Cardinal RD3 User manual

8200-M063-O1 Rev C RD3 Installation and Technical Manual
1
RD3
Remote Display
Installation and Technical Manual

8200-M063-O1 Rev C RD3 Installation and Technical Manual
2

8200-M063-O1 Rev C RD3 Installation and Technical Manual
3
TABLE OF CONTENTS
INTRODUCTION …………..………….....................................
Page 1
SPECIFICATIONS …….……..………………….......................
Page 1
FEATURES ……………………..……………..........................
Page 1
IN
DICATOR COMPATIBILITY
….…………..……......................
Page 1
AUTO-FORMAT FEATURE ………..…………….......................
Page 2
SITE PREPARATION ….………..………….…….....................
Page 2
SINGLE AND MULTIPLE DISPLAYS …………..........................
Page 3
INSTALLATION …………..…………………..…......................
Page 3
Unpacking ……………………………………………………
Page 5
Mounting the RD3 Display ….....…………............................
Page 5
Installing the Wall Bracket ….…....………............................
Page 5
SERIAL CABLE INSTALLATION …………..…...........................
Page 6
Cable Installation ..…………………….…............................
Page 6
RS232 Wiring
…….....…………………….…......................
Page 7
20mA Current Loop Wiring .……..………...…......................
Page 7
CURRENT Cardinal Indicators 20mA Current Loop Connections ....
Page 8
LEGACY Cardinal Indicators 20mA Current Loop Connections …...
Page 10
DISPLAY BOARD …………………………………....................
Page 12
Jumpers ….…………..…..................................................
Page 13
Switches …………..……….....…………..…......................
Page 13
Status LED …….………..……………..…..........................
Page 13
Connectors …….....……..……………..…..........................
Page 13
SETUP AND CONFIGURATION …………..…...........................
Page 14
RE
-INSTALLING THE FRONT PANEL
…....……........................
Page 16
ERROR AND STATUS DISPLAYS …...…..……........................
Page 16
PARTS IDENTIFICATION …..……………..…..........................
Page 17
Final Assembly …………..……………..…..........................
Page 17
Rear Sub-Assembly …………..………..…..........................
Page 18
Front Sub-Assembly …………..………..…..........................
Page 20
PRECAUTIONS
Before using this instrument, read this manual and pay special attention to
all "WARNING" symbols:
IMPORTANT
ELECTRICAL
WARNING
STATIC
SENSITVE
I

8200-M063-O1 Rev C RD3 Installation and Technical Manual
4
Static Electricity Precaution
CAUTION! This device contains static-sensitive circuit cards and components.
Improper handling of these devices or printed circuit cards can result in damage to
or destruction of the component or card. Such actual and/or consequential damage
IS NOT covered under warranty and is the responsibility of the device owner.
Electronic components must be handled only by qualified electronic technicians who
follow the guidelines listed below.
WARNING! ALWAYS use a properly grounded wrist strap when handling, removing,
or installing electronic circuit cards or components. Make certain that the wrist strap
ground lead is securely attached to an adequate ground. If you are uncertain of the
quality of the ground, you should consult a licensed electrician.
ALWAYS handle printed circuit card assemblies by the outermost edges.
NEVER touch components, component leads, or connectors.
ALWAYS observe warning labels on static protective bags and packaging and never
remove the card or component from the packaging until ready for use.
ALWAYS store and transport electronic printed circuit cards and components in anti-
static protective bags or packaging.
FCC Compliance Statement
This equipment generates uses, can radiate radio frequency, and if not installed and used in
accordance with the instruction manual, may cause interference to radio communications. It
has been designed within the limits for a Class A computing device pursuant to Subpart J of
Part 15 of FCC rules to provide reasonable protection against such interference when
operated in a commercial environment. The operation of this equipment in a residential area
may cause interference, in which case the user will be responsible for taking whatever
measures necessary to correct the interference.
You may find the booklet “How to Identify and Resolve Radio-TV Interference Problems”
prepared by the Federal Communications Commission helpful. It is available from the U.S.
Government Printing Office, Washington, D.C. 20402. The stock number is 001-000-00315-4.
Copyright
All rights reserved. Reproduction or use, without express written permission, of editorial or
pictorial content, in any manner, is prohibited. No patent liability is assumed concerning the
use of the information contained herein.
Disclaimer
While every precaution has been taken in the preparation of this manual, the Seller assumes
no responsibility for errors or omissions. Neither is any liability assumed for damages resulting
from the use of the information contained herein. All instructions and diagrams have been
checked for accuracy and ease of application; however, success and safety in working with
tools depend to a great extent upon individual accuracy, skill, and caution. For this reason, the
Seller is not able to guarantee the result of any procedure contained herein. Nor can they
assume responsibility for any damage to property or injury to persons occasioned from the
procedures. Persons engaging in the procedures do so entirely at their own risk.
II

8200-M063-O1 Rev C RD3 Installation and Technical Manual
1
INTRODUCTION
Thank you for your purchase of our Cardinal RD3 Remote Display. It was built with Cardinal
quality and reliability. This manual will guide you through the installation, and operation of your
display. Please read it thoroughly before attempting to install your display. Also, make certain
that you pay attention to the warnings that appear in this manual. Failure to read and follow
these instructions and warnings may result in damage to the display and/or bodily injury.
Please keep this manual handy for future reference.
SPECIFICATIONS
Character Height:
2 in (51 mm)
Viewing Range:
150 Feet
Viewing Angle:
Viewable in direct sunlight with an angle of +/- 70 degrees
Number of Characters:
Six-digit, 14 segments, 2 in (51 mm) high (display)
Display Type:
2 in BACKLIT LCD
Weigh Units:
lb, kg
Enclosure Type:
NEMA 4X/IP66 Thermoplastic
Dimensions:
9.0 in H x 11.2 in W x 4.3 in D
(229 mm H x 284 mm W x 109 mm D)
Weight:
8 lb / 3.6 kg
Data Input:
RS-232 and 20mA Current Loop
Power Requirements:
100 to 240V AC, 47/63 Hz Universal Input
Power Fuse:
1A (located on the power supply)
Operating Temperature:
-10 to 120 °F (-23 to 49 °C)
FEATURES
•Auto-format feature (automatically selects input protocol).
•Auto-baud detection.
INDICATOR COMPATIBILITY
Utilizing the Auto-format feature, the RD3 display can be driven by the following Cardinal
weight indicators and most other weight indicators from other manufacturers.
Current Models:
185/185B, 190/190A, 204, 200, 212/212X, and 825
205, 210, 210FE, 212G/212GX, 225 (with USB)
Legacy Models
180, 204S, 215, 220, 777 Series, 778 Series, and 788 Series
Non-USB 205, 210, 210FE, 212/212X, 212G/212GX, 225

8200-M063-O1 Rev C RD3 Installation and Technical Manual
2
AUTO-FORMAT FEATURE
The RD3 serial interface can automatically select the serial input protocol from the serial output
of an indicator in one of the following serial formats:
SMA, Cardinal SB400, Numbers, Rice Lake IQ355, ANDFV,
WI110, Toledo Short, and Toledo Long
The interface will automatically detect baud rates between 2400 and 19200 baud with the
following settings:
Baud rate: 2400 to 19200 (7 or 8 Data Bits)
Character format: all standard ASCII characters
SITE PREPARATION
Electrical Power
The RD3 display has been designed to operate from 100 to 240V AC at 47/63 Hz.
CAUTION! To avoid electrical hazards and possible damage to the display,
DO NOT, under any circumstance, cut, remove, alter, or in any way bypass the
power cord-grounding prong.
•The power for the display should be on a separate circuit from the distribution panel. This
circuit should be dedicated to the exclusive use of the display.
•The wiring should conform to national and local electrical codes and ordinances and should
be approved by the local inspector to ensure compliance.
•For permanently connected equipment, a readily accessible disconnect device must be
provided external to the equipment.
•For pluggable equipment, the socket outlet shall be installed near the equipment and shall
be easily accessible
•It is the responsibility of the customer to have a qualified electrician install the proper
service disconnect that conforms to national electrical codes and local codes and
ordinances.
Electrical Noise Interference
To prevent electrical noise interference, make certain all other wall outlets for use with air
conditioning and heating equipment, lighting, or other equipment with heavily inductive loads,
such as welders, motors, and solenoids are on circuits separate from the display. Many of
these disturbances originate within the building itself and can seriously affect the operation of
the display. These sources of disturbances must be identified and steps must be taken to
prevent possible adverse effects on the display. Examples of available alternatives include
isolation transformers, power regulators, uninterruptible power supplies, or simple line filters.

8200-M063-O1 Rev C RD3 Installation and Technical Manual
3
SINGLE AND MULTIPLE DISPLAY
The RD3 display has been designed to echo received characters (from a single weight
indicator) to other RD3 displays allowing the same weight data to be shown on multiple
displays. Typical applications might consist of back-to-back displays or displays placed at each
end of the scale.
The figures below are typical installations consisting of a single indicator to a single display
(Figure No. 1), a single indicator to two displays (Figure No. 2), and a single indicator with two
or more displays (Figure No. 3).
Figu
re No. 1 – One RD3
Display
Figure No
. 2 – Two RD3 D
isplays

8200-M063-O1 Rev C RD3 Installation and Technical Manual
4
SINGLE AND MULTIPLE DISPLAY, CONT.
Figure No. 3 – Multiple RD3 Displays

8200-M063-O1 Rev C RD3 Installation and Technical Manual
5
INSTALLATION
Unpacking
Before beginning the installation of your RD3 Display, make certain that it has been
received in good condition. Carefully remove it from the shipping carton and inspect it for
any evidence of damage (such as exterior dents or scratches) that may have taken place
during shipment. Keep the carton and packing material for return shipment if it should
become necessary. It is the responsibility of the purchaser to file all claims for any damages
or losses incurred during transit.
Mounting the RD3 Display
The RD3 Display includes a two-piece bracket that is used to mount it on a wall or other flat
vertical surface using a quick-detach bracket. Note that the Display Bracket is installed on the
RD3 at the factory.
Figure No. 4
Installing the Wall Bracket
Refer to Figure No. 4 for a layout of the wall bracket mounting holes.
1. Make certain the mounting surface is strong enough to support the display and that the
mounting location is where the display can easily be viewed.
2. Position the wall bracket with the wider end at the top, and using the wall bracket as a
template, mark the mounting hole locations and drill the holes.
3. Install the screws through the wall bracket and securely tighten.
4. Insert the narrow end of the display bracket into the wide end of the mounted wall bracket
and pull it down into place.
2.50 in
(63.5 mm)
Clearance for
1/4 in (6.
4 mm)
size screw
1.50 in
(38 mm)
3.00 in
(76 mm)
Display
Bracket
Wall
Bracket

8200-M063-O1 Rev C RD3 Installation and Technical Manual
6
SERIAL CABLE INSTALLATION
Figure No. 5
Cable Installation
1. Remove the 12 screws securing the front panel to the main housing.
2. Referring to Figure No. 5, choose a gland connector for the serial cable, loosen it, and
remove the rubber plug.
3. Slip the single cable through the gland connector and into the enclosure.
4. Remove approximately 3 inches of the outer insulation jacket from the cable then remove
1/4 inch of insulation from each of the wires.
5. Referring to the labels on the circuit board) for terminal connections, connect each of the
wires to terminal block P4. Refer to Figure No. 9 for the terminal block location
6. To terminate a wire, use a small flat-blade screwdriver and press down on the release bar
for the terminal. Insert the wire into the terminal opening. Remove the screwdriver,
allowing the release bar to return to its original position, locking the wire in place.
7. Repeat the procedure until all wires are in place.
8. After all, terminations have been made, remove any excess cable from the enclosure, and
securely tighten the cable gland connector. Finger-tighten only! DO NOT USE TOOLS!
AC Power Serial In/Out 

8200-M063-O1 Rev C RD3 Installation and Technical Manual
7
SERIAL CABLE INSTALLATION, CONT.
RS-232 Wiring
1. Refer to Figure No. 9 for the location of the terminal block.
2. For RS-232 connections, refer to Figure No. 6 (or the circuit
board) for the terminal connections and connect each wire to
the terminal block.
20mA Current Loop Wiring
1. Refer to Figure No. 9 for the location of the terminal block.
2. For PASSIVE connections, refer to Figure No. 7, the table below, or the circuit board for
the terminal connections and connect each wire to the terminal block.
3. For ACTIVE connections, refer to Figure No. 8, the table below, or the circuit board for the
terminal connections and connect each wire to the terminal block.
CAUTION! This device contains static sensitive components. Improper
handling can result in damage to or destruction of the components or board.
Such actual and/or consequential damage IS NOT covered under warranty.
Figure No. 6
Figure No. 7
RD3 PASSIVE END
Figure No. 8
RD3 ACTIVE END
IMPORTANT! A jumper must be installed between P4 terminals
1 and 7 to enable 20mA current loop operation.

8200-M063-O1 Rev C RD3 Installation and Technical Manual
8
SERIAL CABLE INSTALLATION, CONT.
CURRENT Cardinal Indicators 20mA Current Loop Connections
185/185B (Serial RS-232 Only)
RS-232 ONLY
RD3
P6, TX
P4, 7
P6, GND
P4, 9
190/190A (with 190-RS232 Option Card)
CARD (PASSIVE)
RD3
P4,6
P4,6
P4,7
P4,9
JUMPER
P4,4 to P4,5
JUMPER
P4, 1 to P4, 7
200
PORT 1
RD3
PORT 2
RD3
P3, 3
P4, 5
P3, 6
P4, 5
P3, 4
P4, 6
P3, 7
P4, 6
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 1 to P4, 7
205, 210, 210FE, 212/212X, 212G/212GX
PORT 0 (ACTIVE)
RD3
PORT 0 (PASSIVE)
RD3
P13, 5
P4, 5
P13, 6
P4, 6
P13, 6
P4, 6
P13, 7
P4, 9
JUMPER
P13, 5 to P13, 12
JUMPER
P4, 1 to P4, 7
JUMPER
P13, 7 to P13, 10
JUMPER
P4, 4 to P4, 5
JUMPER
P13, 7 to P13, 10
JUMPER
P4, 1 to P4, 7
PORT 1 (ACTIVE)
RD3
PORT 1 (PASSIVE)
RD3
P13, 1
P4, 5
P13, 8
P4, 6
P13, 8
P4, 6
P13, 9
P4, 9
JUMPER
P13, 9 to P13, 10
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 4 to P4, 5
JUMPER
P4, 1 to P4, 7

8200-M063-O1 Rev C RD3 Installation and Technical Manual
9
SERIAL CABLE INSTALLATION, CONT.
CURRENT Cardinal Indicators 20mA Current Loop Connections
225
PORT 0 (ACTIVE)
RD3
P20, 10
P4, 5
P20, 8
P4, 6
JUMPER
P4, 1 to P4, 7
PORT 1 (ACTIVE)
RD3
PORT 1 (PASSIVE)
RD3
P20, 3
P4, 5
P20, 4
P4, 6
P20, 4
P4, 6
P20,5
P4, 9
JUMPER
P20, 5 to P20, 8
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 4 to P4, 5
JUMPER
P4, 1 to P4, 7
PORT 2 (ACTIVE)
RD3
PORT 2 (PASSIVE)
RD3
P16, 1
P4, 5
P16, 2
P4, 6
P16, 2
P4, 6
P16, 3
P4, 9
JUMPER
P16, 3 to P16, 9
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 4 to P4, 5
JUMPER
P4, 1 to P4, 7
825
PORT 2 (ACTIVE)
RD3
PORT 2 (PASSIVE)
RD3
P21, 2
P4, 5
P21, 1
P4, 6
P21, 5
P4, 6
P21, 2
P4, 9
J3 INSTALLED
J7 SHUNT:20mA
JUMPER
P4, 1 to P4, 7
J3 REMOVED
J7 SHUNT:20mA
JUMPER
P4, 4 to P4, 5
JUMPER
P4, 1 to P4, 7

8200-M063-O1 Rev C RD3 Installation and Technical Manual
10
SERIAL CABLE INSTALLATION, CONT.
LEGACY Cardinal Indicators 20mA Current Loop Connections
205, 210, 210FE, 212/212X, 212G/212GX (without USB)
PORT 1
RD3
PORT 2
RD3
P11, 3
P4, 5
P11, 6
P4, 5
P11, 4
P4, 6
P11, 7
P4, 6
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 1 to P4, 7
215
PORT 1
RD3
PORT 2
RD3
P11, 3
P4, 5
P11, 6
P4, 5
P11, 4
P4, 6
P11, 7
P4, 6
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 1 to P4, 7
220
PORT 1 (ACTIVE)
RD3
PORT 1 (PASSIVE)
RD3
P10, 1
P4, 5
P10,2
P4, 6
P10, 2
P4, 6
P10, 3
P4, 9
JUMPER
P10, 3 to P10, 10
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 4 to P4, 5
JUMPER
P4, 1 to P4, 7
PORT 2
RD3
P10, 11
P4, 5
P10, 10
P4, 6
JUMPER
P4, 1 to P4, 7

8200-M063-O1 Rev C RD3 Installation and Technical Manual
11
SERIAL CABLE INSTALLATION, CONT.
LEGACY Cardinal Indicators 20mA Current Loop Connections
225 (without USB)
PORT 1 (ACTIVE)
RD3
PORT 1 (PASSIVE)
RD3
P14, 3
P4, 5
P14, 4
P4, 6
P14, 4
P4, 6
P14, 5
P4, 9
JUMPER
P14, 5 to P14, 8
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 4 to P4, 5
JUMPER
P4, 1 to P4, 7
PORT 2 (ACTIVE)
RD3
PORT 2 (PASSIVE)
RD3
P18, 1
P4, 5
P18, 2
P4, 6
P18, 2
P4, 6
P18,3
P4, 9
JUMPER
P18, 3 to P18, 9
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 4 to P4, 5
JUMPER
P4, 1 to P4, 7
PORT 3 (ACTIVE)
RD3
P18, 12
P4, 5
P18, 13
P4, 6
JUMPER
P4, 1 to P4, 7
778C
(PASSIVE)
RD3
(ACTIVE)
RD3
COMA, 11
P4, 6
COMA, 10
P4, 5
COMA, 23
P4, 9
COMA, 11
P4, 6
JUMPER
P4, 4 to P4, 5
JUMPER
COMA, 23 to COMA, 24
JUMPER
P4, 1 to P4, 7
JUMPER
P4, 1 to P4, 7

8200-M063-O1 Rev C RD3 Installation and Technical Manual
12
DISPLAY BOARD
Figure No. 9

8200-M063-O1 Rev C RD3 Installation and Technical Manual
13
DISPLAY BOARD, CONT.
Jumpers
J1 = BL TEST – Back Light Test jumper. (Jumper must be OFF or on one (1) pin for normal
operation)
J3 = DWI / RD – Operation mode selection jumper. (Jumper must be on pins 2 and 3 (RD) for
Remote Display)
Switches
S3 = (SETUP). Press to begin Setup mode. While in setup, press to advance to the next
setup option.
S2 = (Up Arrow ). This switch has a dual purpose. If pressed while in setup, it will
increment the current value by 1.
S1 = (Left Arrow ). This switch also has a dual purpose. If pressed while in setup, it will
step back to the previous option.
Status LED’s
D22 = BACKLIGHT ON – Turned on to indicate display backlight is ON. D22 is turned off
when the display backlight is OFF.
D23 = MAIN LINE – Display board microprocessor code is executing
D24 = IIC – Serial communication from 210 board (212 only) active
D25 = SPI – LCD display data is being sent to LCD
D26 = SERIAL – Serial data from DWI is present
D27 = VCC – 5VDC power is on
Connectors
P3 = VOUT – For Factory Use Only
P4 = 9 terminal connector for serial cable connections (refer to the table below)
P5 = VIN – Power Input Connector (10.5 to 14VDC)
P6 = IIC Bus – For Factory Use Only
P7 = ISP – In-System Programming connector
P4 Serial Terminal Connector Table
Circuit Board Label
Terminal
Function
TxD-20mA (SRC)
1
Source (SRC) voltage for active 20mA Transmitter
TxD-20mA +
2
20mA Transmitter Output (+)
TxD-20mA -
3
20mA Transmitter Output (-)
RxD-20mA (SRC)
4
Source (SRC) voltage for active 20mA Receiver
RxD-20mA +
5
20mA Receiver Input (+)
RxD-20mA -
6
20mA Receiver Input (-)
RxD-RS232
7
RS232 Receiver Input
TxD-RS232
8
RS232 Transmitter Output
GND
9
Ground

8200-M063-O1 Rev C RD3 Installation and Technical Manual
14
SETUP AND CONFIGURATION
The RD3 display has been pre-configured at the factory and should not require configuration
for use in most applications. If the factory settings do not meet the requirements of your
application, the following describes the steps to configure the display.
The setup mode switch is located on the back of the
display board. You may gain access to it by removing the
12 screws securing the front panel to the rear housing.
Refer to Figure No. 10, for the location of the SETUP
switch.
•When a prompt is displayed, press the SETUP switch
to retain the current value and proceed to the next
prompt.
•To change a setting, press the Up Arrow switch to scroll through and select a new
value.
•Press the Left Arrow switch to "back up" to the previous prompt.
Enter Setup Mode
1. With the front panel removed and the display ON, press and release the SETUP switch.
2. The display will change to show SETUP.
3. Press the SETUP switch again.
4. The display will change to show type=_ and the current value.
tyPE=(Serial Format)
This option allows you to manually select a serial format and override the Auto-format
feature by setting type= to a number listed below. Note that the factory default value is 0
(Auto-format is enabled).
If the value displayed is acceptable, press the SETUP switch again. Otherwise, press the
Up Arrow switch to scroll through and select a new value andthen press the SETUP
switch to save it and proceed to the next prompt. Values from 0 to 8 may be selected.
0= Auto-format
5= ANDFV
1= SMA
6= WI110
2= Cardinal SB400
7= Toledo Short
3= Numbers
8= Toledo Long
4= Rice Lake IQ355
Figure No. 10

8200-M063-O1 Rev C RD3 Installation and Technical Manual
15
bAUd= (Serial Port Baud Rate)
This option allows you to manually select a baud rate and override the Auto-baud feature by
setting baud= to a number listed below. Note that the factory default value is 0 (Auto-baud
is enabled).
If the value displayed is acceptable, press the SETUP switch again. Otherwise, press the
Up Arrow switch to scroll through and select a new value and then press the SETUP
switch to save it and proceed to the next prompt. Values from 0 to 5 may be selected.
0= Auto-baud
1= 2400
2= 4800
3= 9600
4= 19,200
5= 38,400
data= (Serial Port Data Bits)
This option allows you to manually select 7 or 8 data bits for the serial port data format. Note
that if Auto-format is enabled (type=0), the data=setting is ignored.
If the value displayed is acceptable, press the SETUP switch again. Otherwise, press the
Up Arrow switch to toggle to the other value and then press the SETUP switch to save it.
0= 7 Data bits
1= 8 Data bits
LTE=(Backlight Turn-On Level)
This option allows you to set the Light Sensor Reading at which LCD Backlight will turn ON
If the value displayed is acceptable, press the SETUP switch again. Otherwise, press the
Up Arrow switch to toggle to the other value and then press the SETUP switch to save it.
LTE=0
LTE=99
LTE=XX
Backlight always ON
Backlight always OFF
The level that the
backlight turns ON
LT=(Light Sensor Reading)
Current LCD Light Sensor Reading (where XX is the current value) NOTE! This value is not
adjustable.
Setup Complete
Press the SETUP switch to save the settings. Setup and configuration have been completed.
The RD3 will reset. Follow the instructions on the next page to re-install the front panel and
proceed with normal operations.

8200-M063-O1 Rev C RD3 Installation and Technical Manual
16
RE-INSTALLING THE FRONT PANEL
After all the terminations have been made, changes to setup have been completed, and the
display brightness set to the desired level, it’s time to re-install the front panel.
1. Gently pull any excess cable (AC power and serial) from the enclosure.
2. Securely tighten the cable gland connectors.
•Do not over-tighten the connectors but make certain they are snug.
•DO NOT USE TOOLS! Finger-tighten only!
•Ensure that any unused gland connectors are plugged.
3. Make certain no cables or wires are exposed between the rear housing and front panel.
4. Place the front panel onto the rear housing.
5. Secure with the 12 screws removed earlier.
6. Follow a diagonal pattern when tightening the screws.
ERROR AND STATUS DISPLAYS
The RD3 Remote Display is equipped with software that tests various portions of its circuitry
and verifies proper operation. Should a problem be detected, a message will be displayed. The
following lists the messages displayed and their meaning:
Display Meaning
auto-b
This will be displayed for a maximum of 4 seconds when the display is
configured for Auto-baud detection. Note that while detecting the baud
rate, the intensity of the digits will increase to full brightness.
Erro1
Erro2
The auto-baud feature could not detect the baud rate of the indicator.
Verify baud rate of the indicator serial port is set for 2400 to 19200 baud
and try again. If an error continues, manually set the baud rate of the
display and indicator.
autofom This will be displayed for a maximum of 3 seconds when the display is
configured for Auto-format.
Erro3 The auto-format feature was unable to automatically select a serial input
protocol. Verify indicator serial output is one of the eight serial formats
listed in Setup and Configuration and try again. If an error continues,
manually set the serial format of the display and indicator.
Nodata
On some indicators, the serial output will stop when displaying an error
code or if in an "input" mode. When the serial input to the display stops
for any reason, after 3 seconds this message will be displayed.
•
Correct error condition on the indicator.
•
Cancel or complete the input operation on the indicator.
This message could also indicate the serial connection between the
indicator and the display has been lost.
•
Check for a broken, loose, or disconnected serial cable between the
indicator and the display.
