PULSOR® Series
DRIVER'S MANUAL
TABLE OF CONTENTS
1. Introduction ................................................................................................. 2
2. Safety ..................................................................................................... 2
3. Identification & Noise level ..................................................................................... 2
3.1. Nameplate ........................................................................................ 2
3.2. Noise level ........................................................................................ 2
4. Description .................................................................................................. 3
4.1. Cab command description ............................................................................ 3
4.2. Operation Principle ................................................................................. 3
4.2.1. Power source ............................................................................ 3
4.2.2. Operating modes ......................................................................... 3
5. Operation ................................................................................................... 4
5.1. Start the unit ...................................................................................... 4
5.1.1. "Road" mode ............................................................................. 4
5.1.2. "Standby" mode .......................................................................... 4
5.2. Stop the unit ...................................................................................... 5
5.3. Adjust the setpoint temperature ....................................................................... 5
5.4. Start a manual defrost mode ......................................................................... 5
5.5. Change Defrost parameters .......................................................................... 6
5.6. Defrost the eutectic compartment ...................................................................... 6
5.7. Display unit data ................................................................................... 7
5.8. Set user function ................................................................................... 7
6. Change screen brightness ..................................................................................... 8
7. Alarms ..................................................................................................... 8
7.1. Display the alarm list ................................................................................ 8
7.2. Alarm list ......................................................................................... 8
8. Maintenance ............................................................................................... 10
8.1. Introduction ....................................................................................... 10
8.2. Warning stickers maintenance ....................................................................... 10
8.3. Maintenance Schedule ............................................................................. 10
9. Recommendation ........................................................................................... 10
9.1. Before loading .................................................................................... 10
9.2. During loading .................................................................................... 11
9.3. After loading ...................................................................................... 11
10. ATP Agreement ............................................................................................ 12
11. Support .................................................................................................. 12
62-61746-03 1

GB
1. INTRODUCTION
The original guide was written in English. It has been prepared for the
end user of Carrier Transicold refrigeration units. It contains basic
instructions for the daily operation of the refrigeration unit as well as
safety information, troubleshooting tips, and other information that
will help you to deliver the load in the best possible condition.
Please take the time to read the information contained in this booklet
and refer to it whenever you have a question about the operation of
your Carrier Transicold unit.
Your refrigeration unit has been engineered to provide long, trou-
ble-free performance when it is properly operated and maintained.
The checks outlined in this guide will help to minimize on the road
problems. In addition, a comprehensive maintenance program will
help to ensure that the unit continues to operate reliably. Such a
maintenance program will also help to control operating costs, in-
crease the unit's working life, and improve performance.
When having your unit serviced, be sure to specify genuine Carrier
Transicold replacement parts for the highest quality and best relia-
bility.
At Carrier Transicold, we are continually working to improve the
products that we build for our customers. As a result, specifications
may change without notice.
2. SAFETY
Always observe the following safety instructions and regula-
tions.
DANGER
ELECTRICAL HANDLING OF THE UNIT SUCH AS "STAND-
BY" OR "GRID" MODE, MUST BE PERFORMED AS
DESCRIBED IN THIS MANUAL TO AVOID ANY RISK OF
ELECTROCUTION.
E & ECOOL UNITS OPERATE UNDER VERY HIGH VOLT-
AGE. NEVER ATTEMPT TO OPEN OR REPAIR YOUR UNIT
AS IT MAY RESULT IN FATAL INJURY.
CAUTION
SOME UNITS CAN AUTOMATICALLY RESTART IN THE
EVENT OF A LOSS OF ELECTRICAL POWER OR IF IT IS
SET TO START-STOP MODE.
WARNING
NEVER INTERVENE ON THE UNIT OR REMOVE SAFETY EL-
EMENTS & STICKERS. MAINTENANCE AND REPARATION
SHOULD ALWAYS BE PERFORMED BY A CARRIER
TRANSICOLD CERTIFIED TECHNICIAN.
CAUTION
NEVER TOUCH ANY SURFACE DURING OR SHORTLY AF-
TER OPERATION OF THE UNIT. OPERATING TEMPERA-
TURES CAN CAUSE SEVERE HOT AND COLD BURNS.
CAUTION
DO NOT TOUCH THE EVAPORATOR AND CONDENSER
FINS. THESE FINS ARE SHARP AND CAN CAUSE SERIOUS
CUTS.
CAUTION
KEEP HANDS AND CLOTHING AWAY FROM FANS WHILE
THE UNIT IS OPERATING AS MOVING COMPONENTS CAN
CAUSE CUTS AND INJURIES.
DANGER
LEAVE THE DOORS OPEN WHEN LOADING AND MAKE
SURE THAT NO-ONE REMAINS INSIDE THE REFRIGERAT-
ED COMPARTMENT WHEN CLOSING THE DOORS.
WARNING
THIS UNIT PRODUCES HIGH NOISE LEVEL. MINIMISE
CLOSE EXPOSURE TO THE UNIT WHILE IT IS IN OPER-
ATION.
CAUTION
NEVER OPERATE THE CAB COMMAND WHILE DRIVING.
3. IDENTIFICATION & NOISE LEVEL
3.1. NAMEPLATE
Each unit is identified by a nameplate (A) attached to the frame of
the unit. The nameplate identifies the complete model number of the
unit, the serial number (B) and additional information (see manual
cover for sticker location).
If a problem occurs, please refer to the information indicated
on this plate, and note unit the model and serial number be-
fore calling for assistance.
This information will be needed when you contact a tech-
nician so that he may properly assist you.
3.2. NOISE LEVEL
The noise level is also indicated on a sticker (C) attached to
the unit (see manual cover for sticker location).
Unit
Maximum Sound Power level
LWA(dB)
PULSOR® Series 83
62-61746-03 2

GB
4. DESCRIPTION
4.1. CAB COMMAND DESCRIPTION
The cab command shown in this manual is a multi-tempera-
ture model.
The procedures described in this document are the same for
a single-temperature cab command. The only difference are
the additional "COMP2" display and control keys.
1. Display (C1)
2. COMPARTMENT STATUS
led (C1)¹
3. MANUAL DEFROST key
(C1)
4. - key (C1)
5. SET key (C1)
6. + key (C1)
7. OFF key (C1)
8. ON key
9. OFF key (C2)
10. - key (C2)
11. SET key (C2)
12. + key (C2)
13. MANUAL DEFROST key
(C2)
14. COMPARTMENT STATUS
led (C2)¹
15. Display (C2)
16. ROAD OPERATION led
17. STANDBY OPERATION
led
(¹) Green: normal cycling (left half) / Red: malfunction (right
half).
(C1): Compartment 1 / (C2): Compartment 2.
Multi-temperature unit only.
If the cab command is built into the vehicle control panel it
must be located as far as possible from the heating ducts.
Maximum temperature of exposure: 70°C (150°F).
4.2. OPERATION PRINCIPLE
4.2.1. POWER SOURCE
4.2.1.1. IN "ROAD" MODE
PULSOR® units are equipped with the E-Drive all electric system,
which removes mechanical transmissions found in belt-driven refrig-
eration systems and transforms engine power into electricity through
a generator.
The generator is driven by the vehicle's batteries and supplies volt-
age to an inverter, which distributes it to the various components of
the unit.
The unit automatically starts or stops when the vehicle's engine is
switched on or off using the ignition switch.
4.2.1.2. IN "STANDBY" MODE
PULSOR® units can operate when the vehicle is docked by plugging
it into the mains.
The power connection is automatically detected by the unit, which
starts in "Standby" mode after pressing the ON key.
4.2.2. OPERATING MODES
4.2.2.1. CONTROLLED TEMPERATURE (COOLING &
HEATING)
As soon as the setpoint temperature has been reached, the temper-
ature control is achieved by the start-up and shut down of the com-
pressor.
The evaporator(s) fan(s) are programmed to stop during regulation.
When transporting fragile loads such as fresh meat, vegetables and
cheese, it is possible to program the microprocessor to obtain con-
tinuous ventilation by the evaporator during regulation.
To activate or deactivate the function, please refer to the Sec-
tion 5.8, “Set user function” > "EFOr" function.
4.2.2.2. DEFROST
Frost gradually builds up on the evaporator coils during normal op-
eration. The evaporator coil is defrosted by sending hot gas through
the coil (or by using optional electric heater(s)).
Defrost operation is fully automatic from start to finish but, can be
manually initiated if required.
For further information, please refer to the Section 5.4, “Start
a manual defrost mode”.
The start-up parameters can also be changed from automat-
ic to fixed interval. Please refer to the Section 5.8, “Set user
function”.
4.2.2.3. EUTECTIC SPECIFICITIES
PULSOR® units can be equipped with eutectic plates in addition to
an evaporator in order to reach deep-frozen temperatures.
Theses units require special care in order to work properly:
- Deep-frozen temperature require extra time to be reached, there-
fore, units must be started well before your drive (e.g. the night be-
fore) to reach the desired temperature.
- Frost gradually builds up on the eutectic plates. Unlike a regular
evaporator, the defrost sequence is not automatic, but is still crucial
for proper operation, which is why the unit must be defrosted man-
ually on a regular basis.
For further information, please refer to the Section 5.6, “De-
frost the eutectic compartment”.
The eutectic compartment is locked at -40°C (-40°F) and its
set point cannot be changed.
62-61746-03 3

GB
5. OPERATION
5.1. START THE UNIT
Power source selection is fully automatic. This is why there
is no button to select the desired mode. A soon as one op-
erating mode is disabled, the unit automatically starts up in
the other mode.
If the vehicle's ignition is switched on while the PULSOR®
unit is connected to the mains ("Standby" mode) or if the pow-
er plug is connected while the vehicle's engine is running
("Road" mode), the cab command unit will trigger a visual
alarm, in the form of a flashing red malfunction indicator light
and a A035 code.
As soon as one operating mode is disabled, the unit auto-
matically starts up in the other mode and returns to normal
functioning.
5.1.1. "ROAD" MODE
1. Switch on the vehicle's ignition.
2. Press the ON key to start the unit.*
After a prolonged shutdown in cold weather, the
compressor needs to warm up.
During this sequence, the unit displays "CPHT" for 3 to
12 minutes (the duration varies according to the ambient
temperature).
DO NOT SWITCH OFF while "CPHT" is displayed.
3. The setpoint will be highlighted for 5 seconds, followed by the
actual box temperature.
* Once you have started the unit at the beginning of your
drive, the following start and stop sequences are performed
automatically by the vehicle's ignition system.
5.1.2. "STANDBY" MODE
For safe & reliable operation in "Standby" mode, it is important
to consider the following guidelines:
A. ALWAYS check that the unit is OFF from the cab command
before connecting or disconnecting it from the mains.
B. The unit connection cable must be fitted with a ground
connection. The cable must be connected to earth.
C. On the 230V / 400V power supply, the unit must be connected
to a high sensitivity differential protection (30 mA).
D. Operations on the 230V / 400V power supply to the unit must
only be carried out by authorized personnel.
THE USER IS RESPONSIBLE FOR ENSURING THAT THE
ABOVE MEASURES ARE TAKEN AND COMPLIED WITH.
5.1.2.1. GUIDELINE CHART
Electrical
protection
Standardized exten-
sion cable H.07.RNF
Maximum 30m
Unit 230V
1Ph
50Hz
400V
3Ph
50Hz
230 V 400 V
PULSOR®
300 16 A 10 A 3 x 4 mm24 x 2,5 mm2
PULSOR®
350 16 A 10 A 3 x 4 mm24 x 2,5 mm2
PULSOR®
400 16 A 10 A 3 x 4 mm24 x 2,5 mm2
PULSOR®
400 MT 16 A 10 A 3 x 4 mm24 x 2,5 mm2
PULSOR®
500 16 A 10 A 3 x 4 mm24 x 2,5 mm2
PULSOR®
600 MT - 10 A - 4 x 2,5 mm2
5.1.2.2. PROCEDURE
1. Switch off the vehicle's ignition.
2. Plug the unit to the mains.
3. Press the ON key to start the unit.
After a prolonged shutdown in cold weather, the
compressor needs to warm up.
During this sequence, the unit displays "CPHT" for 3 to
12 minutes (the duration varies according to the ambient
temperature).
DO NOT SWITCH OFF while "CPHT" is displayed.
4. The setpoint will be highlighted for 5 seconds, followed by the
actual box temperature.
62-61746-03 4

GB
5.2. STOP THE UNIT
1. In "Road" mode, switch off the vehicle's ignition.
In "Standby" mode, press the OFF key(s).
2. The display(s) & the operation led(s) will go blank once the unit
is off.
On multi-temperature units, if you wish to deactivate a com-
partment, simply press the OFF1 or OFF2 key. Doing so, the
unit will continue to operate, but the selected compartment
will no longer be temperature-controlled.
5.3. ADJUST THE SETPOINT TEMPERATURE
If you wish to return to the compartment temperature display,
either press the ON key or wait 10 seconds. Note that doing
so, any changes made WILL NOT be saved.
1. Press the SET key to enter the setpoint menu (the actual
setpoint temperature will be displayed).
2. Press the SET key again and hold it down until the display starts
flashing.
3. Press or hold down either the - or + key to adjust the
temperature.
4. Press the SET key to save the change.
For multi-temperature units, this procedure is the same for
both compartments but must be carried out individually.
For eutectic units, the compartment fitted with eutectic
plates has its setpoint locked and can only operate at
freezing temperatures. Defrost related parameters are also
locked.
Setpoint parameters such as setpoint lock, highest or lowest
threshold, etc. can be set as required.
Please refer to the Section 5.8, “Set user function”.
5.4. START A MANUAL DEFROST MODE
Defrost operation is fully automatic from start to finish but,
can be manually initiated if required.
The start-up parameters can also be changed from automat-
ic to fixed interval. Please refer to the Section 5.5, “Change
Defrost parameters”.
This does not apply to eutectic units.
1. Press the key.
If the temperature inside the refrigerated box is too high
(> 3°C (37.4°F)) when pressing the key, the defrost
sequence will not start.
The unit will continue to operate normally in its current
mode.
2. "dFSt" will be displayed until defrost termination.
Note that on multi-temperature units, when one
compartment is defrosting, the other continues to
operate normally.
For multi-temperature units, this procedure is the same for
both compartments but must be carried out individually.
For eutectic units, the compartment fitted with eutectic
plates has its setpoint locked and can only operate at
freezing temperatures. Defrost related parameters are also
locked.
62-61746-03 5

GB
5.5. CHANGE DEFROST PARAMETERS
If you wish to return to the compartment temperature display,
either press the ON key or wait 10 seconds. Note that doing
so, any changes made WILL NOT be saved.
1. Press the SET and keys simultaneously (the currently
selected parameter is displayed).
2. Press either the - key or + key to change the parameter (see the
complete list below). The display starts flashing.
3. Press the SET key to validate the change.
For multi-temperature units, this procedure is the same for
both compartments but must be carried out individually.
For eutectic units, the compartment fitted with eutectic
plates has its setpoint locked and can only operate at
freezing temperatures. Defrost related parameters are also
locked.
ORD Display Description Available parameters
OFF
Auto1
Defrost interval (delay
between two defrost
sequences). 0.5H to 6.0H
2
Defrost coefficient K
(multiplies the waiting
time between two de-
frost sequences).
Only accessible if
"df d" is set to "Au-
to".
0.5 to 2.0
5.6. DEFROST THE EUTECTIC COMPARTMENT
Frost gradually builds up on the eutectic plates. Unlike a regular
evaporator, the defrost sequence is not automatic, but is still crucial
for proper operation, which is why the unit must be defrosted man-
ually on a regular basis.
Failing to perform proper defrost as described below, will re-
sult in poor unit performance.
Never use hot water or any flammable source to defrost eu-
tectic plates, as this could damage the system and present
a safety risk for you and your surroundings.
Frost build-up can be avoided by brushing the plates regu-
larly.
1. Stop the unit.
2. Open the box doors and wait for the plates to defrost naturally
(duration varies from 3 to 12 hours depending on ambient
condition).
WARNING
WATER WILL REMAIN ON THE FLOOR OF THE
COMPARTMENT AFTER DEFROSTING, POSING A
RISK OF SLIPPING. MOVE CAREFULLY AROUND
THE UNIT AND DRAIN OFF ANY REMAINING WA-
TER, TO PREVENT IT FREEZING ON THE FLOOR.
62-61746-03 6

GB
5.7. DISPLAY UNIT DATA
If you wish to return to the compartment temperature display,
either press the ON key or wait 10 seconds. Note that doing
so, any changes made WILL NOT be saved.
1. Hold down the SET key during 5 seconds.
2. Press the SET key again to scroll through the list.
3. Wait a few seconds or press the SET and + keys simultaneously
to access the data.
For multi-temperature units, this procedure is the same for
both compartments but must be carried out individually.
For eutectic units, the compartment fitted with eutectic
plates has its setpoint locked and can only operate at
freezing temperatures. Defrost related parameters are also
locked.
ORD Display Description Data
1 Active alarms. Up to 10 alarms.
2 Inactive alarms. Up to 15 alarms.
3Operating time in
Road mode (in hours).
Tens of hours
eg. 0010 displayed =
100 hours
4
Operating time in
Standby mode (in
hours).
Tens of hours
eg. 0005 displayed =
50 hours
5
Calculated time be-
tween two defrost se-
quences (Automatic
defrost).
Time in minutes.
6
Time remaining be-
fore the next defrost
sequence.
Time in minutes.
7Microprocess Soft-
ware version. X.XXX
8Microprocess Hard-
ware version. XXXX
9Cab Command Soft-
ware version. X.XX
10 Inverter Software ver-
sion. X.XX
11 Inverter Hardware ver-
sion. XXXX
5.8. SET USER FUNCTION
If you wish to return to the compartment temperature display,
either press the ON key or wait 10 seconds. Note that doing
so, any changes made WILL NOT be saved.
1. Hold down the key then while holding it, press the - and + keys
simultaneously.
2. Press the SET key to scroll through the list.
3. Press either the - or + key to change the function value.
4. Press the SET key to validate the change.
For multi-temperature units, this procedure is the same for
both compartments but must be carried out individually.
For eutectic units, the compartment fitted with eutectic
plates has its setpoint locked and can only operate at
freezing temperatures. Defrost related parameters are also
locked.
ORD Display Description
Available parameters
* Factory setting
1Lowest Set-
Point treshold.
0°C/-20°C*/-25°C/-30°C
(32°F/-4°F/-13°F/-22°F).
2Highest Set-
Point treshold. +20°C*/+30°C(68°F/86°F).
The list continues on the next page.
62-61746-03 7

GB
ORD Display Descrip-
tion
Available parameters
* Factory setting
3SetPoint
Lock.
OFF (SPOF): The setpoint temper-
ature can be modified.
ON (SPOn)*: The setpoint tempera-
ture cannot be modified.
4
Evap-
orator
Fan(s)
active
during
regula-
tion.
OFF (OFF)*: The evaporator fan
will not turn during regulation se-
quences.
ON (On): The evaporator fan will
turn during regulation sequences
(best practice when transporting
fragile load).
5
Com-
partment
Priori-
ty (only
for mul-
ti-tem-
perature
unit).
AUTO (Auto)*: The unit will give
priority to the compartment with the
lowest setpoint.
Compartment 1 (1): The unit will
give priority to the compartment 1.
Compartment 2 (2): The unit will
give priority to the compartment 2.
6. CHANGE SCREEN BRIGHTNESS
1. Hold down the - key to reduce screen brightness.
2. Hold down the + key to increase screen brightness.
For multi-temperature units, this procedure is the same for
both compartments but must be carried out individually.
7. ALARMS
7.1. DISPLAY THE ALARM LIST
If you wish to return to the compartment temperature display
at any time, press the ON key.
The microprocessor monitors the unit's performance at all time. It
will trigger alarm codes & lights up the alarm led, when detecting
abnormal conditions.
Several alarms can be triggered at the same time and will remain in
memory until they are cleared. Alarms can be cleared by any Carrier
Service Center.
1. Hold down the SET key during 5 seconds to access the active
alarm list (AXXX) or press again the SET key to access the
inactive alarms list (PXXX).
2. Press the - or + key to scroll trough the alarm list.
7.2. ALARM LIST
The list of alarms below is not exhaustive. If the alarm occur-
ring on your unit is not listed below, stop the truck and con-
tact the nearest Carrier Service Center.
ALARM SEVERITY
Alarm only. The unit continues to operate.
Shutdown alarm. The unit can no longer operate.
MALFUNCTION - RED FLASHES
AS CODE DESCRIPTION ACTION
A000
No malfunc-
tion. Unit is ful-
ly operational.
A001
to A003
Compressor
related fault.
Contact the nearest Carrier
Service Center.
A004 AAT Thermis-
tor fault.
The thermistor value is out
of range. Wait until the tem-
perature is within the normal
range.
If the problem persists con-
tact the nearest Carrier Ser-
vice Center.
A010
to A15
Pressure Eq.
valve fault.
Contact the nearest Carrier
Service Center.
A016 VCAB supply
failure.
Over current is detected. The
cab command is switched off.
Contact the nearest Carrier
Service Center.
A017 Wake-up signal
failure.
Contact the nearest Carrier
Service Center.
A018
Microprocessor
temperature
too high.
The microprocessor board
overheated. Wait until the
temperature is within the nor-
mal range.
62-61746-03 8

GB
MALFUNCTION - RED FLASHES
AS CODE DESCRIPTION ACTION
If the problem persists con-
tact the nearest Carrier Ser-
vice Center.
A019
to A020
Inverter or
Compressor
related fault.
Contact the nearest Carrier
Service Center.
A021 Cab command
comm. failure.
A communication failure with
the cab command has been
detected.
Contact the nearest Carrier
Service Center.
A025
Logic board
power relay
failure.
A030
to A031
Battery related
fault.
Contact the nearest Carrier
Service Center.
A035 Double power
supply
The unit detects two power
sources. Switch off the vehi-
cle's ignition or disconnect the
unit from the power grid.
If the problem persists con-
tact the nearest Carrier Ser-
vice Center.
A040 Runtime not
valid
Road or Standby hour meters
not filled.
Contact the nearest Carrier
Service Center.
A050
to A080
Compressor
related fault.
A081
to A082
Condenser fan
motor related
fault.
Contact the nearest Carrier
Service Center.
A083
or SEr
General main-
tenance alert.
Road + Standby runtimes
have exceeded the mainte-
nance period.
Contact your local Carrier
Service Center.
A084 or
SErC
Compressor
maintenance
alert.
The compressor runtimes has
exceeded the maintenance
period.
Contact your local Carrier
Service Center.
A100
A200
RAT Thermis-
tor fault.
A101
A201
DTT Thermis-
tor fault.
The thermistor value is out
of range. Wait until the tem-
perature is within the normal
range.
Contact your local Carrier
Service Center.
If the problem persists con-
tact the nearest Carrier Ser-
vice Center.
A110
to A117
A210
to A217
Evaporator
component re-
lated fault.
Contact the nearest Carrier
Service Center.
A140
to A151
A240
to A251
The box tem-
perature is out-
side the set-
point range.
Wait until the temperature
is within the setpoint range
(±5°C).
Contact the nearest Carrier
Service Center.
MALFUNCTION - RED FLASHES
AS CODE DESCRIPTION ACTION
A155
A255
Defrost se-
quence too
long.
The defrost duration exceed-
ed the normal duration. A
new defrost sequence is au-
tomatically scheduled (if in
AUTO mode).
If the problem persists con-
tact the nearest Carrier Ser-
vice Center.
A165
A265
Evaporator
component re-
lated fault.
Contact the nearest Carrier
Service Center.
A170
to A173
A270
to A273
Heater related
fault.
Contact the nearest Carrier
Service Center.
A500
to A530
Generator re-
lated fault.
The unit can still operate in
Standby mode (except for the
A530).
Contact the nearest Carrier
Service Center.
A600
to A645
Inverter related
fault.
Contact the nearest Carrier
Service Center.
A647
Battery
mismatch
(12V/24V)
The battery installed or the
configuration is incorrect.
Contact the nearest Carrier
Service Center.
A648
to A672
Inverter related
fault.
Contact the nearest Carrier
Service Center.
62-61746-03 9

GB
8. MAINTENANCE
8.1. INTRODUCTION
A comprehensive maintenance program ensures that the unit con-
tinues to operate reliably. Such a maintenance program will also help
to control operating costs, increase the unit's working life, and im-
prove performance.
IMPORTANT TO READ AND FOLLOW
Regular maintenance includes a quick overview of the
unit from a safety perspective. Service Technician must
pay particular attention, but not exclusively to: nuts and
bolts tightening (replacing if missing), electrical wires,
harnesses, fuel lines routing (repairing or replacing if
needed), doors, skins grills, panels conditions (repairing
or replacing if needed).
Confirmation of such operations can be detailed on request.
All maintenance services must be done by a technician
trained on Carrier Transicold products, respecting all safety
and quality standards of Carrier Transicold.
8.2. WARNING STICKERS MAINTENANCE
1. Keep the warning pictograms clean and
without any obstruction material.
2. Clean the pictograms with water and soap
and wipe them with soft fabric.
3. Replace damaged or missing pictograms
with new pictograms available from the
Carrier Transicold network.
4. If a component bearing a pictogram is
replaced by a new one, make sure that the
new component has the correct pictogram.
5. Place a warning pictogram by applying it on
a dry surface. Press down on the outside to
remove any air bubbles.
8.3. MAINTENANCE SCHEDULE
Service Type Service frequency
Hours* Km* Initial
Service Service A Service B
100 5000 X
1000 30 000 X
2000 60 000 X
3000 90 000 X
4000 120 000 X
5000 150 000 X
6000 180 000 X
* Whichever comes first.
9. RECOMMENDATION
9.1. BEFORE LOADING
DEFROST Properly defrost your transport refrigeration unit.
CLEAN THE EQUIPMENT Especially the interior: walls, roof and
floor.
When washing the vehicle, DO NOT point the high-pres-
sure water under the skin.
DO NOT spray water on electric components.
Units charged with low GWP refrigerant are equipped
with refrigerant detectors that are located in the evapora-
tor section (these detectors are identified by a sticker).
Pay special attention to these electrical detectors when
cleaning, DO NOT spray water on them.
When washing the interior, DO NOT spray the fan with
detergent.
PARTIAL LOADING Use movable bulkheads to limit compart-
ment size in case of partial loading.
STRIP CURTAINS To limit the flow of cold air to the outside, use
strip curtains and make sure they are not too old and with a prop-
er length down to the floor.
PRE-COOL THE BODY When possible, pre-cool the body on
standby mode to reduce noise and CO2 emissions. Do not leave
the vehicle unattended during pre-cooling.
GOODS TEMPERATURE Goods must be at the right tempera-
ture before loading.
62-61746-03 10

GB
9.2. DURING LOADING
RESPECT CORRECT TEMPERATURE Products should always
be loaded from a refrigerated loading bay in order to maintain the
correct temperatures. The setpoint doesn’t need to be at -26°C if
only -18°C are required.
SEPARATE GOODS Do not mix refrigerated and dry goods in
the same compartment. The second compartment cannot be
cooled by a fan from the first compartment for hygiene reason.
TEMPERATURE CONTROL Perform load tests with the right
materials to ensure the products are loaded in at the optimal tem-
perature. Do not obstruct the evaporator with the loaded goods.
Make sure that air circulation is not impeded. Properly orientating
the pallets allows the airflow to reach above, through and under-
neath the load. Do not load up to the ceiling, as this will cause
short cycling.
DETECTORS CLEARANCE Units charged with low GWP refrig-
erant are equipped with refrigerant detector that are located in
the evaporator section (these detectors are identified by a stick-
er). Pay special attention to these detectors. At no time should
their access be blocked. Ensure proper airflow to these detec-
tors.
9.3. AFTER LOADING
SHUT DOWN UNIT WHEN OPENING DOORS Cold air is heav-
ier than hot air. Opening doors with no curtains leads warmer air
to replace cooler air. Operating the unit when doors are opened
may result in frost and increase energy consumption. Carrier al-
so offers door switches to shut down the unit automatically when
loading the van, which reduces the warm air penetration into the
box.
KEEPING DOORS CLOSED Keep doors closed as long as pos-
sible.
WAITING TIME Minimize the wait time during which the goods
are on the loading dock.
PARKING Park the vehicle in the shade. Do not park your vehi-
cle in a slope greater than 10% to avoid poor water drainage.
UNIT STORAGE In the event of a prolonged shutdown, open
the doors and compartments of the refrigerated box. Never leave
your unit more than a month without running.
AIR RENEWAL Units charged with low GWP refrigerant should
operate for at least one hour once a month with the refrigerated
box doors and compartments open.
62-61746-03 11

GB
10. ATP AGREEMENT
This unit is subject to the Agreement on the International Car-
riage of Perishable Foodstuffs and on the Special Equipment to
be used for such Carriage (ATP).
This refrigeration unit has therefore been approved by the Regional
Health Department and is marked with a plate indicating the date of
expiration of the approval form.
* Example of an ATP plate showing (from top to bottom) the unit
approval number, equipment number, classification and expiry date.
The plate location might differ depending on the installation.
Regularly check the expiry date of the certificate of ap-
proval. During transport, the certificate of approval or
provisional certificate must be presented to qualified of-
ficials who request it.
11. SUPPORT
Whether you need breakdown support in your own country or inter-
nationally, our team is on hand to help get you back on the road as
soon as possible -- 24/7/365 -- with the minimum of hassle.
WE'RE JUST
ONE CALL AWAY
FIND THE NEAREST
SERVICE CENTER
62-61746-03 12

©2023 Carrier Corporation - Carrier Transicold Europe S.C.S. au capital de 16 090 700 eurosR.C.S. Nanterre 410 041 776
Code APE 4669B - VAT: FR52410041776 - The information contained in this document is not contractually binding, and may
not be reproduced without prior approval.
Our company is constantly seeking to improve the quality of its products and,
therefore, reserves the right to modify its products without prior notice.
Over 600 Carrier Service Centers
in Europe, Russia,
Middle East and Africa
CARRIER TRANSICOLD EUROPE S.C.S.
LE CRISTALIA
3 rue Joseph Monier
92 500 Rueil-Malmaison
Phone: [phone]
Fax: [phone]
www.carriertransicold.eu
62-61746-03_Rev03
