Car Solutions Dension Gateway 100 User manual

Remove antenna and wiring connector
Connect GW 100/300 to the cable harness
Connect iPod connector and USB/AUX
Test and ret
All photos/illustrations are for representation purposes only and may dier
visually from the equipment in your vehicle. Information correct at time of
going to print E. & O. E. Dension Audio Sytems Ltd. and it’s registered partners
cannot be held liable for any damages caused by the incorrect installation of
any Dension product.
Once the head unit has been removed, disconnect the antenna cable (1),
then unclip the main wiring connector from the head unit (2). This again,
will dier in all makes and manufacturers.
With the main radio cable removed, rst connect the Dension supplied
cable to the original factory cable harness.
In some cases there may be an add-in connector. Remove the CD changer
section and replace with the loom supplied with the GW100/300. Turn
page over for car-specic connections.
CD Changer Retention Kits are available which will allow you to keep the full
functionality of your existing OE CD Changer (manufacturer specic). Visit
www.dension.com for more details.
Need more help? Please visit www.dension.com/support
Before you ret the head unit, test the GW100/300 with your car
audio, making sure all connections are correct and that you have full
functionality.
Note: If during testing you notice any changes or inconsistencies in
the way the car’s electrical system operates, disconnect the Gateway
product immediately and consult your dealer.
When you have tested everything, ret your head unit. Take care not to trap
any wires or the Dension product. Ret is the reversal of the removal process
for your specic vehicle, as per your manufacturer’s instructions.
Note: There will be a free black wire on the Dension wiring harness.This
must be connected to the vehicle Ground for safe operation.
Warning! Do not trap the cables, or leave them in a position where they
may become trapped after retting the head unit.
Connect the round iPod connector and USB (GW300 only)/Aux cables to
the GW100/300 and feed them through the dashboard to an appropriate
location.
Ensure the device is correctly tted before running the cable. Then,
reconnect the Dension supplied main radio connector to the rear of the
head unit.
2
3
5
4
Need more help? Please visit www.dension.com/support
The Dension Gateway (GW) 100/300 emulates a CD changer and uses CD
changer controls to access audio sources including iPod, USB devices and
Dension GW accessories.
In some cases, you will be able to view full artist/album/song information
on your head unit display and if you have one, dashboard cluster display.
This may also allow you to view full text and menu selection but please be
aware that this will not always be the case. Each model and manufacturer
will dier. Please consult your head unit’s user manual for more
information.
Warning! Always make sure that your vehicle’s battery is disconnected
before beginning installation and that you have your head unit’s (ra-
dio’s) security code (if applicable).
Introduction
Remove the head unit
First, carefully remove your vehicle’s existing OE head unit as per the factory
instructions and using the correct tools.
In some cases, removing the head unit will require panel removal. Contact
your vehicle’s dealer or installation supplier/installer for more information.
1
Need more help? Please visit www.dension.com/support
[email protected]
car-solutions.com
car-solutions.com

3. 4.
If the CDC connector has separated housing:
Cars with mini ISO connector:
Cars with quadlock connector
(break-in):
BMWs with 17-pin connector:
1. 2. 3.
1. 2.
3. 4.
1. 2.
5. 6.
5.
4.
Cars with quadlock connector (not break-in):
1. 2.
5. 6.
3.
Car-specic connections
6
