Carmen C82013 Mounting instructions

ALL-IN-1 WET & DRY
BODY GROOMER
MODEL C82013
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
www.carmen-products.co.uk

2
CUSTOMER SUPPORT TEAM: [phone]
TECHNICAL DATA
Description: All-In-1 Wet & Dry Body Groomer
Model: C82013
Rated Voltage: 100-240V
Frequency: ~50/60Hz
Power:
Adaptor: Input 100-240V ~50/60Hz 0.2A
Output DC5V 500mA
Battery: 3.7V 600mA
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RKW has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RKW Quality Assurance, United Kingdom

3
www.carmen-products.co.uk
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer,
its service agent or a similarly
qualied person.
• DO NOT let the cord hang over
the edge of a table or counter or
let it come into contact with any
hot surfaces.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• Keep the hot styling barrel away
from the skin.
• Please ensure that the appliance
is placed on a protective heat
mat when on the appliance
is operating or ‘On’. DO NOT
place on any surface whilst
operating without a protective
heat mat.
• DO NOT leave the appliance
unattended while it is operating.
• Never use while sleepy or
drowsy.
• Close supervision is necessary
when any appliance is used by
or near children.
• Children should not play with the
appliance.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Cleaning and user maintenance
should not be undertaken by
children without supervision.
• Take care when any appliance is
used near pets.
• DO NOT use the appliance
outdoors.
• The use of accessory
attachments is not
recommended by the appliance
manufacturer, apart from those
supplied with this product.

4
CUSTOMER SUPPORT TEAM: [phone]
• DO NOT use while bathing, or
place or store the appliance
where it can fall or be pulled into
a bath or sink.
• DO NOT operate with wet
hands.
• DO NOT use this appliance
near water and bathtubs,
showers, basins or other vessels
containing water.
• DO NOT use any extension cord
with this appliance.
• When the groomer is used in a
bathroom, unplug it after use
since the proximity of water
presents a hazard even when
the hair curler is switched o.
• For additional protection, the
installation of a residual current
device (RCD) having a rated
residual operating current not
exceeding 30 mA is advisable
in the electrical circuit supplying
the bathroom. Ask your installer
for advice.
• DO NOT place the appliance on
any surface while it is operating
or while the switch is turned on.
If any appliance falls into water,
unplug it immediately. DO NOT
REACH INTO WATER!
• This appliance is only intended
for shaving and trimming body
parts below the neckline. DO
NOT use it to shave or trim facial
or scalp hair.
• Never operate the groomer with
the air openings blocked or
while on a soft surface, such as
a bed or couch, where the air
openings may be blocked. Keep
the air openings free of lint, hair,
and the like.
• DO NOT operate, charge or
plug in groomer outdoors, where
aerosol (spray) products are
being used or where oxygen is
being administered.
• Always check the foil, cutters,
and trimmers before using
the groomer. DO NOT use the
groomer if the foil, cutters or
trimmers are damaged, as injury
may occur.
• Never put the groomer or
charging handle in direct sunlight
or store at a temperature above
60°C.
• This groomer is water-safe and
can be rinsed under running tap
water or used in shower. DO
NOT submerge this groomer in
water.

5
www.carmen-products.co.uk
• Only use the power cord and
charging stand provided to
charge the groomer.
• The groomer will only charge
when placed in the charging
stand.
• Always unplug the charging
handle from the electrical outlet
immediately after use, except
when groomer is (re)charging.
• Remove power supply cord from
charging stand before cleaning.
• When discarding groomer,
unplug charging handle and
remove groomer from charging
handle before removing
rechargeable batteries.
• The batteries used in this device
may present a re or chemical
burn hazard if mistreated. DO
NOT disassemble, heat above
100℃ (212℉) or incinerate.
• DO NOT put the groomer and/
or charging handle in direct
sunlight.
• DO NOT wrap the power cord
around the appliance to prevent
damage to the cord.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the Customer
Support Team.
HIGH VOLTAGE

6
CUSTOMER SUPPORT TEAM: [phone]
WHAT’S IN THE BOX
Instruction Manual
Groomer
Charging Stand
Adaptor
3x Trimming Combs
Back Shaving Attachment
Lubrication Oil
Cleaning Brush
1. Shaving Head
2. ON/OFF Button
3. Indicator Light
4. Charging Base
5. Back Shaving Attachment
Trimming Combs x 3
1 - 1/8 inch / 3mm
2 - 3/16 inch / 5mm
3 - 9/32 inch / 7mm
BEFORE THE FIRST USE:
1. Remove your appliance from the packaging.
2. Check that there is no damage to the cord or any visible damage to the body.
3. Your appliance is now ready for normal use.
4. Dispose of the packaging in a responsible manner.
5. Before using, check the foil, cutters, trimmers and combs for wear or damage. If the foil,
cutters, trimmers or combs show signs of wear or damage, do not use the groomer until the
damaged parts have been replaced, as injury may occur.
Dispose of the packaging in a responsible manner.
1
2
3
45
6
9

7
www.carmen-products.co.uk
USING YOUR APPLIANCE
Charging Your Appliance:
1. Make sure the ON/OFF switch is in the OFF
position.
2. Plug the adapter into the mains outlet.
3. Place the rechargeable handle on the base
on the charging contacts.
4. The charging indicator light should go on
and turn red, indicating that the unit is
being charged.
5. When charging is nished the charging
indicator light will turn green.
6. Before rst use, charge for at least 3 hours.
Using the Trimmer:
1. Ensure the unit is fully charged.
2. Take o the protective cap.
3. Move the power switch to the ON position
4. Hold the shaver against the skin and move
it gently against the direction of hair growth.
5. Don’t push too hard against the skin as this
will cause irritation and may damage the
shaver.
6. As your skin may be sensitive after shaving,
test your moisturiser on a small patch of
skin and wait to see irritation occurs.
7. Move the power ON/OFF switch to the OFF
position.
Trimming:
• Use this groomer for its intended household
use as described in this manual.
• The groomer comes with 3 trimming
combs to cut hair to 3 dierent lengths.
• If you are trimming for the rst time, be
careful. Do not move the groomer too fast.
Make smooth and gentle movements.
• Practice trimming with trimming comb 3
rst, to prevent accidentally trimming hairs
too short.
• Trimming is easier and more eective when
skin and hair are dry.
Instructions for Trimming:
1. Snap the desired trimming comb onto the
groomer. Make sure the teeth of the comb
point in the direction you will be moving the
appliance in (Fig.1)
2. When you move the groomer towards you,
the teeth should point toward you (Fig.2).
1
2

8
CUSTOMER SUPPORT TEAM: [phone]
3. When you move the groomer away from
you, the teeth should point away from you
( Fig.3).
4. Trimming Length Setting Table. The comb
size (1,2 or 3) is indicated on the back of
the comb.
Trimming Comb Hair length after trimming
1 1/8in./3mm
2 3/16 in./5mm
3 9/32in./7mm
5. Turn the groomer ON by pressing the on/
o button (Fig.4).
6. Move the groomer against the direction
of hair growth, making sure the tips of the
comb point in the same direction as you
are moving the groomer. Always make
smooth and gently movements and be sure
the surface of the comb always stays in
contact with your skin.
Note: Since not all hairs grow in the same
direction, you may want to try dierent trimming
positions (i.e. upwards, downwards, or across).
Practice is best for optimum results.
7. Turn the groomer OFF by pressing by
pressing the ON/OFF button.
Shaving:
• Do not use this groomer to shave or trim
facial or scalp hair. The groomer should
only be used on skin below the neckline.
• When shaving sensitive areas for the
rst time, you may feel some discomfort,
irritation or reddening of the skin. This is
normal as your skin needs time to adjust to
shaving.
• If your hair is longer than 13/32 in/10mm,
trim using trimmer comb 1 to a length
of 1/8 in.3mm rst for optimum shaving
results.
• For dry use, make sure that your skin is
clean and dry before using the groomer.
• For wet use, prepare your skin with
lathered soap or shaving foam before using
the groomer.
• Make sure the shaving foil is in complete
contact with your skin for the closest shave
and minimum foil wear.
• Applying too much pressure to the skin
may cause skin irritations.
• Practice is best for optimum results.
3
4

9
www.carmen-products.co.uk
Instructions for Shaving:
1. Remove any trimming comb from the
groomer (Fig.5)
2. Turn the groomer ON by pressing the ON/
OFF button (Fig.6).
3. Pull your skin taut with your free hand
and gently press the groomer to the
desired area. Move the groomer slowly
and smoothly against the direction of hair
growth. DO NOT press too hard. Too much
pressure can distort the foil and cause skin
irritation.
TIP: Scratching your skin can help prevent skin
irritation.
4. Make sure the shaving head is always in full
contact with your skin.
5. Turn the groomer OFF by pressing the ON/
OFF button (Fig.7)
Shaving with the back shaving attachment:
1. Press the release button (1) and open the
back shaving attachment (2) (Fig.8)
2. Place the groomer in the lower part of
the back shaving attachment holder.
3. Press the top against the top part of
the holder until it clicks into place (Fig.9
next page)
8
6
75

10
CUSTOMER SUPPORT TEAM: [phone]
4. Turn the groomer ON and shave your
back by moving the back shaving
attachment up and down by the
handle (Fig.10).
5. Remove the groomer from the back
shaving attachment by pressing
the ON/OFF button and pulling the
groomer toward you until it releases
from the holder(Fig.11)
6. Press the release button(1)and push
the handle against the holder(2) to
close the back shaving attachment
(Fig.12)
9
12
10
11
TROUBLESHOOTING
Questions Answers
My device will
not turn on?
Ensure the device
is plugged on and
the power switch is
turned to the ‘ON’
position.
How do I know
which comb to
use for my hair?
Every comb is
suitable for a
dierent hair length.
Please refer to table
1c. in the ‘Trimming’
section for this
information.
How do the
accessories
t into the
groomer?
Both the brushes
and the back
shaving attachment
snap onto the main
body of the groomer.
You should hear a
‘click’ when the part
is secured.

11
www.carmen-products.co.uk
CLEANING AND CARE
The groomer should be cleaned after each
use.
• Always switch the groomer OFF and
remove the power cord from the
charging handle and outlet before
cleaning.
• Do not use compressed air, abrasive
cleaning agents, scourers or
aggressive liquids such as gasoline,
alcohol, benzene bleach or acetone to
clean the appliance.
• Never clean, remove or replace the
shaving head assembly while the
motor is on.
• Do not apply pressure to the shaving
head. Do not touch the foil with hard
objects, as this may dent or damage
parts.
• Only use the cleaning brush supplied.
Any other brush may cause damage.
Cleaning the shaving unit:
1. Always switch the groomer o and remove
the power cord from the outlet before
cleaning.
2. Remove any trimming comb from the
groomer(Fig.13)
3. Remove the shaving head by pulling it o
the appliance (Fig.14). Hold the shaving
head by the plastic housing only.
4. Rinse the shaving head under warm
running tap water to remove debris (Fig.15)
Do not use the cleaning brush to clean the
shaving head, as this may cause damage
to the foil or cutters.
13
14
15

12
CUSTOMER SUPPORT TEAM: [phone]
5. Clean the hair chamber with the cleaning
brush, or rinse under warm running tap
water, to remove any residual debris
(Fig.16).
6. Do not use a towel or cloth to dry the
shaving foil or cutters, as this may cause
damage; allow to air dry thoroughly.
7. Reattach the shaving head by snapping it
back onto the groomer (Fig.17)
8. Rinse the groomer’s body and back
shaving attachment under running warm
tap water. Wipe dry with a soft clean towel
or cloth.
Replacing the shaving head:
• If the shaving foil and cutters are worn
or damaged, do not continue using the
groomer. Replace the shaving foil and
cutters immediately.
• It is recommended that your replace your
shaving foil and cutter once a year.
• The foil is a precision part. Handle with
care.
1. Always switch the groomer OFF and
remove the groomer from the charging
stand before replacing shaving head.
2. Remove the shaving head by pulling it o
the appliance (Fig.18).
3. Place the new shaving head on the
groomer by snapping it into place (Fig.19).
You will hear a “click”.
After replacing the shaving head, check that the
shaving head is rmly attached before using the
groomer.
16
17
18
19

13
www.carmen-products.co.uk
WARNING:
DO NOT IMMERSE ANY PART OF THE
APPLIANCE IN WATER
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.
Storage:
• Make sure the groomer is turned o.
Remove the power cord from the outlet
and charging stand before storing in a safe,
dry location where it will not be subject to
damage.
• Do not wrap the power cord around the
groomer or charging stand when storing.
• Store the cord in a safe location where it
will not be cut or damaged.
• Do not place or store the groomer or
charging stand where they can fall or be
pulled into a tub or sink while plugged in.

14
CUSTOMER SUPPORT TEAM: [phone]
NOTES

15
www.carmen-products.co.uk
NOTES

0717.V1
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are giving you an extra 2 years peace of mind.
To receive your extra 2 years guarantee, register your appliance
online within 28 days of purchase by visiting.
www.carmen-products.co.uk
Need help?
For advice, spares and returns.
Call:[phone]
8.30am to 6.00pm Monday-Friday
Visit: www.carmen-products.co.uk
Distributed throughout the UK by RKW LTD
