Cerwin-Vega hed Series User manual

SUBWOOFER CONNECTION
Wire the subwoofer terminal per the wiring diagram. Use minimum of 16 ga. wire
(14 gauge is preferable) between the enclosure terminal and the amplifier. When
wiring the subwoofer up to your system pay close attention to the polarity of the
terminals on the enclosure. Make certain they correspond to the polarity of the
subwoofer amplifier used
4
4
AMPLIFIER 250-500 WRMS
SUBWOOFER PLACEMENT
Placement is important as you need to develop “wavelength” to get the most bass output
from your NEW Cerwin Vega Mobile - loaded subwoofer enclosure. See drawing above.
NOTE: Make sure to secure the subwoofer enclosure as these woofers move a LOT of air and
the enclosure will bounce around under high output settings.
H6E10SV / H6E10DV
H6E12SV / H6E12DV
SUBWOOFER CONNECTIONS
ENCLOSURE TERMINAL
INSIDE
ENCLOSURE
ENCLOSUREMOUNTINGBRACKETS
(mountinghardwareincluded)

H6E10SV
H6E10DV
H6E12SV
H6E12DV
H6E10SV Single 10" inch Subwoofer
Nominal Impedance (Ohms) 2 Ω
Power Handling (Watts)
250 RMS / 1000 Max
Overall Dimensions
(HxWxD) 13” x 20” x 12”
(330mm x 508mm x 305mm)
H6E10SV Dual 10" inch Subwoofers
Nominal Impedance (Ohms) 2 Ω
Power Handling (Watts)
500 RMS / 2000 Max
Overall Dimensions
(HxWxD) 13” x 30” x 13”
(330mm x 762mm x 330mm)
H6E12SV Single 12" inch Subwoofer
Nominal Impedance (Ohms) 2 Ω
Power Handling (Watts)
250 RMS / 1000 Max
Overall Dimensions
(HxWxD) 15” x 21” x 14”
(381mm x 533mm x 357.9mm)
H6E12DV Dual 12" inch Subwoofers
Nominal Impedance (Ohms) 2 Ω
Power Handling (Watts)
500 RMS / 2400 Max
Overall Dimensions
(HxWxD) 15” x 34” x 15”
(381mm x 864mm x 381mm)
20” / 508mm 9” / 229mm
30” / 762mm
13” / 330mm
13”/330mm
12” / 305mm
9” / 229mm
13” / 330mm
21” / 533mm 8” / 203mm
34” / 864mm
14” / 357.9mm
12” / 305mm
15” / 381mm
15” / 381mm
15” / 381mm
H6E10SV / H6E10DV
H6E12SV / H6E12DV
