MGC6050F
Full HD Megapixel IP Camera

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 2
Note
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generate, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into and outlet on a circuit different from that to which
the receiver is connected
 Consult the dealer or an experienced radio/TV technician for help.
Directions
Be careful not to cause any physical damage by dropping or throwing MGC6050F. Especially
keep the device out of reach from children.
Do not disassemble MGC6050F. No After Service is assumed when disassembled.
Use only the power adapter provided with MGC6050F.
Be careful to prevent moisture or water penetration into the unit. Particular attention is
needed when installing MGC6050F. The screw holes for the installation screws and pipe should
be maintained water tight during the whole life time of the product.
All the electrical connection wires running into the unit should be prepared so that water from
the outside cannot flow into the unit through the surface of the wires. Penetration of the
moisture through the wire for extended period can cause malfunction of the unit or
deteriorated image.

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 3
Revision History
Date Revision Details
2013-12-01 1.0 First manual revision creation.
Caution
Any changes or modifications in construction of this device which are not explicitly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 4
Contents
Contents ............................................................................................. 4
1. Introduction ..................................................................................... 5
1.1. Overview ................................................................................................ 5
1.2. Specification ........................................................................................... 6
1.3. Applications of MGC6050F ......................................................................... 8
2. Product Description .......................................................................... 9
2.1. Contents ................................................................................................ 9
2.2. Product Preview ...................................................................................... 9
2.3. Physical description ................................................................................ 10
2.4. Functional Description ............................................................................. 11
3. On Site Installation.......................................................................... 15
3.1. Stand Bracket ....................................................................................... 15
4. Getting Started ............................................................................... 16
4.1. PC Requirement .................................................................................... 16
4.2. Quick Installation Guide ........................................................................... 17
5. Trouble Shooting ............................................................................ 21
5.1. No power is applied ................................................................................ 21
5.2. Cannot connect to the Video ..................................................................... 22
5.3. Windows Vista or Windows 7 .................................................................... 23
5.4. Technical Assistance ............................................................................... 26

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 5
1. Introduction
1.1. Overview
The MGC6050F is a state-of-the-art (Megapixel), triple-codec (H.264, MJPEG) IP camera (or network camera)
built with embedded software and hardware technology. It enables real time transmission of synchronized video
of up to 2 Megapixel or 3 Megapixel and audio data. Remote clients can connect to MGC6050F for the real time
video/audio data through various client solutions running on PC, mobile phones. Real time 2-way
communication is available through bidirectional audio communication feature.
Designed to be a stand-alone streaming audio & video transmission device, MGC6050F can be applied to
various application area such as video security, remote video monitoring, distance education, video conference
or internet broadcasting system.
Embedded PoE (Power over Ethernet, IEEE 802.3af) will enable the owner to reduce TCO (Total Cost of
Ownership) by reducing on-site wiring works for the installation.

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 6
1.2. Specification
Category Sub-Category Details
Video Compression H.264/MJPEG
Resolution **Refer to the datasheet.
Audio
(Bi-directional)
Up 32 Kbps G.726
Down 128 Kbps PCM
Network
Interface RJ-45, 10/100 Mbps, PoE (802.3af)
Access network Static, DHCP, PPP/PPPoE
Application RTP, RTSP, SMTP, FTP, HTTP, SDP, NTP, DNS
I/O
RS-485 For providing RS-485 device
Sensor In 1 NC, NO Selectable
Relay Output 1 For alarm annunciation or
remote ON/OFF control (30V, 1A)
RS-232C For factory use only
Mic/Line In Selectable in Admin page
Line Out 1 V p-p output for amplified speaker
CVBS output For temporal use during installation
Power Supply PoE Power over Ethernet (IEEE802.3af)
DC Adaptor 12V DC adaptor (2A)
Mounting Stand Bracket
Motion Detection 3 zones Arbitrary shape with independent sensitivity
Upgrade Firmware upgrade over IP network
Administration Remote administration over IP network
Client & Viewer
Web Viewer Simple viewing over internet explorer
NVR-Pro Standard CMS software
3rd Party CMS Ask ICANTEK for details
Dynamic IP support DDNS support Supported
Security
Video/Audio stream encryption
ID and Password protection

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 7
Security IP filtering for restricting administrative
access for audio and bi-audio
Time management
Sync to PC Synchronize to PC
Manual Manual time setting
Internet Time Server
Synchronize to Time Server
DLS Day Light Saving
SDK support
Active-X
HTTP

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 8
1.3. Applications of MGC6050F
 Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities,
military, etc.)
 Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)
 Teleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting
 Weather and environmental observation

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 9
2. Product Description
2.1. Contents
The product package contains followings:
Contents Description Remarks
MGC6050F IP camera (MGC6050F ) main unit
Power Adaptor Default built in standard PoE module
(IEEE802.3af)
12VDC Adaptor
(Optional item)
Mounting bracket and
others
Standard mount bracket,
C ring, L wrench Supported
CD Software & User’s Guide
Quick Reference Guide
Quick installation guide
2.2. Product Preview
MGC6050F IP-Installer CMS Software
(NVR-Pro)
Mega pixel IP Camera PC software to allocate an IP
address to the IP Camera
PC software to view and record
the A/V streaming data transmitted
from IP camera.
(Simultaneous support of up to 64
IP cameras@D1)

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 10
2.3. Physical description
2.3.1. External View
Figure 2-1. External view of MGC6050F
2.3.2. Rear panel
Figure 2-2. Rear panel of MGC6050F

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 11
2.4. Functional Description
 DC 12V: Power input for supplying 12V DC power.
Caution: If MGC6050F is powered by PoE, do not plug in DC Jack with active DC power
into DC power connector.
 MIC/LINE IN
Connect external audio source or microphone.
 Line Out
Connect speakers with built in amplifier. Audio from remote site is output through Line out in bi-directional
audio mode.
 100Base-T
100Mbps Ethernet connector (RJ-45) with PoE standard (802.3af). 2 LEDs on the Ethernet connector
shows the status of MGC6050F as the followings:
- Status LED (Dual Color - Red/Green): It will be lit in green or red depending on the status.
 Green: Green color indicates that the camera is in normal operation mode. Continuous green
indicates that data transmission is possible. Blinking green means that someone is
connected to MGC6050F.
 Red: Continuous or blinking red indicates that hardware is in abnormal condition.
- LINK/LAN LED (Orange)
It will be lit with orange color when network cabling is all right. Blinking orange color indicates that
normal data transmission is under way. Off state indicates that there is trouble in network connection.
 RS-232C
3 Pins on the right of the connector are assigned for RS-232 port. Please note that leftmost pin is
numbered as 1.
Pin Description Misc.
Red/Green LED will be lit with red momentarily and it will be lit with green after a while when
power is applied into MGC6050F

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 12
1 Not used
2 Not used
3 RxD (Connect to TxD of the other end)
For debugging & factory use only.
4 TxD (RxD (Connect to RxD of the other end))
5 Ground of RS-232C
 ALARM IN/OUT and Composite Video Output
Figure 2-3 Terminal block for the I/O Connection of MGC6050F
Used for connecting P/T device, sensor, and composite video output. Pin assignments are as follows.
Pin Description Misc.
1 RS-485 Plus (+) For providing RS485 signal to RS485 devices
2 RS-485 Minus (-) For providing RS485 signal to RS485 devices
3 SNS IN (+) Sensor In (+):
NC/NO selectable in admin mode
4 SNS IN (1) Sensor In (-):
NC/NO selectable in admin mode
5 RLY OUT Relay output: Closed circuit in alarm to indicate alarm
status
6 RLY OUT
7 CVBS OUT(+) Composite output of analog video
8 CVBS OUT(-) Ground connection for Composite output of analog
video
 RS-485
Used for connecting Pan/Tilt devices having RS-485 interface standard.

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 13
 SNS IN
Examples of sensing devices are infrared sensors, motion sensors, heat/smoke sensors,
magnetic sensor, etc. Connect the two wires of the sensors to “SNS In”. The sensor type
(NC/NO) can be set in Administrative mode. Multiple sensor devices can be connected in parallel.
Sensor
Device
Sensor
Power
Supply
NO/NCType
Sensor1-
Sensor1+
+12V GND
Sensor
Device
Sensor
Power
Supply
Open CollectorType
Photo Coupler
Figure 2-4. SENSOR Input connection
 RLY OUT
It is used for connecting external alarm generators such as sirens, flashing light, etc. When
activated, relay output configures a closed circuit.
A Relay output is provided for connecting alarm devices or for remote on/off devices such as
light.. Relay is normal open and it will be closed upon alarm annunciation or remote on. The relay
is capable of switching 30V AC/DC, 2A.
Alarm
Out
Device
Relay1
Power
Supply(1~30
VDC/AC,1A )
Relay1
+
-
Relay Switch Power Supply
1V~30VDC/AC,1A
Optional
Relay Switch
Alarm
Out
Device
Power
Supply(30V
~)
Relay
Figure 2-5. RELAY Output connection

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 14
 Factory Default Switch
A switch provided for returning the IP camera to factory default state. Press the switch for a few
seconds while power is applied.
Figure 2-6 Factory Default switch of MGC6050F
Restoring the factory default will erase all settings.
 SD card slot
Please insert SD memory card when you want to use SD memory card. In case of pulling out SD memory
card, please push the SD card.
Factory Default Switch

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 15
3. On Site Installation
3.1. S St ta an nd d B Br ra ac ck ke et t
Please follow through the following procedures for the installation on the wall or ceiling.
1. Fix the mounting bracket and bracket
holder on the wall or the ceiling using
screws.
2. Insert the bolt on the bracket into the
bracket hole and rotate the bolt
clockwise to install the IP camera on
the bracket
3. Rotate the nut and lever clockwise to tighten.

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 16
4. Getting Started
Brief information for first time operation of MGC6050F is provided in this chapter.
4.1. PC Requirement
Audio/Video streaming data received from MGC6050F can be displayed or stored in a PC running client
programs. Minimum requirement of the PC is described below:
Minimum Requirement Recommended Specification
CPU Intel Core i3 3Ghz Intel Core i7
Main Memory 2GB 4GB
Operating System* Windows XP Windows 7 (64bit)
Web Browser Internet Explorer 8, 9 Internet Explorer 8, 9
Graphic Card Video RAM 256MB
Resolution 1920x1080
Video RAM 1GB
Higher than 1920x1080
Network 100 Base-T Ethernet 100 Base-T Ethernet
* Operating Systems supported: Windows 2000 Professional, Windows XP / Vista / 7

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 17
4.2. Quick Installation Guide
1. Connect PC and MGC6050F to network.
1) Prepare a PC to run programs for the installation and video connection
(PC is needed to assign IP address to MGC6050F)
2) In case of using PoE, connect the PC and MGC6050F to the network using one of the following ways.
If your LAN Switch does not support standard PoE, connect MGC6050F as shown in dotted line in
Figure 4-1. The DC power is applied through DC adaptor.
Figure 4-1. Power and network connection
2. Install “IP installer and set IP parameters on MGC6050F
Insert the CD provided with product into the PC. Install WinPcap and IP Installer in sequence.
IP installer Ver. 3.0.1 or later is needed in the configuration of MGC6050F.
Follow the sequence below for setting the IP parameter
i) Run IP installer > Select Network Adaptor >OK
ii) Click in IP installer window.> Double c①lick on > Fill in > make a selection in > Fill the ② ④ ⑤
parameters in ⑥
iii) Click on to apply the settings.⑨
iv) You can connect to admin page by clicking on .⑩
LAN switch
with
standard POE
(802.3af)
LAN switch
DC adaptor

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 18
Click on the field in ③for sorting and rearranging the list.
Select network mode that best suits your case from the drop down list in ⑤. You can choose
either Static or ADSL and Auto (DHCP), respectively. If ADSL and Auto are selected, the fields
in ⑥is deactivated.
In case of ADSL, fill the User Name and Password in ⑧ with the values provided by your ISP.
If DDNS service is needed, do the followings:
i) Check at the box and fill the empty field with “host name” in ⑦.
ii) Register the IP camera on DDNS. Visit http://www.autoipset.com for the
registration. If you don’t have an account on www.autoipset.com, open an account and
register the IP camera after login.
1
2
3
6
4
9
5
7
8
10

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 19
3. Remote video connection to MGC6050F
1) Connection through Web Viewer
Web Viewer offers simplest way of video connection to MGC6050F. For video connection, enter the IP
address of MGC6050F in the URL window of Internet Explorer as:
Note: Active-X module should be installed on your PC before actual connection. If your PC is
not connected to the internet, you cannot download Active-X module. Most convenient way of
installing the Active-X module is installing NVR-pro which is available from the CD or our web
site.
Figure 4-2. Web Viewer
Default ID and password of Admin Page are root, admin. For more detailed information, please refer to the
“User manual_ Eng_ Rev.1.0” Guide.
[e.g.] Port 8080
[e.g.] Port 80 Can be omitted the
default port of 80
Connection to Admin Page Basic Control
Video Crop Control

M
MG GC C6 60 05 50 0F F U Us se er r’ ’s s G Gu ui id de e
Rev.1.0 (Dec.2013) 20
2) Connection through NVR-Pro
NVR-Pro is a multi-channel CMS program for to IP camera or Video server. Install NVR-Pro on remote
PC to connect to these products. It is needed to assign connection information to NVR-Pro program
before connection. Details for the NVR-Pro can be found in [NVR-Pro User’s Guide].
4. Additional settings through connection to the Admin Page
All the parameters of new IP camera follows factory default values. For more sophisticated target application it
is needed to change parameters. The admin page can be connected through
”http://IP_address:HTTP_port_number”/admin.htm
It is needed to enter ID and password of the administrator. Default ID and password are root, admin. It is highly
recommended to change the ID and password to prevent illegal access to the IP camera. For more detailed
information, please refer to the “User manual_ Eng_ Rev.1.0” Guide.
Admin Page Button
Figure 4-3. NVR-Pro
