ERVICE MANUAL
S
D-Series
25D through 100D
Non-Sideshifting &
Sideshifting Clamps,
40D Turnafork TM
Manual Number 669224-R5

i669224-R5
ONTENTS
C
Page Page
INTRODUCTION, Section 1 SERVICE, Section 5
Introduction 1 Attachment Removal 23
Special Definitions 1 Arms 24
INSTALLATION, Section 2 Arm Assembly Removal and Installation 24
Truck Requirements 2 Bolt-On Arm Removal 25
Recommended Hydraulic Supply 3 Multi-Purpose/Rigid and Drum Arm Contact
Surface Replacement 26
Installation Procedure 4
Custom Arm Installation 9 Rigid Arm Contact Pad Rotation and
Replacement 26
Prior to Operation 10
PERIODIC MAINTENANCE, Section 3 Arm Bearing Removal and Installation 27
100-Hour Maintenance 11 Turnafork Arm Service 28
500-Hour Maintenance 11 Turnafork Arm Indexing 29
1000-Hour Maintenance 11 Cylinders 30
2000-Hour Maintenance 11 Cylinder Removal and Installation 30
TROUBLESHOOTING, Section 4 Cylinder Service 32
General Procedures 12 Cylinder Disassembly 32
Truck System Requirements 12 Cylinder Inspection 32
Tools Required 12 Cylinder Reassembly 33
Troubleshooting Chart 12 Restrictor Cartridges 34
Plumbing – Top Mount Valve 13 Restrictor Cartridge Adjustment 34
Hosing Diagram, Non-Sideshifting 13 Check Valves 35
Circuit Schematic, Non-Sideshifting 13 Check Valve Removal – Top Mount Valve 35
Hosing Diagram , Sideshifting
(including Turnafork) 14
Check Valve Removal – Center Mount Valve 35
Check Valve Service – Top Mount Valve 36
Circuit Schematic, Sideshifting
(including Turnafork) 15
Check Valve Service – Center Mount Valve 37
Eliminating the Arm Opening Regenerative
Function 37
Plumbing – Center Mount Valve 16
Hosing Diagram, Non-Sideshifting 16 Base Unit 38
Circuit Schematic, Non-Sideshifting 16 Frame and Mounting Plate Disassembly and
Reassembly 38Hosing Diagram , Sideshifting 17
Circuit Schematic, Sideshifting 18 Solenoid Valve 39
Attachment Troubleshooting 19 Coil Service 39
Clamp Circuit Pressure Test 19 Valve Service 39
Check Valve Pressure Test 20 SPECIFICATIONS, Section 6
Cylinder Test 20 Specifications 40
Sideshift Circuit Pressure Test 21 Hydraulics 40
Electrical Circuit 22 Auxiliary Valve Functions 40
Truck Carriage 41
Torque Values 42

669224-R5 1
NTRODUCTION
I
1.1 Introduction
This Manual provides the Installation, Periodic
Maintenance, Troubleshooting, Service and Specifications
for Cascade D-Series Non-Sideshifting Clamps,
Sideshifting Clamps and 40D Turnaforks.
In any communication about the attachment, refer to the
product I.D. number stamped on the nameplate as shown.
If the nameplate is missing, the numbers can be found
stamped on the right front web of the baseplate.
IMPORTANT: All hoses, tubes and fittings on these
attachments are JIC.
NOTE: Specifications are shown in both inch and (Metric)
units.
1.2 Special Definitions
The statements shown appear throughout this Manual
where special emphasis is required. Read all WARNINGS
and CAUTIONS before proceeding with any work.
Statements labeled IMPORTANT and NOTE are provided
as additional information of special significance or to make
your job easier.
WARNING - A statement preceded by
WARNING is information that should be
acted upon to prevent bodily injury. A
WARNING is always inside a ruled box.
CAUTION - A statement preceded by CAUTION is
information that should be acted upon to prevent
machine damage.
IMPORTANT - A statement preceded by IMPORTANT is
information that possesses special significance.
NOTE - A statement preceded by NOTE is information that
is handy to know and may make your job easier.
cascade
®
cascade
®
CL1159.eps Nameplate
Nameplate

2669224-R5
NSTALLATION
I
WARNING: Rated Capacity of the truck/
attachment combination is a responsibility
of the original truck manufacturer and may
be less than that shown on the attachment
nameplate. Consult the truck nameplate.
GA0380.eps
Truck Relief Setting
2000 psi (140 bar) Recommended
2300 psi (160 bar) Maximum
Truck Flow Volume ➀
Min. ➁Recommended Max. ➂
25D 4 GPM
(15 L/min.)
5.5 GPM
(21 L/min.)
5.5 GPM
(21 L/min.)
35D 4 GPM
(15 L/min.)
7 GPM
(26 L/min.)
7 GPM
(26 L/min.)
40D, 50D 4 GPM
(15 L/min.)
10 GPM
(38 L/min.)
10 GPM
(38 L/min.)
70D, 80D, 100D
7 GPM
(26 L/min.)
12 GPM
(45 L/min.)
15 GPM
(57 L/min.)
➀Cascade D-Series Clamps are compatible with SAE 10W
petroleum base hydraulic fluid meeting Mil. Spec. MIL-0-5606 or
MIL-0-2104B. Use of synthetic or aqueous base hydraulic fluid
is not recommended. If fire resistant hydraulic fluid is required,
special seals must be used. Contact Cascade.
➁Flow less than recommended will result in unequal arm
movement.
➂ Flow greater than maximum can result in excessive heating,
reduced system performance and short hydraulic system life.
Carriage Mount Dimension (A) ITA (ISO)
Minimum Maximum
Class II
Class III
Class IV
14.94 in. (380.0 mm)
18.68 in. (474.5 mm)
23.44 in. (595.5 mm)
15.00 in. (381.0 mm)
18.74 in. (476.0 mm)
23.50 in. (597.0 mm)
A
GA0028.eps
Carriage – Clean and inspect
carriage bars. Make sure the bars
are parallel and that ends are flush.
Repair any damaged notches.
GA0082.eps
Hoist Down
Hoist Up
Tilt Forward
Tilt Backward
Sideshift Left
Sideshift Right
Open
Clamp
Auxiliary Valve Functions
Check for compliance with ITA (ISO) Standards:
2.1 Truck Requirements

3
669224-R5
NSTALLATION
I
2.2 Recommended
Hydraulic Supply
D-Series Clamps provide the best performance with one
of the hydraulic supply arrangements shown below. Refer
to Cascade Hose & Cable Reel Selection Guide, Part No.
212199, to select the correct hose reel for the mast and
truck. The hose and fitting requirements are:
• All hoses and fittings for CLAMP function should be
at least No. 8, minimum internal diameter of 13/32 in.
(10 mm).
• All hoses and fittings for SIDESHIFT function should
be at least No. 6, minimum internal diameter of 9/32 in.
(7 mm).
Non-Sideshifting
A or B
RH or LH THINLINETM 2-port hose reel group
OR
CMast single internal hose reeving group
Sideshifting
A and B
RH or LH THINLINETM 2-port hose reel group
OR
CMast double internal hose reeving group
Sideshifting with Solenoid
A6-N-1 cable/hose reel group
OR
A and C
Cable reel and single internal hose reeving group
GA0033.eps
AB
C

4669224-R5
NSTALLATION
I
2.3 Installation Procedure
Follow the steps shown to install the attachment on the truck.
Read and understand WARNING and CAUTION statements.
If you don't understand a procedure, ask your supervisor or
call the nearest Cascade Service Department for assistance.
CL0442.ai
1
2
Attach overhead hoist
A Remove banding, use multiple chains to
stabilize the attachment while lifting. Set the
attachment upright on the pallet.
B If equipped, remove bolt-on lower mounting
hooks.
Unlock quick-change lower
mounting hooks
A Remove pin and drop hooks into unlocked
position.
B Reinstall pin in lower hole.
WARNING: Check the attachment
weight (located on the nameplate)
to make sure the overhead hoist
and chains or straps are at least the
rated capacity of the attachment.
A
B
cascade
®
C-675514-1
CL0097.eps
A
B
Guide
Pin
LH Lower
Hook 5/8 in. (16 mm)
offset on top
provides maximum
hook clearance. Tighten capscrews to:
CL II/III – 110 ft.-lbs. (150 Nm)
CL IV – 190 ft.-lbs. (260 Nm)
NOTE: Guides can be reversed
to change hook-to-carriage
clearance. Refer to lower hook
installation, Step 6.

5
669224-R5
NSTALLATION
I
3Prepare hoses
CAUTION: Connect the hydraulic hoses to the attachment
using Cascade Attachment Installation Kit No. 659245
for non-sideshifting attachments and attachments with
solenoid adaption, Kit No. 659249 for sideshifting clamps
OR use hoses and fittings as shown.
A Position the truck carriage behind the attachment to
determine hose lengths required for hydraulic supply
configuration.
B Cut hoses to length and install end fittings or use hose
kits supplied.
WARNING: Do not remove the
fitting from the valve CLAMP (CL)
port. For No. 6 hose connection,
use a 6-8 reducer.
CL0448.ai
Sideshift Right – De-energized
Close – Energized
Sideshift Right – De-energized
Close – Energized
Sideshift Right – De-energized
Close – Energized
Sideshift Left – De-energized
Open – Energized
Sideshift Left – De-energized
Open – Energized
Sideshift Left – De-energized
Open – Energized
CL0444.ai
CL0447.eps
Hoses should not project
above the Check Valve
Bracket
No. 8 Hoses
(SAE 100 R5 Single
Wire Braid Rubber
Covered)
Remove fittings
and cut hoses
to length
No. 6 Hoses
(SAE 100 R5 Single Wire
Braid Rubber Covered)
(Sideshifting attachments only)
Top Mount Valve
Center Mount Valve
Top Mounted Valve and
Backrest Mounted Solenoid Adaption
Center Mount Valve
and Solenoid Adaption
Top Mounted Valve
and Solenoid Adaption
CL0911.ai
CL0910.ai
Sideshift Right/Left
(These hoses apply to
sideshifting attachments only)
No. 8 Hoses
(SAE 100 R5 Single Wire
Braid Rubber Covered)
Close/Open

6669224-R5
NSTALLATION
I
4
5
Flush hydraulic supply hoses
A Install hoses using union fittings.
B Operate valves for 30 Seconds.
C Remove union fittings.
Mount attachment on truck
carriage
A Center truck behind attachment.
B Tilt forward and raise carriage into position.
C Engage the mounting hook tab with the
closest upper carriage bar notch. Raise
the truck carriage into position behind the
attachment.
D Lift attachment off the pallet.
NOTE: The attachment may not be perfectly
centered on the carriage bar when the
mounting hook tab is engaged in the closest
carriage notch. This is normal.
NOTE: The lower hooks cannot be properly
installed if the upper hook tab is not engaged in
the carriage notch.
CL0449.ai
CL0912.ai
Tab
C
WARNING: The mounting hooks must
properly engaged with the upper carriage
bar. The tab on the left mounting hook
must be engaged in a mating notch on the
upper carriage bar.

7
669224-R5
NSTALLATION
I
6
7
Install and engage lower hooks
If equipped, install hydraulic
quick disconnect coupling kits
(part no. 671045)
NOTE: Use one kit for non-sideshifting
attachments and two kits for sideshifting
attachments. Refer to Installation 671422 for
complete installation procedures.
cascade
®
C-675514-1
GA0371.eps
ADJUST
SD0066.eps
Slide hook up to
engage bar, install
pin in upper hole
(locked)
Inspect hook for excessive
clearance. To change clearance,
reverse guides. Refer to Step 2.
Lower
Carriage
Bar
3/16 in.
(5 mm)
Maximum
Tap tight
into position
Lower
Carriage
Bar
Tighten capscrews to
165 Nm (120 ft.-lbs.)
QUICK-CHANGE TYPE BOLT-ON TYPE
CL0903.ai
Sideshift
Hoses
Hydraulic Quick
Disconnect Coupling
Kits 671045
Clamp Hoses
NOTE: Each pair of hoses
requires a coupling kit.
Hose terminal
up kits
Hydraulic Quick
Disconnect Coupling
Kits 671045
Hose terminal
up kits

8669224-R5
8Tighten fork or arm capscrews
Use drive extension tool 668020 (25D), 667699
(35D, 40D, 50D) or 676218 (70D, 80D, 100D) to
tighten capscrews to the following torque values:
25D – 190–220 ft.-lbs. (257–298 Nm)
35D, 40D, 50D – 380–320 ft.-lbs. (380-434 Nm)
70D, 80D, 100D – 680–720 ft.-lbs. (922–976 Nm)
IMPORTANT: Be careful not to damage the arm
bar. Premature bearing failure will occur.
Short adapters are commercially available:
Williams .50 in. drive to .625 in. hex (25D) and .5
in. drive to .625 in. hex (35D, 40D, 50D) and .75
in. drive to .75 in. hex (70D, 80D,100D). Drive
extension dimensions are provided to make the
tool from an allen wrench. Do no use mild steel
hex stock.
CL0913.ai
Drive Extension
Capscrew
Arm Bar
CL0456.eps
A
Hex BC
D
63
Dimensions – in. (mm)
Model A B C D
25D .50
(12.7)
.75
(19.0)
.46
(11.6)
3.50
(88.0)
35D
40D
50D
.62
(15.7)
.50
(12.7)
.58
(14.7)
3.50
(88.0)
70D
80D
100D
.75
(19.0)
.50
(12.7)
.75
(19.0)
5.00
(127.0)
NSTALLATION
I

9
669224-R5
2.4 Custom Arm
Installation
Attachments without arms are supplied with two arm
bases. Special forks can be welded directly to them or
they can be used as a base to fabricate custom built arms.
WARNING: Cascade requires that a
qualified or certified welder experienced
in this type of fabrication be used for best
quality.
CAUTION: Weld fabricated arms to the arm bases only.
Do not weld or bolt special built arms or forks directly to
the arm bars.
The arm base material is AISI C-1020 HR with the following
specifications:
• TENSILE STRENGTH – 61,000 PSI (420 mPa) Minimum
• YIELD STRENGTH – 43,000 PSI (300 mPa) Minimum
• CARBON CONTENT – 23% Maximum
CAUTION: The surface flatness of the arm base must
remain within 0.10 in. (.25 mm) in capscrew area and arm
must slide manually.
1 Fasten the arm bases to the arm bars. Tighten the
capscrews to the torque values indicated below
with a drive extension tool, 668020 (25D), 667699
(35D,40D,50D) or 676218 (70D,80D, 100D) to tighten
capscrews to the following torque values:
25D – 190–220 ft.-lbs. (257–298 Nm)
35D, 40D, 50D – 280–320 ft.-lbs. (380-434 Nm)
70D, 80D, 100D – 680–720 ft.-lbs. (922-976 Nm)
IMPORTANT: Be careful not to damage the arm bar.
Premature bearing failure will occur.
Short adapters care commercially available:
Williams .50 in. drive to .625 in. hex (25D) and .50
in. drive to .625 in. hex (35D, 40D, 50D) and .75 in.
drive to .75 in. hex (70D, 80D, 100D). Drive extension
dimensions are provided to make the tool from the allen
wrench. Do no use mild steel hex stock.
2 Lubricate the cylinder rod threads, nut threads and
spherical portion of the nut with wheel bearing grease.
3 Install the hex washer on the rod end with the beveled
side facing the lug.
4 Engage the rod end into the lug.
5 Tighten the rod end nut to the following torque values:
25D, 30D, 40D, 50D – 150–175 ft.-lbs. (203-–237 Nm)
70D, 80D, 100D – 225–250 ft.-lbs. (305–340 Nm)
Prevent rod turning by using wrench on hex washer.
NOTE: The rod nut is being tightened against the hex
washer. The nut will not be tight against the arm base
lug. This looseness allows for cylinder alignment during
clamping.
6 Install the locking cap and cotter pin.
7 Lubricate the bearing portion of the arm bars with a thin
film of chassis grease, if permitted by your application.
CL0457.ai
Drive Extension
Arm Bar
Arm Base
CL4232.ai
Arm Base Lug
Hex washers beveled
side facing lug
1
3
5
6
NSTALLATION
I
CL0456.eps
A
Hex BC
D
63
Dimensions – in. (mm)
Model A B C D
25D .50
(12.7)
.75
(19.0)
.46
(11.6)
3.50
(88.0)
35D
40D
50D
.62
(15.7)
.50
(12.7)
.58
(14.7)
3.50
(88.0)
70D
80D
100D
.75
(19.0)
.50
(12.7)
.75
(19.0)
5.00
(127.0)

10 669224-R5
2.5 Prior to Operation
1 Check the cylinder anchor nuts for properly installed
locking caps and cotter pins.
2 Check for external leaks at the fittings and rod ends.
25D, 35D, 40D and 50D Clamps – The clamp utilizes a
regenerative hydraulic circuit in the arm opening mode.
The arms will open at a faster speed than when closing.
This is normal. If required, the regenerative function
can be eliminated. Refer to Section 5.6-5.
3 Check for equal arm travel. If arm travel is unequal, the
restrictor cartridges should be adjusted as follows:
A Loosen the jam nuts on the restrictor cartridges.
Screw in the plungers until they bottom. Screw each
plunger out three full turns.
B Activate the arms to the fully open position
C Activate the arms to close until one arm bottoms
out. Measure the amount of stroke remaining in the
opposite arm.
D If unequal closing movement exceeds 2 in. (50 mm),
screw the plunger in 1/2 turn on the cylinder that
bottoms first.
E Repeat step Athrough Duntil unequal closing
movement is less than 2 in. (50 mm).
4 Before picking up a load, cycle the clamp function
through several full cycles. Check for operation in
accordance with ITA (ISO) standards.
WARNING: Make sure all personnel are
clear of the clamp during testing.
CL0459.eps
CL0491.eps
1
3
Check for properly
installed locking
caps and cotter pins
Restrictor Cartridge
Plunger
Jam Nut
NSTALLATION
I

11
669224-R5
ERIODIC MAINTENANCE
P
3.1 100-Hour Maintenance
Every time the lift truck is serviced or every 100 hours
of truck operation, whichever comes first, complete the
following maintenance procedure:
• Inspect the cylinder anchor joint for lubrication and
correct hold.
NOTE: Anchor joint operates with a loose clearance.
Lubricate with wheel bearing grease.
• Arm bearing life can be extended by a light application
of chassis grease, if permitted by your application.
• Tighten arm capscrews to the following torque value:
25D – 190–220 ft.-lbs. (257–298 Nm)
35D, 40D, 50D – 280–320 ft.-lbs. (280–434 Nm)
70D, 80D, 100D – 680–720 ft.-lbs. (922–976 Nm)
3.2 500-Hour Maintenance
After each 500 hours of truck operation, in addition to the
100-hour maintenance, perform the following procedures:
• Check the lower mounting hook engagement clearance
with the truck carriage bar:
Quick-Change Hooks – 3/32 in. (2.5 mm) minimum
3/16 in. (5.0 mm) maximum
Bolt-On Hooks – Tight against lower carriage bar
If adjustment is necessary, refer to Installation Step 6.
Tighten the lower hook capscrews as follows:
Class II/III Mounting – 110 ft.-lbs. (150 Nm)
Class IV Mounting – 190 ft.-lbs. (260 Nm)
• 70D, 80D, 100D Clamps – Tighten the upper hook
capscrews to 210 ft.-lbs. (285 Nm).
• Check clamp force. Cascade Clamp Force Indicators
35G-DFI-8RF and 35G-CFI-8RF are available for this test.
3.3 1000-Hour Maintenance
After each 1000 hours of truck operation, in addition to
the 100 and 500-hour maintenance, perform the following
procedures:
• Inspect the arm bearings for wear. If any bearing is
worn to less than .040 in. (1 mm) thickness, replace all
bearings. Refer to Service Section 5.2-5.
3.4 2000-Hour Maintenance
After each 2000 hours of truck operation, in addition to
the 100, 500 and 1000-hour maintenance, perform the
following procedures:
• Inspect the arm bearings for wear. If any bearing is
worn to less than .040 in. (1 mm) thickness, replace all
bearings. Refer to Service Section 5.2-5.
• Tighten the frame mounting plate capscrews to the
following torque value:
25D, 35D – 60 ft.-lbs. (85 Nm)
40D, 50D – 110 ft.-lbs. (150 Nm)
70D, 80D, 100D – 190 ft.-lbs. (260 Nm)
CL1398.ai
Arm Bearings
Frame Mounting
Plate Capscrews
Cylinder Anchor Joint
70D, 80D Upper
Hook Capscrews
Arm Capscrews Lower Hook Capscrews
Front View
Back (Driver's) View
WARNING: After completing any service
procedure, always test the clamp through
five complete cycles. First test the clamp
empty, then test with a load to make sure
the attachment operates correctly before
returning to the job.

ROUBLESHOOTING
669224-R5
T
12
4.1 General Procedures
4.1-1 Truck System Requirements
• Truckhydraulicpressureshouldbewithintherange
showninSpecications,Section6.1.PRESSURE TO
THE ATTACHMENT MUST NOT EXCEED 2300 psi
(160 bar).
• Hydraulicowshouldbewithintherangeshownin
Specications,Section6.1
• Hydraulicuidsuppliedtotheattachmentmustmeet
therequirementsshowninSpecications,Section6.1.
4.1-2 Tools Required
Inadditiontoanormalselectionofmechanic'shandtools,
thefollowingarerequired:
• In-LineFlowMeterKit:
10GPM(37L/min)–CascadePartNo.671476
OR
20GPM(75L/min)–CascadePartNo.671477
• PressureGaugeKit:
5000psi(345bar)–CascadePartNo.671212
• Assortedttings,hosesandquick-disconnectcouplers,
asrequired.
4.1-3 Troubleshooting Chart
WARNING: Beforeservicingany
hydrauliccomponent,relievepressurein
thesystem.Turnthetruckoffandmove
thetruckauxiliarycontrolvalvesseveral
timesinbothdirections.
Aftercompletinganyserviceprocedure,testthe
attachmentthroughseveralcycles.Firsttestthe
attachmentemptytobleedanyairtrappedinthe
systemtothetrucktank.Thentesttheattachment
withaloadtobesureitoperatescorrectlybefore
returningtothejob.
Stayclearoftheloadwhiletesting.Donotraisethe
loadmorethan4in.(10cm)offtheoorwhiletesting.
GA0013.eps
GA0014.eps
AC0127.eps
Flow Meter Kits: 671476 & 671477
Pressure Gauge Kit: 671212
Quick-Disconnect Couplers
(2)No.8-12JIC/O-Ring FlowMeter
(2)No.6-8JIC
Reducer
Pressure
Gauge* No.6-6Hose*
No.6and
No.8JIC
SwivelTee
No.4-6Pip/JIC* No.6-8JIC
Reducer
No.4,No.6*
andNo.8
JIC/O-Ring
*NOTE: DiagnosticsKit397382
includesitemsmarked.
MaleStraightThread
O-RingCoupler:
No.4(PartNo.212282)*
No.5(PartNo.210378)
No.6(PartNo.678592)
FemaleJICThread
Coupler:
No.4(PartNo.210385)*
No.6(PartNo.678591)
Determine All The Facts –Itisimportantthatall
thefactsregardingtheproblemaregatheredbefore
beginningserviceprocedures.Therststepisto
talktotheequipmentoperator.Askforacomplete
descriptionofthemalfunction.Thefollowing
guidelinescanthenbeusedasastartingpointto
begintroubleshootingprocedures:
Clamp Circuit
• Attachmentdropsloadafterithasbeenpickedup.
• Attachmentwillnotcarryloadtoitsratedcapacity.
• Attachmentarmshaveuneventravel.
• Attachmentarmstravelslowly.
• Attachmentarmswillnotmove.
Tocorrectoneoftheseproblems,seeSection4.4-1
and4.4-2.
Sideshift Circuit
• Attachmentdropsloadwhilesideshifting.
• Attachmentdropsloadatendofsideshiftstroke.
• Attachmentsideshiftsleftandrightatdifferent
speeds.
• Attachmentwillnotsideshift.
• Attachmentarmswillnotmove.
Tocorrectoneoftheseproblems,seeSection4.4-2,
4.4-3and4.4-4.

669224-R5
ROUBLESHOOTING
T
13
4.2 Plumbing – Top Mount Valve
4.2-1 Hosing Diagram, Non-Sideshifting
CL2200.eps
1
34
2
CL2201.eps
1
34
2
CL2202.eps
Cylinder
Cylinder
Check
Valve OP
CL
Hose
Terminal
Hose
Terminal
HoseReel
Clamp
Auxiliary
Valve
ARMS OPENING
PRESSURE
REGENERATING
ARMS CLOSING
PRESSURE
RETURN
Cylinder
Cylinder
Check
Valve OP
CL
HoseReel
Clamp
Auxiliary
Valve
4.2-2 Circuit Schematic, Non-Sideshifting
Truck
Relief
Valve TruckHydraulicPump
Cylinders
Check
Valve CL
G
123 4
Hose
Terminal
Hose
Reel
Clamp
Auxiliary
Valve
OP

ROUBLESHOOTING
669224-R5
T
14
4.2-3 Hosing Diagram, Sideshifting (including Turnafork)
CL2203.eps
1
34
2
CL2204.eps
1
34
2
CL2205.eps
1
34
2
CL2206.eps
1
34
2
ToCylinders
ToCylinders
OP
OP
CL
CL
SSL
SSL
SSL
SSL
SSR
SSR
SSR
SSR
Check
Valve
Check
Valve
SolenoidValve
SolenoidValve
Hose
Terminal
Hose
Terminal
HoseReel
HoseReel
Auxiliary
Valve
Auxiliary
Valve
Attachments with
Solenoid Adaption
Attachments with
Solenoid Adaption
ARMS OPENING
PRESSURE
REGENERATING
Hose
Terminal
Hose
Terminal
Cylinder
Cylinder
Cylinder
Cylinder
Check
Valve
Check
Valve
OP
OP
CL
CL
HoseReel
HoseReel
HoseReel
HoseReel
Clamp
Auxiliary
Valve
Clamp
Auxiliary
Valve
Sideshift
Auxiliary
Valve
Sideshift
Auxiliary
Valve
Junction
Block/Hose
Terminal
Junction
Block/Hose
Terminal
ARMS CLOSING
PRESSURE
RETURN

669224-R5
ROUBLESHOOTING
T
15
4.2-3 Hosing Diagram, Sideshifting (Continued)
4.2-4 Circuit Schematic, Sideshifting
(including Turnafork)
CL2207.eps
1
34
2
CL2208.eps
1
34
2
CL2209.eps CL2210.eps
SIDESHIFTING
(Sideshift Left Shown)
PRESSURE
RETURN
REGENERATING
ToCylinders
SSL
SSR OP
CL Solenoid
Valve
Solenoid
Valve
Check
Valve
Hose
Terminal
Hose
Terminal Hose
Terminal
Hose
Terminal
Hose
Reel
Auxiliary
Valve
Auxiliary
Valve Sideshift
Auxiliary
Valve
Clamp
Auxiliary
Valve
Attachments with
Solenoid Adaption
Attachments with
Solenoid Adaption
SSL
SSL
SSR
SSR
Hose
Terminal
Cylinder
Cylinder
Check
Valve
Check
Valve
OP
CL
HoseReel
HoseReel HoseReel
HoseReel
HoseReel
Clamp
Auxiliary
Valve
Sideshift
Auxiliary
Valve
Hose
Terminal
Truck
Relief
Valve
Truck
Relief
Valve
TruckHydraulicPump TruckHydraulicPump
Cylinders
A
B
1234
CL
OP
G

ROUBLESHOOTING
669224-R5
T
16
CL2211.eps CL2212.eps
CL2213.eps
4.3 Plumbing – Center Mount Valve
4.3-1 Hosing Diagram, Non-Sideshifting
Cylinder
Cylinder
Check
Valve
OP
CL
Hose
Terminal
HoseReel
Clamp
Auxiliary
Valve
ARMS OPENING
PRESSURE
RETURN
ARMS CLOSING
PRESSURE
RETURN
Cylinder
Cylinder
Check
Valve
OP
CL
Hose
Terminal
HoseReel
Clamp
Auxiliary
Valve
4.3-2 Circuit Schematic, Non-Sideshifting
Hose
Terminal
Clamp
Auxiliary
Valve
Check
Valve
HoseReel
Truck
Relief
Valve TruckHydraulicPump
Cylinders
CL
OP
G

669224-R5
ROUBLESHOOTING
T
17
4.3-3 Hosing Diagram, Sideshifting
CL2214.eps
B
B
R
CL2215.eps
B
B
R
CL2216.eps
B
B
R
CL2217.eps
B
B
R
Check
Valve
Hose
Terminal
Hose
Terminal
HoseReel
HoseReel
Auxiliary
Valve
Auxiliary
Valve
Cylinder
Cylinder
OP
OP
OP
CL
CL
CL
Hose
Terminal
Hose
Terminal
HoseReel
HoseReel
Clamp
Auxiliary
Valve
SSL
SSL
SSL
SSR
SSR
SSR
Sideshift
Auxiliary
Valve
Solenoid
Valve
Solenoid
Valve
Attachments with
Solenoid Adaption
ARMS OPENING
PRESSURE
RETURN
ARMS CLOSING
PRESSURE
RETURN
ToCylinders
ToCylinders
Cylinder
Cylinder
OP
CL
Hose
Terminal
Hose
Terminal
HoseReel
HoseReel
Clamp
Auxiliary
Valve
SSL
SSR
Sideshift
Auxiliary
Valve

ROUBLESHOOTING
669224-R5
T
18
4.3-3 Hosing Diagram, Sideshifting (Continued)
CL2218.eps
B
B
R
CL2219.eps
B
B
R
Hose
Terminal
HoseReel
Auxiliary
Valve
OP
CL
SSL
SSR
Solenoid
Valve
SIDESHIFTING
(Sideshift Left Shown)
PRESSURE
RETURN
ToCylinders
Cylinder
Cylinder
OP
CL
Hose
Terminal
Hose
Terminal
HoseReel
HoseReel
Clamp
Auxiliary
Valve
SSL
SSR
Sideshift
Auxiliary
Valve
4.3-4 Circuit Schematic, Sideshifting
CL2209.eps
Solenoid
Valve
Hose
Terminal
Auxiliary
Valve
Attachments with
Solenoid Adaption
HoseReel
Truck
Relief
Valve TruckHydraulicPump CL2224.eps
Hose
Terminal
Hose
Terminal
Sideshift
Auxiliary
Valve
Clamp
Auxiliary
Valve
SSL
SSR Check
Valve
HoseReel
HoseReel
Truck
Relief
Valve TruckHydraulicPump
Cylinders
A
B
124
CL
OP
G
