one fast motion to
convert from an eye-level to a waist-
level finder.
o Waist-level Finder FN
This comes in handy in close-up
work, copying, macrophotography and
astrophotography, where it is
neces-
sary to use the camera at a low angle
or
view the subject at a right-angle. A
built-in,
flip-up 4.6X magnifying glass
is provided for precise focusing.
o Waist-Level Finder FN-6X
A new finder unavailable with the
original
F-1 . A built-in 6X magnifying
glass permits extremely precise focus-
ing in c lose-up photography, copy
work and photomicrography. And the
magnifying glass offers magnification
of the entire image area. The Waist -
Level Finder FN-6X
includes built-in
dioptric adjustment for correction from
-5 to +3 diopter.

SELLING POINTS
IChoice of Three Metering Areas
Many cameras featu re interchangeable
focusing screens. The new F-1, how-
ever,
is t he on ly one that also offers a
choice of metering sensitivity patterns,
just by changing the
sc reen.
There are thr
ee differe nt patterns: cen-
ter-weight
ed average, selective-area
and spot metering. Dividing the 13 dif-
.ferent focus
in g sc reens available into
th r ee groups yields a total of 32 focus-
in g screen-metering system combina-
tions. The enti
re series of screens is
available for center-weight ed average
metering and
se lective-area metering.
Six sc reens -only those effecti ve for
this specialized metering meth
od
are available for spot mete rin g.
Center-weighted average meteri ng is
ideal fo r AE photograph y, particu la r ly
with wide-angle len ses. T he degree of
center-weighting in the
ho rizontal di-
rection
is si gnifican tl y increased to
minimi ze exposu re difference between
ve rt ical and horizontal positions.
Se lective-area metering is al so e ff ec-
tive for AE photography
an d stopped-
down
AE in close-up applications
where precise exposure of a specific
ar
ea of th e image is necessar y. Ap -
pr ox imate ly 1 2% of the viewfinder area
is metered.
Th e 3% spot metering pat-
te
rn is diffic ul t to u se, ye t yields spec-
tacular resul ts. Ideal fo r situations
where t he re is extreme contrast be-
tween subject and backgroun
d.
Ne w screens include two Bright Laser-
Maites w hi ch are appr ox. 20%
b ri ghter th an the laser matte and the
Cross
Sp lit w hi ch facilitat es both
ho ri zo ntal and ve rt ical fo rmat focusing.
IIII II I ~
Se lective-ar ea metenng
Spot metering
"Standard Microprism
Matte/Fresnel field with central microprism
rangefinder.
Fo r general photography with
all lenses.
€) New Split
Su itable for general photography with a ll
lenses. Split-image darken in g does no t oc-
cur even with slow lenses.
(!) Overall Laser Matte
Matte/Fresnel field with clear matte enabl es
viewi ng and focu si ng without distraction in
t he center. Ideal for macro and te lephoto
photography.
eLaser Matte wi th Grid
Re ference lines aid in situations where
lateral and vertical composition accuracy is
important, e.g., copy work and architectural
photography. Especia ll y suited for the TS
35mm (Tilt and Shift) Lens.
~ New SplitlMicropri sm
Standard in t he new F- 1. Multip ur pose type
fo r a ll lenses, enables focusing with th e
split-image, microprism, or matte field de-
pendi
ng on the subject or your own pre-
fe ren ce.
oMicroprism/Fast Lenses
An exce ll ent choice wh en us i ng fast len ses
(f/1 .2 to f/2.8). Af fords easy, extremely ac-
curate focusi
ng.
(9 Microprism/Slow Lenses
Similar to F, but for slower maximum aper-
tures of f/3.5 to f/5.6. Does not incur prism
darkening.
~ Laser Matte wi th Scale
For high-magnification applications such as
close-up photography and photomacro-
graphy. With fine matte center and 1mm
gradations
on ve rtical/horizontal lines and
around edges.
oLaser Matte wi th Double Cross-Hair
Reticle
We ll suited fo r applications requiring hi gh
magnifications such
as photomicrography
and astrophotography.
To focus move your
eye from left
to right. If the cross-hairs stay
in the same position
on the subject, the
subject is
in focu s.
t) Bright Laser Matte/Short Lenses
Together with the Bright Laser Matte K, t he
brightest screens of the system. Especially
effective with 50mm to 200mm lenses and
dark subjects or when using small working
apertures.
oBright Laser Matte/Long Lenses
Provides the same unobstructed viewing as
the Bright Laser Matte J. Suitable for
300mm te lephoto lenses or longer. Also ef-
fective for photomacrography.
(I Cross Split
Divides the subject both horizontally and
vertically. Subject is in focus when the four
quar
te rs merge to become one unbroken
image. Applicable
to a ll lenses.
~ A/B Size Laser Matte
The sc reen for those in t he publishing and
advertising fields. Engraved crosses
in co r-
ners facilitate cropping.
Spot
Selective-area
Center-weighted average
}~~~e~!llo; _ ~ ~ ~ ~~Il~ ___ L ____ , ___ __ , _____
[:]
, , ,
" ® i * i * i
, , ,
, , ,
, , ,
, , ,
08 , , ,
, ,
, , ,
,
, * * *
, , ,
, ,
, ,
,
eO , , ,
, ,
,
, , ,
, * , * , *
, , ,
, ,
,
, : ,
, ,
, , ,
,
,
L ' I I , ,
I ,
, , ,
e
~+=h +
, * , * ,
,
, , ,
, , ,
,
, , ,
~ G
, , ,
, ,
, * , * , *
,
, , ,
, ,
, ,
@ [:]
, ,
,
,
, * *
, ,
,
, ,
, ,
,
,
0 [:]
, ,
,
, ,
, * , *
,
, ,
, ,
, , ,
,
BJ
, ,
o ·'~-l-"~
,
, , ,
, , ,
, * *
, , ,
, , ,
, ,
.. ' , M I + , , ,
08 : , :
,
, ,
, ,
* , * , *
, ,
, ,
, , ,
,
, , ,
eO , ,
, ,
, ,
, ,
* , * *
, , ,
, , ,
, , ,
, : ,
, ,
00 , ,
,
, , ,
, , ,
, * * , *
, ,
, ,
, , ,
,
e8 , , ,
, ,
, ,
, ,
, * *
,
, , ,
, ,
,
, , ,
,
~ D
, ,
, , ,
, ,
, * , * ,
,
, ,
, ,
, ,
,
, , ,
SG1-A5

o AE Power Winder FN
The AE Power Winder FN provides the
same convenient operation as the
AE
Motor Drive FN , but at a slower speed
(max 2 fps). It
is powered by four pen-
light batteries and can be set for sin-
gle-frame advance. Provision for re-
mote control of switching functions the
AE Motor Drive FN features is also
available on the
AE Power Winder FN .
All other features, with the exception of
powered film rewind,
ar~ the same as
the
AE Motor Drive FN.
SG1-A6
Warning Lamp
Remote Control Jack
Shutter Release Button
SELLING POINTS
8 AE Motor Drive FN
Rugged, compact and lightweight, the
AE Motor Drive FN fits beneath the
camera and is then always fitted
underneath with one of the power
packs. The camera's own shutter
release, the one on top the motor drive
grip, and the one
on the side of the
power pack (latter
to simplify holding
for vertical shots) operate the motor.
There's choice of speeds, too: high (H)
5 fps, low (L) 3.5 fps and single frame
(S)' Power rewind is pos-
sible, taking only 10
seconds for a 36-exp
roll.
Shutter Release Button
Power Rewind Lever
Three Power Pack Options
o Battery Pack FN
Loaded with twelve penlight batteries,
the Battery Pack
FN enables the AE
Motor Drive FN to advance the film at
5 fps. Under normal temperatures, this
pack will wind fifty rolls of 36-exp film.
Battery condition is indicated by a 3-
step
LED.
o High Power Ni-Cd Pack FN
For shooting at temperatures down to
-20 °C, the High Power Ni-Cd Pack
FN is recommended. At normal tem-
peratures, this unit will wind up to fifty
rolls of 36-exp film between charges.
With the addition of the Battery Cord
C-
FN , the High Power Ni-Cd Pack FN
can be used as external power source
for powering the camera, replacing the
usual battery installed in the new F-1
body.
o Ni-Cd Pack FN
Offering greater economy and com-
pactness, the N
i-Cd Pack FN uses
built-in rechargeable Ni-Cd batteries. It
has a shooting capacity of about thirty
rolls of 36-exp film per charge and the
batteries may
be recharged up to 300
times. The weight of the Ni-Cd Pack
FN is about half the weight of the Bat-
tery Pack
FN loaded with batteries.

MAIN ACCESSORIES
stops.
To install, you simply remove the
camera's back cover.
41) Interval Timer TM-1 Quartz
o Battery Cord C-FN
«i) Data Back FN
This is a special cord for drawing the
camera's power from the alternative
power source
in cold weather. The
camera's usual 6V battery
is removed
and the power
is drawn from the High
Power Ni-Cd Pack.
The voltage from
the High Power Ni-Cd Pack
is stepped
down
to the usual voltage required for
the camera's function.
Removing the camera's back cover
also permits easy installation of the
Data Back
FN. This is a data printing
device with three dials for letters,
Roman numerals and numbers. It can
be used for dating or classifying pho-
tographs. Cord connections are
unnecessary as the camera's electron-
ic circuitry automatically imprints the
information
on the film in perfect syn-
chronization. Electronic flash can be
used at the same time.
This handy accessory permits unman-
ned sequential photography at any
preset time, from one shot every 1-40
seconds to one shot every 1-30
minutes. And the precision quartz
timer may be set
in 14 stages on a
large, easy-to-read dial. The
TM-1
releases the shutter when the camera
is used in combination with the motor
drive or power winder accessories.
And
it will function as a remote control
switch.
8 100 Exposure Film Chamber
FN-100
A: 8.5mm (5 /16")
With its newly designed grip and built-
in shutter release button, this light-
weight,
compact unit greatly improves
hand-held shooting and portability.
Rapid-sequence (up to 5 fps) shooting
of 100 frames
is possible with the AE
Motor Drive FN. This makes the Film
Chamber FN-100 ideal for sports pho-
tography, copying work or recording
experiments.
B: 11 .85mm (7 /16")
4D Wirelesss Controller LC-1
Consisting of a receiver and transmit-
ter, the Wireless Controller LC-1 per-
mits remote-control operation, sequen-
tial or single-frame, from a distance of
60m in a straight line without cord
connection. It has three channels for
setting off cameras
in succession.
Placing receivers
on several cameras,
makes simultaneous multi-camera re-
mote control possible. And with the
three-channel selection, there
is less
chance of another photographer using
the same or similar device accidental-
ly setting off your came ra .
Its manually set subtractive frame
counter automatically disengages the
counter on the motor drive, and indi-
cates the number of exposures re-
maining at any given time. When the
film runs out, the unit automatically
oCanon AE Power Winder FN
Specifications
C: 2.3mm (1/16")
D: 0.7mm (1 /32")
E: 0.9mm (3 /64")
Structure: Motor drive section and power source-in-one unit
Winding Speed: Approx two frames per second for sequence
shooting or
si ngle-frame winding for intermittent shooting.
Operation: Activated by two release buttons on the winder, one
for horizontal and another for vertical
or by the camera's
shutter release button, Remote Switch 3 or 60 using connect-
ing cords, or with the transmitter of Wireless Controller LC -1.
Shooting at fixed intervals possible using Interval Timer
TM-1
Quartz.
Shutter Speed Coupling Range: 8 to 1/2000 sec.
Frame Counting: Frame counter of the Power Winder FN shows
the number of unexposed frames. Functions independent of
camera's frame counter.
Film Rewinding: By rewind crank on camera.
Safety Circuit: When the film is completely exposed or if the
battery power fails, film winding automatically stops and the
LED on Power Winder FN flashes.
Number of Film Rolls: In normal temperature about twenty rolls
of 36-exposure film in continuous or sing le -frame mode, using
ca
rb on zinc batteries.
Power Source: Four AA size batteries, carbon zincs, alkaline-
manganese or Ni-Cd batteries
Size: 157mm(W) x 77mm(D) x 101mm(H); (6-3/16" x 3" x 4")
Weight: 400g, 14-1/8 ozs. (including batteries)
8canon AE Motor Drive FN
Specifications
Structure: Consists of a motor for film winding,
an electro-mag-
netic clutch, a set of gears, and a release button for connec-
tion to the camera base.
Operation: Three shutter buttons provided inc!. battery section
and camera's). Shooting at fixed intervals
is possible using
the Interval Timer
TM-1 Quartz.
Film Rewinding: Motorized rewinding taking approximately 8
sec.
Size: 157mm(W) x 94mm(H) x 72mm(D); (6-3/16" x 3-11 /16" x
2-7/8")
Weight: 396g, 13-15/16 ozs.
SG1-A7

SPECIFICATIONS
8 Canon Battery Pack FN
Specifications
Structure: Consists of a motor control circuit a
nd a chamber for
loading twelve
AA size batteries with a battery magazine.
Winding Speed: Three changeable modes of H (5 frames /s e c. ),
L (3 .5 frames/sec,) and S (single frame).
Operation: Activated by the auxiliary motor drive release on Bat-
tery Pack
FN (vertical shot), shutter release button on the
camera
or on top of the motor drive grip (horizontal shot), Re -
mote Switch 3 or 60 using connecting cords, or with the
transmitter of Wireless Controller
LC-1 .
Shutter Speed Coupling Range: 1/60 to 1 12 000 in H mode; 8
to 1 12 000 in L or S mode.
Frame Counting: Frame counter of the AE Motor Drive FN
shows the number of unexposed frames. Functions indepen-
dently of camera's frame counter.
Safety Circuit: When the film is competely exposed or rewound
or if the battery power fails, film windinglrewinding automat-
ically stops and the LED on AE Motor Drive FN flashes.
Number of Film Rolls: In normal temperature about fifty rolls of
36 -exposure film using H mode.
Power Source: Twelve AA size batteries, alkaline-manganese or
carbon zincs.
Size: 156.7mm(W) x 75.3mm(D) 36mm(H); (6-3/16" x 2- 11 /16"
x 1-1/16")
Weight: 449g, 15-13/ 16 ozs. (including batteries)
e Canon High Power Ni-Cd Pack FN
Specifications
Structure: Consists of a motor control c ir cuit and built- in Ni-Cd
battery. Rechargeable with Ni-Cd Ch arger MA / FN .
Winding Speed: Three operating speeds of H (5 frames/ se c ,) , L
(3 .5 frames/sec.) and S (single frame).
Operation: Activated by the auxiliary motor drive release on
High Power Ni-Cd Pack FN (vertical shot), shutter release
button
on the ca:mera or on top of the motor drive grip
(horizontal shot), Remote Switch 3 or 60 using connecting
cords,
or with the transmitter of Wireless Controller LC-1.
Shutter Speed Coupling Range: 1/ 60 to 1/2000 in H mode; 8
to 112000 in L or S mode.
Frame Counting: Frame counter of the AE Motor Drive FN
shows the number of unexposed frame s. Functions indepen-
dently of camera's frame counter. .
Safety Circuit: When the iilm is completely exposed or rewound
or if the battery power fails, film winding/rewinding automat-
ically stops and the LED on AE Motor Drive FN flashes.
Number of Film Rolls: In normal temperature about fifty rolls of
36 -exposure film using H mode. In - 20 °C temperature, about
twenty rolls of 36-exposure film.
Power Source: Built-in Ni-Cd battery, 14.4V.
Size: 156.7mm (W) x 75.3mm(D) x 36mm(H); (6-3/16" x 2-
15/16" x 1-7/16")
Weight: 469g, 16-9/ 16 ozs.
e!) Canon Ni-Cd Pack FN
Specifications
Structure: Consists of a motor control circuit and built-in
Ni - Cd
. battery. Rechargeable with Ni-Cd Charger MA / FN.
Winding Speed: Three operating speeds of. H (4.5 frames/ sec.),
L(3 frames/sec.) and S (single frame).
Operation: Activated by the auxiliary motor drive release on Ni-
Cd Pack FN (vertical shot), shutter release button on the
camera or
on top of the motor drive grip (horizontal shot), Re -
mote Switch 3
or 60 using connecting cords, or with the
transmitter of Wireless Controller LC-1.
Shutter Speed Coupling Range: 1/60 to 1/2000 in H mode; 8
to 112000 in L or S mode.
Frame Counting: Frame counter of the AE Motor Drive FN
shows the number of unexpos ed frame s. Functions indepen-
dently of camera's frame counter.
Safety Circuit: When the film is completely exposed or rewound
or if the battery power fails, film winding/rewinding automat-
ically stops and the LED on AE Motor Drive FN flashes.
Number of Film Rolls: In normal temperature about thirty rolls
of 36-exposure film using H mode.
Power Source: Built-in Ni-Cd battery, 14.4V
Size: 156.7mm(W) x 67 .8mm(D) x 26.6mm(H); (6-3/16" x 2-
11/16" x 1-1/16")
Weight: 212g, 7-1/2 ozs.
SG1 -A8
f) Canon Film Chamber FN-100
_Specifications
Type: Bulk film chamber for use in conjunction with AE Motor
Drive
FN.
Attachment: By exchange with camera's back cover.
Film Magazine: Two magazines, one ea ch for supply and take-
up, for exclusive use with Film Chamber FN-100.
Film Loading: Film loading into Film Magazine FN-100 using
Film Loader 250 in a dark room.
Maximum Capacity: 100 frames of 35mm roll film.
Film Advance: Film advance via motor drive with a provision for
synchronous film take-
up.
Automatic Film Stop: When the last frame passes over the
guide roller,
an LED warning lamp of the motor drive lights
up.
Automatic Safety Circuit: When the shutter button is pressed,
the film chamber will not operate a
nd the motor drive's wa r n-
ing lamp lights up in the following cases:
1) When there is no film in the film chamber or the film has
run out;
2) When there is film loaded and the Open/Close knob on
the take-up side is at "OPEN ."
Frame Counter: Manually set. subtractive type
Film Magazine Removal: Via two eject levers, one inside each
magazine chamber.
Shutter Release: Four shutter buttons (one on film chamber, two
on motor drive plus camera's) each with a lock le v er.
Back Cover Interlock: Back locked with both OPEN /CLOSE
knobs at "CLOSE" or OPEN /CLOSE knob on magazine supply
side at
"OPEN ."
Dimensions: 258.8(W) x 108.5(H) x 72 .3(D)mm; (10-3/ 16 " x 4-
1/4" x 2-7/8")
Weight: 641 g, 22-5/8 OlS.
.(!)Canon Data Back FN
Specifications
Attachment: By exchange with camera's back cover.
Data Setting: Done by three rotating dial s.
Data Setting Dials:
Right dial: 32 digits and two blanks (0'0,0-31)
' 0 denotes a blank on film.
Central Dial: 39 characters and one blank
(0,0-31, A-G)
Left dial:
39 characters and one blank (0 , 0 to 9, 81 to 92),
Roman numerals I to X and a
to g).
Data Recording: Data is automatically recorded in lower right-
hand corner of frame and through the back of the film by a
built-in flash unit coupled to the shutter release. A separate
button
is provided for manual data exposure.
Exposure (Light Intensity) Adjustment: By setting dial to one
of three positions according
to type of film.
Indicator Lamp: Neon pilot lamp lights up to indicate Data Back
is ready for firing.
Power Source: One 6V alkaline-manganese (4LR44) good for
approximately 2,000 flashe
s. Approximately 1,000 flashes
when using
AE Power Winder FN for sequential shooting at 2
fps.
Main Switch: ON-OFF, when set to OFF , indicator lamp go es out
and no data will be recorded.
Size: 103mm(W) x 14 .3mm(D) x 49.2mm(H); (4" x 9/16" x 1-
7/8")
Weight: 166g, 6 ozs. (including battery)
0Canon Interval Timer TM-1 Quartz
Specifications
Connection: By inserting the plug of the timer to the remote
control jack of one of the power packs for the
AE Motor Drive
FN or to the remote jack of the AE Power Winder FN .
Time Intervals: Shooting in fixed intervals from one second to
30 minutes. Settings for
1, 2, 5, 10 , 15 , 20, 30 and 40 seconds
and
1, 2, 5, 10 , 20, and 30 minutes.
Switch Functions: Power on /off of time setting and separate
on /offlrunning lock switch for activating shutter release
Battery Check: With battery checklight LED on the timer
Power Source: One 6V alkaline-manganese (4LR44)
Size: 38mm(W) x 19.5mm(D) x 94mm(H); (1-9/16" x 13/16" x 3-
11/16")
Weight: 60g, 2-1/8 OlS. (including battery)

MAIN ACCESSORIES
4D Canon Wireless Controller LC-1
Specifications
Operation Range: About 60m (200
ftlin a straight-line course
with
no obstacles in the path. If the angle between the re-
ceiver and transmitter is 20°, about 35m; if 45°, about 15m.
Operation Mode: C (continuous) for sequence shooting, S (sin-
gle) for single-frame shooting.
Number of Channels: Three
Attachment to the Camera: Reciever mounts into camera's ac-
cessory shoe. Synchro cord plugs into t~e remote control jack
on the power winder or motor drive device.
Battery Life: More than 500 times with a new battery provided a
minimum interval of less than 0.5 sec.
is used between each
operation.
_ Battery Check: Operation confirmation lamp doubles as battery
checklight.
Operation Confirmation Lamp: Provided
on the receiver. Prior
to shooting, operation confirmation lamp can be used to
check if the distance between the transmitter and the re-
ceiver is within range.
Power Source:
For the receiver, OC 9V transistor battery,
Eveready 216, Ouracell M1604 or the equivalent. For the
transmitter, two
AA size alkaline-manganese batteries.
Size: Receiver, 35 x 62 x 84.5mm (1-3/8" x 2-7116" x 3-3/8");
transmitter, 49 x 120 x 37mm. (115/16" x 4-314" x 1-1/2")
Weight: Receiver, 153g, 5-3/8 ozs. (including the battery); trans-
mitter, 172g, 6-1/16 ozs. (including batteries).
The New Canon Auto Tuning System
(New CATS) makes flash photography
simple and error-free.
It also allows
many techniques to be used. And
there are seven models
in the Speed-
lite series, plus a Macrolite
ML-1 flash
unit for close-up work.
The high-powered 577G and 533G are
ideal for shooting subjects that are dif-
ficult to approach. Also, tele- and
wide-adapters can
be attached to pro-
vide full flash coverage using lenses
with focal lengths of 100mm or more,
or as wide as 20mm.
Models 133A through 199A fit directly
into the hot shoe
on the viewfinder,
while the grip type 577G and 533G
are camera-mounted using a quick-
release bracket, their independent sen-
sor units mounts on the camera hot
shoe.
The heads of these two rugged, light-
weight units can be tilted up 120· with
intermediate click stops at 60
·, 75°
and 90· to permit bounce flash. Left-
right horizontal turning is also possible.
Both units have three color-coded
autoshooting distance ranges.
o Canon Speed lite 1 33A
Specifications
Type: Electronic computer flash unit with a series control sys-
tem.
Guide Number: 16 (ASA/ISO: 100121 °, m); 26 (ASA IISO: 25/15°,
ft)
Attachment: Via hot shoe
Flash Coverage Angle: 35mm lens
Flash Duration: 1/700-1/100,000 sec.
Power Source: 2 AA-size a.lkaline-manganese or rechargeable
Ni-Cd batteries
Body Dimension and Weight: 62(W) x 37(0) x 95(H)mm
(2-7/16" x 1-7/16" x 3-3/4"). 200g (7-1/16 ozs.l
f) Canon Speedlite 1 55A
SpeCifications
Type: Electronic computer flash unit with a series control sys-
tem.
Guide Number: 17 (ASA/ISO:1 00/21 0, m) ; 28 (ASA/ISO: 25/15°, ftl
Attachment: Via hot shoe
Flash Coverage Angle: 35mm lens
Flash Duration: 1/1000-1/50,000 sec.
Power Source: 4
AA -size alkaline-manganese or rechargeable
Ni - Cd batteries
Manual Flash: Possible
Body Dimension and Weight: 70(W) x 51 (0) x 105(H)mm (2-
3/4" x 2" x 4-1/8"). 300g (10-9/16 ozs.l
SG1-A9

SPECIFICATIONS
8Canon Speedlite 177A
Specifications
Type: Electronic computer flash unit with a series control sys-
tem.
Guide Number: 25 (ASA/ISO: 100/21 ', m) ; 41 (ASAIISO: 25/15',
ft.)
Attachment: Via hot shoe
Flash Coverage Angle: 28mm lens with Wide Adapter
Flash Duration: 1/600-1/50,000 sec.
Power Source: 4 AA-size alkaline-manganese or rechargeable
Ni-Cd batteries
Manual Flash: Possible
Body Dimension and Weight: 72(W) x 58(0) x 107(H)mm
(2-13/16" x 2-1/4" x 4-3/16"). 310g (1-15/16 ozs.)
eCanon Speedlite 188A
Specifications
Type: Electronic computer flash unit with a series control sys-
tem.
Guide Number: 25 (ASA/ISO: 100121', m) ; 41 (ASA/ISO: 25/15',
ft.)
Attachment: Via hot shoe
Flash Coverage Angle: 28mm lens with Wide Adapter
Flash Duration: 1/700-1/50,000 sec.
Power Source: 4 AA-size alkaline-manganese or rechargeable
Ni -Cd batteries
Manual Flash: Possible
Body Dimension and Weight: 68(W) x 52(0) x 103(H)mm
(2 -11/16 x 2-1/16 x 4-1/16"). 290g (10-1/4 ozs.)
oCanon Speedlite 199A
Specifications
Type: Electronic computer flash unit with a series control sys-
tem
Guide Number: 30 (ASA/ISO: 100/21', m); 50 (ASAIISO: 25/15',
ft.)
Attachment: Via hot shoe
Flash Coverage Angle: 24mm lens with Wide Adapter
Flash Duration: 1/500-1/50,000 sec.
Power Source: 4 ·AA-size alkaline-manganese or rechargeable
Ni-Cd batteries
Manual Flash: Possible
Bounce Flash: Up to 90' upward
Slow Sync. Flash: Possible with Canon new F-1 and A-1
Body Dimension and Weight: 79(W) x 83(0) x 116(H)mm
(3-1/3" x 3-114" x 4-9/16"). 490g (1 lb. 1-5/16 ozs.)
oCanon Speedlite 533G
Specifications
Type: Electronic computer flash unit with a series control sys-
tem
Guide Number: 36 (ASA/ISO: 100/21 ', m); 60 (ASA/ISO: 25/15',
ft.)
Attachment: Grip type
Flash Coverage Angle: 20mm lens with Wide Adapter
Flash Duration: 11800c1150,000 sec.
Power Source: 6 AA-size alkaline-manganese or rechargeable
Ni-Cd batteries; 6 C-size alkaline-manganese batteries
or Ni-
Cd Pack TP in the Transistor Pack G
Bounce Flash: Up to 120' upward, 120' left and right
Slow Sync. Flash: Possible with Canon new F-1 and A-1
Body Dimension and Weight: 93(W) x 104(0) x 248(H)mm
(3 -11/16" x 4-1/8" x 9-3/4"). 655g (23-1/8 ozs.)
SG1-Al0
oCanon Speedlite 577G
Specifications
Type: Electronic computer flash unit with a series control sys-
tem.
Guide Number: 48 (ASA/ISO: 100 12 1', m); 80 (ASA/ISO: 25/15',
ft.)
Attachment: Grip type
Flash Coverage Angle: 20mm lens with Wide Adapter
Flash Duration: 1/400-1150,000 sec.
Power Source: 6 C-size alkaline-manganese batteries or Ni-Cd
Pack TP in the Transistor Pack G
Manual Flash: Possible
Bounce Flash: Up to 120' upward, 120' left and right
Slow Sync. Flash: Possible with Canon new F-1 and A-1
Body Dimension and Weight: 99(W) x 107(0) x 245(H) mm
(2-7/8" x 4-1/4" x 9-5/8") 600g (21-3/16 ozs.)
(l)Canon Macrolite ML·1
Specifications
Type: Electronic computer flash unit with a series control sys-
tem.
Guide Number: 16 (ASA/ISO: 100121', m); 26 (ASA/ISO: 25/15',
ft.)
Attachment: Clip-on of Control Unit via hot shoe
Flash Coverage Angle: Image size and framing possible with
New
FD 80-200 f/4 zoom lens and Close-up lens .500T, New
FO 50mm f/3.5 Macro, New FO 100mm f/4 Macro, and New
FO 200mm f/4 Macro.
Flash Duration: 1/500-1/50,000
Power Source: 8 AA-size alkaline-manganese or rechargeable
Ni-Cd batteries
Manual Flash: Possible
Flash Heads: Two flash heads with switch functions to use only
one at a time, if desired. Removable wide adapters for light
diffusion effects. Flash swivel feature to rotate the flash unit
in a 90' arc counterclockwise (as seen from back of camera)
or a
45' arc clockwise, for changeing the direction of il-
lumination.
Body Dimension and Weight:
Flash Unit: 131(W) x 39. 7(0) x 99(H)mm (5.2" x 1.6" x 3.9")
170g (6 ozs.)
Control Unit: 50(W) x 59(0) x 38.6(H)mm (2" x 2.2" x 1.5")
70g
(2 .5 ozs.)
Battery Case (w/8
AA batteries): 77.4 (W) x 35 . 6(0) x
162(H)mm (3" x 1.4" x 6.4") 560g (19.8 ozs.)

Lens Relea se Button
Note: A coin-slotted cover conceals
the Rewind Coupler, AE Coupler
and Winder and Motor Drive
Coupler when an equipment for
motorized photography
is not at-
tached to the camera.
NOMENCLATURE
Winder and Motor
Drive Coupler
Positioning H
Winder and Motor
SG1-A11

VIEWFINDER ACCESSORIES
CODE
NO. DESCRIPTION
C54-0841
C54-08t 1
C54-0821
C54-0831
CA4-3716
5-40701-21
5-41051-00
5-41051-00
5-40711-00
CAI-2370
AE Finder FN (wlFinder Dust Cover)
Speed Finder
FN (wlFinder Dust Cover
FN)
Waist Level Finder FN (w;Fi'nder Dust
Cover
FN)
Waist Level Finder FN-6X (wlFinder
Dust Cover
FN)
Finder Dust Cover FN
Magnifier R
Magnifier Adaptor R
Angle Finder A2
Angle Finder B
Rubber Eyepiece Ring 2
DIOPTRIC ADJUSTMENT LENSES
5-05061-00 Dioptiric Adjustment Lens R
(+3)
5-05062-00 Dioptiric Adjustment Lens R (+ 2)
5-05068-00 Dioptiric Adjustment Lens R (+ 1 .5)
5-05063-00 Dioptiric Adjustment Lens R (+ 1)
5-05069-00 Dioptiric Adjustment Lens R (+0.5)
5-05064-00 Dioptiric Adjustment Lens R (0)
5-05071 -00 Dioptiric Adjustment Lens R (- 0.5)
5-05065-00 Dioptiric Adjustment Lens R
(- 2)
5-05066-00 Dioptiric Adjustment Lens R (- 3)
5-05067-00 Dioptiric Adjustment Lens R (- 4)
FOCUSING SCREENS
C51-9531
C51-9541
C51-9551
CSI-9581
C51-9591
C51-9601
CSI-9611
C51-9621
C51-9631
C51-9561
C51-9571
C51-9651
C51-9661
C51-9532
C51-9542
C51-9552
C51-9582
C51-9592
C51-9602
C51-9612
C51-9622
C51-9632
C51-9562
C51-9572
C51-9652
C51-9662
SG1-A12
Focusing Screen FN-AA (Standard
Microprism) for center-weighted
average metering
Focusing Screen FN-AB (New Split) for
center-weighted average metering
Focusing Screen FN-AC (Overall Laser
Matte) for center-weighted average
metering
Focusing Screen FN-AD (Laser Matte
with Grid) for center-weighted average
metering
Focusing screen FN-AE (New Split
Microprism) for center-weighted
average metering
Focusing Screen FN-AF (Micropr-
ismlFast Lenses) for center-weighted
average metering
Focusing Screen FN-AG (Micropr-
ismlSiow Lenses) for center-weighted
average metering
Focusing Screen FN-AH (Laser Matte
with Scales) for center-weighted
average metering
Focusing sbreen FN-AI (Laser Matte
with Double Cross Hair Reticle) for
center-weighted average metering
Focusing Screen FN-AJ (Bright Laser
MattelShort Lenses) for center-
weighted average metering
Focusing Screen FN-AK (Bright Laser
MatteiLong Lenses) for center-
weighted average metering
Focusing Screen FN-AL (Cross Split!
for center-weighted average metering
Focusing Screen FN-AM (AlB Size
Laser Matte) for center-weighted
average metering
Focusing Screen FN-PA (Standard
Microprism) for selective-area metering
Focusing Screen FN-PB (New Split) for
selective-area metering
Focusing Screen FN-PC (Overall Laser
Matte) for selective-area
met :.: e "- ri c: n,,g ~~
Focusing Screen FN-PD (Laser Matte
with Grid) for selective-area metering
Focusing Screen FN-PE (New Split
Microprism) for selective-area metering
Focusing Screen FN-PF (Micropr-
ismlFast Lenses) for selective-area
metering
Focusing Screen FN-PG (Micropr-
ism/Slow Lenses) for selective-area
metering
Focusing Screen FN-PH (Laser Matte
with Scales) for selective-area meter-
ing
Focusing Screen FN-PI (Laser Matte
with Double Cross Hair Reticle) for
selective-area metering
Focusing Screen FN-PJ (Bright Laser
MattelShort Lenses) for selective-area
metering
Focusing Screen FN-PK (Bright Laser
MattelLong Lenses) for selective-area
metering
Focusing Screen FN-PL (Cross Split)
for selective-area metering
Focusing Screen FN-PM (AlB Size
Laser Matte) for selective-area meter-
ing
ACCESSORIES
C51-9543
C51-9553
C51-9593
C51-9633
C51-9563
C51-9573
Focusing Screen FN-SB (New Split) for
spot metering
Focusing Screen FN-SC (Overall Laser
Matte) for spot metering
Focusing Screen FN-SE (New Split
Microprism) for spot metering
Focusing Screen FN-SI (Laser Matte
with Double Cross Hair Reticle) for
spot metering
Focusing Screen FN-SJ (Bright Laser
MattelShort Lenses) for spot metering
Focusing Screen FN-SK (Bright Laser
MattelLong Lenses) for spot metering
EQUIPMENT FOR MOTORIZED PHOTOGRAPHY
C51-9441-011
C51-9441-001
C58-5481 -001
C56-2117
C58-5491-011
C58-5531
C58-5521-001
C58-5501
C51 -9451 -001
C51-9461
CG4-0044
5-19181-00
5-81071-00
5-22051-00
5-22041-01
C58-5351 -211
C58-5351-001
C58-5352
C51-9182
AE Motor Drive FN Set (Consists of AE
Motor Drive FN, Battery Pack FN, Bat-
tery Magazine
FN)
AE Motor Drive FN
Ni-Cd Pack FN
Ni-Cd Charger MAIFN
High Power Ni-Cd Pack
FN (w/Battery
Cord C-FN)
Battery Cord C-FN
Battery Pack
FN (w/Battery Magazine
FN)
Battery Magazine FN
AE Power Winder FN
Film Chamber FN-100 (w/Film Mag-
azine
FN-l00 in case)
Film Magazine FN-100 in case
Film Loader 250
Extension Cord El000
Remote Switch 60
Remote Switch 3
Wireless Controller LC-l Set (consists
of Receiver and Transmitter)
LC-l Transmitter
LC-1 Receiver
Interval Timer TM-l Quartz
FLASH ACCESSORIES
C50-0371 -201
C50-0311-201
(;50-0361-211
C50-041 1-21 1
CA4-2332
C50-0321-211
C50-1481
C50-1431 -001
C50-1441-001
C50-0301-221
Y12-6725
Y19-0165
Y19-0166
Y12-6756
Y12-6758
C50-1432
C50-0381-221
C50-0391-211
C50-1561
C50-1501
C50-1491
C50-1492
C50-1541
C50-1543
C50-1542
C50-1544
C50-1545
CSO-1546
C50-1547
C50-1571
C50-1581
C50-1557
C50-1521 -221
C50-1521-311
Speedlite 133A Set in Case
Speedlite 155A Set in Case
Speedlite 177A Set in Case wIWide
Adapter
Speedlite 188A Set in Case wIWide
Adapter
Wide Adapter for 188A and 177A
Speedlite 199A Set in Case wIWide
Adapter
Wide Adapter for 199A
Battery Magazine D
Synchro Cord A
Macrolite ML-1 Set
Wide Adapter
ML-l
Macrolite Adapter 55
Macrolite Adapter 52
Tightening Ring 55
Tightening Ring 52
Battery Magazine
DM for Macrolite ML-1
Speedlite 533G Set
Speedlite 577G Set
Battery Magazine 533G
One-Touch Bracket G
Sensor Unit G20
Sensor Unit G1 00
Wide Adapter 533G-24
Wide Adapter 577G-24
Wide Adapter 533G-20
Wide Adapter 577G-20
Tele Adapter 533G
Tele Adapter 577G
Adapter G for Motor Drive MF
Battery Magazine
TP
Ni-Cd Pack TP
Ni-Cd Charger TP
Transistor Pack G Set (consists of Ni-
Cd Pack
TP, Ni-Cd Charger TP and
Power Cord)
Transistor Pack G Set (consists of Bat-
tery Magazine
TP and Power Cord)
DATA
BACK ACCESSORIES
C51-9471 Data Back
FN
MISCELLANEOUS ACCESSORIES
C50-3151-001 Camera Holder
F4
5-63061-00 Release 30
5-63062-00 Release 50
CASES
C46-1 124
C46-1123
C46-1 122
C46-1121
Case AE-L for new F-l (for FD 50mm
flt.2 lens plus AE Finder FN)
Case AE-S for new F-l (for FD 50mm
f/l.4, 111.8 lens plus AE Finder FN)
Case L for new F-1 (for FD 50mm 111.2
lens)
Case S for new F-1 (for FD 50mm
f/l.4, f/1.8 lens)
MACROPHOTO & CLOSE-UP ACCESSORIES
4-20601
-20 Copy stand 4
4-25901 -03 Handy Stand F52 Set
4-46201-20
4-25117-00
4-25301-00
4-25302-00
4-25303-00
4-25323-01
4-25324-01
4-25325-01
4-25315-00
4-25321-00
4-25316-01
4-25316-00
4-25317-00
4-25322-00
4-25711-00
4-25721-00
C42-5731
5-42011-00
5-42021-00
5-42031-00
5-42071-00
0-00000-33
5-43231-01
5-43241-01
5-43251-01
5-43331-01
5-43571-00
5-43561-01
C54-3741
C54-3731
5-59042-20
5-59181-02
5-59181-01
43-6370
CA4-2418
43-6371
43-6372
C26-1 151-21 1
C26-1161-
211
C55-9044-21 1
C42-6501
C42-6511
C42-6521
C42-6541
C55-9182-011
C55-91 82-01 2
C42-6571
C42-6581
C42-6591
C42-6693
C42-6692
C42-6691
C42-6681
C42-6612
C42-6611
BODY COVER
C45-2031
STRAP
C56-1241
Photo Micro Unit F
Macro Hood
Extension Tube A
Extension Tube B
Extension Tube C
Extension Tube
FD 50 Universal in
Case
Extension Tube
FD 25 Universal in
Case
Extension Tube FD 15 Universal in
Case
Extension Tube
FL 15
Extension Tube
FL 25
Extension Tube M Set
Extension Tube M5
Extension Tube M10
Extension Tube M20
FL58 Macrophoto Coupler
FL55 Macrophoto Coupler
FL52 Macrophoto Coupler
Lens Mount Converter A
Lens Mount Converter B
Lens Mount Converter E
Lens Mount Converter P
Lens Mount Converter N
58 Close-Up 450
58 Close-Up 240
48 Close-Up 450
48 Close-Up 240
55 Close-Up 450
55 Close-Up 240
52 Close-Up 450
52 Close-Up 240
Bellows
FL
Slide Duplicator 52
Slide Duplicator 55
Attachment Ring
48 for Slide Duplica-
tor
Attachment Ring 52 for Slide Duplica-
tor
Attachment Ring 55 for Slide Duplica-
tor
Attachment Ring 58 for Slide Duplica-
tor
Macrophoto Lens 20mm
113.5 in Case
Macrophoto Lens 35mm
112.8 in Case
Auto Bellows
Macro Auto Ring
Double Cable Release
Focusing Rail
Macro Stage
Duplicator 35-55R
Duplicator 35-52R
Roll Film Stage
Duplicator 8
Duplicator 16
Macrophoto Adapter MA-58
Macrophoto Adapter MA-55
Macrophoto Adapter MA-52
Duplicator G
Vari-Extension Tube M30-55
Vari-Extension Tube M15-25
Camera Cover R-F-2
Neck Strap L1 with
Pad
PLEASE NOTE: For further information on accessories
please see the sections as follows:
Sect. 2: Canon Interchangeable Lenses
Sect. 6: Miscellaneous Accessories Cross-Ref-
erenced
(including Canon Filters, Cases, etc.!
