Product Overview
Congratulations on your purchase of the Cellferno M Series LTE Outdoor
CPE. With this LTE (Long Term Evolution) CPE (which is also known as
4G CPE), you can share high speed mobile broadband connectivity in a
wide range of computing environments. Before you begin using the LTE
outdoor CPE, read this document to familiarize yourself with the device.
Features

Embedded high gain directional antenna

IP66 protection against dust and water

Easy configuration based on Web Interface

Provide 5 – 10dB more coverage gain compared to indoor CPE

Support Passive Power over Ethernet.

Easy installation and use
Package Contents
The following items come with your package. If any of them is damaged or missing,
please contact your retailer.
LTE Outdoor CPE
Pole Mount
(M10*100 Bolt, Nuts, and
Spring Washers
Quick Installation
Guide
Passive PoE Adapter
(Power over Ethernet)
Power Cord
Cap
(For SIM card)
Nylon Cable Gland
(For RJ-45 Ethernet
Cable)

5
Hardware Overview
1
Ethernet (RJ-45)
port
Connect to the passive PoE adapter using an
Ethernet cable.
2 LED Indicators +
SIM card slot +
Reset button
LED Indicators:
The left LED indicates power status.
The right LED indicates the signal strength.
SIM card slot:
Insert the SIM card.
Reset button:

Short press to restart the device.

Long press for 10 seconds to reset the
settings to the factory default settings.

3
Grounding
Terminal
Connect a grounding cable to the terminal and a
ground connection.
NOTE 1
Use with Ethernet lightning protector between the
Ethernet cable and the PoE is suggested for better
lightning and surge protection.
NOTE 2
For additional lightning protection, use of a lightning
arrestor on the Ethernet cable near the area where the
Ethernet cable enters a building is suggested.

Installation
Notice before installation
Install the SIM card
1.
Unscrew the SIM card slot.
2.
Insert a valid SIM card into the SIM card slot. Push it until it clicks in
place.
3.
Screw the cap on tightly.
Choose a solid and safe pole for CPE installation
1.
Choose the best location of the house and the orientation of the CPE
to get the strongest signal reception from base station.
2.
The ambient temperature for the CPE must be within -40°C to
65°C (-40°F to 149°F).
NOTE
For lightning protection ground the CPE via Grounding Terminal and optimum
reception, there are a few things you should consider before installation. Please
see “Important Installation Considerations” on page 8 for more details.
Prepare two Ethernet cables
Be sure that one of the cables used is an outdoor grade CAT 5e (or above)
Ethernet cable type and the length of the cables are adequate to reach
the location of the CPE and indoor PPoE are.
Prepare wrenches
Prepare one wrench. The wrench size: 17mm x 1.
Warning:
Do NOT start any traffic test (ex: throughput test and Internet browsing)
before the installer returns to the ground.

Important Installation Considerations
The LTE Advanced Outdoor CPE should be pole-mounted outdoors and
aligned so its antenna faces the nearest LTE eNB. Before installing the
outdoor CPE, consider the appropriate location, clearance, and device
orientation.
Location and Cable wiring
1.
Consult your Service Provider to find the best location and angle for getting the
strongest signal from the base station.
2.
Do a walking test around the house to find the best spot with the strongest signal
if you don’t obtain related information from Service Provider.
3.
Mount the CPE at the highest possible location with a clear view of the base
station signal source. Buildings or other obstructions will affect the quality of the
signal you receive.
4.
Keep the best distance as possible from other devices that maycause
interference.
5.
Keep the LTE Advanced Outdoor CPE away from power lines.
6.
Avoid placing LTE Advanced Outdoor CPE too close to any metallic reflective
surfaces.
7.
Disconnect the power cord first before mounting the CPE. Otherwise this may
result in personal injury due to electric shock.
8.
Be sure to ground LTE Advanced Outdoor CPE with an appropriate grounding
wire (not included) by attaching it to the grounding screw on the unit and to a
good ground connection.

Mounting the Unit
Mount LTE Advanced Outdoor CPE on a 1”-4” pole using the supplied kit,
or the optional tilt accessory.
Using the clamp
1.
Thread the M10*100mm bolts through spring washers, flat washers and bracket
holes.
2.
With the connectors facing downwards, attach the LTE Advanced OutdoorCPE
to a 1” to 4” pole.
3.
Attach the bracket to the other side of the pole.
4.
Thread the M10*100mm bolts through the holes the bracket and into the LTE
Advanced Outdoor CPE.
Ground the CPE
For safe outdoor use, use the grounding terminal to ground the CPE
housing before making any connections.
You need the following:

Spring washer

M5x8 mm screw
NOTE
The spring washer and M4x8L screw are not included in your package.

To ground the CPE:
1.
Insert the washer to the M4x8L screw.
2.
Attach the screw halfway into the earth ground terminal.
3.
Insert the grounding cable under the washer.
4.
Tighten the screw.
Making the Connections
Connect the Ethernet Cable to the Unit
Use only 5E 4x2x24# FTP (or above) outdoor shielded patch cables from
an approved manufacturer.
1.
Remove the sealing cable gland plug from the gland nut.
2.
Open the sealing gland nut and remove it. Do not disassemble the
gland base from the bracket.
3.
Insert the Cat5 RJ-45 cable into the sealing gland base and connect it
to the Ethernet port at the bottom of the unit. Make sure that the
connector is completely inserted and tightened.
NOTE
The total length of the Ethernet cable from the unit to the RJ-45 port on the PoE
must not exceed 80 meters.
4.
Insert the rubber bushing on the cable into the gland base.

5.
Tighten the gland nut. Use the dedicated tool for fastening thesealing
glands.
Connect the Ethernet Cable to Computers
1.
After connecting the Ethernet cable to the unit, install a protective
cover on the connector at the other end of the Ethernet cable.
2.
Connect the Ethernet cable to the port on the PoE adapter labeled
POE.
3.
Connect another Ethernet cable to the port on the PoE adapter
labeled LAN and the RJ-45 port on a PC/Notebook
PC/Hub/Swtch.
4.
Connect the PoE adapter to a power source via the power
adapter/power cable.

Using Web-based Management
This chapter will guide you on how to configure your CPE via the
web-based utility.
Login
1.
Launch a web browser.
2.
In the address bar, enter http://192.168.2.1, then press
Enter.
3.
In the login window, enter the username “admin” and
password “admin”.
4.
Click OK to login to the main screen.
5.
Click one of the menus or submenus to configure the system.


The CPE uses the network domain 192.168.2.X, for any
downstream connections, all devices should avoid using this
network domain otherwise there might be conflicting IP addresses
which will cause communication failure.

If you cannot connect to the network, please follow the steps below to
set the APN manually:
1.
Go to Network Settings > WWAN Setting > APN Profile Settings to
enter the APN profile name, and then click Add.
2.
Enter the APN, User Name, and Password, and then click Save.
3.
Go to Network Settings > WWAN Setting > Network Settings and
change the APN field to Manual, then select the profile name you added
and click Apply. The changes will be applied after the system is
rebooted.

If PIN verification on you SIM card is enabled, go to Network Settings
> Mobile Settings > UICC/SIM PIN Management to unlock the PIN
code.

If a SIM card is reinserted you must restart the CPE to read the SIM
card properly.

Signal Strength & Operator
On the top-left corner of the web-based management interface, the signal
and operator indicator next to the menu bar demonstrates the signal
strength and name of Internet service provider.
Signal Strength:
Displays signal type and signal strength.
If the mobile Internet connection is not
established, No Service will appear.
If the mobile Internet connection is established,
3G or LTE will appear based on its
corresponding signal type.
Operator: Displays the name of Internet service provider.

Status
The Status menu displays status information for the router. The
associated submenus are: System Information, DHCP Clients, Log,
and Mobile Information.

System Information
The System Information submenu displays general information about
the router.
Click Refresh at the bottom of this menu to update the system
information.

System
This section displays system information: model, product name, uptime,
system time, router firmware version ,module firmware version, module
IMEI, module ICCID, time zone, and mac address.
Click Refresh to refresh the IP address.
Wired LAN Port Settings
This section displays the wired LAN port and its connection status.
DHCP Clients

The DHCP Clients submenu displays DHCP lease information for each
client, including IP address, MAC address, and lease time remaining.
Click Refresh to update the DHCP lease information.

Log
The Log submenu tracks system activities after the system is powered
on.
Click Save to save the record of system activities.
Click Clear to clear the record of system activities.
Click Refresh to update the record of system activities.
