2XX-EIP
EtherNet/IP Interface Card
Installation and Setup Manual
For 205, 210, and 225 Weight Indicators

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
2

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
1
INTRODUCTION
The 2XX-EIP has been designed for the industrial environment where interfacing through an
EtherNet IP network is desired. When coupled with a 205, 210, or 225 digital weight indicator,
it can provide the weight reading and control of multiple scale commands. The interface card
resides in the main enclosure of the indicator and has a 16-pin dual in-line connector to
provide an easy connection to the indicator's internal hardware. A single RJ-45 connector is
provided to connect to the EtherNet IP network. The 2XX-EIP supports 10/100 Mbit, full or half-
duplex operation.
The purpose of this manual is to provide you with a guide through the installation and setup of
the 2XX-EIP EtherNet/IP interface card. Please read it thoroughly before attempting to install it
in your indicator and keep it available for future reference.
SPECIFICATIONS
Temperature Range: ........
14 to 104 F (-10 to +40 C)
Network Connections: ......
(1) RJ-45 connector
Diagnostics: ...............
.......
Onboard LEDs CS (Chip Select),
LK (Link), and ML (Main Line)
FCC COMPLIANCE STATEMENT
This equipment generates uses and can radiate radio frequency and if not installed and used
in accordance with the instruction manual, may cause interference to radio communications. It
has been tested and found to comply with the limits for a Class A computing device pursuant
to Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection
against such interference when operated in a commercial environment. Operation of this
equipment in a residential area may cause interference in which case the user will be
responsible to take whatever measures necessary to correct the interference.
You may find the booklet “How to Identify and Resolve Radio-TV Interference Problems”
prepared by the Federal Communications Commission helpful. It is available from the U.S.
Government Printing Office, Washington, D.C. 20402, Stock No. 001-000-00315-4.
All rights reserved. Reproduction or use, without expressed written permission, of editorial or
pictorial content, in any manner, is prohibited. No patent liability is assumed with respect to the
use of the information contained herein.
While every precaution has been taken in the preparation of this manual, the Seller assumes
no responsibility for errors or omissions. Neither is any liability assumed for damages resulting
from the use of the information contained herein. All instructions and diagrams have been
checked for accuracy and ease of application; however, success and safety in working with
tools depend to a great extent upon individual accuracy, skill, and caution. For this reason, the
Seller is not able to guarantee the result of any procedure contained herein. Nor can they
assume responsibility for any damage to property or injury to persons occasioned from the
procedures. Persons engaging in the procedures do so entirely at their own risk.
PRECAUTIONS
Before beginning installation of this option card, read this manual and pay
special attention to all "WARNING" symbols:
IMPORTANT
ELECTRICAL
WARNING
STATIC
SENSITVE

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
2
INSTALLATION
Mounting the 2XX-EIP Option Card
NOTE: Should your indicator come with the 2XX-EIP option card already installed, the
following section describing mounting does not apply. Proceed to the Node Address Setup
section.
CAUTION! This board contains static sensitive components. Improper
handling can result in damage to or destruction of the components or board.
Such actual and/or consequential damage IS NOT covered under warranty.
1. Make sure the power to the indicator is OFF. Unplug the AC power cord.
2. Loosen the gland connectors where the AC power cord and any other cables enter the
indicator.
3. Remove the rear panel on the indicator.
On the 205/210, remove the 12 acorn nuts securing the rear panel to the front housing.
On the 225, remove the 14 acorn nuts securing the rear panel to the front housing.
4. Separate the rear panel from the front housing on the indicator.
5. Lift the panel from the main housing, taking care not to stretch the cable and wires between
the panel and main housing. Lay the panel on the workbench next to the indicator.
6. Referring to the illustrations on page 3, locate the threaded stand-off and the OPTION
BOARD connector on the indicator mainboard.
205/210 – The threaded stand-off is below P3 and the OPTION BOARD connector
is P10.
225 – The threaded stand-off is near P9 and the OPTION BOARD connector is P15.
7. To install the option 2XX-EIP card, carefully align the connector P4 (pins on the bottom side
of the 2XX-EIP board) with connector P10 on the 205/210 or P15 on the 225 mainboard
and then apply even downward pressure to the end of the 2XX-EIP board (with P4 pins on
the bottom side).
8. Align the hole in the 2XX-EIP board with the threaded stand-off on the indicator main board
and using the lock washer and screw supplied with the 2XX-EIP board, secure the 2XX-EIP
to the indicator mainboard.
9. To attach the ground wire:
On the 205/210, remove a 6-32 nut and
washer from the threaded stud at the corner
of the indicator mainboard.
On the 225, remove a 6-32 nut and washer
from the threaded stud at the center of the
indicator mainboard.
10. Connect the ground wire from the option card by
placing the ring terminal over the 6-32 threaded
stud.
11. Reinstall the washer and 6-32 nut and tighten.
NOTE: The ground wire attachment example
shown is on the 205/210 mainboard. The
attachment for the 225 is similar.
Attach
Ground Here

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
3
INSTALLATION, CONT.
Mounting the 2XX-EIP Option Card, Cont.
205/210 Main PCB
NOTE: 205 Main PCB shown. The 210 Main PCB will have connector P2,
REMOTE OUTPUTS, and J7, REMOTE OUTPUT SRC jumper installed.
225 Main PCB
P15
OPTION
BOARD
THREADED
STAND-OFF
ATTACH
GROUND WIRE
TO THREADED
STUD HERE
THREADED
STAND-OFF
P10
OPTION
BOARD
ATTACH
GROUND WIRE
TO THREADED
STUD HERE

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
4
INSTALLATION, CONT.
Ethernet Cable Installation
1. Loosen an unused cable gland connector for the cable.
2. Insert the Ethernet cable (CAT 5 or equivalent) through the gland connector and into the
enclosure.
3. Consult your network administrator for the proper procedure to terminate the cable.
4. After the cable has been terminated, plug the cable into the RJ-45 jack on the 2XX-EIP.
Item # Description Item # Description
1 Status LED’s 4 EtherNet/IP Module
2 Ethernet Connector 5 P2 Expansion Connector
3 P4 Connector (pins on trace
side of board)
6 Ground Wire
2XX-EIP Status LED’S
The 2XX-EIP EtherNet/IP Interface Card contains three LEDs to indicate the communication
status with the indicator mainboard.
CS, Chip Select
LK, Link
ML, Main Line
If the CS (Chip Select) LED is off, communications may
have been lost between the EtherNet IP module and the
indicator mainboard. Cycle power (press ON/OFF key
twice) to re-establish communications.
The LK (Link) LED displays the communication status.
It will be on or flashing rapidly when communications between the 2XX-EIP and the EtherNet
IP network are established.
The ML (Main Line) LED will be on to indicate the 2XX-EIP is powered up and running.
IMPORTANT: A load cell connection is required when testing the indicator.
An ERR AL or ERR AH condition will cause the communications from the
mainboard and the module to be very slow and will inhibit communications
with the EtherNet/IP module.
CS
ML
LK

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
5
RE-INSTALLING THE REAR PANEL
When the installation is complete:
1. Remove the excess cable from the indicator enclosure.
2. Make certain no cables or wires are exposed between the main housing and rear panel and
then place the rear panel onto the main housing.
3. Secure the panel to the main housing with the acorn nuts (12 on the 205/210, 14 on the
225) removed earlier.
4. Tighten the gland connector nut to seal the cable.
Do not over-tighten the connector but make certain they are snug.
DO NOT USE TOOLS! Finger-tighten only!
Make sure any unused gland connectors are plugged.
5. If required, install the lead and wire calibration seal.
205/210 INDICATOR SETUP
With the 2XX-EIP option card installed, a sub-menu (Option) has been placed after
(Key Lock Out Function). The sub-menu contains the setup selection to
change the output weight byte order.
NOTE: The prompt will display as when using the CAL switch and when
using the ENTER key to advance through the setup prompts.
(Output Weight Byte Order)
Press the ENTER key to show the current setting. If the setting displayed is acceptable,
press the ENTER key again to save it. Otherwise, using the numeric keys (or the arrow keys
on the 205) enter the new setting, then press the ENTER key to save it. Allowable values
are:
Default setting.
225 INDICATOR SETUP
With the indicator ON, press the SHIFT key and then press the Navigation ENTER key (red
square key in the center of the Navigation arrows). The display will change to show the
SETUP/REVIEW MENU.
SETUP/REVIEW MENU
1.ENTER CALIBRATION AND SETUP
2.VIEW AUDIT TRAIL COUNTERS
3.CALIBRATE SCALE 1 8.SCALE ID=00
9.DEL CUSTOM TICKET
10.PRINT SETUP
Enter Selection: 1 ^ EXIT
Press the ENTER key, and then press the NEXT Navigation arrow until SETUP MENU #3 is
displayed.

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
6
225 INDICATOR SETUP, CONT.
SETUP MENU #3
1. G/N ACCUMS=XXX 6. KEY LOCKOUT
2. BACK LITE= X 7. LRPort=COM3
3. PASSWORD
4. 2XX-EIP/MODBUSTCP
5. BADGE RDR 10. Send Grs En=XXX
Enter Selection: 0 ^ PREV ` EXIT
With SETUP MENU #3 displayed, press the 4 key and then the ENTER key. The display will
change to show the 2XX-EIP/MODBUSTCP SETUP MENU.
2XX-EIP/MODBUSTCP SETUP MENU
5. BYTEORDER = XXXX
Enter Selection: 0 ^ EXIT
With 2XX-EIP/MODBUSTCP SETUP MENU displayed, the current setting for the
BYTEORDER = parameter will be shown. Note that XXXX is the current setting for the byte
order. If the setting displayed is acceptable, press the Navigation EXIT arrow until the indicator
goes into the weight display mode.
Otherwise, press the 5 key, the ENTER key, and then using the numeric keys, enter the setting
for the byte order. Press the ENTER key to save the new setting and return to the
2XX-EIP/MODBUSTCP SETUP MENU. Allowable values are:
1234 4321 3412 2143
Default setting.
Press the Navigation EXIT arrow until the indicator goes into the weight display mode.
NODE ADDRESS SETUP
On an EtherNet/IP network,
each node must be assigned its
own unique TCP/IP address.
The 2XX-EIP EtherNet IP
interface card IP address is set
using the Anybus IPconfig Tool
Utility, available when logged
into the dealer-protected
software section of
CardinalScale.com. Download
the file from CardinalScale.com
by navigating to 225 Navigator
> Resource Type > Software >
2XX-EIP Anybus IPconfig Tool
Utility.
NOTE: EtherNet/IP makes use of TCP port number 44818 for explicit messaging and UDP
port number 2222 for implicit messaging.
Double click on the highlighted module
.
Change DHCP to a fixed IP address.

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
7
CONFIGURE THE PLC USING RSLogix5000
Either create a new project or use an existing one, set the program in “Offline” mode. Add the
module to the configuration in the PLC. Start by right click the EtherNet/IP module/bridge in the
I/O configuration, and select “New Module”.
Now a dialogue window will appear. In this dialogue window, select “Generic Ethernet module”
and press OK.

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
8
CONFIGURE THE PLC USING RSLogix5000, CONT.
In the next dialogue window, RSLogix 5000 will ask for information regarding the
communication to the module. First, enter a name for the module. This name will create a tag
in RSLogix5000, which can be used to access the memory location in the PLCs memory
where the data for the module will be stored. With the name entered, press Next.
In the next dialogue box enter a value for the time between each scan of the module, called
Request Packet Interval (RPI). Make sure that “Inhibit Module” isn’t checked. After this, press
Finish.

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
9
CONFIGURE THE PLC USING RSLogix5000, CONT.
Now the module has been added to the I/O configuration in RSLogix5000. The main screen
will look as follows.
Now go online and download the configuration to the PLC.
1. Select Go Online in the communication menu.
2. A new window will open.
3. Select download.
4. A new window will pop up with the question if you want to download the configuration.
5. Select “Download”. The configuration will now be downloaded to the PLC.
Now it’s possible to access the data exchanged by ControlLogix5000 and the module. To do
this, open the “Controller Tags” window and go to monitor tags. Three tags named
“Cardinal_2XX:C”, “Cardinal_2XX:I”, and ”Cardinal_2XX:O” should be visible, representing the
three instances configuration, input, and output. The configuration instance will be created
even if we selected zero as its size. The Cardinal_2XX:I tag is data coming from the module
and the Cardinal_2XX:O tag holds data going to the module.

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
10
CONFIGURE THE PLC USING RSLogix5000, CONT.
Input
The weight data begins at Data[0] and uses the next four bytes to produce a floating-point
program tag.
Float = (Data[0], Data[1], Data[2], Data[3])
Weight
Weight Status
PWC Status
CMD 0 return
when complete
CMD 1 return
when complete
CMD 0
CMD 1
N/A
Float Byte 0
Float Byte 2
Float Byte 3
Float Byte 1

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
11
205/210 COMMUNICATIONS
Data Sent from the 205/210 Indicator to the PLC
Byte0 Float point weight. Byte 0 Float point weight. Byte 1 Byte1
Byte2 Float point weight. Byte 2 Float point weight. Byte 3 Byte3
Byte4 Weight status. See bit definitions below PWC status. Bit0 = PWC1... 1=on Byte5
Byte6 Cmd0. Returned by the 205/210
indicator when complete
Cmd1. Returned by the 205/210
indicator when complete
Byte7
Data Sent from the PLC to the 205/210 Indicator
Byte0 Cmd0. See definition below Cmd1. See definition below Byte1
Byte2 N/A N/A Byte3
Byte4 Float point value for Cmd. Byte 0 Float point value for Cmd. Byte 1 Byte5
Byte6 Float point value for Cmd. Byte 2 Float point value for Cmd. Byte 3 Byte7
205/210 WEIGHT STATUS (Data[4])
Bit0 MOTION
Bit1 BELOW ZERO
Bit2 CENTER OF ZERO
Bit3 OVER CAPACITY
Bit4 WEIGH UNITS 0=unit1 (lb)/1=unit2 (kg)
Bit5 WEIGH MODE 0=Gross/1=Net
Bit6 Not defined
Bit7 Scale Error. The indicator has failed to communicate for at least 3 seconds,
data is invalid.
205/210 PWC STATUS (Data[5])
NOTE: The following status section applies only if the PWC has been enabled. Refer to the
Technical and Installation manual of your indicator for instructions on enabling and using the
PWC feature.
Bit0 PWC1 – 0=off/1=on
Bit1 PWC2 – 0=off/1=on
Bit2 PWC3 – 0=off/1=on
Bit3 PWC4 – 0=off/1=on
Bit4 PWC5 – 0=off/1=on
Bit5 PWC6 – 0=off/1=on
Bit6 PWC7 – 0=off/1=on
Bit7 PWC8 – 0=off/1=on

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
12
205/210 COMMANDS
CMD0 and CMD1 combined to make the command word. Command words are broken into
command bits for PLC ease of programming. To invoke a command set the bit to one. The
PLC should continue to send a command until the command is returned by the indicator. If the
indicator cannot perform a command the returned command will include Bit7.
Bit00 GROSS/NET
Bit01 PRINT
Bit02 ZERO
Bit03 PB TARE
Bit04 KB TARE requires float point value be sent in Bytes 4, 5, 6, and 7
Bit05 not defined
Bit06 not defined
Bit07 This bit is the error bit from the 2XX when a command fails.
Bit08 PWC1 requires float point value be sent in Bytes 4, 5, 6, and 7
Bit09 PWC2 requires float point value be sent in Bytes 4, 5, 6, and 7
Bit10 PWC3 requires float point value be sent in Bytes 4, 5, 6, and 7
Bit11 PWC4 requires float point value be sent in Bytes 4, 5, 6, and 7
Bit12 PWC5 requires float point value be sent in Bytes 4, 5, 6, and 7
Bit13 PWC6 requires float point value be sent in Bytes 4, 5, 6, and 7
Bit14 PWC7 requires float point value be sent in Bytes 4, 5, 6, and 7
Bit15 PWC8 requires float point value be sent in Bytes 4, 5, 6, and 7

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
13
225 COMMUNICATIONS
Data Sent from the 225 Indicator to the PLC
Byte0 Float point weight. Byte 0 Float point weight. Byte 1 Byte1
Byte2 Float point weight. Byte 2 Float point weight. Byte 3 Byte3
Byte4 Weight status. See bit definitions below Scale Number (Bits 4-7) Byte5
Byte6 Cmd0. Returned by 225 Indicator when
complete
Cmd1. Returned by 225 Indicator
when complete
Byte7
Data Sent from the PLC to the 225 Indicator:
Byte0 Cmd0. See definition below Cmd1. See definition below Byte1
Byte2 N/A N/A Byte3
Byte4 Float point value for Cmd. Byte 0 Float point value for Cmd. Byte 1 Byte5
Byte6 Float point value for Cmd. Byte 2 Float point value for Cmd. Byte 3 Byte7
225 COMMANDS
CMD0 and CMD1 are combined to make the command word. Command words are broken into
command bits for PLC ease of programming. To invoke a command, set the bit to one. The
PLC should continue to send a command until the command is returned by the indicator. If the
indicator cannot perform a command, the returned command will include bit 7. The scale
number is encoded as a four-bit binary number, 1 through the number of scales available.
NOTE: ALL COMMAND BITS SHOULD BE RELEASED AFTER THEY ARE
PROCESSED BY THE INDICATOR.
Bit0 Gross/Net
Bit1 Print
Bit2 Zero
Bit3 PB Tare
Bit4 KB Tare, requires float point value be sent in bytes 4, 5, 6, and 7
Bit5-6 not defined
Bit7 This bit is the error bit from the 225 when a command fails.
Bit8-11 not defined
Bit12 Select scale number, bit 0 (least significant)
Bit13 Select scale number, bit 1
Bit14 Select scale number, bit 2
Bit15 Select scale number, bit 3 (most significant)

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
14
225 SCALE NUMBER
The scale number is encoded as a four-bit binary number, 1 through the number of scales
available. For example, Scale #1 (00010000), Scale #2 (00100000), Scale #3 (00110000), and
Total scale (01000000).
Bit0 (not used)
Bit1 (not used)
Bit2 (not used)
Bit3 (not used)
Bit4 Select scale number, bit 0 (least significant)
Bit5 Select scale number, bit 1
Bit6 Select scale number, bit 2
Bit7 Select scale number, bit 3 (most significant)
225 WEIGHT STATUS
Bit0 Motion
Bit1 Below Zero
Bit2 Center of Zero
Bit3 Over Capacity
Bit4 Weigh Units 0=unit 1 (PRIMARY UNITS), 1=unit 2 (ALTERNATE UNITS)
Bit5 Weigh Mode 0=Gross, 1=Net
Bit6 Not Defined
Bit7 Error. Data is invalid.
225 FLOATING POINT WEIGHT DATA
Example for weight data 5000 = Floating-point 459C4000h
Byte0 45h
Byte1 9Ch
Byte2 40h
Byte3 00h
Some PLCs may require Byte 1 and Byte 0 to be swapped to be compatible with the Allen-
Bradley floating-point data format.

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
15
TROUBLESHOOTING
EtherNet/IP Module Status LEDs
The EtherNet/IP Module has three LEDs to indicate run time status and errors to the user.
During power up, a LED test sequence is performed according to the EtherNet/IP specification.
Keep the enclosure back panel off during the configuration of the device so you can see the
EtherNet IP module status LEDs.
LED # INDICATION STATE DESCRIPTION
1 Network Status Off No power or no IP address
Green On-line, one or more connections
established (CIP Class 1 or 3)
Green, Flashing On-line, no connections established
Red Duplicate IP address, FATAL error
Red, Flashing One or more connections timed out
(CIP Class 1 or 3)
2 Module Status Off No power
Green Controlled by a Scanner in Run state
Green, Flashing Not configured, or Scanner in Idle
state
Red Major fault (EXCEPTION-state,
FATAL error, etc.)
Red, Flashing Recoverable fault(s)
3 Link/Activity Off No link, no activity
Green Link established
Green, flickering Activity
LED 2
LED 1
LED 3

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
16

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
17

8200-M554-O1 Rev C 2XX-EIP Installation and Setup Manual
18
Cardinal Scale Mfg. Co.
102 E. Daugherty, Webb City, MO 64870 USA
Ph: 417-673-4631 or 1-800-641-2008
Fax: [phone]
www.cardinalscale.com
Technical Support: 1-866-254-8261
E-mail: [e-mail]
8200-M554-O1 Rev C 04/21
Printed in USA
