CARE CCSI300 User manual

Clothing Steam Iron
MODEL: CCSI300
1. READ these instructions carefully before installing and operating the
appliance. Keep them for further reference.
2. Record in the space below the “SERIAL/MODEL NUMBER” found on the back
or bottom of your appliance and retain this information for future reference.
SERIAL NUMBER:
MODEL NUMBER:
DATE OF PURCHASE:
Save and staple your sales receipt to your manual for warranty coverage.

Page 2
CONTENTS
SAFETY INFORMATION
Important Safety Instructions ............................................................................................................................. 3
Electrical Requirements ........................................................................................................................................ 4
SET UP & USE
Installation Guide ..................................................................................................................................................... 5
Parts & Features ....................................................................................................................................................... 6
Operation Instructions........................................................................................................................................... 7
Functions............................................................................................................................................................... 8-10
Helpful Tips ...............................................................................................................................................................10
CLEANING & CARE.................................................................................................................................11
TROUBLESHOOTING & WARRANTY
Before You Call For Service................................................................................................................................13
Customer Service....................................................................................................................................................13
Troubleshooting ......................................................................................................................................................13
Limited Warranty....................................................................................................................................................14
Staple your receipt to your manual.
You will need it to obtain warranty service.
Thank you for purchasing our
COMMERCIAL CARE product.
This easy-to-use manual will guide
you in getting the best use of your
refrigerator.
Remember to record the model and
serial numbers. They are on a label
on the back of the product.
_____________________________
Model number
_____________________________
Serial number
_____________________________
Date of purchase
PRODUCT REGISTRATION

Page 3
SAFETY INFORMATION
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
1. Before connecting the appliance, check if the voltage indicated on the rating
plate corresponds with the voltage in your home.
2. Use the iron only for its intended purpose, for ironing fabrics on ironing
board. To protect against burns or injury to persons, do not iron or steam
fabrics while being worn on the body.
3. The iron should always be turned to the MIN setting before connecting or
disconnecting from the power supply. Do not pull on the cord to disconnect
the plug from the wall socket. Instead, grasp the plug and pull on the plug to
disconnect the iron.
4. If the power cord is damaged or defective, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in order to
avoid a hazard. Incorrect assembly might result in a risk of electric shock
when the iron is used after reassembly.
5. When you have nished ironing or when you are leaving iron unattended:
- turn the Steam Control switch to NO STEAM position, and the Temperature
Control Dial to “0”
- stand the iron upright,
- disconnect the iron from the wall outlet.
6. The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance. Do not leave the iron unattended while the iron is connected or
on ironing board.
7. To avoid the risk of electric shock, do not immerse the iron or the cord into
water or any other liquid.
WARNING
When using electrical appliances, basic safety
precautions should be followed, including the following

Page 4
SAFETY INFORMATION
8. The plug and cord should not be allowed to touch the hot soleplate. Let
the iron cool down completely before taking it away. Coil the cord loosely
around the iron for storage.
9. Always disconnect the iron from the wall outlet before lling with water or
when emptying the water after use.
10. To avoid an overloaded circuit, do not operate another high voltage
appliance in the same electric circuit.
11. If an extension cord is absolutely necessary, a cord with an ampere rating
equal to or greater than the iron should be used. A cord with less amperage
can result in a risk of re or electric shock due to overheating. Care should
be taken to arrange the cord so that it cannot be pulled or tripped over.
12. The iron must be used and rested on a stable surface. When placing the iron
on its Heel Rest, ensure that the surface on which the Heel Rest is placed is
stable.
13. The iron is not to be used if it has been dropped, if there are visible signs of
damage or if it is leaking.
14. The iron is for household use only.
15. To protect against burns or injury to persons, do not direct steam toward
the body when ironing or self-cleaning.
16. Always turn the iron OFF before plugging or unplugging the iron from the
electrical outlet. Never pull on the cord to disconnect the iron from the
electrical outlet; instead, grasp the plug and pull on the plug to disconnect
the iron.
17. Do not let the cord touch hot surfaces. Let the iron cool completely before
putting the iron away. Coil the cord loosely around the iron when storing.
18. Do not operate the iron with a damaged cord or in the even the iron has
been dropped or damaged. To avoid the risk of electric shock, do not
disassemble the iron. Take it to a qualied servicemen for examination and
repair. Incorrect assembly might result in a risk of electric shock when the
iron is used after reassembly.
19. Burns can occur from touching hot metal parts, hot water, or steam. Use
caution when you turn upside down - there might be hot water in the
reservoir.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
NOTE: · Some parts of the iron have been slightly greased and as a result, the iron may smoke
slightly when switched on for the rst time. It will not happen again after a few uses.
· Before using for the rst time remove any protective lms or stickers from the soleplate
and the cabinet. Clean the soleplate with a soft cloth.
· When using the iron for the rst time, test it on an old piece of fabric to ensure that the
soleplate and water tank are completely clean.

Page 5
SAFETY INFORMATION
ELECTRICAL REQUIREMENTS
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to t into a polarized outlet only one way.
If the plug does not t into the outlet, reverse the plug. If it still does not t, contact a
qualied electrician. Do not attempt to modify the plug in any way.
NOTE: This appliance requires a minimum of 1200 watts and it should be the only appliance
operating on the circuit.
NOTE: Neither Commercial Care nor the dealer can accept any liability for damage to the product
or personal injury resulting from failure to observe the electrical connection procedures.
POWER SUPPLY CORD
1. A short power supply cord is provided to reduce the risk of becoming entangled in
or tripping over a longer cord.
2. If the power supply cord is too short, do not use an extension cord. Have a
qualied electrician or serviceman install an outlet near the appliance.
3. If it is absolutely necessary to use longer cord sets or an extension cord, extreme
care must be exercised.
a) Use an extension cord rated no less than 10-amperes.
b) The marked electrical rating of the cord set or extension cord must equal to
or be greater than the electrical rating of the appliance. The longer cord should
be arranged so that it will not drape over the counter top or table top where it
can be pulled on by children or tripped over unintentionally.
NOTE: Neither Commercial Care nor the dealer can accept any liability for damage to the product
or personal injury resulting from failure to observe the electrical connection procedures.
INSTALLATION GUIDE
1. Make sure that all the packing materials are removed from the steam iron.
2. Check the steam iron for any damage. If there is any damage, do not operate the
steam iron. Contact the Customer Satisfaction Center, see page 13.
3. Make sure that the power supply cord is undamaged and does not run under the
steam iron or over any hot or sharp surface.
4. The receptacle used for power must be readily accessible so that the cord can be
quickly reached and easily unplugged in an emergency.

Page 6
SET UP & USE
PARTS & FEATURES
Diagram for instructional purposes only.
Steam control switch
Spraying button
Steam burst button
360 degree
rotating cord
Indicator light
Temperature
control dial
Water tank
Self-clean button
Cover of water lter
Spray jet
Soleplate

Page 7
OPERATION INSTRUCTIONS
HOW TO FILL WITH WATER
1. Set the Steam Control Switch to “0” and the
Temperature Control Dial to “MIN.”
2. Lift the cover to the water reservoir. Fill with water to
the maximum level “MAX”. Do not over ll.
3. To rell, unplug the iron from the wall outlet, and wait
for the iron to cool down.
CHOICE OF WATER
This iron can be used with normal tap water. If the water in your area is particularly
hard, it is advisable to use distilled or demineralized water. Do not use chemically
descaled water or any other liquids for relling.
TEMPERATURE SETTING
1. Stand the iron upright on a stable surface. Insert the plug in the wall socket.
2. Turn the Temperature Control Dial to the desired temperature setting.
3. The desired temperature has been reached when the thermostat operating light
has turned off. The thermostat operating light will turn on and off from time to
time, indicating that the selected temperature is being maintained.
TEMPERATURE CONTROL SETTING
1. Always check garment label for ironing instructions
before ironing garment.
2. Start ironing the fabrics requiring the lowest temperature
and progress to the higher ones because the iron heats
up quicker than it cools down.
3. If the fabric consists of multiple bres (e.g. cotton with
polyester) you should select the ironing temperature for
the material with the lowest advised temperature.
SET UP & USE
max

Page 8
FUNCTIONS
SPRAYING
This function can be used with stream or dry ironing and does not affect the ironing
temperature.
1. Check the water level. Add water if needed.
2. Aim the nozzle towards the garment.
3. Press the Spray Button, . Repeat if spray does not
work immediately.
STEAM IRONING
This function can be used only at higher ironing temperatures.
•• For moderate steam
••• or MAX For maximum steam
1. Check the water level. Add water if needed.
2. Stand the iron upright and be sure the temperature dial is set to MIN.
3. Plug the power cord into electrical outlet.
4. Turn the Temperature Control to the “••,” “•••” or MAX setting. Consider the fabric
type to be ironed.
5. The temperature operating indicator light turns off when the required
temperature is reached. The iron is ready for use. The light will go ON and OFF
while ironing.
6. Adjust the Steam Switch to the required position, steam starts coming out from
the holes in the soleplate.
NOTE: With conventional steam ironing, water may leak from the soleplate if too low a
temperature has been selected. If this happens, turn the Temperature Control to the
advised position. Steam will recommence as soon as the appropriate temperature has
been reached.
DRY IRONING
1. Ensure that the Steam Control Switch is in position “0.”
2. Select the setting on the Temperature Control. Consider the fabric type to be
ironed.
3. When the temperature operating indicator light turns off, the required
temperature is reached. The iron is ready for use.
SET UP & USE
max

Page 9
BURST OF STEAM
This function provides an extra amount of steam to remove stubborn wrinkles.
1. Check the water level. Add water if needed.
2. Turn the temperature control to the position “MAX.”
3. The temperature operating indicator light turns off
when the required temperature is reached.
4. The iron is ready for use.
5. Press the Burst of Steam button once, .
6. Steam will penetrate into the garment removing the
wrinkles.
7. Wait a few seconds before pressing the Steam Burst
Button again when there are stubborn wrinkles.
VERTICAL STEAMING
To get better result when using vertical steam, hang
the garment on a clothes hanger. Curtains and drapes
may also be steamed once they’re hung. Hold the iron
away from your body, close to but not touching the
fabric. Pull the fabric tight with your free hand and
pump the Vertical Steam Button (Steam Button) at
2-5 seconds intervals as you pass the iron over the
wrinkled fabric.
ANTI-DRIP SYSTEM
When the temperature of the iron drops too low, the water chamber valve
automatically closes. This prevents hot water from spilling out through the vents of
the soleplate.
ANTI-CALC SYSTEM
Your iron contains an anti-scale cartridge to reduce scale deposits.
This considerably prolongs the operational life of your iron.
The anti-scale cartridge is an integral part of the water tank and does not need to be
replaced.
max
SET UP & USE
max
max

Page 10
AUTO SHUT-OFF
The Auto Shut-Off feature (or setting the thermostat to “OFF”) is not intended to
take the place of unplugging the cord. Disconnect the electric iron when not in use!
Even though the iron is unplugged, the soleplate is still hot. Be sure to rest the iron on
its heel, away from fabric.
1. When the iron is not moved with the
soleplate facing down (Fig. A) for 30 to
35 seconds approximately, the iron will
automatically turn off the power to the
heater.
2. When the iron is vertical on the Heel
Rest (Fig. B) for more than 8 to 9
minutes approximately, the iron will
automatically turn off the power to the
heater.
3. To turn the heater back on and resume
ironing, simply move the iron in any
direction. Place the iron on its Heel
Rest and allow the iron to reheat
before resuming ironing.
NOTE: · The Auto Shut-Off System works
regardless of position of the
Temperature Control Dial.
HELPFUL TIPS
Always read garment labels and follow the manufacturer’s ironing instructions.
• Sort the articles to be ironed according to the type of fabric.
• You should rst iron garments requiring low temperature to avoid damaging
them with an iron that is too hot.
• If you are unsure of the fabric content of the garment, test a small area, such as
a seam or facing, before ironing a visible area. Start with a low temperature and
gradually increase the heat to nd the best setting.
• When changing the temperature from a high setting to a low setting, allow
approximately 5 minutes for the lower temperature to be reached.
• When steam ironing, use long, slow passes over the fabric. This will allow the
steam to penetrate the fabric while allowing the heat of the soleplate to dry out
the moisture.
• To iron linens, turn garment inside out. Be careful not to use iron that is too hot
because the lining may melt or stick to the soleplate.
• To iron zippers, use an ironing cloth or make sure the zipper is closed and iron
over the ap. Never use iron over an unprotected zipper.
SET UP & USE
max
Fig. A
Soleplate facing
down
30-35 seconds
max
Fig. B
Steam iron on its
heel rest
8-9 minutes
