CaptiveWorks CW-3000HD User manual

CW-3000HD
User Manual
Version 0.6
PAGE 1 BACK TO TOC

Safety Precautions
Electrical Safety
●To prevent electrical shoc hazard, disconnect the power cable from the electrical outlet
before relocating the system
●When adding or removing signal cables or devices from the system ensure that the
power cable is unplugged before doing so.
●See professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
●Do not attempt to repair or modify the power supply. Doing so could create the ris of
electrical shoc or fire.
Operational Safety
●Before operating the system, carefully read the manual that came with the system.
●Before using the system ensure that all cables are correctly connected and there is no
damage to the power or signal cables. If any damage is detected, contact the dealer
immediately.
●To avoid short circuits, eep paper clips, screws, staples and, other metallic devices
away from connectors and ventilation openings.
●Avoid dust, humidity and, temperature extremes. Do not operate the system in any area
that may become wet.
●Place the system on a stable surface
●Do not bloc ventilation holes in the system. The system requires ventilation to ensure
proper operation.
●If technical problems are encountered with the system, contact a qualified service
technician or the retailer where the product was purchased.
Table of Contents
System Specifications...................................................................................................................................6
Hardware................................................................................................................................................6
System Software......................................................................................................................................6
Multimedia Software................................................................................................................................7
Dimensions.............................................................................................................................................7
Pac age Contents.....................................................................................................................................8
System Placement....................................................................................................................................8
Remote Control Unit................................................................................................................................8
Cable Connections...................................................................................................................................9
Rev. 1.................................................................................................................................................9
Rev. 2..............................................................................................................................................10
DVB & ATSC..................................................................................................................................11
Rev 1...........................................................................................................................................11
Rev 2...........................................................................................................................................1
DUAL DVB.....................................................................................................................................13
Rev 1...........................................................................................................................................13
Rev 2...........................................................................................................................................14
PAGE 2 BACK TO TOC

Quic Start Guide.......................................................................................................................................15
System Bootup...........................................................................................................................................17
System Setup.............................................................................................................................................18
Main Menu...........................................................................................................................................18
Admin Menu....................................................................................................................................19
Updates Menu.............................................................................................................................. 0
Date........................................................................................................................................ 1
Downloading Updates..............................................................................................................
Adding And Editing An Updates Server............................................................................... 3
Installing Updates.................................................................................................................... 4
Chec ing System Version........................................................................................................ 5
Bac up Settings....................................................................................................................... 6
Restore Settings....................................................................................................................... 6
Configuration Menu..................................................................................................................... 7
Adapter Setup......................................................................................................................... 8
Display Setup.......................................................................................................................... 9
Size Setup..........................................................................................................................30
Timeout Setup....................................................................................................................31
Themes Setup.....................................................................................................................3
Networ Setup........................................................................................................................33
Audio Setup............................................................................................................................34
Storage Setup..........................................................................................................................35
Shared Folders........................................................................................................................37
Satellite TV Setup...................................................................................................................39
Weather Setup.........................................................................................................................40
Antenna Menu.............................................................................................................................41
Satellite Setup.........................................................................................................................4
Adding A Satellite..............................................................................................................44
Satellite Scanning...............................................................................................................45
Editing Channels............................................................................................................46
Motor Support....................................................................................................................47
ATSC Scanning..................................................................................................................51
Edit ATSC.....................................................................................................................5
Cable Scanning...................................................................................................................53
Edit QAM.....................................................................................................................54
Profiles Menu..............................................................................................................................55
Adding A Profile.....................................................................................................................56
Editing A Profile.....................................................................................................................57
Assigning Antenna Channels....................................................................................................58
Assigning IP Channels.............................................................................................................59
Configure IP Channels.............................................................................................................60
Add IP Channel..................................................................................................................61
Assigning Applications............................................................................................................6
PAGE 3 BACK TO TOC

System Operation.......................................................................................................................................63
Profiles.................................................................................................................................................63
Profile Applications..........................................................................................................................64
IPTV...........................................................................................................................................65
IPTV Channel Pac ages...........................................................................................................65
IPTV Channel Categories.........................................................................................................66
TV..............................................................................................................................................67
Navigating Through The On Screen Menus...............................................................................68
The Grid Program Guide..........................................................................................................69
The "Schedule" Menu..............................................................................................................70
Selecting A Channel................................................................................................................71
Selecting Audio Trac s............................................................................................................71
Instant Recording....................................................................................................................7
Pausing Live Video.................................................................................................................7
Replaying A Recording............................................................................................................73
Replay Control........................................................................................................................73
Editing Recordings..................................................................................................................74
Explained...........................................................................................................................74
Quic Mini-Howto..............................................................................................................75
Programming The Timer..........................................................................................................76
Video..........................................................................................................................................78
Video Selection.......................................................................................................................78
Video Viewer Keys.................................................................................................................80
Pictures.......................................................................................................................................81
Picture Viewer Keys................................................................................................................8
Web............................................................................................................................................83
DVD...........................................................................................................................................84
DVD Viewer Keys..................................................................................................................84
Music..........................................................................................................................................85
Music Player Keys...................................................................................................................87
Roaster........................................................................................................................................88
Prepare DVD..........................................................................................................................89
Prepare Video.........................................................................................................................91
Burn DVD..............................................................................................................................9
Burn Video.............................................................................................................................93
Games.........................................................................................................................................94
CD..............................................................................................................................................95
CD Player Keys.......................................................................................................................95
PAGE 4 BACK TO TOC

Appendix...................................................................................................................................................96
External USB Device Connection...........................................................................................................96
Keyboard / Mouse Connection................................................................................................................97
Networ ing With Windows PC's............................................................................................................98
Seeing Files Over The Networ .........................................................................................................98
Enabling More Shared Folders...........................................................................................................98
Playing Your Recordings Over The Networ ......................................................................................98
Remote Control - Keyboard Cross-reference...........................................................................................99
Troubleshooting.......................................................................................................................................100
Accessing Logs...................................................................................................................................100
BIOS Settings.....................................................................................................................................100
Display Diagnostics.............................................................................................................................101
Remote Control Diagnostics.................................................................................................................10
Roaster Diagnostics.............................................................................................................................10
Satellite TV Diagnostics......................................................................................................................103
Shared Folders Diagnostics..................................................................................................................104
Software License......................................................................................................................................106
Warranty Information...............................................................................................................................107
Technical Support....................................................................................................................................107
PAGE 5 BACK TO TOC

System Specifications
Hardware
●Processor:
●Sempron 3000+ 64Bit CPU AM2 Soc et (CW-3000HD rev. 1)
●Athlon X2 4000+ 64Bit CPU AM2 Soc et (CW-3000HD rev. 2)
●Memory: 512MB DDR2 RAM Expandable to 8GB
●Flash Drive: 1 GB System Flash
●Hard Drive: Not Included
●Video:
●Nvidia GeForce 6150 (CW-3000HD rev. 1)
●Nvidia GeForce 7050 (CW-3000HD rev. 2)
●Satellite Tuner:
○Input terminal: F-type 75 Ohm
○Receiving frequency: 950~2150 MHz tuning range
○Input level: -65~-25dBm
○Support MCPC and SCPC
○Symbol rate: 2~45 Msps
○FEC Codes: 1/2,2/3,3/4,5/6,7/8 and Auto
○QPSK
●ATSC Tuner
○Latest LG 5th generation tuner for enhanced reception
○Supports QAM 64 and QAM 256 Cable signals
○One TV antenna 75 ohm reception port
●Video Output: VGA/HDMI or DVI/Component/S-Video
●Audio Ouput: Analog and SPDIF Dolby Digital Audio output
●USB Ports: 4 USB v2.0 ports on bac panel and 2 USB v2.0 ports on front pane
●Media Reader: All In One Media Reader. Supports most popular flash cards
●Ethernet Port: RJ-45 10/100/1000 Mbits compatible
●DVDRW: Read/Write DVDs and CDs
System Software
●Linux Operating System based on 2.6.21 Kernel
●Graphical X-Windows Environment
●Java 1.4.2 Based Graphical User Interface
●Software Upgradeable Via Internet and/or USB Storage Device
●Networ sharing to Des top computers using Samba (3)
●All software is 100% Open Source with the exception of the Java user interface
PAGE 6 BACK TO TOC

Multimedia Software
●Satellite TV
○DVB-S Free To Air using Video Dis Recorder (VDR)
○ATSC Reception using Video Dis Recorder (VDR)
○Grid And List Style Electronic Program Guides (EPG)
○Customizable User Interface Through Themes
○Comprehensive Digital Video Recording Functionality - Stored on Hard Drive (1)
○Automatic Timer Recording For Series and Daily/Wee ly Programs (1)
○Pause Live TV With Full Fast-Forward and Rewind Capability (1)
○Timer Recording Through Program Guide (1)
●IP TV - Internet TV Streaming Video Player (2)
●P2P TV - Peer To Peer TV Streaming Video Player (2)
●Video - Viewer for popular video formats li e AVI, MPG and even DVD-ISO
●DVD – Viewer for DVD movie media
●Music - Player for popular audio formats including MP3 and WMA
●Pictures - Viewer with popular functions including Slide-show, Zoom and Rotate
●Roaster (1)
○Prepare DVD - Convert HD and SD recordings to DVD-ISO image
○Prepare Video - Create HD or SD MPG-ISO image of recordings
○Burn - Burn DVD-ISO and MPG-ISO images
○Bac up – Create bac ups of CD/DVD media (not currently active)
●Web - Mozilla web browser with support for popular plug-ins including Flash (2)(4)
●Games - Mame game support (1)(5)
●Expandable With Hundreds of Linux Applications
(1) Requires the addition of a Hard Drive.
(2) Networ connection with Internet access required.
(3) Internal networ connection to a PC through a router or crossover networ cable
required
(4) Requires eyboard and mouse
(5) Requires an external download and pac age installation
Dimensions
●The CW-3000HD is 14" wide by 5.5" tall by 15" deep Physical Installation
PAGE 7 BACK TO TOC

Package Contents
1. CW-3000HD Multimedia System
2. Remote Control Unit
3. A/V Connection Cable
4. Power Cable
5. (2) AAA Batteries for Remote Control Unit
6. CD containing system restore image and user manual
System Placement
●Place the system on a stable surface. The unit can be damaged or cause damage if it
were to fall to the floor.
●Place the system in a well ventilated area. The system will generate heat and needs to
have free air movement to eep internal devices from overheating.
●Do not bloc the vents in the case. This is required to allow for free air movement.
●Do not place the system on a carpeted surface. System needs to be on a solid surface.
●System should be placed close to the display device. Optionally, an Internet connection
and satellite feed should be in close proximity to the installation location to use IPTV
and satellite functions of the system.
●If system requires extension cables or cable installation, consult a qualified installer to
ensure signal integrity to the system.
Remote Control Unit
●The remote control unit is used to control all system functions.
●Do not allow the remote control unit to be used in a wet environment. Allowing the
remote control unit to become wet can damage the unit.
●Remove the battery compartment cover on the bac of the unit and insert the included
batteries the remote control unit paying close attention to the battery orientation pictures
inside the battery compartment.
PAGE 8 BACK TO TOC

Cable Connections
Rev. 1
●6 pin DIN Keyboard and Mouse connectors are for use with an optional eyboard/mouse.
●The 4 USB-2 connectors are for connecting external devices to the CW-3000HD. This
allows external USB memory stic s, DVD/CDROM drives, or other USB devices to be
used.
●RJ-45 Networ connector for standard 10/100/1000 connection.
●The green 1/8” mini-jac connector is the stereo analog audio output jac .
●The RCA composite connector is for use with a SDTV.
●The 4 pin DIN S-Video connector is suitable for SDTV.
●The RGB-Video analog connectors for VGA output for use on a suitably equipped HDTV
or computer style monitor.
●The 15pin D-Sub connector is a standard VGA output for use on a suitably equipped
HDTV or computer style monitor.
●The 24 pin DVI-D connector is suitable for 1920x1080P, 1920x1080i, 1280x720P HDTV.
NOTE: It is recommended to use a quality DVI cable no longer than 9 feet.
PAGE 9 BACK TO TOC

Cable Connections
Rev.
●6 pin DIN Keyboard and Mouse connectors are for use with an optional eyboard/mouse.
●The 4 USB-2 connectors are for connecting external devices to the CW-3000HD. This
allows external USB memory stic s, DVD/CDROM drives, or other USB devices to be
used.
●RJ-45 Networ connector for standard 10/100/1000 connection.
●The green 1/8” mini-jac connector is the stereo analog audio output jac .
●The RCA composite connector is for use with a SDTV.
●The 4 pin DIN S-Video connector is suitable for SDTV.
●The RGB-Video analog connectors for VGA output for use on a suitably equipped HDTV
or computer style monitor.
●The 15pin D-Sub connector is a standard VGA output for use on a suitably equipped
HDTV or computer style monitor.
●The 19pin Type-A HDMI connector is suitable for 1920x1080P, 1920x1080i, 1280x720P
HDTV.
NOTE: It is recommended to use a quality HDMI cable no longer than 9 feet.
PAGE 10 BACK TO TOC

DVB & ATSC
Rev 1
●Digital Audio RCA connector
●75 ohm DVB & ATSC reception ports
●Connect the satellite cable to the upper connector of the vertical connector pair. The
lower connector should have a 75 ohm F Terminator affixed.
(This is important to decrease interference and increase reception quality)
●Connect an antenna to the ATSC connector. It is the single connector.
PAGE 11 BACK TO TOC

DVB & ATSC
Rev
●Digital Audio Optical and RCA connectors
●75 ohm DVB & ATSC reception ports
●Connect the satellite cable to the upper connector of the vertical connector pair. The
lower connector should have a 75 ohm F Terminator affixed.
(This is important to decrease interference and increase reception quality)
●Connect an antenna to the ATSC connector. It is the single connector.
PAGE 12 BACK TO TOC

DUAL DVB
Rev 1
●Digital Audio RCA connector
●75 ohm Dual DVB reception ports
●For dual satellite connections the upper connector in each vertical pair should be
connected. The lower connectors should have 75 ohm F Terminators affixed.
(This is important to decrease interference and increase reception quality)
●For a single satellite connection connect the upper connector on the vertical pair closest
to the edge of the unit. In other words use DVB # 1
To fully utilize all the functions of the CW-3000HD you should have 2 satellite cables
connected to the unit. Both cables need to contain identical feeds.
(ie. You need a dual output LNB with 2 separate lines)
PAGE 13 BACK TO TOC

DUAL DVB
Rev
●Digital Audio Optical and RCA connectors
●75 ohm Dual DVB reception ports
●For dual satellite connections the upper connector in each vertical pair should be
connected. The lower connectors should have 75 ohm F Terminators affixed.
(This is important to decrease interference and increase reception quality)
●For a single satellite connection connect the upper connector on the vertical pair closest
to the edge of the unit. In other words use DVB # 1
To fully utilize all the functions of the CW-3000HD you should have 2 satellite cables
connected to the unit. Both cables need to contain identical feeds.
(ie. You need a dual output LNB with 2 separate lines)
PAGE 14 BACK TO TOC

Quick Start Guide
Owners are encouraged to read through this manual to get familiar with the CW-3000HD.
Here is a quic start guide for those who simply must dive in immediately.
1. Connect the receiver to your TV.
Only use 1 video connection between the CW-3000HD and the TV. The CW-3000HD is only
capable of displaying on 1 device at a time. Shutdown the CW-3000HD before changing the
video connection.
Analog audio is connected to the middle green 1/8" minijac on the bac panel. Digital audio
connection is via the RCA connector. You may connect these simultaneously.
2. Connect the Satellite and or Antenna connections.
Satellite and ATSC tuner system:
Connect the satellite cable to the upper connector of the vertical connector pair. Connect
an antenna to the ATSC connector. It is the single connector.
Dual satellite tuner system:
To fully utilize all the functions of the CW-3000HD you need to have 2 satellite cables
connected to the unit. Both cables need to contain identical feeds.(ie. You need a dual
output LNB with 2 separate lines) The upper connector in each vertical pair should be
connected. For a single cable connection you should connect the upper connector on the
vertical pair closest to the edge of the unit.
3. Connect the networ connection.
4. Start the system. The first screen you will see is the adapter settings screen. It is important
that you disable any adapters that do not have an antenna connection. Failure to do so will
result in erratic channel changes.
5. The second screen will be the display settings screen. IT IS EXTREMELY IMPORTANT
THAT YOU SET THESE SETTINGS CORRECTLY. Incorrect settings here may cause you to
not be able to view anything but a blac screen!.This setting also chooses a video calibration
setting that is tailored for the output that you use. Changing the display connection requires
changing this setting to get the correct display calibration.
6. The next screen will be to set the system time. Set it correctly.
7. Restart the system for the display settings to ta e effect. That means press the power button
on the remote and then press the yellow button to restart.
PAGE 15 BACK TO TOC

8. Chec for any system updates. Enter the admin profile. Highlight updates and press enter.
Highlight system and press enter. Ma e note of the current version of the software on your
system. Bac out to the updates screen and highlight download. Press enter. Highlight the
chec button and press enter. Compare the update version to your system version. If the update
is newer download it. (For those with no networ connection, you may use your browser to
chec ftp://ftp.captivewor s.org/cw3000hd for the update file.)
Install the update. Instructions are available in the announcement for the update on the
Technical Support forum found at http://captivewor s.org.
9. Setup for channels. Enter the admin profile and choose Antenna. Choose satellite or ATSC.
ATSC: (If you don't have an ATSC system, don't bother. It won't wor .) The ATSC area
allows you to scan for channels. Ma e sure you have a good antenna connection to the ATSC
antenna connector and press the green button to begin scanning. This will configure the
channels available to you. Press the blue button to save the list when the scan is finished. If you
would li e to change the channel numbers you may press the yellow button for Channels and
renumber them as you see fit.
Satellite: If you use a switch, choose your switch type. This will enable either 2 or 4 of the
positions depending on the switch you choose. Choose the LNB types connected to the switch
and then choose the satellite the LNB is aimed at. If you wish to separate the satellites you can
add an offset to the channel numbers so you may find each sats channels quic ly and prevent
overlapping channel numbers. You may set that under edit. 10000 is generally a good number
to separate each satellite or provider. Once all is configured clic the SAVE button. Next you
may scan each satellite you wish to view. Each satellite needs to be scanned separately. Press
the blue button to save the results of the scan.
10. Ma e sure the channels are available in the user profile. Enter the admin profile. Highlight
profiles and press enter. Highlight channels and press enter. Ensure that all the channels you
would li e are in the selected column. You may also remove any unwanted channels if you
choose.
11. At this point you should be ready to enter the user profile and explore what all is available.
PAGE 16 BACK TO TOC

System Bootup
●When first powering on the CW-3000HD you will be presented with this type of a screen.
This is what is called the bios splash screen.
●After the bios splash screen another screen much li e the first will be presented.
(approx. 15-20 seconds unless the files system needs scanning)
PAGE 17 BACK TO TOC

System Setup
System Remote Buttons
Remote buttons in GUI screens are as follows:
Up/Down = Move up or down on large buttons or, change values in setup screens
Left/Right = Move from item to item in setup screens
Channel up/down = Scroll up and down a page at a time
Enter = Select item highlighted
Erase (←) = Bac space
Bac = Move bac to previous screen
Red = Context button on bottom of screen
Green = Context button on bottom of screen
Yellow = Context button on bottom of screen
Blue = Context button on bottom of screen
Numbers = Numbers or letters in text entry areas. The numbers wor li e a cell phone.
The letters for each number are below the number on the remote.
Main Menu
NOTE: CW-3000HD will not function without complete initial setup.
●Admin – Section for profile setup and system configuration.
●user – The built in initial profile
PAGE 18 BACK TO TOC

Admin Menu
Choose Admin from the main screen.
When prompted for a pin, enter 1111 (default pin) and press the blue button.
This will bring up the Admin screen where the majority of the system configuration will ta e
place.
●Updates - System software update download and installation
●Configuration – Configuration menu
●Antenna - Antenna setup menu
●Profiles - User profile creation and setup
PAGE 19 BACK TO TOC

Updates Menu
One of the first things anyone with a new product that includes an update mechanism should do
is download and install the latest update. This allows the owner to get the latest features and the
improved stability of software refinements.
System updates for the CW-3000HD can be installed from the Admin screen.
Press enter on the Updates button to enter the updates screen.
●Date: Allows users to set date, time and time zone.
●Download: Allows the user to chec for and download updates from the Internet.
●Install: Allows the user to install updates downloaded from the Internet
or updates stored on external media.
●System: Shows installed software version information.
●Bac up: Allows the user to create a hard copy of their settings by burning them to disc.
●Restore: Allows a user to restore their settings from a restore disc.
PAGE 20 BACK TO TOC
