Celtic Magic FEATHER User manual

1
www.CelcMagic.org 1
USER MANUAL
Ver 280421
FEATHER
Light Force & Customisable
Joysck / Mouse

2
www.CelcMagic.org 2
Warnings
The Feather uses small magnets
within its construcon and
although no stronger then what
would be found in headphones
those users with pacemakers
should be aware and take
precauons and advice before
using a Feather device.
The Feather joysck has an
exchangeable knob that would be
a choking hazard to small
children.
The Feather is a very sensive
device. Avoid leaving the in
direct sunlight that may cause
small distorons aecng its
accuracy.

3
www.CelcMagic.org 3
1 Introducon
1.1 Models
1.2 Hardware view
1.3 Conguraon Applicaon
1.3.1 Basic Joysck Controls
1.4 Mounng
1.5 Adjusng the force
1.6 Knob selecon
1.7 Opons
1.8.1 External displays
1.8.2 Sip & Pu
2 Operaon
2.1 Mouse Model CM/FM
2.1.1 Conguraon
2.1.2 Manual / Auto Scanning
2.2 Joysck Model CM/FJ
2.2.1 Conguraon
`2.3 Game Control Mixer Model CM/FGCM
2.3.1 FGCM Buon inputs
2.3.2 Conguraon
2.3.3 Connecng things up
2.3.4 Changing J-modes basics
2.3.5 Changing J-modes detailed
2.3.6 J-mode summary
2.3.7 Single sck Walking & Driving
3 Specicaon & Support
3.1 Dimensions
3.2 Spec details
3.3 Support & Recalibraon
3.4 Legal & Conformity
3.5 Warranty
Contents

4
www.CelcMagic.org 4
1 Introduction
1.1 Models
There are three models, the hardware is the same between each model but the
soware within the Feather models diers.
Models:
CM/FM Feather: Mouse model
CM/FJ Feather: Joysck model
CM/FGCM Feather: Game Control Mixer (an advanced gaming version)
1.2 Hardware View

5
www.CelcMagic.org 5
1.3 Conguraon Applicaon
The PC Feather Conguraon App can be
downloaded from the Celc Magic website and
is used to congure any model of Feather.
Angular Sensivity: This sets the angle of movement to achieve 100% output.
Full = +/- 6 degrees | Mid = +/- 4.5 degrees | Tight = +/- 3 degrees
Deadband: The amount of movement that is ignored before the output starts.
Orthogonal control: Restricts movement to Up/Down and Le/Right only ie all
angles in between are ignored. Auto allows any angle at high values of movement
and restricts to orthogonal for ne movements.
Tremor Filter: Slows down inputs to reduce the eects of hand tremor at the cost
of speed.
Polaries: Swaps the axis and axis polaries to allow for novel installaons
Led Bright: Sets the brightness of any external Led displays if used
1.3.1 Basic Joysck Controls

6
www.CelcMagic.org 6
1.4 Mounng
Feathers can be mounted either by simple Vel-
cro tape or using the 4mm mounng holes.
Any screws must not enter the Feather further
than 5mm or damage may occur.
Adaptors supplied with the Feather
1) Camera Mount 1/4” UNC threaded
2) Triform Mount on three cushioned feet
Camera Mount
Part CM/F-CAM_MNT Tri Mount
Part CM/F-TRI_MNT
Oponal Feather Hand Support System
Part CM/F-HSS

7
www.CelcMagic.org 7
1.5 Adjusng the Force
The force necessary to move the Feather is adjustable
in four steps ranging from approx. 5 grams to 20
grams. The force is set by ng one, two, three or
four magnets. These being ed under the 3mm grub
screw at the centre of the of the base.
Spare magnets are stored under the second grub screw.
Normally 2 magnets are ed as standard giving approx. 10 grams of force.
Magnets
Fied
Approx.
Force
note
15g Min
210g Normal
315g
420g Max
Important that:
• No more than 4 magnets are ed.
• The magnets polarity is preserved
else the joysck will not centre.
• The grub screw is NOT SCREWED IN
FURTHER THAN FLUSH else damage
can occur

8
www.CelcMagic.org 8
Minimum force
1 Magnet
Maximum force
4 Magnets
Warnings
DO NOT mix up the
storage grubscrew
with the centre grub-
screw as they are
slightly dierent.
To avoid damage only
screw the grub screw
unl level (ush) with
the body of the
Feather.
1.5 Adjusng the Force
connued
Carefully remove the 3mm grub screw taking
care not to reverse the polarity & to insert
the new arrangement of magnets at.

9
www.CelcMagic.org 9
1.6 Knob selecon
The knob can be replaced . The
standard knob is a low prole
20mm cork sphere and is suita-
ble for all conguraons of
force from 5g to 20g.
See secon 1.5
Other knob opons are not rec-
ommended for the lightest (5g)
force opon as the heavier
knobs can tend to hold the
Feather o centre.
Large Rubber
Suitable for opera-
on
15g-20g
Part
CM/Knob-LR
Small Cork (20mm)
Standard
Suitable for ultra
light operaon
5g-20g.
Part
CM/Knob-SC
Extended Cork
Suitable light
operaon
10g-20g
Part
CM/Knob-EC
Large Cork
35mm diameter
Suitable for ultra
light operaon
5g-20g.
Part
CM/Knob-LC

10
www.CelcMagic.org 10
1.7 Opons
Dependant on the model of Feather several addional opons are available
1.7.1 External Displays
Feather Mouse : display type CM/ED1
If the user requires scanning to select
controls then the Celc Magic external
Display bar type CM/ED1 is required.
This ts to the top or to the side of a
monitor screen indicang the mode that
the mouse can be put into.
Ie clicks/ Drag / scroll etc.
Feather FGCM: display type CM/ED2
The advanced game play possible with the FGCM mod-
el is greatly enhanced by using the a compass style CM/
ED2 external display that shows the current games
mode selected in a colour coded compass paern.
1.7.2 Sip & Pu
Feature Pending
Feather Hand Support System
Part CM/F-HSS
Allows the Feather to be accu-
rately posioned at any angle-
close to your hand .

11
www.CelcMagic.org 11
Mouse Control
The Feather mouse model CM/FM appears to the computer as a USB mouse and
can be customised using the Celc Magic Feather PC conguraon applicaon to
suit the user.
There are three basic types of mouse operaon to choose from.
1 Normal
Le and right buons via the
external inputs give access to le
& right clicks
2 Manual scan
Used with a Celc Magic external
display (model CM/ED1) that will
show which command is being
selected. See secon 2.1.2
3 Auto (Buon free)
With the joysck centred the rightmost three leds on the ED1 display toggles
between Red & Green. When on Green if the joysck is moved then the mouse
cursor will move normally.
However if moved to the right (East) whilst Red leds are showing then the
command can be selected as in Manual Scan above.
If moved Up, Le or Down when the Red leds are on, selects opons associated
with the le buon ie single/double click or drag..
See secon 2.1.2
External Display ED1
2.1 Operation Mouse: model CM/FM

12
www.CelcMagic.org 12
2.1.1 Conguring Mouse Features
Auto Scan: Selects buon free selecon using only joysck movements to also
operate buons and features. See secon 2.1.3 for full details.
Scan Speed: Sets the speed for Auto or Manual scan selecon of buons and
features. See secons 2.1.2 & 3
Scroll Speed: The rate that the screen scrolls up and down when scroll is acvated.
Standard Inputs: Each
buon can be selected
to be any of the shown
funcons.
Oponal Inputs:
As standard Inputs
using Sip & Pu if
Feather has the Sip &
Pu opon ed.

13
www.CelcMagic.org 13
2.1.2 Manual & Auto Scanning
Using the external display (CM/ED1) any mouse features can be selected either by
using a single buon congured as Manual Scan or by using no buons if the
buon free Auto Scan is turned on.

14
www.CelcMagic.org 14
2.2 Operation Joystick: model CM/FJ
Simple Joysck Control
The Feather joysck model CM/FM appears to a computer as a simple PC joysck
with two buons & is customised using the Celc Magic Feather PC conguraon
applicaon.
When used with a PC the two buons can be congured to be any of 1–8 buons
available on a PC joysck.
It is also compable with the
Microso Adapve Controller
oen referred to as a XAC.
The XAC unfortunately does
not support joysck buons
in a useful way.
2.2.1 Conguraon
Unlike the Mouse or FGCM
variants of the Feather there
are fewer customisable fea-
tures apart form the standard
elements covered in secon
1.2 above.

15
www.CelcMagic.org 15
2.3 Operation Games Control Mixer: model CM/FGCM
Games Control Mixer
The Feather Games Control Mixer model CM/FGCM is designed to operate as a
input device into the Console Tuner Titan Two device running Celc Magic J
method soware. The combinaon of the Feather oering unparalleled sensivity
and the Titan oering access to all popular consoles is a powerful combinaon.
The details of all the opons available are beyond this hand book and further
informaon is available on the Celc Magic website.
The concept is that a single buon or sip or pu changes the Joysck into a four
ways switch North/ East/ South & West. 8 dierent modes (called J modes) are
then available in each of these direcons, eg changing the single Feather joysck
from say le sck to right sck and a host of other possibilies.
2.3.1 FGCM Buon inputs
Unlike the Mouse & standard Joysck models the Feather FGCM supports up to 4
inputs in is normally used with two spier cables that allows for byons PB1—PB4
as shown. One of these inputs should be congured as SHIFT and by default this is
PB2.

16
www.CelcMagic.org 16
2.3.2 FGCM Conguraon
One of the two Standard Inputs PB inputs should be congured as SHIFT and by
default this is PB2.
Addional Oponal Inputs are available ,up to four PBs on request.
Sip & Pu is also supported* and oers
the same opons along with TITAN ONLY
where analogue levels of Sip & Pu can
be ulised for example to accelerate or
brake.
* feature pending

17
www.CelcMagic.org 17
2.3.4 Changing J-modes basics : FGCM
2.3.3 Connecng things up : FGCM

18
www.CelcMagic.org 18
2.3.6 J-mode summary : FGCM
2.3.5 Changing J-mode detailed : FGCM

19
www.CelcMagic.org 19
2.3.7 Single sck Walking & Driving :
For more informaon on using all the advanced features of the FGCM model of the
Feather Joysck visit... www.celcmagic.org\feather
3 Specification & Support
3.1 Dimensions

20
www.CelcMagic.org 20
3.2 Specicaons
Electrical notes
Connecon to computer USB
Max load 60mA With ext. display
Lead length 1.2m
No of inputs 2x 3.5mm 4 oponal
Outputs 1x 3.5mm To external display
Input—push buons 2/4 x 3.5mm 4 is an opon
Sensor technology Magnec ux
Angular resoluon 0.5%
Mechanical
Ingress rang IP42
Suspension system magnec
Operang temperature 0C—30C
Storage Temperature -15C—40C
Operang force 5/10/16/20 grams user selectable
Movement angle +/- 6 degrees
Sip & Pu max +/-1psi
For the latest support informaon please visit the support
webpage or scan the QR code
www.celcmagic.org/feather-support
If the feather exhibits symptoms that indicate a recalibraon is
necessary such as creeping on its own or not achieving full output
then it is simple to recalibrate follow the short video on the same
webpage.
3.3 Support & Recalibraon
