1. Introduction
1.1. What is a tachograph?
Basically, a tachograph is a device that measures and records the speed and distance driven by a vehicle.
The data are recorded in the form of graphics on a paper disk.
The new digital tachographs record those data on its embedded memory and also on the smartcard of the
driver.
2. Description
2.1 Technical specifications
- Graphic FSTF LCD Display:
100 x 32 px (4 lines x 20 char) - White LED backlight
- Size: 150 x 100 x 45 mm
- Supply voltage: 9 to 30 VDC
- Supply current: 12mA
- Case: green-blue ABS (IP40)
- Operating temp: -20…+70°C
- Weight: 155g
Page 3sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
2.2. Keyboard
- Alternate function keys 'F1', 'F2' & 'F3' are active when a function in
inverted video appears on the bottom line of the display.
F1= MODIFY, F3=OK
- Alernate function key '↑' & '↓' are used for example to navigate the
menus.
- Alernate function key '←' & '→' are used to select the digit in some
parameters.
- 'Ent' (=Enter) is used to select a function or enter a value.
- 'Esc' key is used to go back in the menu, leave a function, to erase
the last digit entered and to switch the programmer ON & OFF when
powered by the battery.
2.3. Connections
- Left connector:
Serial port for software upgrade (upgrade cable).
- Center connector:
Connection for crocodile clip cable (K13xx/K1318).
- Right connector:
Connection for tachograph cable.
Track length
0020m
MODIFY OK
Page 4sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
3. Operation
3.1. Power supply and tachograph type detection
For all tachograph types, except for the K13xx/1318 and the FTCO1319, the programmer is powered by the
tachograph itself. An automatic tachograph type detection is executed on power ON, so don't switch the
programmer ON, simply connect it to the tachograph with the appropriate cable. The programmer will switch
ON and detect the tachograph type.
In the case of the K13xx/1318 and the FTCO1319, switch the programmer ON pressing the 'I/O' key.
If the FTCO1319 is connected, the programmer will detect it.
To switch the programmer OFF, press and hold the 'I/O' key.
If no tachograph is detected, the K13xx/1318 will be selected by default.
On power ON, the programmer will display the product information (Software version, Serial number, etc...),
then the menu for the tachograph type detected.
Page 5sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
3.2. Menu trees
The functions available in the main menu depend on tachograph model detected (or selected manually).
The tachograph model appears on the top line.
3.2.1. KTCO 13xx/1318
KTCO 13xx/1318
1.Measure W
1.Manual
2.Photo sensor
2.Measure K
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Clock test
6.Select Tacho.
7.Product info.
8.Language.
3.2.2. MTCO 1324/1390
MTCO 1324/1390
1.Measure W
1.Manual
2.Photo sensor
2.Parameters
1.K Factor
2.Odometer
3.Instal. Date
4.Calibr. Date
5.Time & Date
6.O/P shaft
7.Service delay
8.CAN priority
9.Binary code
10.Product Code
11.VIN
12.N-RPM Factor
13.L-Tyre
14.Serial number
15.Maximum speed (1390 only)
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Erase DTCS
6.Sensor pairing
7.Clock test
8.Select Tacho.
9.Product info.
10.Language.
Page 6sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
3.2.3. Motomet.EGK100
Motomet.EGK100
1.Measure W
1.Manual
2.Photo sensor
2.Parameters
1.K Factor
2.Kn
3.U1
4.U2
5.U3
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Select Tacho.
6.Product info.
7.Language.
Page 7sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
3.2.4. Kienzle 1319
Kienzle 1319
1.Measure W
1.Manual
2.Photo sensor
2.Measure K
3.Parameters
1.K factor
2.Odometer
3.Instal. Date
4.Calibr. Date
5.Odometer Unit
6.Speed Warning
7.Fitter Number
8.Clock Speed
9.Kn ON/OFF
10.Kn Max
11.Kn Warning
12.Code
13.Mercedes ID
14.EEC Tacho.
15.SWISS ABZ
16.Driver change
17.4imp/m output
18.Note
19.Service
20.Tot. distance
21.Model
22.Serial number
23.Electronics
24.Code SO
25.Code ME
26.Code PR
4.Speed test
1.Manual
2.Automatic
5.Odometer test
6.Clock test
7.Select Tacho.
8.Product info.
9.Language.
Page 8sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
3.2.5. V.Root VR2400
V.Root VR2400
1.Measure W
1.Manual
2.Photo sensor
2.Parameters
1.K factor
2.Odometer
3.Pulse per rev.
4.Idle rpm
5.Economy rpm
6.Poor Econ. rpm
7.CANBus RPM
8.RPM Display
9.Dist displ.0s
10.DTCs Display
11.Overspd Flash
12.Overspeed
12.Time & Date
13.O/P shaft
14.4th Chart Tr
15.CANBus enable
16.CAN Type
17.Dual Axle
18.D.Axle Ratio
19.D6 pin funct.
20.Speedo.OP fact
21.Serial Comms
22.Ignit.On rec.
23.Driver 2 Duty
24.Reset HeartBt
25.Eject pin code
26.Sensor type
27.Service Delay
28.Installat.date
29.Calibrat. date
30.Repair Shop ID
31.Vehicle ID n°
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Erase DTCS
6.Sensor pairing
7.Clock test
8.Select Tacho.
9.Product info.
10.Language.
Page 9sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
3.2.6. Digital VDO
DIGITAL VDO
1.Measure W
1.Manual
2.Photo sensor
2.Parameters
1.Calibration
1.W factor
2.K factor
3.L (Tyre Circ.)
4.Tyre Size
5.Max.Auth.Speed
6.Odometer
7.Time & Date
8.Next Cal. Date
9.Veh.Reg.Nation
10.Veh.Reg.Number
11.Veh.Id.Number
2.Other param.
1.ResetHeartbeat
2.TCO1 priority
3.O/P shaft
4.CAN rep.rate
3.Manufacturer
1.Part number
2.Drv1 ign.ON
3.Drv2 ign.ON
4.Drv1 ign.OFF
5.Drv2 ign.OFF
6.D1D2 Record
7.RPM Record
8.Speed Record
9.Install. date
10.ResetHeartbeat
11.CAN error
12.CAN2 TC01 mess
13.CAN2 WakeUp D3
14.CAN2RemoteDown
15.RD interface
16.Speed Warning
17.Illum.mode
18.IMS Activation
19.IMS source
20.IMS factor
21.VDO Counter
4.Information
1.Supplier Id
2.Manufact. Date
3.Serial number
4.Hardware number
5.Hardware vers.
6.Software number
7.Software vers.
8.License number
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Read DTCS
6.Erase DTCS
7.Sensor pairing
8.Clock test
9.PIN code
10.Select Tacho.
11.Product info.
12.Language.
Page 10 sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
3.2.7. Digital SE5000
DIGITAL
SE5000
1.Measure W
1.Manual
2.Photo sensor
2.Parameters
1.Calibration
1.W factor
2.K factor
3.L (Tyre Circ.)
4.Tyre Size
5.Max.Auth.Speed
6.Odometer
7.Time & Date
8.Next Cal. Date
9.Veh.Reg.Nation
10.Veh.Reg.Number
11.Veh.Id.Number
12.O/P shaft
2.Other param.
1.ResetHeartbeat
2.TCO1 priority
3.O/P shaft
4.CAN rep.rate
5.Part number
3.Manufacturer
1.Part number
2.CanBus activat
3.Speed Corr.
4.D6
5.D4
6.Light input
7.RPM input
8.Default lang.
9.Serial Output
10.D1D2 Record
11.RPM Record
12.Speed Record
13.Kn factor
14.Install.date
15.IMS Source
16.IMS Gain
17.IMS Factor
4.Information
1.Supplier Id
2.Manufact. Date
3.Serial number
4.Hardware number
5.Hardware vers.
6.Software number
7.Software vers.
8.License number
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Read DTCS
6.Erase DTCS
7.Sensor
pairing
8.Clock test
9.PIN code
10.Select
Tacho.
11.Product
info.
12.Language.
Page 11 sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
3.2.8. Digital ACTIA
DIGITAL ACTIA
1.Measure W
1.Manual
2.Photo sensor
2.Parameters
1.Calibration
1.W factor
2.K factor
3.L (Tyre Circ.)
4.Tyre Size
5.Max.Auth.Speed
6.Odometer
7.Time & Date
8.Next Cal. Date
9.Veh.Reg.Nation
10.Veh.Reg.Number
11.Veh.Id.Number
12.O/P shaft
2.Other param.
1.ResetHeartbeat
2.TCO1 priority
3.O/P shaft
4.CAN rep.rate
5.Part number
3.Specific
1.Default Lang
2.Card Language
3.Backlight conf.
4.Drv1 ign.ON
5.Drv2 ign.ON
6.Drv1 ign.OFF
7.Drv2 ign.OFF
8.Install. date
4.Information
1.Supplier Id
2.Manufact. Date
3.Serial number
4.Hardware number
5.Hardware vers.
6.Software number
7.Software vers.
8.License number
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Read DTCS
6.Erase DTCS
7.Sensor pairing
8.Clock test
9.PIN code
10.Select Tacho.
11.Product info.
12.Language.
Page 12 sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
3.2.8. Digital EFAS
DIGITAL EFAS
1.Measure W
1.Manual
2.Photo sensor
2.Parameters
1.Calibration
1.W factor
2.K factor
3.L (Tyre Circ.)
4.Tyre Size
5.Max.Auth.Speed
6.Odometer
7.Time & Date
8.Next Cal. Date
9.Veh.Reg.Nation
10.Veh.Reg.Number
11.Veh.Id.Number
12.O/P shaft
2.Other param.
1.ResetHeartbeat
2.TCO1 priority
3.O/P shaft
4.CAN rep.rate
5.Part number
3.Specific
1.CAN-A activat.
2.CAN-A tr.rate
3.CAN-A ID mode
4.CAN-A sample
5.CAN-A pro.tach
6.CAN-A pro.diag
7.Trip Reset
8.ExtSerial act.
9.ExtSerial prot
10.Illumination
11.Engine Speed
12.N Factor
13.EngSpdThreshold
14.SpeedThresholds
15.Lang.Handling
16.PrtLocalTimeEn
17.CAN-C activat.
18.CAN-C tr.rate
19.CAN-C ID mode
20.CAN-C sample
21.RemoteDataTrans
4.Information
1.Supplier Id
2.Manufact. Date
3.Serial number
4.Hardware number
5.Hardware vers.
6.Software number
7.Software vers.
8.License number
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Read DTCS
6.Erase DTCS
7.Sensor pairing
8.Clock test
9.PIN code
10.Select Tacho.
11.Product info.
12.Language.
Page 13 sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
4 Functions description
4.1. Measure W
4.1.1. Manual
1. Check the track length.
Press F3 (OK) to go on, or press F1(MODIFY) to change the track length.
(optional)
to set the 'Track length', enter the new value and press 'Ent'.
2. Press F3 (START) and drive the vehicule along the track.
The pulse count will start.
3. At the end of the track, press F3 (STOP).
The W factor will be calculated as a function of the pulse count and the
track length.
4. Press F3 (K FACTOR) to access K factor setting.
5. The closest value from the K factor
table of the 1318 is displayed with
the corresponding switches
positions.
Press 'Esc' to go back to main menu.
5. Present K factor will be read from the tachograph and displayed.
'NEW K' is the W factor that has been measured and should be recorded
as the new K factor.
Press F2 (YES) to record it or F3 (NO) to leave it unchanged.
6. If 'YES' has been selected previously, the new K factor will be read
back from the tachograph.
This factor can modified manually if required pressing F3 (MODIFY).
Track length
0020m
MODIFY OK
Track length
0020m
[50 ]
Pulse counter
0000.0
START
Pulse counter
0123.0
STOP
W factor
6150.0
P:0123.0 K FACTOR
K Factor
K = 05347p/km
MODIFY
W=
6150
p/km
K TABLE:06147p/km
SWITCHES:1_3_5_7_9_
K FACTOR:05347p/km
NEW K: 05347p/km
RECORD NEW K ?
YES NO
K1318
Other
tachographs
Page 14 sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
4.1.2. Photo Sensor
The W measure with a photosensor is exactely the same as in manual mode, except that the 'START' and 'STOP'
pulses are generated by the sensor. In photo sensor mode, the 'F3' (START & STOP) will not be active.
You can connect any photo sensor using a MiniDIN 4-pins connector connected to the left connector of the
CD400.
- Shielding: Ground (GND 0V).
- Pin n°2: photo sensor signal (the signal should be low when the reference
object/reflector is not detected).
4.1.3. Rolling road.
[Under development]
4.1.4. Constant speed.
[Under development]
4.1.5. Draw-wire.
[Under development]
Page 15 sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
4.1.6. Odometer (only for digital tachographs).
[Under development]
Using the odometer parameter to measure the W factor does not require the workshop card.
Therefore, this function can be useful for transport companies or for the authorities.
The latest is calculated by measuring the distance driven by a vehicle when the high resolution odometer is
incremented by 5m.
Drive slowly, the CD400 will detect the Start Point
within +/- 5m.
Mark the Start Point on the ground.
Drive slowly, the CD400 will detect the Stop Point in
around 5m (depending on last calibration accuracy).
Measure the driven distance using a decameter and
enter the value in centimeter into the CD400.
As a result, the CD400 will display the K factor of the
tachograph, the W factor of the vehicle and the
calibration error in %.
Start point
Stop point
Driven distance to be measured (+/-5m)
No workshop card required!
Start Point
detection
Drive slowly...
Mark
Start Point
OK
Stop Point
detection
Drive slowly...
Enter distance:
[ 503]cm
K: 5546 p/km
W: 5512 p/km
Error: + 000.6 %
OK
Page 16 sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
4.2 Measure K
This function is available only for the K1314/1318 and the FTCO 1319.
Measuring the K factor takes a few seconds.
The value is updated every time the progress bar is completed.
4.3. Parameters
The parameter list is available at: 3.2. Menu trees
4.4. Speed test
4.4.1 Manual
For the K1314/1318 the K reference is set to the last K measured if available,
otherwize it is set to 8000. For the other tachographs the K reference is set to the
K factor programmed in the tachograph.
If required, the K reference can be adjusted manually pressing 'F1' (MODIFY).
By default the speed is set to 60 km/h.
Press F1 (ON/OFF) to start/stop speed simulation.
The text "km/h" is blinking when the speed is currently simulated.
Pressing the '↑' and '↓' keys, will increase/decrease the speed by 1km/h steps.
Pressing the '←' and '→' keys, will increase/decrease the speed by 0.1km/h steps.
Press F1(MODIFY) to insert a new speed value.
Measure K
K:0020
p/km
K Factor
K = 8000 p/km
MODIFY OK
060.0km/h
K:8000 p/km
MODIFY ON
060.0km/h
K:8000 p/km
MODIFY OFF
Page 17 sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
4.4.2 Automatic
Select the speed diagram to be executed and press 'Ent'.
For the K1314/1318 the K reference is set to the last K measured if available,
otherwize it is set to 8000.
For the other tachographs the K reference is set to the K factor programmed in
the tachograph.
If required, the K reference can be adjusted manually pressing 'F1' (MODIFY).
Press 'F3' (OK) if you agree with the K factor value.
Using the '↑' and '↓' keys, you can check the speed and duration of each step of
the automatic test.
Press 'F3' (START) to start the test.
The 'EDIT' funtion (F1) is available only for the custom diagram to edit the speed
and duration of current step of the automatic test. The automatic test will end at
the first step at which the duration is set to zero.
A count down will show the time left for present step.
Press 'F3' (STOP) to stop the bench test
Bench test completed.
Press 'F3' (OK) to go back to the menu.
Select diagram
→1.Custom diag.
2.Tacho. 100km/h
3.Tacho. 125km/h
4.Tacho. 140km/h
5.Tacho. 160km/h
6.Tacho. 180km/h
Custom diag.
Kref= 08000 p/km
MODIFY OK
Custom diag.
Step:01/23
180 km/h - 010s
EDIT START
Custom diag.
Bench test
Compleleted
OK
Custom diag.
Step:01/23 - 007s
180 km/h -010s
K:05000 START
Page 18 sur 23

Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014)index
4.5. Odometer test
The programmer will automatically simulate a speed of 50km/h on 1000m distance and check if the
odometer as been incremented by 1000m.
For the K1314/1318 the K reference is set to the last K measured if
available, otherwize it is set to 8000.
For the other tachographs the K reference is set to the K factor
programmed in the tachograph.
If required, the K reference can be adjusted manually pressing 'F1'
(MODIFY).
KTCO1318/FTCO1319/EGK100
MTCO/VR2400/DIGITAL
Press 'F2' to adjust the position of the start point.
Press 'F3' (START) to start the test.
The inital value of the odometer (D1) will be read.
Press 'F3' (START) to start the test.
Wait until the progress bar is completed.
The test can be aborded pressing 'F3' (STOP).
Wait until the progress bar is completed.
The test can be aborded pressing 'F3' (STOP).
At the end of the test, the final odometer value will
be read (D2). The difference between D2 and D1 will
be calculated (D2-D1). If the difference equals
1000m, the test has been successful.
Odometer test
Kref= 08000 p/km
MODIFY OK
Odometer test
1000
m
+START
Odometer test
0 1000m
STOP
Odometer test
D1:0041728740m
START
Odometer test
D1:0041728740m
STOP
Odometer test
D1:0041728740m
D2:0041729740m
(-) 1000m OK
Page 19 sur 23
