CHAINTECH 6OIA3T User manual

Declaration of Conformity
According to 47 CFR, Parts 2 and 15 of the FCC Rules
The following designated product:
EQUIPMENT: MAINBOARD
MODEL NO.: 6OIA3T
is a Class B digital device that complies with 47 CFR Parts 2 and 15 of the FCC Rules.
peration is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operation.
This declaration is given to the manufacturer:
CHAINTECH - EXCEL COMPUTER U.S., INC.
4427 Ente p ise ST. F emont, CA 94538, U.S.A.
hattp://www.chaintech-excel.com
Chaintech President: Simon Ho
Signature:

Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following two
conditions
!This device may not cause harmful interference
!This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy. If this equipment is not installed
and used in accordance with the manufacturer's instructions, it may cause harmful
interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures
!Reorient or relocate the receiving antenna.
!Increase the separation between the equipment and receiver.
!Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
!Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modifications to this unit not
expressly approved by the party responsible for compliance could void the user's authority
to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for audio noise emissions from
digital apparatuses set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Manufacturer's Disclaimer Statement
The information in this document is subject to change without notice and does not represent a
commitment on the part of the vendor. No warranty or representation, either expressed or implied,
is made with respect to the quality, accuracy or fitness for any particular purpose of this document.
The manufacturer reserves the right to make changes to the content of this document and/or the
products associated with it at any time without obligation to notify any person or organization of
such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental
or consequential damages arising out of the use or inability to use this product or documentation,
even if advised of the possibility of such damages. This document contains materials protected
by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted
in any form, by any means or for any purpose without expressed written consent of it's authors.
Product names appearing in this document are mentioned for identification purposes only. All
trademarks, product names or brand names appearing in this document are registered property
of their respective owners.
Printed in Taiwan August 2001August 2001
August 2001August 2001
August 2001
POST-CONSUMER
RECYCLED PAPER

Table of Contents
Chapter 1 Introduction ........................................................................ 1
1-1 Product Specifications ..........................................................1
1-2 Package Contents .................................................................3
1-3 Mainboard Layout ..................................................................4
1-4 Connector and Jumper eference Chart ..............................5
Chapter 2 Hardware Setup ...................................................................6
2-1 Installing a CPU in Socket 370 .............................................6
2-2 Setting Your CPU's Parameter...........................................6
2-3 Connector and Jumper Settings ...........................................7
2-4 Main Memory Configuration ................................................11
Chapter 3 Award BIOS Setup Program ........................................... 12
3-1 Standard CMOS Features ...................................................13
3-2 Advanced BIOS Features ...................................................15
3-3 Advanced Chipset Features ................................................18
3-4 Integrated Peripherals .........................................................19
3-5 Power Management Setup ..................................................21
3-6 PnP/PCI Configuration ........................................................24
3-7 PC Health Status.................................................................25
3-8 SeePU Setup .......................................................................25
3-9 Load Fail-Safe Defaults .......................................................26
3-10 Load Optimized Defaults .....................................................26
3-11 Supervisor Password & User Password Setting ................27
3-12 Save and Exit Setup ...........................................................27
3-13 Exit Without Saving .............................................................27
Appendix Embedded Flash Utility ...................................... 28
Feature ExplanationsFeature Explanations
Feature ExplanationsFeature Explanations
Feature Explanations
Software Power-off Control .............................................................7
Blinking LED in Suspend Mode ......................................................7
Poly-fuse Over Current Protection .................................................7
Over-ride Power Button...................................................................8
Power On By Modem .......................................................7/23
esume By Alarm .......................................................23
Wake Up By PCI Card .......................................................23
Wake Up On LAN ..........................................................................10

1
Introduction
+D=FJAH 
Introduction
1-1 Product Specifications
!!
!!
! Processor
- Supports Socket-370 processors
- Supports 66/100/133MHz system clock speeds
!!
!!
! Chipset
- Intel 815EP -Step+ICH2
!!
!!
! DRAM Memory
- Two 3.3V 168-pin DIMM sockets support up to 512M SDRAM
- Supports PC-100/133 SDRAM modules
!!
!!
! Expansion Slots
- One Universal-AGP slot for both 2X/4XAGP (v2.0 compliant)
- Three 32-bit PCI slots (Rev 2.2 compliant)
- One CNR slot for modem, audio and LAN support
!!
!!
! Boot-Block Flash ROM
- Award System IOS, supports PnP, APM, DMI, ACPI & Multi-device booting
features i.e. floppy, LS120, CD/DVD-ROM, HDD(IDE, SCSI), ZIP-ATAPI etc.
!!
!!
! Embedded ltra DMA-100 PCI IDE controller
- Supports two IDE ports up to 4 ATAPI devices
- Supports up to PIO Mode 4 up to 16.6M ps, Multi Mode 4 up to 66M ps
and Multi Word Mode 5 up to 100M ps with bus mastering
- us Mastering software drivers for common multi-task operating systems
!!
!!
! Onboard ltra I/O
- ITE 8712 LPC with system monitoring hardware
- Three UARTs support two serial ports and IR function for HPSIR and ASKIR
- One parallel supports SPP/ECP/EPP
- One floppy disk drive connector supports up to 2.88M , Japanese 3-Mode,
and 1Mbps transfer rates
!!
!!
! EmbeddedUSB Controller
- Four US ports (UHCI v1.0 compliant)
- Optional US riser with additional 2 US ports

2
Chapter 1
!!
!!
! Double Stack Back-Panel I/O Connectors
- PS/2 Mini-DIN keyboard and mouse port
- Two US ports
- One RJ45 port (optional)
- Two 9-pin D-Sub male Serial port
- One 25-pin D-Sub female Printer port
- Audio Line-in/out and Mic-in jacks
- One 15-pin D-Sub female Game/MIDI port
!!
!!
!
""
""
" Onboard PCI Audio Subsystem
- CMedia 8738 audio chip w/ legacy audio S 16/Pro compatible
- Full-duplex operation for simultaneous recording and playback
- Supports HRTF 3D positional audio with MSDS, DS3D, DirectMusic, Aureal
A3D and Creative EAX (Environment Audio Extensions), C3DX APIs
- 6-Channel speaker audio support
!!
!!
! Network Controller (optional)
- ICH2 Embedded Fast Ethernet controller with Intel 562EM
-10/100Mbit/sec Ethernet support
!!
!!
! EmbeddedSystem Monitor Hardware
- 8 external voltage inputs
- 2 temperature sensor with thermistor for CPU and System
- 2 Fan speed monitoring with ON/OFF control in suspend
!!
!!
! Board Dimensions
- Micro ATX form factor, 244mm x 215mm, 4 Layers

3
Introduction
1-2 Package Contents
This product comes with the following components:
!One mainboard
!One 40-pin (80-wire) UDMA-100 IDE connector ribbon cable (Figure 1-1)
* Color coded connection for DMA 100 cable
lue to mainboard, Gray to Master and lack to slave
!One 34-pin floppy disk drive ribbon cable (Figure 1-2)
!Optional US adaptor (Figure 1-3)
!One User's Manual
!One CD-ROM that includes
- Acrobat Reader
- Award Flash Utility
- Award DMI Utility for DOS
- Audio driver and utility
- Intel LAN driver for Win9x/Win2000/WinNT(optional)
- Intel Service Pack for Win9x/Win2000/WinNT including us Master IDE
drivers, AGP VxD and etc.
- Optional Value Pack 2001 software group including Norton AntiVirus, AutoSave,
ADO E ActiveShare, Acrobat Reader, Imagemore, X-stop, Appio and Ewalla.
See the Readme.txt file in the CD-ROM's root directory for installation
instructions of all driver and software utilities.
Figure 1-2 Standard Floppy cable
Figure 1-1 UDMA 66/100 IDE cable
USB4
USB3
JP1
Figure 1-1 Optional US Adaptor
#

4
Chapter 1
1-3 Mainboard Layout
Line-in MIC
CN2,CN3,CN4A,CN4B
CN7,JP8,IR2
JP5,JP6,FAN1
PS/2 Mouse Printer Port Game PortRJ45(Optional)
PS/2 Keyboard
SB 1/2
Line-out
COM1
CN1,CN5,CN6,CN10,JP1
COM2
FAN2

5
Introduction
1-4 Connector and Jumper Reference C art
Jumper &
C
onnector No. Function Page
JP1 Clear CMOS Data Jumper 9
JP5 Power-on Keyboard 9
JP6 Power On By USB 9
JP8 Onboard udio 9
CN1
Over-ride power button Connector 8
Power indicator LED Connector 8
System reset switch Connector 8
Speaker Connector 8
Green switch Connector 8
IDE activity LED Connector 8
CN2 CD-ROM udio in Connector 9
CN3 uxiliary udio-in Connector 9
CN4 Front Panel udio Connector 10
CN4B Bass/Center Speaker Connector 10
CN5 WOL (Wake-on-L N) Connector 10
USB1/CN6 USB 1/2 Ports and USB 3/4 Connector 10
CN7 Smart Card Reader Connector 10
IR1 IR/CIR Connector 10
F N1/F N2 CPU/System Cooling Fan Connectors 11
PT1 PS/2 Mouse and Keyboard Ports 11
PW1 TX Power Supply Connector 7

Chapter 2
6
+D=FJAH
0=H@M=HA5AJKF
If your mainboard has already been installed in your computer you may still need
to refer to this chapter if you plan to upgrade your system's hardware.
2-1 Installing a CPU in a Socket 370
The Intel Socket 370, designed for the eleron/ oppermine processor, has been
incorporated as a standard mainboard specification To insert your PU into Socket
370 please do the following:
1. Locate a small dot marked on the top surface of the PU close to one if it's corners.
The same corner will also be cut off, leaving a noticeable notch in the PU's corner.
These markings indicate Pin 1 of the PU.
2. Pull up the lever of Socket 370 so that it is perpendicular with the surface of the
mainboard. Gently insert the PU with Pin 1 at the same corner of Socket 370
that contains the end of the lever. Allow the weight of the PU to push itself
into place. Do not apply extra pressure as doing so may result in damaging your
PU. Snap the lever back into place.
Installing a heat sink with cooling fan is necessary for proper heat dissipation
from your CPU. Failing to install these items may result in overheating and
possible burn-out of your CPU.
The use of a eatsink and Fan designed for the FC-PGA on a FC-PGA2 can cause
damage to the socket or motherboard and will void any warranty. The extra
thickness created by the I S will cause the eatsink and fan retention clip to
exert extra stress on the Socket, Processor or Motherboard.
2-2 Setting Your CPU's Parameter
This board support plug and play PU configuration, if you install a PU on this
mainboard, the board will automatically detect and set PU parameters. It is no longer
necessary to make many jumper settings as on conventional mainboards.
You can also manually configure your PU clock ratio according to your processor's
specifications by selecting a desire PU clock ratio at the SeePU Setup option in the
the CMOS Setup Utility (Section 3-8).
You do not need to make voltage settings because SeePU automatically sets
your CPU voltage.

Hardware Setup
7
2-3 Connector and Jumper Settings
onnectors are used to link the system board with other parts of the system, including
the power supply, the keyboard, and the various controllers on the front panel of
the system case.
The power supply connector is the last connection to be made while installing a
mainboard. Before connecting the power supply, please make sure it is not
connected to the power source.
ATX Power Supply Connector (PW1
The power cord leading from the system's power supply to the
external power source must be the very last part connected when
assembling a system.
The ATX power supply provides a single 20-pin connector
interface which incorporates standard +/-5V, +/-12V, optional 3.3V
and Soft-power signals. The Soft-power signal, a 5V trickle supply
is continuously supplied when A power is available. When the
system is in the Soft-Off mode, this trickle supply maintains the
system in it's minimum power state.
Software Power-Off Control
This mainboard can be powered down using theWindows 95 Software Power-Off
function. To power down your computer, click the START button on the Windows 95
task bar. Select "Shut Down The omputer" and the system turns off. The message "It
is now safe to turn off your computer" will not be shown when using this function.
Power-On By Modem
While in Soft-off state, if an external modem ring-up signal occurs, the system wakes up
and can be remotely accessed. You may enable this function in BIOS's Power
Management Setup menu. (See section 3-5)
Blinking LED in Suspend Mode
While in Suspend mode, the LED light on the front panel of your computer will flash.
Suspend mode is entered by pressing the Override Power Button, pushing the Green
button on your ATX case, or enabling the Power Management and Suspend Mode
options in BIOS's Power Management menu. (See section 3-5)
Poly-fuse Over Current Protection
The poly-fuse protects the system from dangerous voltages the system might be
exposed to via the keyboard or USB connectors. In case of such exposure, the poly-
fuse will immediately be disconnected from the circuit, just like a normal fuse. After
being disconnected for a certain period of time, the poly-fuse will return to its normal
state, after which the keyboard or USB can function properly again. Unlike
conventional fuses, the poly-fuse does not have to be replaced, relieving the user
wasted time and inconvenience.

Chapter 2
8
Front Panel Connector Set (CN1 A through F
A. Over-ride Power Button Connector
The power button on the ATX chassis can be used as a
normal power switch as well as a device to activate
Advanced Power Management Suspend mode. This mode
is used for saving electricity when the computer is not in use
for long periods of time. The Soft-OFF by PWR-BTTN
function in BIOS's Power Management Setup menu must be
set to "Delay 4 Sec." to activate this function.
When the Soft-OFF by PWR-BTTN function is enabled,
pushing the power button rapidly will switch the system to
Suspend mode. Any occurence of external activities such
as pressing a key on the keyboard or moving the mouse will
bring the system back to Full-On. Pushing the button while
in Full-On mode for more than 4 seconds will switch the
system completely off. See Over-ride Power Button
Operation diagram.
B. Power Indicator LED Connector
The power indicator LED shows the system's power status. It is important to
pay attention to the correct cables and pin orientation (i.e., not to reverse the order
of these two connectors.)
C. Green Switch Connector
Some ATX cases provide a Green switch which is used to put the system in
Suspend mode. In Suspend mode, the power supply to the system is reduced
to a trickle, the PU clock is stopped, and the PU core is in it's minimum power
state. The system is woken up whenever the keyboard or mouse is touched. The
system resumes in different ways as defined by Power Management Setup screen
in BIOS.
D. Syste Reset Switch Connector
This connector should be connected to the reset switch on the front panel of
the system case. The reset switch allows you to restart the system without turning
the power off.
E. Speaker Connector
This 4-pin connector connects to the case-mounted speaker
F. IDE Activity LED Connector
The IDE activity LED lights up whenever the system reads/writes to the IDE
devices.
Over-ride Power Button

Hardware Setup
9
L
1
R
GND
Clear CMOS Data (JP1
To clear the contents of the MOS, please follow the steps
below.
1. Disconnect the system power supply from the power source.
2. Set the jumper cap at location 2~3 for 5 seconds, then set it back
to the default position.
3. onnect the system's power and then start the system.
4. Enter BIOS's MOS Setup Utility and choose Load Setup
Defaults. Type Y and press enter.
5. Set the system configuration in the Standard MOS Setup
menu.
Power On By Keyboard (JP5
This board is able to be turned on by the PS/2 keyboard (hot
key). To use this function, select a hot key of your choice at
the PS2KB Wakeup option under Wake Up Events in the BIOS's
Power On Management screen. You must also set this jumper's
cap to pins 2-3 to use this function.
Power On By USB (JP6
This board is able to be turned on by a USB keyboard hot key
or a USB mouse click. To use this function, select a hot key
of your choice at the USB Resume From S3/S4/S5 option under
Wake Up Events in the BIOS's Power On Management screen.
You must also set this jumper's cap to pins 2-3 to use this
function.
Onboard Audio (JP8
This function allows you to enable and disable the on board
audio. You must set the jumper's cap to pins 1-2 to enable or
set pins 2-3 to disable this function.
CD-ROM Audio-in (CN2
Use the audio cable enclosed with your D-ROM disk drive to
connect the D-ROM to your mainboard. This will enable your
D-ROM's audio function.
Auxiliary Audio-in (CN3
This connector is for use with a secondary D-ROM, DVD-ROM
or DR/ DRW disk drive.




Pin Definition
1~2 Normal (default)
2~3 Clear CMOS Data




Pin Definition
1~2 Disable (default)
2~3 Enable




Pin Definition
1~2 Disable (default)
2~3 Enable




Pin Definition
1~2 Enable
2~3 Disable

Chapter 2
10
Front Panel Audio Connector (CN4A
This connector give you the option to choose between standard
audio jack rear panel) or use a an optional front panel audio
jack cable ext. to be plug into a special custom designed system
case. To use the standard audio jack short jumper caps to pin1-
2 and pin 3-4 Default). To use the front panel audio jack cable
ext., simply removed both jumper caps and plug into the audio
jack cable.
Bass/Center Speaker Connector (CN4B
This connector is for enter+Bass speaker output ext. Plug in
the optional A 3 Surround enter+Bass jack extension into this
connector. The black colored jack is for surround speaker output
and the orange colored jack is for center+bass speaker output.
WOL (Wake-on-LAN Connector (CN5
Enable the Wake Up On LAN selection in BIOS's Power
Management Menu to use this function. This header is used
to connect an add-in NI (Network Interface ard) which gives
WOL capability to the mainboard.
USB 1/2 Ports and USB 3/4Connector (USB1/CN6
If you want to use a USB Keyboard, you must enable the USB
keyboard support function in BIOS's Integrated Peripherals
menu (See Section 3-4). This board contains a USB Host controller
and includes a root hub with two USB 1/2 ports a connector for
optional USB Adaptor (USB 3/4).
Smart Card Reader Connector (CN7
This connector must be connected to a Smart card reader .
IR Connector (IR1
Select a UART Mode in BIOS's Integrated Peripherals menu the
UART port to support IR/ IR functions. (See section 3-4)
Rear
Panel
Front
Panel
Smart Card Reader (Optional)

Hardware Setup
11
CPU/System Cooling Fan Connectors (FAN1/FAN2
The board's management extension hardware is able to detect
the PU and system fan speed in rpm (revolutions per minute).
These connectors supports 3-pin cooling fans with minimum
of 4000 RPM. The wiring and plug may vary depending on the
manufacturer. On standard fans, the red is positive (+12V), the
black is ground, and the yellow wire is the rotation signal.
PS/2 Mouse and Keyboard Ports (PT1
If a PS/2 mouse is used, BIOS will automatically detect and assign
IRQ12 to the PS/2 mouse.
2-4 Main Memor Configuration
The DRAM memory system consists two banks and the memory size ranges from
32~512MBytes. If you only use one bank it does not matter which one you use and if
you use two or more banks, it does not matter which bank you install first.
DRAM Specifications
DIMM type: 3.3V, 64/72-bit Synchronous DRAM
Module size: Single/double-sided 32/64/128/256/512MBytes
DRAM speed: 7.5/10ns for Synchronous DRAM
Parity: Either parity or non-parity
This mainboard supports 3.3v, unbuffered, 4-clock, SDRAM DIMM only.
Buffered, 5V, or 2-clock SDRAM DIMMs should not be used.
Due to loading anomalies, using DIMM with an 'n x 4' DRAM base on this
mainboard is not recommended. For example, a DIMM that uses sixteen
16Mb x 4 devices should not be used.
Pin Definition
1Data
2No Connect
3Ground
4+5V (fused)
5Clock
6No Connect

User's Manual
12
Standard CMOS Features
Advanced BIOS Features
Advanced Chipset Features
Integreted Peripherals
Power Management Setup
PnP/PCI Configurations
PC Health Status
+D=FJAH !
!
Award BIOS Setup Program
Award's BIOS ROM has a built-in setup program that allows users to modify the basic
system configuration. his information is stored in CMOS RAM so that it can retain
the setup information, even when the power is turned off.
When you turn on or reboot the system, press the Delete key to enter the Award
BIOS setup program. he primary screen as shown in Figure 3-1 is a list of the menus
and functions available in the setup program. Select the desired item and press enter
to make changes. Operating commands are located at the bottom of this and all other
BIOS screens. When a field is highlighted, on-line help information is displayed on
the left bottom edge of the screen.
Select Item
Esc Quit
F10 Save & Exit Setup
Figure 3-1 Setup Program Initial Screen
SeePU Setup
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
Set User Password
Save & Exit Setup
Exit Without Saving
CMOS Setup Utility- Copyright (C) 1984-2001 Award Software
Time, Date, Hard Disk Type...

Award BIOS Setup Program
13
3-1 Standard CMOS Setup
he Standard CMOS Setup allows users to configure system components such as
hard disk drive, floppy disk drive and video display as well as date, time and boot-
up error signaling. his configuration menu should be changed when installing a
mainboard for the first time, changing hardware in your system such as the HDD,
FDD, video display, or when the CMOS data has been lost or contaminated. Choose
the Standard CMOS Setup option from the CMOS Setup Utility menu (Figure 3-1)
to display the following screen. When a field is highlighted, on-line help information
is displayed on the left bottom edge of the screen.
Date/Time
Set the date and time. Do not skip this function as all of your timed events such
as power management, saving files, etc. are based on this timer.
Hard Disk Setup (Primary/Secondary; Master/Slave)
his category identifies up to four IDE hard disk drives that have been installed in
the computer. his section does not show information on other IDE devices such
as CD-ROM drives or other hard drive types such as SCSI drives.
CMOS Setup Utility- Copyright (C) 1984-2001 Award Software
Sta dard CMOS Features
Item Help
Menu Level
Date (mm dd yy) Mon, July. 23, 2001
Time (hh mm ss) 17 14 44
IDE Primary Master None
IDE Primary Slave None
IDE Secondary Master None
IDE Secondary Slave None
Drive A 1.44M, 3.5 in.
Drive B None
Floppy 3 Mode Support Disabled
Video EGA/VGA
Halt On All Errors
Base Memory 640K
Extended Memory 30720K
Total Memory 31744K
Figure 3-2 Standard CMOS Features Screen
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F :Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

User's Manual
14
Floppy Disk Drives
Choose the memory capacity and disk size that corresponds with that of your floppy
disk drive(s).
Video
Select the type of video adapter present in your system. You can ignore this setting
if you are using a VGA monitor since VGA BIOS automatically configures this setting.
Halt
When the system is powered on, BIOS performs a series of diagnotic tests called
POS (Power On Self est). his function stops the computer if BIOS detects a
hardware error. You can tell BIOS to halt on all errors, no errors, or not to halt on
specific errors.

Award BIOS Setup Program
15
Item Help
Menu Level
Figure 3-3 Advanced BIOS Features Screen
CMOS Setup Utility- Copyright (C) 1984-2001 Award Software
Adva ced BIOS Features
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F :Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
3-2 Advanced BIOS Features
By choosing the Advanced BIOS Features option from the Standard CMOS Features
menu (Figure 3-1), the screen below is displayed. his sample screen contains the
manufacturer's default values for the mainboard.
A. Anti-Virus Protection
Trend +DEF)M=OVirus
rend ChipAway Virus is a code incorporated in the mainboard's BIOS firmware.
During the boot-up sequence, BIOS loads before loading of the partition table
or boot sector. ChipAway Virus loads with BIOS and is able to detect boot-up
viruses before they have a chance to infect the hard drive. ChipAway Virus
employs rule-based logic that doesn't look for specific viruses but rather detects
patterns found in every virus, eliminating the need to perform periodical version
updates after new viruses have been found.
Anti-Virus Protection
CPU Internal Cache
External Cache
CPU L2 Cache ECC Checking
Processor Number Feature
Quiet Post
Quick Po er On Self Test
First Boot Device
Second Boot Device
Third Boot Device
Boot Other Device
S ap Floppy Drive
Boot Up Floppy Seek
Boot Up NumLock Status
Gate A20 Option
Typematic Rate Setting
x Typematic Rate (Chars/Sec)
x Typematic Delay (Msec)
Security Option
Disabled
Enabled
Enabled
Enabled
Enabled
Disabled
Enabled
Floppy
HDD-0
LS120
Enabled
Disabled
Enabled
On
Fast
Disabled
6
250
Setup

User's Manual
16
B. CPU Internal and External Cache
Cache memory is much faster than conventional DRAM system memory. hese
fields allow you to enable or disable the CPUs Level 1 built-in cache and Level
2 external cache. Both settings are left enabled to significantly increase the
performance of your computer.
C. Processor Number Feature
If you have Pentium III processor installed on the mainboard. Enable this option
allows the serial code inside the Pentium III processor to be published on certain
application.
D. Boot Up Features
After turning on the system, BIOS will perform a series of device initializations
and diagnostic tests discussed below.
uick Power On Self Test (POST)
Enable this function to reduce the amount of time required to run the POS (Power
On Self est). BIOS saves time by skipping some items during POS . It is
recommended that you disable this setting. Discovering a problem during bootup
is better than loosing data during your work.
First/Second/Third/Boot Other Device
his option sets the sequence of drives BIOS attempts to boot from after POS
completes. BIOS will search these drives for an operating system.
Swap Floppy Drive
Enabling this function will swap the floppy drive assignment so that drive A will
function as drive B, and drive B will function as drive A. Note that the boot
sequence assignment mentioned directly above does not inlcude booting from
floppy drive B. his function is useful if floppy drives B and A are of a different
format and you want to boot from floppy drive B.
Boot up Floppy Seek
During POS , BIOS will determine if the installed floppy disk drive has 40 or 80
tracks. A 360K drive has 40 tracks and 720K, 1.2M and 1.44M drives have 80 tracks.
All modern floppy disk drives have 80 tracks.
Boot Up NumLock Status
his function defines the keyboard's numberpad as number keys or arrow keys.
E. ate A 20 Option
Gate A20 refers to the way the system addresses memory above 1 MB (extended
memory). When set to Fast, the system chipset controls Gate A20. When set to
Normal, a pin in the keyboard controller controls Gate A20. Setting Gate A20 to
Fast improves system speed, particularly with OS/2 and Windows.

Award BIOS Setup Program
17
F. Keyboard Interface
Typematic Rate Setting
When enabled, you can set the following two typematic control items. When
disabled, keystrokes are determined arbitrarily by the keyboard controller in your
system.
Typematic Rate (Chars/Sec)
he typematic rate sets the rate at which characters on the screen repeat when
a key is pressed and held down.
Typematic Delay (Msec)
he typematic delay sets how long after you press a key that a character begins
repeating.
. Security Option
he Supervisor and/or User Password functions shown in Figure 3-1 must be set
to take advantage of this function. See Section 3-11 for password setting
information. When the Security Option is set to System, a password must be
entered to boot the system or enter the BIOS setup program. When the Security
Option is set to Setup, a password is required to enter the BIOS setup program.
H. OS Select (For DRAM > 64MB)
If your system's DRAM is larger than 64MB and you are running OS/2, select
OS/2 as the item value. Otherwise, set the item value to Non-OS/2 for all other
operating systems.
