MDB Family 5954 Installation and operating instructions

Changer / Chest (5954) - Assembly and Operation Manual
Congratulations on purchasing an MDB Family product. This product will provide many years of service
if you adhere to the following guidelines for assembly, maintenance and operation. This product is for
residential use only. Any institutional use is strictly prohibited.
Please be sure to follow the instructions for proper assembly. Use a Phillips head screwdriver for
assembling the product in addition to the Allen wrench included in the hardware box. Do not use power
screwdrivers. All of our products are made from natural woods. Please understand that natural woods
have color variations which are the result of nature and not defects in workmanship.
DO NOT SUBSTITUTE PARTS. ALL MODELS HAVE THE SAME QUANTITY OF PARTS AND HARD-
WARE. YOUR MODEL MAY LOOK DIFFERENT FROM THE ONE ILLUSTRATED DUE TO STYLIS-
TIC VARIATIONS.
revised 26FEB2013 page 1

page 2
HARDWARE
PARTS
Tools Needed
(not included)
Phillips
screwdriver

STEP 1:
Install Left Panel Glides (H9) on Left Side Panel (A)
using Small Wood Screws (H6)
STEP 2:
Screw three Cam Bolts (H2) into Left Side Panel (A)
page 3

Step 3: Insert Cam Locks (H3) into Support Rails (E,F and G)
and into Cupboard Bottom (H)
Step 4: Insert five Cam Bolts into Right Side Panel (B)
Align dowel holes on F and G with appropriate pre-drilled
holes on Right Side Panel (B). Use Cam Locks (H3) to fasten.
Step 5: Align holes on Cupboard Bottom (H)
with Cam Locks (H3) on Right Side Panel (B).
Rotate Cam Locks (H3) on H to fasten.
Slide until flush with B.
H3 H3
H
H3 H3
page 4

Step 6: Screw two Cam Bolts (H2) into right side
of Middle Panel (C) after installing the Right Panel
Glides (H8) onto Middle Panel (C).
Align dowels on the bottom of C with pre-drilled
holes in the Center of F and G and
Cam Bolts (H2) on C with pre-drilled holes on H.
Rotate Cam Locks (H3) on H to fasten C.
Step 7: Align Top Back Support Rail (E)
into place with pre-drilled holes on Right
Side Panel (B).
Use Cam Bolt (H2) to tighten
Step 8: Align dowels on Left Side Panel (A) with pre-drilled
holes on E, F and G. Use Cam Locks (H3) to tighten
FE
G
F
G
H
B
C (left side up)
H6
H6
H6
H8
page 5

Step 12: Align dowels on Side Panels
(A and B) with pre-drilled holes on D.
Lower D onto assembled case piece.
Use Cam Bolts (H3) to tighten.
Place Metal Pegs (H12) into pre-drilled
holes on B and C. Lower Cupboard
Shelf (P) onto Metal Pegs.
B
C
page 6
A

Step 13: Align back panels (J and K) onto back of the assembled chifferobe.
Secure back panels with Small Wood Screws (H6).
page 7
DRAWER ASSEMBLY INSTRUCTIONS
14
14a 14b
R

page 8
14c
14d
14e
14f
FURNITURE ANTI-TIPPING KIT INSTALLATION
15
Serious or fatal crushing can occur when furniture tips over on
children. To help prevent tip-over, follow the steps below to
install this anti-tipping strap.
WARNING
Place heaviest item in the lowest drawers.
do not set TVs or other heavy objects on
top of this product.
Never allow children to climb or hang on
drawers, doors, or shelves.
Never open more than one drawer at a time.
(OR)
Do not defeat or remove the drawer interlock
system.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is permanent label. Do not attempt to remove!
Unless specifically designed to accommodate,
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
X 2
X 1 X 1
X 1

Locate a 2” x 4” stud behind the
wall, and make a mark.
15a
15b
Install the strap on the wall with
long screw and washer.
15c
Install the other end of strap on
the back of dresser with short
screw and washer into the wood
framing of the dresser.
2” x 4” wall stud
page 9
Phillips
screwdriver
Tools Needed (not included)
Pencil
Stubby
Screwdriver

KEEP THIS MANUAL IN A SAFE
PLACE FOR FUTURE REFERENCE.
READ ALL INSTRUCTIONS BEFORE USING THE
PRODUCT. KEEP THE INSTRUCTIONS FOR
FUTURE USE.
Finish
