CBS Products C-823-13 Operating instructions

CBS Products Ltd, Pillings Road, Oakham, Rutland, LE15 6QF, UK Tel: [phone]
Fax: [phone] E-mail: [email protected] Website: www.cbsproducts.com
C-823-13 DRUM TRAILER
OPERATING AND
MAINTENANCE MANUAL
Copyright ©2017 by CBS Products Limited
All rights reserved. No part of this publication may be copied, reproduced or transmitted in any form
whatsoever without written permission of CBS Products Ltd.

2
REVISION HISTORY:
Rev
No.
Date
Details
Author
01
03-2017
Original issue
A. GRAHAM

3
Contents
1INTRODUCTION...................................................................................................4
2SAFETY INSTRUCTIONS ....................................................................................5
3GENERAL DESCRIPTION....................................................................................8
4SPECIFICATIONS................................................................................................9
5OPERATING PROCEDURE...............................................................................12
5.1 ATTACHING TO VEHICLE...........................................................................12
5.2 LOADING THE TRAILER.............................................................................12
5.3 UNLOADING TRAILER................................................................................13
5.4 WINCH OPERATING INSTRUCTIONS........................................................14
5.5 POSITIONING AND BRAKING OF CONDUCTOR DRUM...........................14
6MAINTENANCE AND SERVICING.....................................................................16
6.1 WINCH.........................................................................................................16
6.2 AXLE BRAKES AND TYRES .......................................................................16
6.3 SERVICING..................................................................................................16
7TOWING INSTRUCTION....................................................................................18
7.1 BEFORE TOWING.......................................................................................18
7.2 WHEN ON THE ROAD REVERSING –AUTO REVERSING BRAKES .......19
7.3 PARKING –AUTO REVERSING BRAKED TRAILERS ...............................19
8LAYOUT OF EQUIPMENT (TYPICAL) ...............................................................20
9SPARES .............................................................................................................22
10 GENERAL ARRANGEMENT...........................................................................23
11 CE CERTIFICATE ...........................................................................................24
12 WINCH MANUAL.............................................................................................25

4
1 INTRODUCTION
CBS Products Limited is a long established UK company situated in rural Oakham,
Rutland. From its 4-acre site, CBS design and manufacture, test and market a
comprehensive range of quality products for the electricity, telecommunication and
CATV industries. Products include Overhead Line and Underground Winches, Cable
Drum Trailers and Stands, Stringing Equipment, in fact everything required for the
installation or erection of conductors and cables.
With a long history of designing standard and specialised equipment to meet the
needs of customers worldwide, CBS has invested in the latest computer aided design
and analysis systems and an integrated manufacturing plant.
The CBS Design Facility is available to discuss specific customer requirements for
any product / project, existing or new. Please contact CBS Products Ltd for further
information.
CBS Products Ltd operates stringent quality throughout the organisation and has a
quality assurance system certified to ISO 9001:2008. Our total commitment to
providing quality products and service is reflected in the high standard of the finish,
use and long life of all our products.
There are certain controls and control functions, included in the
drum trailer, which are critical to the safe operation of the
equipment. These safety critical controls are clearly marked in
the manual with the following symbol. It is imperative that these
operating and maintenance procedures are followed exactly, to
ensure safe operation.

5
2 SAFETY INSTRUCTIONS
THIS EQUIPMENT MUST ONLY BE USED BY AUTHORISED
PERSONNEL, WHO HAVE BEEN SUITABLY TRAINED AND
COMPETENT TO DO SO
THESE INSTRUCTIONS ARE TO BE MADE AVAILABLE TO
OPERATORS OF THIS EQUIPMENT AT ALL TIMES.
1. Read and understand the operation and maintenance manual supplied with
this equipment. Keep it in a convenient place for future reference.
2. Keep children and untrained personnel away from this equipment whilst in
operation.
3. Keep all guards and safety devices in place. Do not operate this equipment
with guards removed or damaged.
4. Keep hands, feet and loose clothing away from moving parts.
5. Always stop the machine to carry out lubrication and servicing.
6. Check machine before starting for worn or damaged parts. Check that all nuts
and bolts are tight.
7. If machine is left unattended, ensure that unauthorised use is prevented.
8. Never leave the machine unattended whilst in use.
9. Use safety barriers to create an exclusion zone and prohibit access
by any person(s) to the drum trailer except the operator, this is
especially important when used in public places.
10. Beware of pinch points involved with rotating components, e.g. rope/cable
drums and shafts.
11. Some component and assembly parts are in excess of 25kg (55lb). When
lifting care must be taken, ensure sufficient man power/lifting gear is available,
to prevent personal injury and damage to the machine.
12. Suitable protective clothing, footwear, gloves, eye protection and hard hat
must be used by the operator when using, servicing or maintaining the drum
trailer.
13. Do not use the drum trailer if lighting levels are poor, such that make operation
hazardous.
14. Do not operate the drum trailer with any component parts
removed, missing or damaged.
15. Do not use or manoeuvre the drum trailer on surfaces or in a

6
position that is unstable and/or inclined that could result in the drum trailer
rolling, sliding or turning over.
16. Avoid using the drum trailer in thunderstorm conditions and/or where there is a
risk of lightning, snow / ice or high winds.
17. The drum trailer must not be used in a potentially explosive atmosphere.
18. The operator should monitor the drum trailer for potential problems and
hazards when the drum trailer is in use, these may arise slowly, quickly or
suddenly
19. Only use the machine for its intended purpose.
20. No personnel are to be in manholes or ducts when the drum trailer is in
operation, (if applicable).
21. All drum collars must be positioned and secured to prevent any lateral
movement.
22. The drum trailer must be operated on firm ground in a level and
stable condition suitably anchored down for the pulling operation
to be undertaken.
23. Stay clear of cables or lines under tension.
24. The operator must take care not to trip or fall when moving the drum trailer.
25. When winching is complete do not depend on winch to support
load, always insert drum frame locking pins.
26. On soft or uneven ground wooden battens or other suitable
spreaders may be required to assist loading / unloading drums on and off of
the trailer.
27. Check the condition and function of all retaining ‘R’ clips before use each time
the drum trailer is used, (replace if worn, distorted or faulty).
28. No personal should be to the rear of the trailer, where the drum/
drum frame will be lowered to the ground, when the winch is in
operation.
29. Never apply load on winch with cable or rope fully extended.
Keep at least three full turns of cable or rope on the reel.
30. If additional front mounted prop is fitted, ensure it is correctly
stowed and secured when towing.
31. When towing ensure that the drum shaft retaining pins and R
clips are fitted and that the drum is fixed securely.
32. When towing ensure that the rope/conductor is fixed securely,
this to prevent uncoiling during transit.

7
33. When towing always ensure that the drum frame locking pins are fitted and
secured with R clips.
34. The trailer should be in a level position when towing (Chassis side members in
a horizontal attitude).
35. Prior to transit always ensure that the trailer has a positive Nose
Weight at the towing coupling and does not exceed the maximum
specified in Section 4.
36. Ensure the nose weight is within the limit of the towing vehicle.
37. Ensure that both of the rear props are in the raised position during transit.
38. Ensure rear prop locking pins are fitted and secured using R clips when in
transit and during operation.
39. Before towing the trailer, connect breakaway cable to towing attachment on
towing vehicle, ensure that is passes through the hole in the front chassis
support bracket, check the condition, if frayed, kinked or damaged, replace
immediately.
40. When towing always ensure that the jockey wheel is facing to the
rear, fully retracted such that the wheel is no longer free to rotate
and is fully raised into the chassis and secured.
41. The drum trailer must not be operated until full training and
compliance with the directives of this Operator Instruction Manual
and the Operator Instruction Manual for any the equipment to be
used in conjunction with has been fully completed.

8
3 GENERAL DESCRIPTION
The CBS 823-13 drum trailer has been designed to provide a compact,
manoeuvrable trailer capable of handling drums up to 2000mm in diameter with a
maximum weight of 1300 kg. The trailer is suitable for towing behind tractors or other
suitable vehicles.
The trailer provides ease of drum lifting using a manually operated winch. The drums
are secured in transit with suitable retaining pins.
Braked shaft options are available which may be used to provide a tensioning facility
for stringing operations.
The robust welded steel chassis is fitted with running and towing gear to satisfy the
latest UK road requirements.

9
4 SPECIFICATIONS
Trailer VIN
Vehicle Identification Number:
SA9C823XX17247 __ __ __
Max. Drum Weight: 1300kg
Drum Diameter: 2000mm maximum
Drum Width: 1100mm maximum
Dimensions:
Length 3100 mm
Width 2000 mm
Height 1900 mm
Weight 575kg
Coupling centre 3100 mm
to rear of trailer
Trailer excluding the 2850 mm
coupling device
Towing Eye: 50mm diameter (as standard, others sizes available)
Tyres:
Tyre size 195 R14 C8
Tyre pressure 4.5 BAR (65 P.S.I.)
Wheel nut torque 150 NM (110 LB FT)
Max. speed 96 kph (60 mph)
Hydratow coupling
Fixing nut torque: 125 NM (92 LB FT)
Lighting
A 13 pin 12 volt lighting plug is fitted to the trailer and wired to current E.U.
regulations.
A 13 pin socket should be fitted to the towing vehicle.
(A 7 pin vehicle to 13 pin trailer conversion adaptor is available to suit 7 pin vehicles,
Note:- the reversing lamp will not work with this adaptor as there is not a wire
available for the reverse lamp function, to obtain this function the vehicle should be
changed to a 13 pin socket).
CBS Products Ltd can offer a trailer design facility when our standard trailers do not
meet your exact requirements.

10

11
Optional braking:
Brake Band
Disc Brake
Statutory Plate Information
A Name of Manufacturer
B Vehicle Identification Number (VIN)
C Maximum Permitted Laden Mass of the Trailer
D Maximum Permitted Coupling Nose Weight
E Maximum Permitted Laden Road Mass for the 1st Axle from the front
F Maximum Permitted Laden Road Mass for the 2nd Axle from the front
(If applicable)
G Year of Manufacture

12
5 OPERATING PROCEDURE
IT IS IMPERATIVE THAT ALL PERSONS USING, OPERATING OR
MAINTAINING THIS DRUM TRAILER BE FULLY TRAINED AND
COMPETENT TO DO SO, AND HAVE READ THE ENTIRE
OPERATING MANUAL.
CBS PRODUCTS LTD CANNOT BE HELD RESPONSIBLE FOR MIS-
USE OF THIS EQUIPMENT.
5.1 ATTACHING TO VEHICLE
The CBS 823-13 Cable Drum Trailer has been designed for towing behind a category
M1, M2 or N1 vehicle, therefore ensure that the towing vehicle has the correct towing
arrangement to match the trailer. It should also be at a height that enables the trailer
to travel in a horizontal position, and not leaning up or down, (Ensure that there is a
positive nose weight), if the latter is the case, the vehicle towing arrangement should
be adjusted to suit.
The towing facility on the trailer is to E.U. specification and is of the inertia type (i.e.
overrun). The towing bracket is fitted with a handbrake for holding the trailer in the
stationary condition. It is essential to apply the handbrake when the trailer is
separated from the towing vehicle.
The adjustable height jockey wheel allows the towing eye to be adjusted to
ease the operation of attaching the trailer to the vehicle. Once attached the
safety wire should be applied around the towing pin of the vehicle.
The 13 pin lighting plug is wired to current E.U. regulations. The plug should be
connected to the vehicle socket before towing commences.
To avoid problems with the electrics it is advisable to ensure the plug is kept dry and
free from dirt. When fitting and removing the plug do not pull on the connecting
cables.
5.2 LOADING THE TRAILER
It is safer to load and unload the trailer when it is attached to the vehicle, and to
adhere to the following:
Ensure handbrake is applied.
Lower rear prop stands to ground and lock in position.
Ensure that spindle retaining pins are located and secured using R clip.
Ensure winch rope is tight enough on drum frame to take load when
drum frame locking pins are removed.
Ensure no personal are to the rear of the trailer, in the area where
drum frame/ drum will be lowered in.
Remove the drum frame locking pins.
Lower drum frame using the winch (See winch manual for operating
instructions, section 12)

13
When lowering the drum frame without a drum already loaded the handle will
be needed to help it get over its tipping point. Once over the tipping point the
frame will lower itself.
If brake is fitted:
If a disc braked drum spindle is fitted remove the brake and drum shaft
coupling.
If a band brake is fitted remove band from brake drum by turning tommy bar
on screw handle to release tension and sliding brake band off the drum.
Remove the spindle retaining pins, and lift spindle from the yokes.
Unscrew locking collar and remove both locking and locating collar from the
spindle.
Ensure that the drum shaft and collars are free from dirt and debris, apply a
smear of grease to the revolving collar bores.
Refit spindle locating collars, ensuring the inner part of the locating collars fit
securely into the drum.
Slide the spindle through the drum to be loaded, ensuring the torque arm drive
pins are located securely into the drum. It should be noted that the conductor or
cable should be fed from the rear of the trailer and off the top of the drum.
Refit the locking collar and lock in position by tightening the two securing screws.
IMPORTANT –The drum must be located firmly on the collars and there should
be no endplay on the drum.
Roll the drum into the trailer chassis and present spindle to yokes adjusting the
frame height as necessary with the winch.
Rotate the brake shaft, fit drum and brake shaft coupling, fit locating pin and
secure locating pin using R clip.
Insert spindle retaining pins into yokes and secure using R clips.
Ensure no personal are to the rear of the trailer, in the area where
drum frame/ drum will be lowered in.
Winch drum frame into position and insert drum frame locking pins,
securing using R clips.
Take load off the winch.
Lift rear prop stands and lock in upright position using locking pin, secure using R
clip.
You are now ready to tow your trailer
IMPORTANT- NO PERSONAL SHOULD BE TO THE REAR OF THE
TRAILER, WHERE THE DRUM/ DRUM FRAME WILL BE LOWERED
TO THE GROUND, WHEN THE WINCH IS IN OPERATION.
5.3 UNLOADING TRAILER
It is safer to load and unload the trailer when it is attached to the vehicle, and to
adhere to the following:
Ensure handbrake is applied.
Lower rear prop stands to ground and lock in position.
Ensure that spindle retaining pins are located and secured using R clip.
Ensure winch rope is tight enough on drum frame to take load when drum frame
locking pins are removed.
Ensure no personal are to the rear of the trailer, in the area where
drum frame/ drum will be lowered in.
Remove the drum frame locking pins from the drum frame.

14
Lower drum frame using the winch (See winch manual for operating instructions,
see section 12.)
When lowering the drum frame without a drum already loaded the handle will
be needed to help it get over its tipping point. Once over the tipping point the
frame will lower itself.
If brake is fitted:
If a disc brake drum spindle is fitted remove the brake and drum shaft
coupling.
If a band brake is fitted remove band from brake drum by turning tommy bar
on screw handle to release tension and sliding brake band off the drum.
Remove the spindle retaining pins, and rotate drum out of the yokes.
Unscrew locking collar and remove both locking and locating collar from the
spindle.
Take spindle out of the drum.
Ensure that the drum shaft and collars are free from dirt and debris, apply a
smear of grease to the revolving collar bores.
Slide locating collars on to spindle and move them up to the toque arm.
Refit the locking collar and lock in position by tightening the two screws.
IMPORTANT –Ensure the locating collars cannot slide freely down spindle to
prevent damage when in transit.
Put spindle into the trailer chassis and present spindle to yokes adjusting the
frame height as necessary with the winch.
Rotate the brake shaft, fit drum and brake shaft coupling, fit locating pin and
secure locating pin using R clip.
Insert spindle retaining pins into yokes and secure using R clips.
Ensure no personal are to the rear of the trailer, in the area where
drum frame/ drum will be lowered in.
Winch drum frame into position and insert drum frame locking pins,
securing using R clips.
When raising the drum frame without a drum loaded, the handle will be
needed to keep some straining on the rope once the drum frame is over the
tipping point. This is only needed to be done until the suspension units are
applying load to the rope.
Lift rear prop stands and lock in upright position using locking pin, secure using R
clip.
You are now ready to tow your trailer.
IMPORTANT- NO PERSONAL SHOULD BE TO THE REAR OF THE
TRAILER, WHERE THE DRUM/ DRUM FRAME WILL BE LOWERED
TO THE GROUND, WHEN THE WINCH IS IN OPERATION.
5.4 WINCH OPERATING INSTRUCTIONS
See Winch manual, section 12, for operating instructions and general
winch safety information.
5.5 POSITIONING AND BRAKING OF CONDUCTOR DRUM
Once on site, position the trailer at approximately 20-30 metres distance from the first
pole to be strung. Align the trailer so the centre of the drum is in line with the first
pole. This ensures the conductor comes off the drum without fouling the drum
flanges.

15
Ensure the drum is loaded with the conductor feeding off the top of the drum.
Anchor the trailer down, by either leaving attached to towing vehicle or by
the use of slings and ground anchors (CBS 804), and also apply the
trailer brakes. Lower the rear prop stands of the trailer to stabilise during
the pulling operation, on soft ground it may be necessary to place wooden battens
under the rear prop stands to spread the load, the trailer must be stable and
adequately restrained.
Check that the drum retaining pins and brake pins are located correctly and have not
moved during transportation.
Do not use a drum that does not fit the drum collars.
If drums with larger diameter spindle holes are to be used, it is recommended that
you order special collars from CBS Products LTD. to suit in advance of operating the
drum trailer.
Band Brake:
For a drum braking operation apply the drum brake lightly by turning the tommy bar
on the screw handle. Rotate the drum slightly by hand to ensure that the brake band
is just making contact with brake drum.
Note: The tommy bar screw controls the braking at a coarse level, and should be left
set once the required tension is achieved. The brake lever provides finer control of
the tension and can be adjusted by the operator during the stringing operation if
necessary.
Disc Brake:
For a disc braking operation apply the disc brake lightly by taking out the R clip from
the castle nut on the disc brake and turning the castle nut. Always replace R clip after
adjustment of the brake. Rotate the drum slightly by hand to ensure that the brake
pads are just making contact with the brake disc. The brake lever can then be used
to provide more braking force as required.
Note: The castle nut controls the braking at a coarse level, and should be left set
once the required tension is achieved. The brake lever provides finer control of the
tension and can be adjusted by the operator during the stringing operation if
necessary.

16
6 MAINTENANCE AND SERVICING
6.1 WINCH
See winch manual for maintenance and servicing requirements.
6.2 AXLE BRAKES AND TYRES
The brakes fitted are the auto reverse type to make towing easier. The
maintenance of the drum brakes should be undertaken by trained personnel only,
and adjusted when necessary to ensure the drums just run clear when the wheel is
rotated in a forward direction only. It is important to keep these adjusted every 6
months, as too large a drum movement can affect the performance of the auto
reverse facility and parking brake.
After adjusting the drum brakes, remove any slack in the operating system by
loosening the lock nut and tightening the pull rod, but without pre loading brakes
(check this again by rotating each wheel in a forward direction).
The tyres should be kept at the correct pressure (refer to section 4 for details) and
checked weekly, the tyres should be checked daily for damage prior to use of the
trailer.
The linkage mechanism should be oiled weekly to ensure smooth operation and to
protect from moisture.
Check the condition of the brake cables weekly, replace if frayed or damaged.
Apply alight oil as required to ensure cables move freely.
6.3 SERVICING
Tow-eye and Axle:
a) Apply grease to ball and to cup of ball head after cleaning each item.
(Alternatively towing eye and jaw if fitted). This to be carried out each time the
trailer is to be towed.
b) Oil all moving parts weekly having wiped away all corrosion and dirt deposits.
c) Every 3,000 miles or 3 months, or as necessary, apply grease gun to grease
nipples fitted to the coupling using general purpose grease.
d) After first 500 miles, then every 3,000 miles (or more often if required), adjust
wheel brakes at back plate adjusting points, to take up any wear. Follow brake
manufacturers appropriate instructions in this respect.
NOTE: do not adjust for brake wear anywhere other than at the wheel brakes
themselves. An indication of break wear will be given by increased handbrake travel.

17
e) After adjusting the drum brakes, remove any slack in the operating system by
loosening the lock nut and tightening the pull rod, but without pre-loading brakes
(check this again by rotating each wheel in a forward direction).
f) Check the condition of the brake cables every week, replace if frayed or
damaged.
g) Check the condition of the brake away cable each time the drum trailer is used,
replace if kinked or damaged.
h) Check the condition of all pin retaining wires, each time the drum trailer is used,
replace if kinked or damaged.
i) Check the condition and function of all retaining ‘R’ clips each time the drum
trailer is used, (replace if worn, distorted or faulty).
j) Check the ball head for wear each time trailer is used, (if applicable).
Brake Band (if fitted):
a) Check wear of brake band lining, if worn to within 2 mm of the rivets the brake
band should be replaced.
b) Adjust tommy bar on the screw handle to accommodate wear as required.
c) Check brake drum for damage and replace as required.
d) Check for smooth operation of brake.
Disc Brake (if fitted):
a) Grease disc brake caliper mounting lugs and ensure free lateral movement of
caliper.
b) Check brake pad wear and replace as required.
c) Tighten castle nut on disc caliper to adjust for wear as required.
d) Check disc for damage, excessive corrosion and wear, replace as required.
e) Check for smooth operation.

18
7 TOWING INSTRUCTION
7.1 BEFORE TOWING
a) Check the ball head cup is well greased (if fitted).
b) Handbrake is fully applied.
c) Raise the coupling head above height of ball bracket by use of jockey wheel
provided.
d) Reverse towing vehicle until ball bracket is directly below ball head on coupling.
e) Grasp locking handle on top of coupling and press trigger backwards with thumb.
Then lift handle (you can now release trigger). With handle still raised wind up
jockey wheel until ball on towing vehicle enters ball cup on coupling. Now release
handle and continue winding up jockey wheel until locking handle automatically
drops down and trigger snaps shut. If this does not occur lift handle again and
check if ball seats this time and trigger snaps shut. If there is still no success,
check if ball or head is worn.
f) If ball seats properly, then continue winding up jockey wheel until it is fully
retracted.
g) If towing eye is fitted instead of ball head, remove pin from towing jaw and reverse
towing vehicle until eye enters jaw. Then replace pin and locking pigtail or other
securing device.
h) Continue to wind up jockey wheel until fully retracted and wheel is no longer free
to rotate. Loosen jockey clamp and raise jockey wheel up into chassis with wheel
facing rearwards and re-tighten clamp firmly ensuring wheel is well clear of brake
linkage, ensure that the rear prop stands are raised and that the retaining clip on
both rear prop stands are fitted and the handles are positioned inline with the
main chassis side member.
If an additional front mounted prop is fitted, ensure it is correctly stowed and
secured for towing.
Please remember brake linkage and handbrake must be free to move fully during
overrun braking when on the road so that breakaway cable can apply brakes if
trailer should part company with towing vehicle.
i) Check condition of breakaway cable. If frayed or kinked at all replace
immediately before use. Then connect breakaway cable to towing attachment on
towing vehicle. The cable must be free of knots.
j) Connect electrical plug to socket on rear of towing vehicle and check all lights are
fully operational.
k) Check the load is distributed to give the correct nose weight for the coupling, refer
to Section 3 for information on the hydratow coupling, a positive nose weight is
required to ensure stable towing. Also ensure nose weight is within limit of towing
vehicle.
l) When fitting the number plate ensure that if is fitted centrally beneath the number
plate lamp.

19
m) Ensure that the retaining clip on both rear prop stands is fitted and the handle is
positioned inline with the main chassis side member when in the raised position.
n) If towing with a car transporter vehicle, or any other vehicle, which has a long rear
overhang, extra forces can be applied to the coupling and towing device causing
rapid wear and damage. Please consult our Sales Department.
7.2 WHEN ON THE ROAD REVERSING –AUTO
REVERSING BRAKES
a) Simply reverse with towing vehicle having checked all is clear around you. Initial
resistance will be felt as brakes are applied on trailer and then automatically ‘roll-
off’, allowing reversing to continue. If reversing a heavy trailer up an incline, or on
grass or other slippery surfaces, wheel spin on the towing vehicle may occur, as
brakes initially come on.
b) If so, simply pull forward on to flat surface and recommence reversing operation
from there.
c) If trailer regularly has to be reversed up a steep incline, then an optional manual
override for such conditions can be offered.
7.3 PARKING –AUTO REVERSING BRAKED TRAILERS
a) Apply handbrake fully (if energy stores is fitted to rear of coupling then apply
further pressure to the handbrake to compress the spring which is fitted within the
energy store component). This ensures that should brake roll-off occur when a
trailer is parked with the rear facing down an incline that the brakes will
automatically be re-applied. . Please remember brake linkage must be free to
move fully during overrun braking when on the road, also handbrake so that
breakaway cable can apply brakes if trailer should part company with towing
vehicle. If the unit is fitted with a power assisted handbrake, then no further action
is required as the handbrake will automatically take up any further movement
should roll-off start to occur when parked on a slope.
b) Disconnect electrical plug from socket and store in safe position.
c) Loosen jockey clamp and lower jockey wheel to ground. Firmly re-righten clamp
(by hand). Press back trigger with thumb and lift handle on coupling head. At the
same time raise front of trailer by use of jockey wheel until head is fully clear of
ball on towing vehicle, if additional front mounted prop is fitted, ensure it is
correctly lowered and secured.
d) Disconnect breakaway cable from towing vehicle.
e) Drive towing vehicle clear of trailer. (in the case of a coupling fitted with an eye
follow above instructions except in respect of the final disconnecting of the towing
vehicle in which case the instructions supplied with the towing jaw or hook should
be used accordingly).
f) As extra security it is strongly recommended that the wheels of the trailer should
be chocked as an additional safeguard.

20
2
3
4
5
6
7
8
9
8 LAYOUT OF EQUIPMENT (TYPICAL)
1 Winch
2 Hydratow Coupling
3 Jockey Wheel
4 Rear Prop
5 Drum shaft Assembly and Drum Brake
6 Drum Frame Locking Pin
7 Brake Control Lever
8 Torque Arm
9 Cable Drum
1
