CAVE TeamUp TX20i User manual

CAVE-TEK TeamUp TX20i Camera User Guide
CAVE-TEK
TeamUp TX20i Camera
User Guide
English (V1.0)

CAVE-TEK TeamUp TX20i Camera User Guide
Table of content
1Packing List 1
2Quick Start 1
3About TX20i 2
3.1 Interfaces and Buttons 2
3.2 Dimension 2
3.3 Remote Control 3
3.4 RS-232 Interface 4
3.5 Serial Communication Control 4
4GUI Settings 5
4.1 MENU 5
4.2 EXPOSURE 5
4.3 COLOR 6
4.4 IMAGE 6
4.5 P/T/Z 7
4.6 NOISE REDUCTION 7
4.7 SETUP 7
4.8 COMMUNICATION SETUP 8
4.9 RESTORE DEFAULT 8
5Network Function 9
5.1 Operating Environment 9
5.2 Equipment Installation 9
5.3 Internet Connection 9
5.4 Camera controlled by LAN 9
5.4.1 Setup IP address 9
5.4.2 Login IP Camera admin 10
5.4.3 Open Network stream with VLC player 11
5.5 Camera Setup 12
5.5.1 Homepage Introduction 12
5.5.2 Video Settings 14
5.5.3 Image Settings 15
5.5.4 Audio Settings 16
5.5.5 System Settings 17
5.5.6 Network Settings 17
5.5.7 Device Information 18

CAVE-TEK TeamUp TX20i Camera User Guide
1
1 Packing List
Open the box, you will find below items:
Name
Quantity
TeamUp TX20i Camera
1
AC Power Adaptor
1
Power Cable
1
RS232 Cable
1
Mount Kit
1
Remote Control
1
Quick Installation Guide
1
2 Quick Start
1) Please check below connects first.
2) Connect the power adapter to the power connector on the rear panel of the camera. The power
indicator on the front panel of the camera is on.
3) After the camera is powered on, it starts to boot up to the initialization position. Then both horizontal
and vertical go to the middle position, the motor stops running, and the initialization is completed.
(Note: If preset 0 is saved, Camera will be moved to preset 0)

CAVE-TEK TeamUp TX20i Camera User Guide
2
3 About TX20i
3.1 Interfaces and Buttons
Item
Name
1
AUDIO IN Interface
2
LINE OUT Interface
3
System Select Switch
4
RS485 Interface
5
RS232 IN Interface
6
RS232 OUT Interface
7
Network Interface
8
HDMI Interface
9
USB 3.0 Interface
10
3G-SDI Interface
11
DC 12V Interface
12
Power Switch
3.2 Dimension

CAVE-TEK TeamUp TX20i Camera User Guide
3
3.3 Remote Control
Key Description
1. Standby Key
Press this button to enter standby mode. Press it
again to enter normal mode.
2. Number Key
To set preset or call preset.
3. *Key
To configure the special function key.
4. Preset Key
Set preset: Store a preset position.
[SET PRESET] + Numeric button (0-9): Setting a
corresponding numeric key preset position.
5. HOME Key
Confirm the selection, or move the camera back to
the middle position
6. Return Key
Return to the previous menu
7. Zoom Key
Slow Zoom: Zoom In [+] or Zoom Out [-] slowly
Fast Zoom: Zoom In [+] or Zoom Out [-] fast
8. Left/Right Setting Key
Press with 1 button and 2 buttons setting the
direction of the Pan-Tilt.
●Simultaneously press L/R Set +1[STD]: set the
Pan-Tilt to turn the same direction as the L/R
Set.
●Simultaneously press L/R Set +2[REV]: set the
Pan-Tilt to turn the opposite direction as the
L/R Set.
9. Focus Key
To adjust the focus.
Press [AUTO] adjust the focuses on the center of
the object automatically. Or to adjust the focus
manually.
Press [MANUAL] adjusts the focus on the center of
the object manual.
10. Selection Key
Press the button corresponding to the camera you
want to operate with the remote controller.
11. #Key
To configure the special function key.
12. IR Remote Control Key
[*]+[＃]+[F1]: Address 1
[*]+[＃]+[F2]: Address 2
[*]+[＃]+[F3]: Address 3
[*]+[＃]+[F4]: Address 4
13. Reset Key
Clear preset: Erase a preset position.
[CLEAR PRESET] + Numeric button (0-9)
Or: [*]+[#]+[CLEAR PRESET]: Erase all the preset
individually.
14. PTZ Control Key
Press arrow buttons to perform panning and tilting.
Press [HOME] button to face the camera back to
front.
15. Menu Key
MENU: enter or exit OSD MENU.
16. Backlight Key
BLC ON/OFF: Press this button to enable the
backlight compensation. Press it again to disable
the backlight compensation.
17. PTZ Reset Key
Preset Pan/Tilt self-test.
18. Special Function Key
[*]+[＃]+[1]: Change OSD menu to English
[*]+[＃]+[4]: Display current IP address
[*]+[＃]+[6]: Reset to system defaults
[*]+[＃]+[8]: Display camera firmware Info.
[*]+[＃]+[9]: set mounting mode (normal / vertical
flip)
[＃]+[*]+[4]: Set Network configuration to DHCP
[*]+[＃]+[Manual]: Reset network to default.
[*]+[＃]+[F1]: Assign Camera to IR Address 1
[*]+[＃]+[F2]: Assign Camera to IR Address 2
[*]+[＃]+[F3]: Assign Camera to IR Address 3
[*]+[＃]+[F4]: Assign Camera to IR Address 4

CAVE-TEK TeamUp TX20i Camera User Guide
4
3.4 RS-232 Interface
No.
Function
1
DTR
2
DSR
3
TXD
4
GND
5
RXD
6
GND
7
IR OUT
8
NC
The correspondence between the camera and
Windows DB-9 pin:
The correspondence between the camera and
the Mini DIN pin:
3.5 Serial Communication Control
●RS232 Communication Control
The camera is controlled via RS232. The RS232 serial port parameters are as follows:
Baud rate: 2400/4800/9600/38400 bit/s;
Starting Position: 1 bit
Data bit: 8 bits
Stop bit: 1 bit
Check digit: None
●RS485 Communication Control
Control camera via RS485, half-duplex mode:
Baud rate: 2400/4800/9600/38400 bit/s;
Starting position: 1 bit
Data bit: 8 bits
Stop bit: 1 bit
Check digit: None
●List of protocols
For a detailed list of VISCA/Pelco-D/Pelco-P protocols, please check www.cave-tek.com.
9.RI
8.CTS
8.NC
7.RTS
7.IR OUT
6.DSR
6.GND
5.GND
5.RXD
4.DTR
4.GND
3.TXD
3.TXD
2.RXD
2.DSR
1.CD
1.DTR
Windows DB-9
Camera
4.GND
4.GND
8.NC
8.NC
7.NC
7.IR OUT
6.GND
6.GND
5.RXD
5.RXD
3.TXD
3.TXD
2.DSR
2.DSR
1.DTR
1.DTR
Mini DIN
Camera

CAVE-TEK TeamUp TX20i Camera User Guide
5
4 GUI Settings
4.1 MENU
Press the [MENU] button to display the main menu on the display, using the arrow button to move the
cursor to the item. Press the [HOME] button to enter the corresponding sub-menu.
MENU
Exposure
Color
P/T/Z
Noise Reduction
Setup
Communication Setup
Restore Default
[Home] Enter
[Menu] Exit
4.2 EXPOSURE
Move the main menu cursor to [EXPOSURE], and press [HOME] key enter the exposure page, as shown in
the following figure.
EXPOSURE
Mode
Auto
ExpCompMode
On
ExpComp
+1
Backlight
Off
Gain Limit
3
Anti-Flicker
50Hz
Meter
Average
DRC
2
Select Item
Change Value
[Menu] Back
Mode: Exposure mode, Auto, Manual, SAE, AAE, Bright.
ExpCompMode: Exposure the compensation mode, On, Off (Effective only in Auto mode).
ExpComp: Exposure the compensation value, -7~7 (Effective only in ExpCompMode item to On).
Backlight: Set the backlight compensation, On, Off (Effective only in Auto mode).
Bright: Intensity control, 0~17 (Effective only in Bright mode).
Gain Limit: Maximum gain limit, 0 ~ 15 (Effective only in Auto, SAE, AAE, Bright mode).
Anti-Flicker: Anti-flicker, Off, 50Hz, 60Hz (Effective only in Auto, AAE, Bright mode).
Meter: Average, Center, Smart, Top.
DRC: DRC strength, 0 ~ 8.

CAVE-TEK TeamUp TX20i Camera User Guide
6
4.3 COLOR
Move the main menu cursor to [COLOR], and press [HOME] key enter the color page, as shown in the
following figure.
COLOR
WB Mode
Auto
RG Tuning
0
BG Tuning
0
Saturation
100%
Hue
7
AWB Sens
High
Select Item
Change Value
[Menu] Back
WB-Mode: White balance mode, Auto, Indoor, Outdoor, One Push, Manual, VAR.
RG Tuning: Red gain fine-tuning, -10 ~ +10 (Effective only in Auto, One Push, VAR mode).
BG Tuning: Blue gain fine-tuning, -10 ~ +10 (Effective only in Auto, One Push, VAR mode).
Saturation: 60% ~ 200%.
Hue: 0 ~ 14.
AWB Sens: The white balance sensitivity, Low, Middle, High.
4.4 IMAGE
Move the main menu cursor to [IMAGE], and press [HOME] key enter the image page, as shown in the
following figure.
Luminance
6
Contrast
8
Sharpness
3
Flip-H
Off
Flip-V
Off
B&W-Mode
Off
Gamma
0.5
Style
Clarity
Select Item
Change Value
[Menu] Back
Luminance: 0 ~ 14.
Contrast: 0 ~ 14.
Sharpness: Auto, 0 ~ 15.
Flip-H: On, Off.
Flip-V: On, Off.
B&W-Mode: On, Off.
Gamma: Default, 0.45, 0.5, 0.56, 0.63.
Style: Default, Norm, Clarity, Clarity (LED), Bright, Soft, 5S.

CAVE-TEK TeamUp TX20i Camera User Guide
7
4.5 P/T/Z
Move the main menu cursor to [P/T/Z], and press [HOME] key enter the P/T/Z page, as shown in the
following figure.
P/T/Z
SpeedByZoom
On
AF-Zone
Center
AF-Sense
High
L/R Set
STD
Display Info
On
Image Freeze
Off
DigitalZoom
2x
Call Preset Speed
24
Pre Zoom Speed
5
Select Item
Change Value
[Menu] Back
SpeedByZoom: The depth of field scale switch, On, Off.
AF-Zone: Interested in focusing area, Top, Center, Bottom.
AF-Sense: Automatic focusing sensitivity options, Low, Normal, High.
L/R Set: STD, REV.
Display Info: On, Off.
Image Freeze: On, Off.
Digital Zoom: Off, 2x, 4x, 8x, 16x.
Call Preset Speed: 1 ~ 24.
Pre Zoom Speed: 0 ~ 7.
4.6 NOISE REDUCTION
Move the main menu cursor to [NOISE REDUCTION], and press [HOME] key enter the noise reduction page,
as shown in the following figure.
NOISE REDUCTION
NR2D-Level
Off
NR3D-Level
3
Select Item
Change Value
[Menu] Back
NR2D Level: 2D noise reduction, Off, Auto, 1 ~ 5.
NR3D Level: 3D noise reduction, Off, 1 ~ 8.
4.7 SETUP
Move the main menu cursor to [SETUP], and press [HOME] key enter the setup page, as below.
SETUP
Language
EN
DVI Mode
DVI
Auto Scan Shoot
Off
Auto Inversion
On
SDI-3G Mode
Level-A
Tracking
On
Tally Mode
On
[Home] Enter
[Menu] Back
Language: EN, Chinese, Russian.
DVI Mode: DVI, HDMI.

CAVE-TEK TeamUp TX20i Camera User Guide
8
Auto Scan Shoot: On, Off.
Auto Inversion: On, Off.
SDI-3G Mode: LEVEL-A, LEVEL-B.
Tracking Mode: On, Off.
Tally Mode: On, Off.
4.8 COMMUNICATION SETUP
Move the main menu cursor to [COMMUNICATION SETUP], and press [HOME] key enter the
communication setup page, as shown in the following figure.
COMMUNICATION SETUP
Protocol
VISCA
V_Address
1
V_AddrFix
Off
Net Mode
Serial
Baudrate
9600
Select Item
Change Value
[Menu] Back
Protocol: Control protocol type, Auto, VISCA, PELCO-D, PELCO-P.
V_Address: 1 ~ 7. (Effective only in Auto, VISCA protocol).
V_AddrFix: On, Off (When set to On, useless in 88 30 01 FF Command).
P_D_Address: 0 ~ 254. (Effective only in PELCO-D protocol).
P_P_Address: 0 ~ 31. (Effective only in PELCO-P protocol).
Net Mode: Set the serial port network control, Serial, Paral.
Baudrate: Serial port baud rate, 2400, 4800, 9600, 38400.
4.9 RESTORE DEFAULT
Move the main menu cursor to [RESTORE DEFAULT], and press [HOME] key enter the restore default page,
as shown in the following figure.
RESTORE DEFAULT
Restore?
No
Change Value
[Home] OK
[Menu] Back
Restore: Confirm restore factory settings, Yes, No.
Note: Press [HOME] button to confirm, all parameter restore default, include IR Remote address and VISICA
address.

CAVE-TEK TeamUp TX20i Camera User Guide
9
5 Network Function
5.1 Operating Environment
Operating System: Windows 7/8/10, Mac OS X, Linux, Android
Network Protocol: TCP/IP
System Requirement: Intel Duo Core /256M RAM/40G HDD/ Graphics card support DirectX 9.0 or later
version.
5.2 Equipment Installation
1) Connect internet camera to your internet or to your PC directly via network cable.
2) Turn on DC 12V power.
3) If the network connection is normal, the connection light (green) at the network interface will light up
within 5 seconds. The data indicator (orange) will flash, indicating that the camera's physical
connection has been completed.
5.3 Internet Connection
There are two main ways to connect network camera.
Connect by Network Cable
Connect by Switch/Router
5.4 Camera controlled by LAN
5.4.1Setup IP address
If you don't know the camera IP, view as below:
Method 1: Press * and # and 4 on the remote controller one by one; the camera IP address will be shown
on screen.
Change IP address, two methods as below:
Method 1: Login to the web page, select "Network > Lan Settings," change IP address. Click "Apply" then
restart the camera.
Method 2: Press * and # and Manual on the remote controller one by one; the camera IP address will
restore to the default IP address (192.168.100.88).

CAVE-TEK TeamUp TX20i Camera User Guide
10
Note: IP camera default IP address "192.168.100.88", the username is "admin", password is "admin".
5.4.2Login IP Camera admin
Enter 192.168.100.88 on browser, a login window pop up, input login name: admin, password: admin,
shown as below:
After login, shown as below:

CAVE-TEK TeamUp TX20i Camera User Guide
11
Note: If users first use this camera by internet (only for new user), they must install a player software (VLC).
Please go to VLC website http://www.videolan.org/vlc/#download and Install VLC (player software). After
installation, login again, will show as above.
5.4.3Open Network stream with VLC player
Step 1 Open VLC media player.
Step 2 Click "Media > Open Network Stream", or click "Ctrl + N"; as below:
Step 3 Input URL address:
rtsp://ip: port number/1 (First stream);
rtsp://ip: port number/2 (Second
stream).
Step 4 Finish.
Note: RTSP default port number 554.

CAVE-TEK TeamUp TX20i Camera User Guide
12
5.5 Camera Setup
5.5.1Homepage Introduction
A. Preview window
1) Video playback pause button: control real-time video pause, stop the last picture, click recoverable
video again.
2) Audio control buttons: can set silent mode.
3) Full-screen switch button.
B. PTZ Setup
PTZ direction control box: Up, down, left,right, home button as above.
Rate: Pan Speed can be chosen as 1 ~ 24,
Tilt Speed can be chosen as 1 ~ 20.
Select the corresponding speed and click the direction button to realize PTZ speed up or speed down.
Zoom In/Zoom out: For zooming in or zooming out. Focus In/Focus Out: Focusing on distant the objects or
focusing on close the objects.
Set/Call: When PTZ turns to the expected position, set up the preset that the user wants as below.
Method 1: Type a number into the Preset box.

CAVE-TEK TeamUp TX20i Camera User Guide
13
Method 2: Type the name into the Presets Information.
Click "Set" button, when PTZ turn to other position, click "Call" button or click "No." of the Presets
Information, PTZ will turn back to preset position.
PTZ / MENU: When system in menu mode, OSD menu display in the upper corner of the image page. PTZ
direction control box: Up/down button select menu, and the home button enter the submenu, the left/right
button modify the submenu. After the menu to be modified, select PTZ. If in the main menu, save the
setting and exit automatically. Otherwise, return to the previous menu.
PTZ: system in PTZ mode.
C. Language selection
Chinese/English/Russian

CAVE-TEK TeamUp TX20i Camera User Guide
14
5.5.2Video Settings
1) Video Format
Support 50Hz (PAL) and 60Hz (NTSC), and Dial Priority three formats.
2) Encode Level
Support baseline, mainprofile, highprofile and svc-t four levels.
3) Encode Protocol
Support H.264, H.265 and MJPEG three formats.
4) Resolution
First stream support 3840x2160, 1920x1080, 1280x720, 1024x576, 960x540, 640x480, 640x360. Second
stream support 1920x1080, 1280x720, 1024x576, 720x576 (50Hz support), 720x480 (60Hz support),
720x408, 640x360, 480x270, 320x240, 320x180;
5) Bit Rate
Set up the Bit Rate.
6) Frame Rate
Set up the frame rate.
7) I Key Frame Interval

CAVE-TEK TeamUp TX20i Camera User Guide
15
Set interval between 2 I frame, the bigger interval is the response will be lower from viewing window.
8) Bit Rate Control
Constant Bit Rate: Video encoder will be encoding according to preset speed.
Variable Bit Rate: Video encoder will adjust the speed based on preset speed to gain the best image quality.
9) Fluctuate Level
Restrain the fluctuation magnitude of variable rate, grade 1 ~ 6.
10) Slice Split Enable
Enable or disable slice split function.
11) Split Mode
Select split mode, optional items: Fixed blocks, Fixed bytes.
12) Slice Size
Set the size of slice.
5.5.3Image Settings
1) Brightness
Image bright 0~14, slider control, on the right shows the corresponding numerical.
Default value is 6.
2) Saturation
Saturation 0~14, slider control, on the right shows the corresponding numerical.
Default value is 4.
3) Contrast
Contrast 0~14, slider control, on the right shows the corresponding numerical.
Default value is 8.
4) Sharpness
Sharpness 0~15, slider control, on the right shows the corresponding numerical.
Default value is 3.
5) Hue
Hue 0~14, slider control, on the right shows the corresponding numerical.
Default value is 7.
6) Flip & Mirror
Tick Flip to realize image upside down, tick mirror to realize image around the mirror. Default value is not
tick.

CAVE-TEK TeamUp TX20i Camera User Guide
16
5.5.4Audio Settings
1) Audio Switch
Enable or disable audio switch.
2) Audio Type
Audio type: G711A, AAC.
3) Sample Rate
Sample rate 44.1K and 48K selectable.
4) Bit Rate
Bit rate 96K, 128K, 256K selectable.
5) Input Type
Input type line in.
6) Input Vol L
The volume of the left channel.
7) Input Vol R
The volume of the right channel.
8) ADTS Options
Optional items: On, Off.

CAVE-TEK TeamUp TX20i Camera User Guide
17
5.5.5System Settings
1) Work Mode
The default work mode is RTSP.
Optional items: RTSP, SDK, Multicast.
2) Reboot
Click the "Reboot" button, system restart.
3) Username and password
The user can modify the password (letters and numbers only).
5.5.6Network Settings

CAVE-TEK TeamUp TX20i Camera User Guide
18
1) LAN Settings
Default the IP address is 192.168.100.88, the MAC address can not be modified.
2) Port Settings
A. HTTP Port
The port setting is to set up a web server program using which port to transmit. When port mapping, need
to be consistent with the port number (default port: 80).
B. RTSP Port
Network camera support RTSP protocol, use the VLC tools broadcast.
C. PTZ Port
Support PTZ protocol, default port: 5678.
3) Control Protocol Settings
Setting the camera control communication protocol, include Visca address, Pelco-D address, and Pelco-P
address.
4) RTMP Settings
Setting the MRL of RTMP, select enable or disable video and audio. You can select the control code stream
of "On", "Off", "Video", "Audio" between in the two streams.
5) RTSP Settings
Turn On/Off RTSP auth.
6) ONVIF Settings
Turn On/Off ONVIF and ONVIF auth.
7) Multicast Settings
Turn On/Off multicast. Setting the multicast address (default value is 224.1.2.3) and port (default value is
6688, then 6688 is the multicast port of the first stream; 6690 is the multicast port of the second stream).
8) SDK Settings
Turn On/Off active connection. Setting SDK address (default value is 192.168.100.138) and port (default
value is 1234).
9) NTP Settings
Turn On/Off NTP time sync, main time show and sub time show. Setting NTP server address, time interval,
primary stream position and sub stream part.
5.5.7Device Information
Display the current device information, as shown below.
V1.0_20210528
