Certikin Affinity Stellar User manual

Instruction Manual
Affinity Stellar
Beauty/Tattoo Chair
AFSTELLAR/BLK or AFSTELLAR/W

Table of Contents
1. Specifications
2. User Instructions
3. Upholstery Care
4. Maintenance & Safety

Specifications
Removable Head
Pillow/Breathe Hole
Bung Backrest Hand Lever
Leg Rest Hand Lever
Removable Arm Rests
Leg Rest Hand Lever
Seat Angle Adjuster
Lever
Weighted Base
Pull Out Leg Extenders
Continued …
Hydraulic height
adjust assembly
Adjustable Feet

Height Adjustment: 24” (61cm) to 30.5” (77cm)
Weight (approx.): 50Kgs
Set up Dimensions:
Length (flat): 74-76” (188-193cm), Length (seated): 56” (142cm).
Width: 24.5″ (62cm), Width (with arm rests) 33.5” (85cm)
Materials: Steel, 4″ Semi firm Therafoam padding, PU
Lifting Capacity: 200kgs (31.5 stones)
Warranty: 2 years
Includes: Adjustable foot extenders, removable side arm rests, removable
pillow/plug.
Colour: Black White
Shipping W&Ds (approx): L 130cm x W70cm x H80cm (not incl. pallet), Gross weight: 52kg
Specifications

Instructions
How to adjust the height:
The chair height can be easily adjusted using the foot pedal.
Gentle presses, in quick succession, on the foot pedal will engage the hydraulics and raise the
chair.
To lower the chair, press down on the pedal and hold for a moment. The chair will slowly
lower.
How to rotate the chair:
The chair top can be rotated through 360°
Once in desired position, lift the foot pedal to lock the top into place.

Instructions
How to tilt the seat:
For added comfort and positioning options, the
couch top/seat can be adjusted up and down
through 15°.
To operate, lift the seat angle adjuster lever.
With the lever depressed, gently push down or pull
up the head end of the seat until you have the
Required angle.
How to lower and raise the leg sections:
Each leg can be independently positioned.
To operate, pull the lever towards the cushion pad and gently
raise or lower to the desired position. To lock into place, remove
your hand from the lever.

How to extend the leg sections:
Instructions
How to insert/remove the arm rest:
With a hand at either end, gently guide
the prongs into/out of the locator holes
in the side of the chair.
With a hand at either edge of the foot
panel, gently pull it towards you until
you have reached the desired position.
To return to original position, gently
push the extension back towards the
chair.
Accessing the breathe hole:
The breathe hole can be found
underneath the head cushion. To
access the breathe hole, simply lift the
cushion.
Balancing the chair:
Although we don’t recommend using
on an uneven surface, the 4 feet each
has a small amount of adjustment for
balancing. Simply turn the foot in a
clockwise direction to allow a couple of
mm adjustment.

Upholstery Care
It is a known fact that upholstery will deteriorate over time. A good care routine will help
you get the best out of your chair for the longest period.
Here are our tips to help safeguard against premature ageing:
•Avoid storing your chair in extreme cold temperatures as excessive coldness will cause
cracking.
•Avoid storing or using your chair in or near extreme heat. The heat from heaters,
electrical appliances or direct sunlight can cause the fabric to stretch and pucker, and
eventually start to peel.
•If you are using sharp objects during your practice, such as needles, make sure you have
a protective layer over the table. Laying a towel or blanket over your chair can help
prevent any scratching or puncturing of the upholstery.
•As the oils found naturally on our skin can upholstery to breakdown, it is important that
you clean your upholstery fabric every day using a mild detergent (avoiding anti bacs
and citrus). This will help to protect against oil stains and dirtiness which will cause
cracking and permanent stains over time. Common practise is to mix a little detergent
with warm water in a spray bottle. Spray the mixture onto the table and gently wipe
over with a soft cloth. Rinse and pat dry. Take care to include face cradle cushions,
carry handles and inside the breathe hole as well as the main couch surface.
CAUTION:
•Due to the drying nature of alcohol, wiping upholstery with alcohol can dry out the vinyl
and cause it to crack. Aromatherapy oils and natural body oils can also be very
aggressive in nature and attack the upholstery.
Upholstery Care:

Please read this instruction manual before operating this product.
Follow these safeguards to ensure proper use of the equipment and to help
prevent injury and material damage.
Please check the padding and upholstery when unpacking the chair. Do not use if
there is any sign of damage. Our warranty does not cover the damages caused by
improper set-up, accident or abuse.
Use this equipment only for its intended purpose or as described in this manual.
Do not expose the equipment to extreme temperature or humidity.
The chair cannot be fully rotated with the leg sections fully down as they will not
clear the base.
To protect the hydraulic system, when not in use, the chair should be placed in the
lowest position.
Do not sit directly on the head or feet end of chair or armrest.
We recommend checking all moving parts on a regular basis.
In the case of safety-relevant signs of wear contact your original retailer.
Unauthorised modification or alteration of this couch is prohibited and will void
the warranty.
Safety/Maintenance
Safety/Maintenance:

Thank you for choosing Affinity.
Every care has been taken to ensure that this
product reaches you in excellent working
condition.
Should you have any questions or concerns
please refer back to your original supplier who
will be happy to assist.
Affinity TM
Certikin International Ltd, Unit 4, Tungsten Park, Colletts Way, Witney, Oxon, OX29 0AX
www.affinityequipment.co.uk
