Capital CGSR484G2 User manual

Self
-
clean (primary oven only).
Convection oven (primary oven only) .
Large oven: 4.6 cu. ft. oven cavity
–
27” W X 14” H X 21” D .
Small oven: 2.1 cu. ft. oven cavity
–
12” W X 14” H X 21” D.
Large oven fits 26” W X 18” D commercial size pans.
18,000 BTU infrared broiler behind glass (primary oven).
30,000 BTU primary oven for uniform baking.
15,000 BTU secondary baking oven.

Moto
-
Rotis™motorized rotisserie system (primary oven only).

Heavy
-
duty cast stainless steel rotisserie prongs.

Stainless steel rotisserie spit rod.

Flex
-
Roll™oven racks for smooth operation.
Adjustable rear casters for easy installation.
Adjustable front legs for easy leveling.
Titanium speck porcelain oven interior.
40
-
Watt bright oven lights.
5 Rack positions w/ 3 racks provided .
Broil pan provided.
1
-
1/4" diameter professional
-
style handle.
Heavy
-
duty oven door hinges.

Extra large viewing windows w/ embossed design.
SELF
-
CLEAN
CGSR484BG
48” RANGE
-
TOP FEATURES
48” SELF
-
CLEAN OVEN FEATURES
OTHER OVEN USES
OVEN MODES
Bake, broil, convection bake, convection broil, open
-
door broil rotisserie,
convection rotisserie, self
-
clean
Defrost, preheat, warm, slow cooking, normal thawing,
advanced thawing
(see use and care manual for details)
* Capital Exclusive Features

ALL BURNERS ARE RATED AT 23,000 Btu / hr to deliver intense
commercial kitchen heat to sauté food and all burners are capable of
turning down to give 145° F simmer.

Commercial Quality Broiler Grates With Cast Iron Grease Gutters.

Quality Cast Iron Grates and Burners Porcelain Coated

HYBRID RADIANTS With Ceramic Rods Encased in Stainless Steel Sheet Metal.

18,000 BTU Thermo
-
Griddle
-
Plate™
–
3/8" thick 12”Width Stainless steel
thermostatically controlled .

30,000 BTU Thermo
-
Griddle
-
Plate™
–
3/8" thick 24”Width Stainless steel
thermostatically controlled .

EZ
-
Glides™
–
Full extension removable drip trays mounted on ball bearing rails.

Stay
-
Cool™
–
Die cast, chrome plated metal knobs with Black Trims (cabernet red
optional)
Auto
-
ignition/re
-
ignition on all burners.

Stainless steel BBQ grill and griddle covers come standard.
Island trim included.
Oven Flex
-
Roll™
Motorized
Rotisserie System
12” or 24” Griddle
12” or 24” BBQ Grill
Cast Iron Wok Grate
Accessory
Power Burner
Large
Oven Capacity

Power
-
Flo OpenTop Burner
23,000 btus/hr
Optional Cabernet
red knobs
Capital exclusive feature:
Flex
-
Rolls oven racks
Large Oven Capacity
48” SELF
-
CLEAN GAS CONVECTION
AVAILABLE ACCESSORIES
0” clearance base cabinet installation
Field convertible to LP or NG depending on gas type
SHIPPING WEIGHT
ELECTRICAL RATINGS
VOLTAGE CURRENT/POWER
FREQUENCY
120 VAC 20 AMP 60 HZ
NATURALGAS
PROPANE
Manifoldpressure:
5.0" W.C.
10" W.C.
GAS RATINGS
OTHER
WARRANTY
650 LBS
Capital Cooking Equipment Inc.
13211 Florence Ave.
Santa Fe Springs, CA 90670
Phone: 562
-
903
-
1168
Toll Free: 866
-
402
-
4600
email: customerservice@capital
-
cooking.com
Made in the U.S.A.
Visit our web site:
www.capital
-
cooking.com
© 2010 Capital Cooking Equipment, Inc.
CGSR484GG
–
48"
Four
-
burner gas convection range
+ 24” Thermo
-
Griddle
CGSR484BB
–
48"
Four
-
burner gas convection range
+ 24” BBQ Grill
CGSR488
–
48"
Eight
-
burner gas convection range
CGSR484G2
–
48"
Six
-
burner gas convection range
+ 12” Thermo
-
Griddle
CGSC484B2
–
48"
Six
-
burner gas convection range
+ 12” BBQ Grill
CGSR484BG
–
48"
Four
-
burner gas convection range
+ 12 BBQ Grill + 12” Thermo
-
Griddle
Conversion kits
Birch wood chopping blocks
Cabernet Red knobs
P48SHS
–
18" stainless steel wall mount high shelf
P48SLB
–
9" stainless steel wall mount low back
CWR Cast Iron Wok ring
PSVH48L
–
48" Performance Series vent hood w/ 1200 CFM blower + lights
PSVH48HL
–
48" Performance Series vent hood w/ 1200 CFM blower + heat
lamps + lights
Duct covers
Simmer
turning down to give 145° F
ONE (1) Year full parts and labor covers entire product. (Light bulbs covered
for 60 days after installation)
FIVE (5) Years limited part replacement warranty. Covers part replacement,
as noted below, due to malfunction during normal operation.
Ranges*, Range Tops*, & Ovens*: All Burners, Heating Elements, Grates*,
Griddle Plates, & Oven Racks
Barbeques: Gas Valves & all burners (excluding infrared burners)
*Excludes Porcelain Enamel Coating for ovens and grates. Porcelain enamel is
prone to wear over time and use.
LIFETIME warranty (non
-
transferable) on stainless steel sheet metal body
parts against rust. (Excludes damage and normal heat discoloration). Does not
include barbeque grates.

Capital Cooking Equipment Inc.
13211 Florence Ave.
Santa Fe Springs, CA 90670
Phone: 562
-
903
-
1168
Toll Free: 866
-
402
-
4600
email: customerservice@capital
-
cooking.com
Made in the U.S.A.
Visit our web site:
www.capital
-
cooking.com
© 2010 Capital Cooking Equipment, Inc.
C A B I N E T P R E PA R AT I O N

Capital Cooking Equipment Inc.
13211 Florence Ave.
Santa Fe Springs, CA 90670
Phone: 562
-
903
-
1168
Toll Free: 866
-
402
-
4600
email: customerservice@capital
-
cooking.com
Made in the U.S.A.
Visit our web site:
www.capital
-
cooking.com
© 2010 Capital Cooking Equipment, Inc.
R A N G E & B AC K G U A R D D I M E N S I O N S
