CDA CRI751/1 User guide
IO-REF-1219
(12.2023)
Integrated refrigerator- freezer
Use and maintenance
CRI751/1
- 2 -
EN - Table of contents
GUIDELINES CONCERNING THE SAFETY OF USE 4
INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE 9
INSTALLATION BEFORE USING THE APPLIANCE FOR THE FIRST TIME 9
MINIMUM DISTANCES FROM THE HEAT SOURCES 9
MAINS CONNECTION 10
DISCONNECTING THE MAINS 10
CLIMATE RANGE 10
UNPACKING 11
DISPOSAL OF OLD APPLIANCE 11
CONTROLS 12
APPLIANCE CONTROLS 12
ADJUST TEMPERATURE INSIDE THE APPLIANCE 12
ADDITIONAL INFORMATION ON THE TEMPERATURE 13
LIGHTING 13
REPLACE THE LIGHT BULB 13
OPERATION AND FUNCTIONS 14
STORAGE OF FOOD IN THE FRIDGE-FREEZER 14
FREEZING FOOD** 14
USING THE REFRIGERATOR EFFICIENTLY 16
PRACTICAL EVERYDAY TIPS 16
UNDERSTANDING THE STARS 16
PRACTICAL TIPS 17
FOOD THAT SHOULD NOT BE STORED IN A REFRIGERATOR 17
DEFROSTING, WASHING AND MAINTENANCE 18
DEFROSTING THE FRIDGE*** 18
DEFROSTING THE FREEZER** 18
DEFROST THE FREEZER CHAMBER FOLLOWING STEPS:** 19
AUTOMATIC FRIDGE DEFROSTING**** 19
AUTOMATIC FRIDGE DEFROSTING**** 19
WASHING THE FRIDGE AND FREEZER CHAMBERS MANUALLY**** 19
TAKING OUT AND PUTTING IN THE SHELVES***** 19
TAKING OUT AND PUTTING IN THE DOOR SHELF***** 19
TROUBLE-SHOOTING 20
WARRANTY AND AFTER SALES SERVICE 22
WARRANTY 22
- 3 -
Dear customer,
From now on, your daily housework will be easier
than ever before. Your appliance is exceponal-
ly easy to use and extremely ecient. Aer reading
these Operang Instrucons, operang the appliance
will be easy.
Before being packaged and leaving the manufacturer,
the appliance was thoroughly checked with regard to
safety and funconality.
Before using the appliance, please carefully read
these Operang Instrucons. By following these
instrucons carefully you will be able to avoid any
problems in using the appliance. It is important to
keep these Operang Instrucons and store them in a
safe place so that they can be consulted at any me.
Follow these instrucons carefully in order to avoid
possible accidents.
Sincerely,
- 4 -
GUIDELINES CONCERNING
THE SAFETY OF USE
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
• This appliance is intended to be used in household and sim-
ilar applications such as:
1. Sta kitchen areas in shops, oces and other working envi-
ronments
2. Farm houses and by clients in hotels, motels and other resi-
dential type environments
3. Bed and breakfast type environments
4. Catering and similar non-retail applications
• The manufacturer reserves the right to introduce
changes which do not aect the operation of the ap-
pliance.
• Some provisions in this user manual are unied for
refrigerating products of dierent types (for a refriger-
ator, refrigerator-freezer or freezer)
• The Manufacturer shall not be held liable for damage
arising from the failure to observe the instructions con-
tained in this manual.
• Keep this manual for future reference, or to pass it
over to the next user.
• This appliance is not intended for use by persons (in-
cluding children) with limited physical or mental capa-
bilities and persons who lack experience or familiarity
with the appliance.
• Do not allow children to use the appliance. Do not al-
low them to play with the appliance. They must not
climb inside the drawers and swing on the doors.
• The appliance operates properly at the ambient tem-
perature (see product che). Do not use it in the cellar,
unheated summer cottage during autumn and winter.
• When placing, moving, lifting the appliance, do not
hold the door handles, do not pull the condenser at
the rear part of the refrigerator and do not touch the
compressor unit.
- 5 -
• When transporting, moving or positioning the
fridge-freezer do not tilt it by more than 40° from the
vertical position. Should such a situation occur, the ap-
pliance should be switched on after minimum 2 hours
from its replacement in the right position (g.2).
• Pull the plug out from the mains socket before each
maintenance activity. Do not pull on the cord, but hold
the body of the plug instead.
• The “cracking” sound, which the appliance may emit is
caused by the expansion and contraction of parts as a
result of temperature variations.
• For safety reasons do not repair the appliance yourself.
Repairs carried out by persons who do not have the
required qualications may result in serious danger for
the user of the appliance.
• Air the room in which the appliance is placed for a few
minutes (the size of the room for a product contain-
ing isobuthane/R600a must be at least 4m3) to avoid
damage to the cooling system.
• Do not refreeze partly thawed products.
• Do not store beverages in bottles and cans, especial-
ly carbonated beverages, in the freezer chamber. The
cans and the bottles may explode.
• Do not put frozen products, taken out directly from the
freezer (lollies, ice cubes, etc.) into your mouth, their
low temperature may cause severe frostbite.
• Make sure you do not damage the cooling system, by
puncturing the refrigerant pipes in the evaporator or
breaking the pipes. The refrigerant is ammable. If the
refrigerant makes contact with the eyes, rinse them
with clean water and call for medical assistance imme-
diately.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similar qualied
persons in order to avoid a hazard.
• This appliance is intended for food storage, do not use
it for other purposes.
• When performing activities, such as cleaning, mainte-
nance or moving, the appliance must be completely
- 6 -
disconnected from power supply (by pulling the plug
out from the socket)
• This appliance can be used by children aged 8 years
and older or by persons with physical, mental or sen-
sory handicaps, or by those who are inexperienced or
unfamiliar with the appliance, provided they are su-
pervised or have been instructed how to safely use the
appliance and are familiar with risks associated with
the use of the appliance. Ensure that children do not
play with the appliance. Cleaning and maintenance of
the appliance should not be performed by children un-
less they are 8 years or older and are supervised by a
competent person.
• WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
• WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are of the type recommended by the manufac-
turer.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, its service
agent or similar qualied persons in order to avoid a
hazard.
• In order to obtain more space in the freezer, you can
remove the drawers and place the food directly on the
shelves. This has no eect on the product mechanical
properties and cooling performance. Declared freezer
capacity was calculated with the drawers removed.
• WARNING: Do not damage the refrigerant circuit.
• This appliance is not intended for use at altitudes ex-
ceeding 2000 m.
WARNING: Risk of re / ammable
materials
• Children aged from 3 to 8 years are allowed to load
- 7 -
and unload refrigerating appliances.
• WARNING: When positioning the appliance, ensure
the supply cord is not trapped or damaged.
To avoid contamination of food, please respect the fol-
lowing instructions:
• Opening the door for long periods can cause a sig-
nicant increase of the temperature in the compart-
ments of the appliance.
• Clean regularly surfaces that can come in contact
with food and accessible drainage systems.
• Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip
onto other food.
• Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making ice-cream
and making ice cubes.
• One-, two- and three-star compartments are not
suitable for the freezing of fresh food
• WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unles
they are of the type recommended by the manufac-
turer
Compartments
TYPE
Target storage
temp.[OC] Appropriate food
1 Fridge +2≤+8
Eggs, cooked food, packaged food, fruits and
vegetables, dairy products, cakes, drinks and
other foods are not suitable for freezing.
2Freezer
!
≤-18
Seafood (sh, shrimp, shellsh), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and nutrition),
suitable for frozen fresh food.
3Freezer
@
≤-18
Seafood (sh, shrimp, shellsh), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and nutrition),
are not suitable for frozen fresh food.
4Freezer
#
≤-12
Seafood (sh, shrimp, shellsh), freshwater
aquatic products and meat products
(recommended for 2 months, the longer the
storage time, the worse the taste and nutrition),
are not suitable for frozen fresh food
5Freezer
$
≤-6
Seafood (sh, shrimp, shellsh), freshwater
aquatic products and meat products
(recommended for 1 months, the longer the
storage time, the worse the taste and nutrition),
are not suitable for frozen fresh food.
- 8 -
60- star
compartment -6≤0
Fresh pork, beef, sh, chicken, some packaged
processed foods, etc. (Recommended to eat
within the same day, preferably no more than
3 days). Partially encapsulated processed foods
(non-freezable foods)
7 Chill 2≤+3
Fresh/frozen pork, beef, chicken, freshwater
aquatic products, etc.(7 days below 0OC and above
0OC is recommended for consumption within that
day, preferably no more than 2 days). Seafood
(less than 0 for 15 days, it is not recommended to
store above 0OC)
8 Fresh Food 0≤+4
Fresh pork, beef, sh, chicken, cooked food,
etc. (Recommended to eat within the same day,
preferably no more than 3 days)
9 Wine +5≤+20 red wine,white wine,sparkling wine etc.
• Note: please store dierent foods according to the
compartments or target storage temperature of your
purchased products.
• If the refrigerating appliance is left empty for long
periods, switch o, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.
• Water dispenser cleaning (special for water dispenser
products): Clean water tanks if they have not been
used for 48 h; ush the water system connected to a
water supply if water has not been drawn for 5 days.
• Pursuant to Commission Regulation (EU) 2019/2019,
the minimum availability period for spare parts nec-
essary to repair the appliance is 7 or 10 years de-
pending on the type and purpose of the spare part.
• The list of spare parts and the ordering procedure
are available on the websites of the manufacturer,
importer or an authorized representative.
• For more information about the product, please refer
to the EU EPREL Product Database at https://eprel.
ec.europa.eu. For more information, please use your
mobile device to scan the QR code on the energy la-
bel or enter the product model listed on the energy
label in the EPREL search engine https://eprel.ec.eu-
ropa.eu/
- 9 -
INSTALLATION AND OPER-
ATING CONDITIONS OF THE
APPLIANCE
This refrigeration appliance is intended for use as a built-in appliance.
WARNING: Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.”
Installation before using the appliance for the rst time
• Take the product out of the package, remove the scotch tape protect-
ing the door and the equipment. Any remaining adhesive stains may
be removed with a mild washing agent.
• Do not throw away the polystyrene elements of the packaging. If it is
necessary to transport the fridge-freezer, pack it in the polystyrene
elements and lm as well as protect ing it with scotch tape
• Clean the interior surface of the fridge- freezer and the elements of
the equipment with a washing agent dissolved in lukewarm water,
then wipe it dry.
• Place the fridge-freezer on an even, at and stable surface, in dry,
aired and shaded room, far from the heat sources such as: oven,
hob, central heating radiators, central heating pipes, hot water in-
stallation, etc.
• On the exterior surface of the product may be a protective foil, this
foils should be removed.
• Make sure the appliance is placed in a horizontal position by screwing
in the 2 adjustable front legs (g. 3)
• To ensure that the door opens freely, the distance between the side
of the appliance (on door hinges side) and the wall is shown on gure
5.*
• Ensure adequate ventilation of the room and free air circulation from
all sides of the appliance (g. 6).*
• WARNING: Keep ventilation openings, in the appliance enclosure or
in the built - in structure, clear of obstruction
Minimum distances from the heat sources
• from the electric gas and other ovens - 30 mm,
• from oil or coal red ovens - 300 mm,
• from built-in ovens - 50 mm
If there is no possibility of ensuring the above- mentioned distances,
provide an appropriate insulation board.
Warning:
• The rear wall of the refrigerator, in particular, the condenser and oth-
er elements of the cooling system must not contact other elements,
which may damage them, (e.g. central heating pipes and the water
supply pipes).
• It is forbidden to readjust or modify any parts of the unit. It is crucial
not to damage the capillary tube visible in the compressor recess.
The tube may not be bent, straightened or wound.
• If the capillary tube is damaged by the user the guarantee will be
void (g. 8).
- 10 -
• In some models the handle is put into the appliance, You should
screw it with Your own screwdriver,
Mains connection
• Prior to connection, it is recommended to set the temperature control
knob to an „OFF” or other position that disconnects the appliance
from the power supply (See page with the control description).
• This appliance should be connected to AC 220-240V 50Hz supply
socket. The socket must be tted properly, and must be supplied with
an earthing conduit and a 10A fuse.
• It is a legal requirement that the appliance is properly earthed. The
manufacturer will not be held liable for any damage or injury which
may result from the failure to full this requirement.
• Do not use adapters, multiple sockets and two-wire extension leads.
If it is necessary to use the extension lead, it must be equipped with
a protection ring and a single socket and must have a VDE/GS safety
certicate.
• If an extension lead is used (with a protection ring and safety certif-
icate), its socket must be located at a safe distance, away from the
sinks, and must not be in a place where it could be ooded by water
or waste water.
• See the type plate at the lower part of the internal wall of the appli-
ance for detailed specications**.
Disconnecting the mains
Make sure the appliance can be easily disconnected from the mains,
either by pulling the plug out of the mains socket, or by switching the
two-pole switch o (g. 9).
Climate range
The information about the climate range of the appliance is provided
on the rated plate. It indicates at which ambient temperature (that is,
room temperature, in which the appliance is working) the operation of
the appliance is optimal (proper).
Climate class Allowable ambient temperature
SN Extended Temperate
This refrigeration appliance is intended for use
at an ambient temperature ranging between
10°C and 32°C
NTemperate
This refrigeration appliance is intended for use
at an ambient temperature ranging between
16 °C and 32°C
ST Subtropical
This refrigeration appliance is intended for use
at an ambient temperature ranging between
16 °C and 38 °C
TTropical
This refrigeration appliance is intended for use
at an ambient temperature ranging between
16 °C and 43 °C
* Only free-standing appliances
** According to the model
- 11 -
UNPACKING
During transportation, pro-
tective packaging was used to
protect the appliance against
any damage. After unpacking,
please dispose of all elements
of packaging in a way that will
not cause damage to the envi-
ronment. All materials used for
packaging the appliance are environmentally
friendly; they are 100% recyclable and are marked
with the appropriate symbol.Important! Packaging
materials (bags, polyethylene, polystyrene, etc.)
should be kept away from children during unpack-
ing.
DISPOSAL OF OLD APPLIANCE
In accordance with European Direc-
tive 2012/19/EU and local legislation
regarding used electrical and elec-
tronic goods, this appliance is marked
with the symbol of the crossed-out
waste container. This marking indi-
cates that the appliance must not
be disposed of together with other
household waste after it has been
used. The user is obliged to hand it
over to waste collection centre collecting used elec-
trical and electronic goods. The collectors, includ-
ing local collection points, shops and local authori-
ty departments provide recycling schemes. Proper
handling of used electrical and electronic goods
helps avoid environmental and health hazards re-
sulting from the presence of dangerous compo-
nents and the inappropriate storage and process-
ing of such goods.
- 12 -
CONTROLS
Appliance controls
The control panel is shown in gure 10. For reference it is also shown
below:
2
1
1 — Light
2 — Temperature control dial
Adjust temperature inside the appliance
Turn the dial to adjust the temperature in the appliance:
OFF/0/● position Appliance is o
Setting 1 The highest temperature inside the appliance
(warmer)
Settings 2-4 Medium temperature inside the appliance
Setting 5 The lowest temperature inside the appliance
(cooler)
Note:
• The temperature control dial in your appliance can be marked dif-
ferently than in this manual. The general principle of operation is
described above.
• If there is no position marked "OFF" or "0” on the dial, turn o your
appliance by unplugging the power cord from the wall outlet. Before
unplugging set the lowest setting on the temperature control dial.
• If device has SF position:
- 13 -
• Turn the knob to SF to freeze fresh food quickly. In this position, the
freezer compartment will operate at lower temperatures. After your
food freezes, turn the thermostat knob to its normal use position. If
you do not change the SF position, your appliance work will auto-
matically return to its last used thermostat position according to the
time indicated in the note. Return the thermostat switch to the SF
position and return it to normal use according to the time indicated
in the note.If the thermostat switch is in the SF position when your
appliance is rst started, your appliance work will automatically re-
turn to the operation in the thermostat-3 position according to the
time indicated in the note.
• The super mode will be cancel automatically after max 48 hours.
Additional information on the temperature
• The temperature inside the appliance is inuenced by many factors.
How you set the temperature control dial depends on the ambient
temperature, sun exposure, how often you open the door and the
amount of food stored. The middle setting of the dial is most optimal
in most cases.
• Do not put food into the fridge freezer before it has reached its oper-
ating temperature, which takes minimum 4 hours.
• Do not change the temperature settings due to the change in the
season of the year. The ambient temperature increase will be detect-
ed by the sensor and the compressor will be switched on automati-
cally for a longer period of time in order to maintain the temperature
set inside the chambers.
• The slight changes in temperature are perfectly normal and may oc-
cur, for instance during the storage of great quantities of fresh prod-
ucts in the fridge, or when the door is open for a longer period of
time. This will not aect the condition of the stored foodstu, and the
temperature will quickly return to its set value.
LIGHTING
This section applies to units factory equipped with incandescent lightbulb
and selected appliances equipped with LED lighting with E14 thread.
Replace the light bulb
• Set the knob to "OFF/0/ ●", then unplug the appliance.
• Remove the bulb cover (Fig. 18).
• Replace the bulb with one having identical parameters as the factory
installed bulb (E14 thread, 220-240V, maximum dimensions: 26 mm
diameter, 55 mm length).
• Replace the bulb cover.
• Bulbs of a higher or lower power should not be used, only use bulbs
of the specication given above.
Note:
• The light bulb must not be used for room illumination.
• If Figure 18 is not shown in this manual, light source can only be
replaced by a qualied service technician.
• If your refrigerator has LED lighting, contact the help desk as this
should be changed by authorized personnel only.
- 14 -
OPERATION AND FUNCTIONS
Storage of food in the fridge-freezer
• The products should be placed on plates, in containers or packed in
food wrap. Distribute them evenly over the shelves.
• If the food contacts the rear wall, it may cause frosting or wetting of
the products.
• Do not put dishes with hot food into the fridge
• Products which absorb avours easily such as butter, milk, white
cheese and products with intense avour, such as sh, smoked meat,
hard cheese must be placed on shelves, packed in food wrap or in
tightly sealed containers.
• The storage of vegetables containing signicant quantities of water
will cause the deposition of condensation on the vegetable contain-
ers, it does not impact on the proper functioning of the fridge.
• Before putting the vegetables into the fridge, dry them well.
• Excessive moisture shortens the shelf life of vegetables, especially
the leafed vegetables.
• Do not wash the vegetables before storing in the refrigerator. Wash-
ing removes the natural protection, therefore it is better to wash the
vegetables directly before consumption.
• It is recommended to place the products in freezer drawers 1, 2, 3*
up to natural loading capacity (Fig. 11a / 11b).**
1. Packed products
2. Shelf
3. Natural loading capacity
4.
!
• Stacking of products on the freezer shelves is acceptable.*
• It is acceptable to place products beyond the natural loading capacity
by 20-30 mm.**
• In order to increase the loading capacity of the freezer chamber and
allow the stacking of products on the freezer evaporator wire shelves
up to maximum height it is possible to remove drawers 1 and 2.*
Freezing food**
• Practically all the food products, except for vegetables consumed
raw, such as lettuce can be frozen.
• Only food products of the highest quality, divided into small portions
for single use, should be frozen.
• Products should be packed in materials that are odourless, resistant
to air and moisture penetration, and not susceptible to fat. Plastic
bags, polyethylene and aluminium sheets are the best wrapping ma-
terials.
• The packaging should be tight and should stick to the frozen prod-
ucts. Do not use glass containers.
• Keep fresh and warm foodstu at ambient temperature away from
the products, which have already been frozen.
• We advise you not to place more of fresh food at a time to the freezer
per day (see table witch technical specication).
- 15 -
• In order to maintain optimum quality of the frozen food, reorganise
the food that is in the middle of the freezer, so that it does not touch
the products that are not yet frozen.
• It is recommended that you move the already frozen products to one
side and place the fresh products that are to be frozen on the oppo-
site side, as close to the rear and side walls as possible.
• To freezing products, use space marked
!
.
• Bear in mind that the temperature in the freezer is aected by sev-
eral factors, including the ambient temperature and the quantity of
food products in the chamber, the frequency of opening the door, the
amount of frost in the freezer, and the thermostat setting.
• If you cannot open the freezer door immediately after closing it, al-
low 1-2 minutes for the negative pressure to compensate, and try
again to open the door.
The storage time for frozen products depends on their quality before
freezing when fresh, and on the storage temperature. The following stor-
age periods are recommended when the temperature of -18°C or lower
is maintained:
Products Months
Beef 6-8
Veal 3-6
Giblets 1-2
Pork 3-6
Poultry 6-8
Eggs 3-6
Fish 3-6
Vegetables 10-12
Fruit 10-12
Do not store frozen food in rapid cooling chamber. Ice cubes can be pre-
pared and stored in this chamber.
Note: If the appliance does not have a freezer compartment (
!
), it
is not suitable for freezing foodstus.
* Applicable to appliances with a freezer compartment at the bottom of the appliance.
** Applicable to appliances with a freezer compartment
!
*** Not applicable to appliances with a freezer compartment marked
!
- 16 -
USING THE REFRIGERATOR
EFFICIENTLY
Practical everyday tips
• Do not place fridges or freezers next to radiators, heaters, stoves or
in direct sunlight.
• Make sure that air vents are not covered up and clean the dust o
them once or twice a year.
• Select the right temperature: 6 to 8°C in your refrigerator and -18°C
in your freezer is sucient.
• When on holiday, turn up the temperature in your fridge.
• Only open your fridge or freezer when necessary. It helps if you know
what food each contains and where it is located. Return food to the
fridge or freezer as soon as possible after you have used it so that it
does not warm up too much.
• Wipe the inside of your fridge regularly with a cloth soaked in a mild
detergent. Appliances which are not self-defrosting will require regu-
lar defrosting. Do not allow frost layers thicker than 10 mm to form.
• Keep the seal around the door clean, otherwise it will not shut prop-
erly. Always replace broken seals.
Understanding the stars
$
Temperature is at least -6°C; sucient to store frozen food
for about a week. Drawers or compartments marked with
one star used to be a feature of (mostly) cheaper fridges.
#
Food can be stored at -12°C or below for 1-2 weeks without
losing its taste. Not suitable for freezing food.
@
This rating is mainly used to store foods at -18°C or below.
Can also be used to freeze up to 1 kilogram of fresh food.
!
This appliance is suitable for storing foods at -18°C or be-
low and freezing larger quantities of fresh foods.
- 17 -
Practical tips
Due to the natural circulation of the air in the appliance, there are dif-
ferent temperature zones in the refrigerator chamber.
• The coldest area is directly above the vegetables drawers. Use this
area for all delicate and highly perishable food e.g.:
- Fish, meat, poultry
- Sausage products, ready meals
- Dishes or baked goods containing eggs or cream
- Fresh dough, cake mixtures
- Pre-packed vegetable and other fresh food with a label stating it should
be kept at a temperature of approx 4OC.
• The warmest area is in the top section of the door. Use this for storing
butter and cheese.
Food that should not be stored in a refrigerator
• Not all food is suitable for storing in the refrigerator, particularly:
- Fruit and vegetables which are sensitive to cold, such as bananas,
avocado, papaya, passion fruit, aubergines, peppers, tomatoes and cu-
cumbers.
- Fruit which is not yet ripe
- Potatoes
Warning:
Example of storing the food - see gure 12.
To achieve the most eective food preservation for the longest possible
time and to avoid wasting any food, position the products as shown in
Figure 12. In addition, this gure illustrates the layout of drawers, bas-
kets and shelves, which allows the most ecient use of energy.
Optimal temperature and storage conditions will extend product shelf
life and optimize electricity consumption. Optimal storage temperature
range should be stated on the food product packaging.
- 18 -
DEFROSTING, WASHING AND
MAINTENANCE
Never clean the product’s casing or plastic parts using solvents or strong,
abrasive detergents (e.g. washing powders or creams)! Use mild liquid
detergents and soft cloths only. Do not use sponges.
External surfaces made of plastic should be cleaned with a microber
cloth, otherwise irreversible micro scratches will appear.
Defrosting the fridge***
• Frost settles on the rear wall of the fridge chamber. It is removed
automatically. During the defrosting, the condensate, which contains
contaminants may clog the opening in the through. Should it occur,
carefully unclog the opening with the cleaning plug (g. 13).
• The appliance operates in cycles: it refrigerates (then the frost set-
tles on the rear wall), and defrosts (water ows down the rear wall)
• Disconnect the appliance from the mains before cleaning by remov-
ing the plug from the mains socket or switching o the fuse. Prevent
water from penetrating the control panel or the light.
• Do not use defrosting aerosols. They may cause the formation of an
explosive mixture, or contain solvents which may damage the plastic
components of the appliance and even be harmful to health.
• Make sure the water used for cleaning does not ow into the evapo-
ration container through the discharge opening.
• The whole appliance, except for the door gasket must be cleaned
with a mild cleaning detergent. The door gasket should be cleaned
with water and wiped dry.
• Wash all the accessories (vegetable containers, door shelves, glass
shelves, etc.).
• WARNING: Do not use mechanical devices or other means to accel-
erate the defrosting process, other than thode recommended by the
manufacturer
Defrosting the freezer**
• It is recommended to combine defrosting the appliance with washing
it.
• Excessive accumulation of ice on the freezing areas impairs the ap-
pliance’s freezing capacity and increases the energy consumption.
• Defrost the appliance at least once or twice a year. In case of a higher
ice build-up, defrosting must be carried out more frequently.
• If there is food in the freezer, set the knob to the max. position about
4 hours before the planned defrosting. This will ensure the possibility
of storing the food at the ambient temperature for a longer time.
• After taking the food out of the freezer, put it in a container, wrap it
with several layers of paper, a blanket and store it at a cool place.
• The defrosting operation should last as short as possible. Long stor-
age of food at the ambient temperature shortens their shelf life.
- 19 -
Defrost the freezer chamber following steps:**
• Switch of the appliance using the control panel and pull the plug out
from the socket..
• Open the door and remove the food from the freezer.
• Depending on the model, pull out the drainage tube located in the
bottom of the freezer compartment and place a suitable vessel un-
derneath.
• Leave the door open, this will speed up the defrost process. Addi-
tionally, a pot with hot water (not boiling) may be placed inside the
freezer compartment.
• Wash the interior of the freezer and wipe it dry.
• Switch on the appliance as per the relevant point in the manual.
Automatic fridge defrosting****
The fridge chamber has been equipped with an automatic defrosting
function. However, frost may settle on the rear wall of the fridge cham-
ber. This happens usually, when large quantities of fresh food products
are stored in the fridge.
Automatic fridge defrosting****
The freezer chamber has been equipped with an automatic defrosting
function (no-frost). The food is frozen in the cooled circulation air, and
the moisture from the freezer chamber is discharged outside. As a result,
no ice and frost is produced in the freezer and the products do not freeze
on each other.
Washing the fridge and freezer chambers manually****
It is recommended to wash the fridge and freezer chambers at least once
a year. This prevents the formation of bacteria and bad odours. Switch
o the appliance, using button (1), remove the food from the chambers
and wash them using water with a mild detergent. Then, wipe the cham-
bers dry with a cloth.
Taking out and putting in the shelves*****
Slide the shelf out, then slide it in as much as possible so that its clamp
could t the guide groove (g. 15).
Taking out and putting in the door shelf*****
Lift the door shelf, remove it and put it back from the top into its required
position (g. 16).
WARNING! You must not put an electric heater, a heating fan or a hair
dryer into the freezer by any means.
** Applicable to appliances with a freezer compartment
!
Not applicable to appliances with a Frost-free System.
*** Applicable to appliances with a refrigerator compartment
Not applicable to appliances with a Frost-free System.
**** Applicable to appliances with a Frost-free System.
***** Does not apply to freezers
- 20 -
TROUBLE-SHOOTING
Problems Possible causes Remedies
The appliance does not work The electric circuit is dis-
rupted
- check whether the plug is
properly inserted into the
socket
- check whether the power
cable of the appliance is not
damaged
- check whether there is
voltage in the socket, by
plugging another appliance,
e.g. a night lamp
- check whether the ap-
pliance is switched on by
setting the thermostat to a
position above 0.
The lighting inside the
chamber does not work
The bulb is loose or fused
(only appliances with bulb
lightning type)
- t the bulb correctly or
replace it (see section above
“Replacing the interior light
bulb)
The appliance works contin-
uously
Incorrect setting of the
adjustment knob
- reset the knob to a lower
position
See. ”Temperature inside
the appliance is not low
enough for description of
other possible causes
See. ”Temperature inside
the appliance is not low
enough for description of
other possible remedies
Water collects in the lower
part of the appliance
The water discharge open-
ing is clogged (depending
on the model)
- clean the discharge
opening (see the operating
manual – chapter entitled
”Defrosting the fridge”)
Internal air circulation ob-
structed
- place the food and con-
tainers in such a way as
that they do not touch the
rear wall of the fridge
The appliance generates
unusual noise
Incorrect levelling of the
appliance
- level the appliance prop-
erly
The appliance is touch-
ing furniture and/or other
objects
- place the appliance at a
location that ensures proper
clearances around it
Table of contents
Other CDA Refrigerator manuals
