Car Solutions Video Interface User manual

Warning
When installing the main unit, do not remove or alter existing
vehicle fasteners, including nuts, bolts, screw, clips, and fittings.
Never detach, move or alter existing vehicle wiring, including
electrical grounds and straps. Alteration of existing vehicle
components may make vehicle unsafe to operate. Should be
no any electronic devices or magnetic pole around installation
place.
Air bags are vital part of a safety system. Never install main unit
in a way which will alter air bag wiring or interfere with air bag
deployment. Air bags must function properly in the event of an
accident.
Before installing, check the location of pipe, tank, electrical
cables and others.
ead and follow the instruction manual.
Wiring location must not interfere driving, get in or out from car.
Use electrical tape to insulate the ends of all wires, even if they
are not used. Proper insulation prevents arcs, shocks and fires.
When installation is complete, test all vehicle electrical systems
to ensure they operate correctly, including lights, horn, brake
lights, and emergency flashers.
According to our sales policy, any problems caused by user’s
mistake, careless can not be guaranteed.
Caution
All steps of installation should be done by well-trained specialist.
During installation ignition key should be taken off and after all
installation finish connect power cable with interface for the last step.
Do not install the main unit in places where it ma be exposed to dew
condensation (around the air conditioning hose, etc), or in locations
where it may come in contact with water, high levels of moisture, dust
or oily smoke
Install wiring in a manner in which cables will not come in contact with
metal parts. The wiring may be damaged by contact with metal parts,
resulting in fire and shocks. Avoid all contact with hot surfaces when
wiring the main unit. High temperatures may damage wiring, causing
shorts, arcing and fires.
Kindly check all parts are in the box, when receiving the product, if
anything missing, inform to the supplier or manufacturer.
Warning / Caution
www.car-solutions.com
Car-Solutions.com

Table of Contents
1. Specifications
1.1 Main Specifications
1.2 Functions
1.3 System Diagram
1.4 Components
1.5 Exterior
2. Installation
2.1 Installation Diagram
2.2 Installation
2.3 CAN wire Installation
3. Settings
3.1 DIP Switch
3.2 emote Control
3.3.1 Parking guidelines/3D PDC
3.3.2 PIP(picture in picture)
3.3.3 Factory Mode -IMAGE, PA K
3.3.4 Factory Mode – UTIL 1
3.3.5 Factory Mode – UTIL 2
3.3.6 Factory Mode – INFO
3.3.7 Factory Mode – OSD Analog GB
3.3.8 Factory Mode – OSD Video
4. Trouble Shooting
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
19
20
21
22
www.car-solutions.com
Car-Solutions.com

1. Specifications
-1-
1.1 Main Specifications
1. Car Compatibility
Volvo S 0, XC 0 2015 year
2. Components
Interface* 1EA
3. MULTIMEDIA INTE FACE input specification
3 * A/V input (video external input)
1 * CVBS( ear Camera) input
2 * Analog GB input (Navigation system, HDMI)
1 * LCD input (Car system input)
4. MULTIMEDIA INTE FACE output specification
1 * LCD output
5. Power specification
Input power : 8VDC ~ 18VDC
Consumed power : 5WATT
www.car-solutions.com
Car-Solutions.com

1. Dynamic PAS(Parking assistance system)+3D PDC(Parking
distance control)
- moving parking line according movement of steering
wheel
- Front / ear car distance sensor display in external mode
2. Support PIP display – showing sources at the same time
(Picture in Picture)
1. Specifications
1.2 Functions
-2-
www.car-solutions.com
Car-Solutions.com

1. Specifications
-3-
1.3 System Diagram
DIS LAY
A/V 1
NAVIGATION Input
(Analog RGB)
CVBS
(Rear camera)
Car Screen Input
(CAR MAIN BOARD)
A/V 2
A/V 3
VIDEO
CI CUIT
VIDEO MUX
MCU
ower Input
(+8VDC ~ +18VDC)
POWE
CI CUIT
Dip S/W
A/V OUT HEADREST
MONITOR
Remote control Switch for source toggle
OEM Button (Can Signal)
Car Installation
OEM LCD
Rear Camera ower
(+12 VDC)
HDMI Input
(Analog RGB-2)
www.car-solutions.com
Car-Solutions.com

1.4 Components
1. Specifications
-4-
AV cable * 1ea
TOUCH OUT cable * 1ea EA CAME A
POWE cable * 1ea
(HA ETC0002)
(HAVCAB0002)
MODE cable * 1ea
(HA ETC0001)
GB_IN cable(9P) * 1ea
(H GBCA0013)
I cable * 1ea
(HI CAB0002)
(HTOUCH0004)
7P POWE cable * 1ea
(HTOUCH0068)
LVDS IN/OUT cable * 1ea
(HLCDCA0028)
TOUCH IN cable * 1ea
(HTOUCH0009)
www.car-solutions.com
Car-Solutions.com

① ⑥ ⑦
⑨
⑩⑪
② ③ ④ ⑤
⑫
-5-
Dimension
Width 164mm
Length 91mm
Height 19mm
①MODE
②I
③POWE
④TOUCH OUT
⑤EA
⑥GB-IN(HDMI)
⑦GB-IN(NAVI)
⑧AV/INOUT
⑨LVDS IN
⑪TEST
⑩T/S-IN
⑫LED
1. Specifications
1.5 Exterior
⑧
⑬
⑬ DIP S/W
www.car-solutions.com
Car-Solutions.com

2. Installation
-6-
2.1 Installation Diagram
※ Pl ease connect ACC cabl e t o B+ cabl e
R
E
A
R
(9V O
U
T)
G
N
D
AV1
AV2
AV3
EA C
Audio L
Audio
AV/OUTVideo
EA -C
N.C
N.C
ACC
CAN-L
CAN-H
GND
COMMAND
MONITOR
Supplied LCD IN
Supplied LCD OUT
OEM LCD Cable
www.car-solutions.com
Car-Solutions.com

3. Settings
-9-
3.1 DI Switch
PI N
PI N Funct i on
Funct i on
Dip S/W Selection
Dip S/W Selection
1Displaying GB input ON : RGB mode ski p
OFF : RGB mode di spl ay
2Displaying A/V 1 ON : A/V 1 mode ski p
OFF : A/V1 mode di spl ay
3Displaying A/V 2 ON : A/V 2 mode ski p
OFF : A/V2 mode di spl ay
4Displaying A/V 3 ON : A/V 3 mode ski p
OFF : A/V3 mode di spl ay
5, Sel ect Car model 5-ON, -OFF : V40
5, -OFF : S 0, XC 0
7Setup of rear camera use ON : CVBS4
OFF : MAI N
8no use
※Example DIP S/W usage
- Use input mode : A/V2, A/V3
- Use original navigation
- External rear camera
▷DIP S/W : 1 ON (hide INPUT MODE)
▷DIP S/W : 2,3 OFF (A/V1,2 display)
▷DIP S/W : 4 OFF (A/V3 display)
▷DIP S/W : 5 ON/OFF
▷DIP S/W : 6 ON/OFF
▷DIP S/W : 7 ON (display external rear cam)
▷DIP S/W : 8 OFF
※ON : DOWN / OFF : U
Default: #8 OFF
www.car-solutions.com
Car-Solutions.com

3. Settings
-10-
3.2 Remote Control
Key
Key Funct i on
Funct i on
POWER Unavailable
PI P A/V 1~2 Mode : emote control UI Display
HDMI, A/V 3 Mode : Mode switching UI Display
MENU Activating OSD menu
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can access the factory
mode.)
▶
Moving rightward
(If you press this button 2 seconds long, you can reset all the
data about user environment.)
www.car-solutions.com
Car-Solutions.com

3. Settings
-11-
3.3.1 Rear parking guidelines
< Rear camera full screen >
< I screen >
☞ Mode swi t ches :
NAV but t on :
- Long Pr ess
( Swi t ch t o ext er nal
mode)
- Shor t Pr ess
( Swi t ch t o OEM mode)
☞ Change t he si ze of i mage : Pr ess CAM but t on i n Rear mode.
www.car-solutions.com
Car-Solutions.com

3. Settings
-12-
3.3.2 I ( icture in icture)
< Before Approaching objects>
< After Approaching objects>
- PI P i mage wi l l be shown as above.
(Car without Front sensor : Not applicable)
www.car-solutions.com
Car-Solutions.com

3. Settings
-13-
3. Settings
3.3.3 FACTORY MODE-IMAGE, ARK
Adjust navigation position and size
H-POSITION : Move display horizontally
V-POSITION : Move display vertically
FACTORY mode – ress button 2 seconds long on the remote control.◀
ARK
PAS TYPE : Selecting Type of parking guide line
- NOT USED : Not use Parking guide line
- PAS ON : Selecting Dynamic Parking guide
line
- PAS OFF : Selecting fixed Parking guide line
PAS SETUP : Adjusting the position of the parking
guide line
EA TYPE : Choose rear camera recognition
* LAMP - Detecting the rear view camera
via rear lamp (Installer must connect “ ear-C”
cable of the power cable to the rear lamp of
the car.)
*CAN - Detecting the rear view camera by
CAN signal (Installer must connect “CAN” cable
of the power cable to the “CAN” cable of the
car.)
SAFE ENABLE : If your car is connected with CAN
cable and it is in ”ON” state, you can NOT
watch DVD or A/V except original image or
navigation while driving. At that time the screen
get back to the main (default : OFF)
ADA ENABLE : When set the gear to “ ”,
Display PDC
www.car-solutions.com
Car-Solutions.com

3. Settings
-14-
3.3.4 FACTORY MODE-UTIL1
FACTORY mode – ress button 2 seconds long on the remote control.◀
UTIL1 – NAVI MODEL
Definition of the navigation
resolution
DEAFULT
NAV-506TP
MYVI
WP9200
HDMI
GI-8000N 3D
GI-5000A
I-ONE
KD-900
PAPAGO
LS-901
* Go into FACTORY/ IMAGE (as
shown right) and adjust the
position and the size of the
navigation after setting the
definition of the navigation
Setup for navigation
UTIL1 - CAR MODEL
Selecting model of the car
Volvo
Setup for car model
HDMI SKI
HDMI SKI
HDMI SKI
HDMI SKI
www.car-solutions.com
Car-Solutions.com

3. Settings
-15-
3.3.4 FACTORY MODE-UTIL1
FACTORY mode – ress button 2 seconds long on the remote control.◀
UTIL1 – AVOUT SELECT
Selecting background sound
After
returning navigation or original
mode
DEFAULT : Selecting AV sound
just before changing
navigation or original mode
from the AV mode
AV 1~3 : Sound of the selected
AV source 1~3
UTIL1 - FACTORY RESET
FACTO Y MODE ESET
UTIL1 – HDMI SKI
Selecting whether to use
HDMI function or not
ON(Not use) / OFF(use)
HDMI SKI
HDMI SKI
HDMI SKI
www.car-solutions.com
Car-Solutions.com

UTIL2 – IR MEMORY
To register DVD, DTV remote control, the
remote control value must be registered
and can be control with Jog shuttle
DVD(A/V1), DTV(A/V2)
※To use this function, in UTIL2-I_D V
EMOTE select USE mode
DVD / DTV
3. Settings
-16-
3.3.5 FACTORY MODE-UTIL2
FACTORY mode – ress button 2 seconds long on the remote control.◀
UTIL2 - I_DRV CONTROL
Selecting whether to use I_D V
function or not
ON / OFF
A/V1 : Control DVD emote control UI
A/V2 : Control DTV emote control UI
UTIL2 - I_DRV REMOTE
Choose DTV and DVD model
to be control I_D V function
LI-1DISC
NEC-6DISC
USE (when using I MEMO Y)
•Select DVD model: Setting on
AV1 Mode
•Select DTV model : Setting on
A/V2 mode
UTIL2 – CALIBRATE
Touch Calibration
YES / NO
www.car-solutions.com
Car-Solutions.com

3. Settings
-17-
3.3.5 FACTORY MODE-UTIL2
①First of all, press button on ◀
remote controller 2 seconds
long or press
UP→DOWN→UP→MENU button
in order to access Factory
mode. Choose I MEMO Y on
UTIL2.
In I MEMO Y, you can choose
AV source of DTV and DVD you
want to use.
②Picture above shows DVD
remote control button value
input, select menu you want
to save. (To register DVD
remote control button value,
select I MEMO Y – DTV and
follow below instructions.
Example)
a. After select OK button on
OSD menu, press intended I-
Drive button
b. Indicated part above will
flicker, and press POWE on
DVD remote control.
(continue to next page)
FACTORY mode – ress button 2 seconds long on the remote control.◀
What is IR-MEMORY Mode?
Is to allow Jog shuttle and touch screen to control other DVD or DTV
(besides the existing,; for example : SANYO, NECVOX) by register
remote control value.
UTIL2 – IR MEMORY
www.car-solutions.com
Car-Solutions.com

3. Settings
-18-
3.3.5 FACTORY MODE-UTIL2
③After register, select “S C” button
in OSD menu. Then you can see
confirmation window as shown
above. At the moment,
(If data is saved, DVD TYPE and
DTV TYPE will be changed to
“USE ” automatically.)
If you see “SUCCESS” on screen, the
data is saved clearly and you can
control DVD via touch screen. BUT,
you MUST change the option in
FACTO Y-UTIL2-I_D V EMOTE to
“USE ”.
※ When t ouch t he scr een or Sel ect PI P but t on i n r emot e cont r ol l er , you
can
cont r ol DVD, DTV usi ng r emot e cont r ol UI vi a t ouch scr een or Jog
shut t l e
※ DVD( A/V1) , DTV( A/V2) mode, Can see r emot e cont r ol UI
HDMI , A/V3 mode, Can see mode swi t chi ng UI
- I f you want t o see mode swi t chi ng UI i n DVD, DTV mode, Sel ect “ SRC”
but t on
FACTORY mode – ress button 2 seconds long on the remote control.◀
UTI L2 – I R MEMORY
Instruction> continued…
c. The values that you
registered will appear as green
text in the marked area on
pressing the button. And the
values will be saved
automatically.
d. egister remain buttons’
value in OSD menu like the
above-mentioned.
www.car-solutions.com
Car-Solutions.com

3. Settings
-19-
3.3.6 FACTORY MODE-INFO
FACTORY mode – ress button 2 seconds long on the remote control.◀
I NFO
Check mai n ver si on and Tr i p ver si on
www.car-solutions.com
Car-Solutions.com
Other manuals for Video Interface
1
Table of contents
