Car-Interface CI-DAB-MMI2G User manual

www.car-interface.com
2. Uruchomienie
USER MANUAL
AUDI MMI 2G
1. Introduction
CI-DAB-MMI2G device is a DAB/DAB+ radio receiver. It is
designed to receive digital radio stations in vehicle equipped with
digital sound system. CI-DAB-MMI2G supports the "following
service" function.
To start listening of digital radio stations from DAB/DAB+ radio
receiver, press the RADIO button 1 and next press the SOURCE
button 2 on MMI control panel. Then using main knob
system select Digital Radio DAB from list.
3 of MMI2G
fig.1 fig.2
DAB+/DAB Radio for CAR
CI-DAB-MMI2G
2
1
3
1

www.car-interface.com
3. Selecting and changing
3. Searching process
WARNING!
At first start up of device run a SCAN function to search new stations
and add them to list, using main knob of MMI2G system.
fig.3 fig.4
After scan process finish, system shows list of available radio services
(fig.5). To select next or previous service use main knob of MMI2G
system or buttons under the knob (fig.6).
Sample list of available radio stations fig.5
fig.6

www.car-interface.com
3. Service Following
The CI-DAB-MMI2G device is equipped with the Service Following
function for automatic tracking of the selected radio station within the
digital
transmitters area DAB/DAB+. An additional option is the ability to activate
the function in the MMI unit allowing automatic switching of the selected
radio station to receive from FM transmitters after DAB/DAB+ digital
signal loss. Radio automatically will return to digital reception when it
recovers DAB/DAB+ signal.
fig.7
fig.8
An example of the operation of the Service Following function
fig.9
