Car Solutions ROiK User manual
- MODEL : ROiK
ROiK GPS BOX MANUAL
- DATE : 2016.04.25
Car-Solutions.com
www.car-solutions.com
1. Main Spec.
OS : Android 5.0.2(Lollipop)
CPU : NXP4330Q - Cortex-A9 Quad Core @1.4Ghz Mali-400 MP4 GPU
Internal Memory : 1GB DDR3 @800Mhz + 8GB eMMC (NAND)
SD Card : 8GB (SDHC Class10, Max 32GB support, FAT32)
USB : USB2.0 High Speed Port x 2
Signal : 802.11 b/g/n WiFi, Bluetooth 4.0
GPS : Ublox7
Touch : Resistor and Capacitive touch support
RGB : 800x480
Speaker : 2W
FM Transmitter : 88.0Mhz~108.0Mhz
I/O : AV IN, Stereo Audio Out
Voltage: DC 12V ~ 24V
Temperature : Storage -20 C ~ +80 C/ Operating -15 C ~ +70 C
Size: 122mm(W) x 88mm(H) x 23mm(D)
Weight : 160g
Car-Solutions.com
www.car-solutions.com
2. Dimension
122mm(W) x 88mm(H) x 23mm(D)
122mm
23mm
88mm
Car-Solutions.com
www.car-solutions.com
3. External Appearance - 1
POWERRGB OUT
GPS
DIP SW AV IN/OUT
USB1USB2KEYSD SLOT
WIFI/BT
DEBUG
Car-Solutions.com
www.car-solutions.com
4. External Appearance - 2
POWER RGB OUT DIP SWAV IN/OUT
USB1 USB2 KEY SD SLOT
DEBUG GPS WIFI/BT
Car-Solutions.com
www.car-solutions.com
5. Power Connector Pin Assignment
BAT(Battery Power)
GND
ACC 12V IN
1
2
3
1 2 3
Car-Solutions.com
www.car-solutions.com
6. RGB OUT Connector Pin Assignment
1 2 3 4 5 6 7
Red
Green
Blue
1
2
3
C-Sync
GND
NC
4
5
6
NC7
Car-Solutions.com
www.car-solutions.com
7. AV IN/OUT Connector Pin Assignment
531 97 151311 1917
642 108161412 2018
2321
2422
Speaker +
AUX OUT R
AUX OUT L
Capacitive Touch SCL
Capacitive Touch SDA
Capacitive Touch Interrupt
Touch X-
Touch X+
UART TX
UART RX
AVIN
NC
1
3
5
7
9
11
13
15
17
19
21
23
Speaker -
GND
GND
GND
Capacitive Touch 3.3V
Capacitive Touch Reset
Touch Y-
Touch Y+
MIC +
MIC -
GND
FMT ANTENA
2
4
6
8
10
12
14
16
18
20
22
24
Car-Solutions.com
www.car-solutions.com
8. Product Composition
GPS Box Power Cable AV Cable RGB OUT Cable External GPS
Antenna
Resistive Touch
Cable Speaker SD Card WiFi/BT
Antenna
Capacitive Touch
Cable
Car-Solutions.com
www.car-solutions.com
9. DIP S/W Setting
ON 1 2
ON 1 2
ON 1 2
ON 1 2
* ON : DOWN, OFF : UP
PIN
1
2
OFF
Resistive Touch
ON
Capacitive Touch
RGB 800X480 RGB 480X234
Use Resistive Touch
RGB 800X480
Use Resistive Touch,
RGB 480X234
Use Capacitive Touch
RGB 800X480
Use Capacitive Touch
RGB 480X234
Car-Solutions.com
www.car-solutions.com
VIDEO INTERFACE
RGB IN
ACC 12V
Capacitive touch
Speaker
GPS
AUX OUT
VAV IN
10. Install Manual - Capacitive touch
L
R
+ -
Car battery
Car-Solutions.com
www.car-solutions.com
VIDEO INTERFACE
RGB IN
ACC 12V
Speaker
GPS
AUX OUT
VAV IN
11. Install Manual - Resistive touch
L
R
+ -
Car battery Resistor touch
Car-Solutions.com
www.car-solutions.com
12. Calibration –Resistive touch
Push button 8~10 sec after booting
Calibration mode After calibration, push screen few second
* Capacitive touch panel no need set calibration
Car-Solutions.com
www.car-solutions.com
13. Device Settings
Analog RGB Setting : RGB 800x480 or 480x234 screen change size and position
FMT Setting : Setting FM frequency
External Speaker : Turn on/off external speaker
Softkey Position : Change HOME Menu button position to Right or Left
Startup App : Select Startup APP
Music Play on Booting : Select booting startup sound
Touch Calibration : Set resistive touch calibration. (No need to set Capacitive touch panel)
Initialization : Reset Device Settings
Car-Solutions.com
www.car-solutions.com
14. FMT Settings
FM Transmitter On/Off or select FM frequency.
Button + , - change FM frequency by 0.05Mhz FM.
Car-Solutions.com
www.car-solutions.com
15. Firmware Upgrade
Copy ‘system_up’ folder to SD Card root and insert to GPS.
Push hold this button and turn on (connect power cable), it will start upgrade
*‘/sdcard/system_up’ Folder have ‘partmap.txt / boot.img / root.img’ files
