Carwires CR200BT User manual

User’s Manual
CR200BT
MP3/BLUETOOTH COMPATIBLE
DIGITAL MEDIA RECEIVER
WITH USB AND SD MEMORY CARD PORTS
AND FRONT PANEL AUX INPUT

[PWR]: Press to POWER on or off the unit
[MUTE]: Press to MUTE the audio sound from your speakers
[BAND]: Press to shift to the next set of radio station presets while in the radio mode.
FM1 --- FM2 --- FM3
[VOLUME] knob: Adjust the volume level (rotate).
Press knob repeatedly to select from various sound settings.
Rotate knob to adjust each sound setting accordingly.
Sound Settings
1. Bass/Treble/Balance/Fader
2. Loudness: ON/OFF
3. EQ PRESETS: (Pop, Rock, Classic)
4. Local/DX
5. Stereo/Mono
[MODE]: Select playback source
[CLK]: Clock display switch,
a) Long press CLK button for time adjustment.
b) Rotate VOLUME knob to adjust hours
c) Press VOLUME knob again to adjust the minutes.
d) Press CLK button to finish.
[APS]: Automatic Program Search (Radio Mode)
Press to automatically seek FM radio stations and stay on each for 5 seconds. During these 5
seconds, press it again to stay on the station. Press the APS for more than 3 seconds, it will clear
previous station memory and re-seek and store new stations. Press again to finish.
(USB/SD Mode) Press to enable direct track searching, use the VOLUME knob to search.
[|<<, >>|]: Radio mode, press to automatically scan to the next FM radio station. Long press to
manually adjust the FM tuner. USB/SD Mode, press to advance to the next or previous song.
Long press to fast forward or rewind a music track.
[1/PAUSE]: SD or USB mode, press to pause, press again to play.
[2/INT]: Music Browse, Press “INT” to play each song for only 10 seconds in order. Press again to
stop music browse and playback normally.
[3/RPT]: Song Repeat; Press to repeat playback of the same track.
[4/RDM]: Random Playback; Press for random playback of your music library.
[5/-10]: Press to skip 10 songs backward; Long press transfer document backward.
[6/+10]: Press to skip 10 songs forward; Long press transfer document forward.
General Operation

Display Information
During playback, ID3 tag information will display on the LCD screen:
FOLDER, FILE, ALBUM, TITLE, ARTIST and Track Number with Elapsed Time.
Micro SD Card and USB Slots
Located on the right side of the LCD display behind the door.
Accepts MicroSD Cards and USB Thumb Drives up to 32GB Capacity.
Auxiliary Audio Input
Located in the bottom right corner.
Accepts a standard 3.5mm Audio Cable.
Bluetooth Setup
1. Turn on your smartphone’s Bluetooth
2. Press the [MODE] button on the CAR STEREO to set the source to “BT”.
3. Now go back to your smartphone’s Bluetooth settings, you should now see a new Bluetooth device
show up called “CAR BT”. Select that new device and should now be connected.
4. For some reason the setup fails, turn off your smartphone’s Bluetooth and turn it back on and repeat
steps 1-3.
Wiring Diagram
Notes of connection
• To avoid short circuit in the electrical system, ensure that the negative battery cable is disconnected
USB/SD/AUX and Bluetooth Function
Device Connections

before installation. 
• To prevent short circuit in the wiring and damaging to this unit, secure all wirings with cable clamp or
adhesive tape. Route the wirings in a secured, out of heating place without touching any moving parts
such as gear shift, handbrake, and seat rails to prevent the wiring insulation being melted / wore off. 
• Never pass the yellow power cord through the installation hole into the engine compartment and connect
to the car battery. Otherwise, a high possibility of serious short circuit to the electrical system may be
occurred. 
• Replacing a new fuse with 10A rating when the old one is broken, using no fuse or fuse with improper
rating may cause damage to this unit or even res. If a proper fuse is installed and electrical problems still
occur, please contact with any professional car shops for inquiry. 
• DO NOT connect other equipment with the car battery to avoid battery overheating. 
• Please make sure all the wiring connections & the cables of the Speakers are well- insulated. Otherwise,
this unit may be damaged by short circuit. 
• If there is no ACC available, please connect ACC lead to the power supply with a switch. 
• If an external power amplifier is connected, please don't connect P.CONT lead to the power lead of the
external power amplifier, otherwise, electric spark or other damage may be resulted. 
• Never ground the speaker output to prevent the damage to the built-in power amplifier. 
1. Disconnect battery
Before you begin, always disconnect the battery negative terminal.
Note:
If the unit is to be installed in a car equipped with an on-board drive or navigation computer, do not
disconnect the battery cable. If the cable is disconnected, the computer memory may be lost. Under these
conditions, use extra caution during installation to avoid causing a short circuit.
2. Remove unit from sleeve
Lift latches on both sides of sleeve to remove half-sleeve from the unit.
Mounting Sleeve Installation
1. Slide the mounting sleeve off the chassis, use the removal tools (supplied) to disengage it.
2. Check the dashboard opening size by sliding the mounting sleeve into it.
If the opening is too small, carefully cut or file as necessary until the sleeve easily slides into the opening.
Do not force the sleeve into the opening or cause it to bend or bow. Check for sufficient space behind the
dashboard for the unit chassis. This unit can be installed in any dashboard with a suitable 7.2-inch (W) x
2.04-inch (H) opening as shown above. The dashboard should be ¼-inch thick in order to support the unit.
3. Locate the series of bend tabs along the top, bottom, and sides of the mounting sleeve. With the sleeve
fully inserted into the dashboard opening, bend as many of the tabs outward as necessary to firmly secure
the sleeve to the dashboard.
4. Place the unit in front of the dashboard opening so the wiring can be brought through the mounting
sleeve. Follow the wiring diagram carefully and make certain all connections are secure and insulated with
wire nuts or electrical tape. After completing the wiring connections, turn the unit on to confirm operation
(vehicle ignition must be on). If the unit does not operate, re-check all wiring until the problem is corrected.

Installation Guide

5. Make sure the radio is right-side up, then carefully slide the radio into the mounting sleeve until it is fully
seated and the spring clips lock it into place.
6. Secure the rear of the unit to the car body using the mounting bolt and rubber cushion. 
7. Test the unit using the “Operation” instructions that follow. 
Kit Installation
If your vehicle requires the use of an installation kit to mount this unit, follow the instructions included with
the installation kit to attach the unit to the mounting plate supplied with the kit.
1. Wire and test the unit as outlined in the Mounting Sleeve Installation instructions.
2. Install the radio/mounting plate assembly
to the sub-dashboard according to the
instructions in the installation kit.
3. Replace the dashboard trim panel.
ISO Installation
This unit has threaded holes in the chassis side panels which may be used with the original factory
mounting brackets of some vehicles to mount the radio to the dashboard. Please consult with your local
car stereo shop for assistance on this type of installation.
1. Remove the existing factory radio from the dashboard or center console mounting. Save all hardware
and brackets as they will be used to mount the new radio.
2. Carefully unsnap the plastic frame from the front of the new unit chassis. Remove and discard the
frame. 
3. Remove the factory mounting brackets and hardware from the existing unit and attach them to the new
unit. Please use the attached screws. Unsuitable screws may damage components inside the chassis. 
4. Wire the new unit as outlined in the Mounting Sleeve Installation instructions. 
5. Mount the new unit assembly to the dashboard or center console using the reverse procedure of step 1.

General
Power supply: 12VDC (12V-15V), negative ground
Maximum power output: 50W x 4 channels
Continuous power output: 20W x 4 channels
Suitable speaker impedance: 4-8 ohm
Components
Mounting Sleeve x 1 PC
Wire Harness x 2 PCS (1 speaker, 1 power)
Trim Ring x 1 PC
Removal Keys x 2 PCS
Operating Instructions x 1 PC
Wireless Remote Control x 1 PC
Specifications

Carwires USA
18521 E Queen Creek Rd, Suite 105-440
Queen Creek, AZ 85142
www.carwires.com
844.227.9473
warranty support: www.carwires.com/warranty-information
