KGALB0101KIT
Installation Instructions
LABEL KIT FOR FIXED SPEED, 2---STAGE
AND VARIABLE SPEED, 33.3 IN (846 MM)
MULTIPOISE, NON---CONDENSING FURNACES
NOTE: Read the entire instruction manual before starting the
installation
SAFETY CONSIDERATIONS
FIRE, EXPLOSION, ELECTRICAL SHOCK
HAZARD
Failure to follow this warning could result in personal
injury, death and / or property damage.
Improper installation, adjustment, alteration, service,
maintenance, or use can cause carbon monoxide poisoning,
explosion, fire, electrical shock, other conditions, which
could result in personal injury or death. Consult your
distributor or branch for information or assistance. The
qualified installer or agency must use only factory--
authorized kits or accessories when servicing this product.
!WARNING
Installing and servicing heating equipment can be hazardous due
to gas and electrical components. Only trained and qualified
personnel should install, repair, or service heating equipment.
Untrained personnel can perform basic maintenance functions
such as cleaning and replacing air filters. All other operations
must be performed by trained service personnel. When working
on heating equipment, observe precautions in the literature, on
tags, and on labels attached to or shipped with the unit, and other
safety precautions that may apply.
Follow all safety codes. In the United States, follow all safety
codes including the National Fuel Gas Code (NFGC) NFPA No.
54--2006/ANSI Z223.1--2009. In Canada, refer to the National
Standard of Canada, Natural Gas and Propane Installation Codes
(NSCNGPIC), CAN/CGA--B149.1 and .2--2010.
Wear safety glasses and work gloves. Have a fire extinguisher
available during start--up, adjustment procedures, and service
calls.
Recognize safety information. This is the safety--alert symbol !
!.
When you see this symbol on the furnace and in instructions or
manuals, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING,
CAUTION, and NOTE. The words DANGER, WARNING, and
CAUTION are used with the safety--alert symbol. DANGER
identifies the most serious hazards which will result in severe
personal injury or death. WARNING signifies hazards which
could result in personal injury or death. CAUTION is used to
identify unsafe practices which would result in minor personal
injury, or product and property damage. NOTE is used to
highlight suggestions which will result in enhanced installation,
reliability, or operation.
INTRODUCTION
This instruction covers the installation of safety, service and
information labels used on Fixed Speed, 2--speed and
Variable--speed, 80 AFUE, 33.3--in. (846mm) high, induced--
combustion furnaces.
Table 1 – Kit Contents
PART NUMBER PART NAME
327558--- 101 Label, Warning
336996--- 101 Label, Clearance, and Warning
327801--- 201 Label, Info
337802--- 201 Label, Info
337803--- 201 Label, Info
I I K --- K G A L B --- 0 4 Installation Instructions

2
DESCRIPTION AND USAGE
This kit may be used to replace labels that are upside--down when the furnace is installed in the Downflow position. Only the labels that are
upside--down when the outer door and blower access door is installed are included in this kit. The unit rating plate is NOT included in this kit.
The unit rating plate is unique to each furnace and is not considered a service item.
Use the following tables to determine the correct label for the following furnaces:
STANDARD MODEL DELUXE MODEL 2 --- S P E E D M O D E L VARIABLE SPEED MODEL
Label Number 58STA/STX 58DLA/DLX
58PHA/PHX 58CTA/CTX 58CVA/CVX
327558--- 101 X X X X
336996--- 101 X X X X
337801--- 201 X X N/A N/A
337802--- 201 N/A N/A XN/A
337803--- 201 N/A N/A N/A X
X --- L a b e l u s e d
STANDARD MODEL DELUXE MODEL 2 --- S P E E D M O D E L VARIABLE SPEED MODEL
Label Number 310AAV/JAV 311AAV/JAV
313AAV/313JAV 312AAV/JAV 315AAV/JAV
327558--- 101 X X X X
336996--- 101 X X X X
337801--- 201 X X N/A N/A
337802--- 201 N/A N/A XN/A
337803--- 201 N/A N/A N/A X
X --- L a b e l u s e d
STANDARD MODEL DELUXE MODEL VARIABLE SPEED MODEL
Label Number PG8MAA/PG8JAA PG8MEA/PG8JEA PG8MVA/PG8JVA
327558--- 101 XXX
336996--- 101 XXX
337801--- 201 X X N/A
337802--- 201 N/A N/A N/A
337803--- 201 N/A N/A X
X --- L a b e l u s e d
APPLY THE CORRECT LABELS
1. From the unit rating plate and the tables above, determine the correct labels required.
2. Turn off electrical power to furnace at service switch, fuse, or circuit breaker.
3. Remove outer door and blower access door.
4. It is not necessary to remove old labels from doors. However, doors must be dry and free of dust, dirt, grease and oil. If necessary,
clean old label surfaces with household glass or surface cleaners.
5. Remove the paper backing from the appropriate label.
6. Orient the label in the correct position and apply over the surface of the old label. Prevent air bubbles in the new label by applying the
label at one corner and smooth the label out, working toward the opposite corner.
7. Repeat for the other labels.
8. Re--install the blower access door and unit outer door.
9. Turn on electrical power to furnace.
10. Check furnace for correct operation (refer to furnace Installation Instructions.)
Copyright 2012 CAC / BDP D7310 W. Morris St. DIndianapolis, IN 46231
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
C a t a l o g N o : I I K --- K G A L B --- 0 4
Replaces: IIK--KGALB--02
Printed in U.S.A. Edition Date: 02/12
