JCM 800 2204
50W GUITAR AMPLIFIER
User’s Manual

!
!
2
Thank you for the purchase of your Ceriatone guitar amplifier!
Here, we hope to explain how best to use your new amp.
Table of Contents
1) About the 2204…….……….…………………………………………………………………………………………page 2
2) Quick setup……………………………………………………………………………………………………………page 3
3) Front Panel controls………………………………………………………………………………………………….page 4
4) Rear Panel controls…………………………………………………………………………………………………..page 6
5) Tube compliment and external bias jacks and adjustment………………………………………………………page 8
6) Frequently Asked Questions………………………………………………………………………………………...page 12
1) About the JCM800 2204 amplifier
Our British series of amplifiers has been overwhelmingly popular, and is still the backbone of our amplifier line. One of the most
popular models in this series is the JCM800 2203/2204.
This amplifier is based on the British amplifiers built in the late 1970s and 1980s.Their iconic sound is signature to countless
records, ranging from blues, to classic rock, fusion, and heavy metal. While their lineage is in the Plexi Super Lead amplifiers
of the late 1960s, the JCM800 2203/2204 provided a modern, updated perspective.
You’ll notice our version holds true sonically, but adds modern features including external bias measurement and adjustment,
an effects loop. It is worth noting we do not use a PCB for this amplifier, as was done on the original. Our construction method
employs handmade turret boards and wiring, as on the original Plexis of the 1960s.
Most of all, we hope the 2204 becomes an integral part of your tone equation to exhilarate your playing and music.
Rock on!
-Nik Azam

!
!
3
2) QUICK SETUP (for instant gratification)
1) Plug your guitar using a 1/4” instrument cable into the HIGH on the right of the front panel
2) Plug a suitable power cable from the 2204’s rear panel MAINS cable inlet to your wall power receptacle
3) Plug the 2204 into your speaker cabinet using 1/4” speaker cable
4) Set the IMPEDANCE SELECTOR to the match the impedance of your speaker cabinet
5) Set all rotary tone and gain controls on the front panel to 12:00 (clock face)
6) Set MASTER control at just above minimum
7) Set front panel POWER switch in the ON position (down position, with adjacent STANDBY switch in the “STANDBY”
mode) for 30 seconds to allow tube filaments to warm up
8) Set front panel STANDBY switch to “ON” mode (down position)
9) ROCK!!!!!!

!
!
4
3) FRONT PANEL CONTROLS
From left to right:
1) POWER 2-way toggle switch
2) STANDBY 2-way toggle switch
3) INDICATOR LED
4) PRESENCE control
5) BASS control
6) MIDDLE control
7) TREBLE control
8) MASTER VOLUME control
9) PREAMP VOLUME control
10)HIGH and LOW SENSITIVITY input ¼” instrument jack
POWER two-way toggle switch powers the 2204 on and off. With the toggle switch in the DOWN (“ON”) position, the 2204 is
on. In the UP position, the 2204 is OFF.
STANDBY applies high voltage to the vacuum tube anodes (and screen grids) during use of the 2204.To ensure long tube life,
first power the unit on with the STANDBY toggle switch in UP position for approximately 30 seconds. You can then switch to
DOWN (“ON”) to use the 2204. With the toggle switch in the UP position, the 2204 is in STANDBY mode. In the DOWN
position, the 2204 is in OPERATE mode

!
!
5
INDICATOR will illuminate when the 2204 is powered by turning the front panel POWER toggle switch to the ON position. If
INDICATOR does not turn on, check your power cable connections, and then the fuse on the rear of the unit.
PRESENCE adjusts the high frequency response of the power amplifier using negative feedback. Use this control to add
sparkle and clarity to your tone.
BASS adjusts low frequencies
MIDRANGE adjusts the mid frequency response
TREBLE adjusts the high frequency response
MASTER VOLUME sets the overall volume
PREAMP GAIN adjusts the amount of distortion in the amplifier
HIGH and LOW SENSITIVITY INPUT is a ¼” jack for instrument cables. Plug your guitar in here. Use the HIGH SENSITIVITY
input for more gain and the traditional JCM 800 sound. Plug in the LOW SENSITIVITY jack for a clean, brighter, and thinner
tone. We recommend using the HIGH SENSITIVITY input.

!
!
6
4) REAR PANEL CONTROLS
1) SEND ¼” instrument jack
2) RETURN ¼” instrument jack
3) IMPEDANCE SELECTOR three-way rotary selector
4) SPEAKERS ¼” speaker jacks (x2)
5) BIAS TEST probe jacks (x2)
6) COM probe jack
7) FULL / HALF 2-way toggle switch
8) HT FUSE
9) MAINS FUSE
10)MAINS IEC cable inlet
SEND ¼” instrument jack can be used to directly interface the preamps of the JCM800, thereby bypassing the power amplifier.
Conversely, this is usually used as the SEND of the effects loop. Plug the input of your effects unit, or interface device (ex – C-
lator, Klein-ulator) into this jack using ¼” instrument cable.
RETURN ¼” instrument jack can be used to directly interface the power amp of the JCM800, thereby bypassing the preamp
and using the amplifier as a power amplifier. Conversely, this is usually used as the RETURN of the effects loop. Plug the
output of your effects unit, or interface device (ex – C-lator, Klein-ulator) into this jack using ¼” instrument cable.

!
!
7
IMPEDANCE SELECTOR three-way rotary selector. Set to the position that matches the impedance of your speaker cabinet.
NOTE – if you are using two speaker cabinets in parallel (ex – two 16 Ohm cabinets), set the impedance selector to half that of
a single cabinet (in this case, 8 Ohms).
SPEAKERS ¼” speaker cable jacks. Use a ¼” speaker cable to connect your speaker cabinet to the amplifier using these
jacks. If you use one speaker cabinet, either jack is acceptable.
NOTE – never turn your amplifier to OPERATE mode (“1” / DOWN position on STANDBY) without connecting the amplifier to a
speaker cabinet or suitable dummy load! Failing to do so may damage your amplifier!
FULL / HALF switches the power output of the power amp. For the 100W JCM800, half mode is approximately 50W, and for
the 50W JCM800, this is approximately 20W. HALF mode configures the power tubes to run in triode operation, and this
negates any need to reconfigure the IMPEDANCE SELECTOR.
BIAS TEST and COM multimeter probe jacks – use this for external bias current measurements (see Section 5, Page 8)
HT FUSE T500mA fuse – used to protect your amplifier from voltage spikes or excessive current draw. Replace only when
necessary.
MAINS FUSE slow-blow fuse – used to protect your amplifier from voltage spikes or excessive current draw. Replace only
when necessary. 3A is used for amplifiers used with a 120VAC country supply, and 2A is used with 240VAC.
MAINS IEC cable inlet – plug a suitable IEC power cable into this inlet to power your amplifier

!
!
8
5) TUBE COMPLIMENT AND EXTERNAL BIAS JACKS AND ADJUSTMENT
From left to right:
V1 – JJ 12AX7/ECC83S(input stage 1 and gain stage 2)
V2 – JJ 12AX7/ECC83S(gain stage 3 and tonestack driver)
V3 – JJ 12AX7/ECC83S(phase inverter for power amplifier)
V4 – JJ E34L
V5 – JJ E34L

!
!
9
In this diagram, we have color coded features for simplicity
1) Blue arrow – bias adjustment potentiometer
2) Green arrow = bias probe jacks (left = V4, right = V5)
3) Red arrow = black probe jack, ground (“COM”)

!
!
10
To measure your power tube bias, carefully follow these steps with the amplifier in OPERATE and connected to a speaker
load (not doing so may damage your amplifier!):
1) Turn on a digital multimeter (DMM), and set it to read millivolts (mV) in the 100mV range (this will vary from DMM to
DMM)
2) Plug a black probe into the color-coded jack on your DMM, and do the same for a red probe
3) Insert the black probe tip into the black probe jack (red arrow). This is GROUND in the amplifier.
4) Insert the red probe tip into the V4 red probe jack (green arrow) on the left. This measures bias for V4.Write down your
measurement
5) Repeat step 4 for V5 (red probe jack on the right). Write down your measurement
6) Adjust bias adjustment (blue arrow) SLOWLY until your DMM reads approximately 36mV (see calculations, following
page)
7) Remeasure V4 bias, and adjust as needed
To calculate bias, there are two pieces of information you need to know: your amplifier’s power tube plate voltage, and the
published value for maximum plate dissipation for the power tubes used in your amplifier. To save you some time and energy,
here are those two values:
-Approximate V4-5 plate voltage for Plexi 50W series amplifiers = 420-435VDC
-Maximum plate dissipation for EL34s = 25W
…and now some math. The formula for calculating bias is as follows:
𝑚𝑎𝑥𝑖𝑚𝑢𝑚 𝑝𝑙𝑎𝑡𝑒 𝑑𝑖𝑠𝑠𝑖𝑝𝑎𝑡𝑖𝑜𝑛
𝑎𝑚𝑝𝑙𝑖𝑓𝑖𝑒𝑟 𝑝𝑙𝑎𝑡𝑒 𝑣𝑜𝑙𝑡𝑎𝑔𝑒 ×𝑝𝑒𝑟𝑐𝑒𝑛𝑡 𝑜𝑓 𝑚𝑎𝑥𝑖𝑚𝑢𝑚 𝑑𝑖𝑠𝑠𝑖𝑝𝑎𝑡𝑖𝑜𝑛×1000 =𝑏𝑖𝑎𝑠 𝑐𝑢𝑟𝑟𝑒𝑛𝑡 (𝑚𝐴)
In most cases, amplifiers are biased between 50% and 75% dissipation. We bias the 50W Plexi series amplifier to
approximately 35-37mV on a DMM, which is 65% dissipation.

!
!
11
An example is as follows:
25𝑊
430𝑉𝐷𝐶 ×65%×1000 =𝑎𝑏𝑜𝑢𝑡 35 −37𝑚𝐴
You might wonder why your DMM is set to millivolts and not milliamps – simply, we have a 1 Ohm resistor placed between your
probe jacks and ground to convert a current reading to a voltage reading. That way, a bias current of 36mA measures as 36mV
on your DMM.
NOTE – Only set your DMM to mV for measuring bias on the amplifier. Not doing so may damage your DMM.
A FEW COMMENTS ON BIASING
Due to the nature of vacuum tube amplification, there are inherent risks when biasing your amplifier. Extremely high-voltages
are present, and vacuum tubes reach high temperatures during use.
The risk of electrical shock and/or skin burns should ALWAYS be kept in mind. Therefore, bias at your own risk, and only while
paying attention and taking all precautionary measures.
Biasing should only be done on a clean workbench with no distractions. Do not wear loose clothing or any jewelry. Take your
time, and think carefully before each step.
Even though the bias test points and adjustment is external to reduce risk of electrical shock, all precautions must be taken
while biasing.
Again, bias at your own risk. Ceriatone Amplification is not responsible for any damages or injuries resulting from user biasing.

!
!
12
8) FREQUENTLY ASKED QUESTIONS
How do I hook up this thing?
-See Section 2, beginning on page 3.
Is the FX loop series or parallel? Active or parallel?
-The FX loop is series, and is currently parallel. However, we have plans to release an option for a tonally
transparent solid-state FX loop. Stay tuned!
When I plug effects into the effects loop, my tone noticeably changes. Sometimes the effects don’t sound quite right. What’s
the deal?
-Generally, what you’re hearing is a significant mismatching of impedances, and/or an overloading of the effect
unit itself. Most rack-mount units have different input impedance than pedals, and thus can sometimes
function fine without a buffer before them. In addition, some of these rack-mounted effects can pad the
volume they receive, preventing it from overloading. Pedals do not have proper input impedance or padding
ability, and therefore do not play nicely.
-For best results, an effects loop interface like the C-lator or Klein-ulator should be used. These units prevent
impedance mismatching, as well as provide the ability to pad down the volume sent to the effects units hence
preventing any overloading.
Can I substitute different tube types for the 12AX7/ECC83s or 6L6GCs?
-Although you can try 12AT7s, 12AU7s, 5751s without any harm, the design is optimized for 12AX7s, and are
therefore the only recommended tube in the preamp positions. Usage of other power tubes (ex – 6550s,

!
!
13
6L6GCs, modern 6V6s like Electro-Harmonix, JJ) may be possible, but please first consult Ceriatone
Amplification or your local competent amplifier technician.
Do I need to use a matched and balanced phase inverter?
-It is not necessary. Feel free to experiment with different tubes (of the same type) in your Chupacabra,
though!
I’ve read that the components used in this type of amplifier are really important. What is inside my amplifier?
-We use a combination of parts custom-made for us to our specifications (power transformer, output
transformer, choke, high-temperature / low-ESR electrolytic capacitors) and those used in our British series
(1/2W carbon composition resistors, 1W carbon film resistors, TAD Mustard capacitors, high-voltage silver
mica capacitors, Belton tube sockets, and Alpha potentiometers, Cliff jacks). Finally, we occasionally use
NOS components from our vast surplus parts collection in locations they work well and complement the
voicing or enhance the performance of the amplifier.
I like to use rack-mounted multieffects units. What is the output level straight from the EFFECTS LOOP SEND jack, -10dB or
+4dB?
-While not exact, -10dB is a better approximation than +4dB. The actual output level will depend on your
settings, particularly the volume controls. +4dB is usually reserved for recording/P.A. equipment with
balanced connections.
