CHAINTECH V915P User manual

CHAINTECH
V915P
Intel 915P&ICH6
ATX Motherboard
Reference Manual

DeclarationofConformity
Accordingto47 CFR,Parts2and15oftheFCCRules
Thefollowingdesignatedproduct:
EQUIPMENT:MAINBOARD
MODELNO.: V915P
isaClass Bdigitaldevice thatcomplieswith47 CFRParts2and15oftheFCC
Rules.Operationissubjecttothefollowingtwoconditions:
1.Thisdevice maynotcauseharmfulinterference.
2.Thisdevice mustaccept anyinterferencereceived,includinginterference that
maycauseundesiredoperation.
Thisdeclarationisgiventothemanufacturer:
CHAINTECH-EXCELCOMPUTERINC.
4427EnterpriseSt.Fremont,CA94538,U.S.A.
http://www.chaintechusa.com
ChaintechPresident:Simon Ho
Signature:

Federal CommunicationsCommissionStatement
ThisdevicecomplieswithFCCRulesPart15.Operation issubjecttothefollowingtwo conditions:
*Thisdevicemaynotcauseharmfulinterference.
*Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.
Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora ClassBdigitaldevice,pursuantto
Part15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection againstharmfulinterferenceina
residentialinstallation. Thisequipmentgenerates,uses,andcan radiateradiofrequencyenergy.Ifthisequipmentisnot
installedandusedinaccordancewiththemanufacturer'sinstructions,itmaycauseharmfulinterferencetoradio
communications.However,thereisno guaranteethatinterferencewill notoccurinaparticularinstallation.Ifthis
equipmentdoescauseharmfulinterferencetoradioortelevisionreception, whichcan bedeterminedbyturningthe
equipmentoffandon, theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing
measures:
*Reorientorrelocatethereceivingantenna.
*Increasetheseparationbetweentheequipmentandreceiver.
*Connecttheequipmenttoanoutleton a circuitdifferentfrom thattowhichthereceiverisconnected.
*Consultthedealeroran experiencedradio/TVtechnician forhelp.
Theuseofshieldedcablesforconnection ofthemonitortothegraphicscardisrequiredtoassurecompliance
withFCCregulations.Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatethisequipment.
CanadianDepartmentofCommunicationsStatement
ThisdigitalapparatusdoesnotexceedtheClassBlimitsforaudionoise emissionsfromdigitalapparatusesset
outintheRadioInterferenceRegulationsoftheCanadianDepartmentofCommunications.
Manufacturer'sDisclaimerStatement
Theinformation inthisdocumentissubjecttochangewithoutnoticeanddoesnotrepresenta commitmenton
thepartofthevendor.Nowarrantyorrepresentation, eitherexpressedorimplied,ismadewithrespecttothequality,
accuracyorfitnessforanyparticularpurposeofthisdocument.Themanufacturerreservestherighttomake changes
tothecontentofthisdocumentand/ortheproductsassociatedwithitatanytimewithoutobligationtonotifyany
person ororganization ofsuchchanges.Inno eventwillthemanufacturerbeliablefordirect,indirect,special,
incidentalorconsequentialdamagesarisingoutoftheuseorinabilitytousethisproductordocumentation, evenif
advisedofthepossibilityofsuchdamages.Thisdocumentcontainsmaterialsprotectedbycopyright.Allrightsare
reserved.No partofthismanualmaybereproducedortransmittedinanyform,byanymeansorforanypurpose
withoutexpressedwrittenconsentofit'sauthors.Productnamesappearinginthisdocumentarementionedfor
identificationpurposesonly.Alltrademarks,productnamesorbrandnames appearinginthisdocumentareregistered
propertyoftheirrespective owners.
PrintedinTaiwan.
Mar2004
OST-CONSUMER
RECYCLED PAPER
100%

SPECIFICATIONS..................................................................................................1
INTRODUCTION....................................................................................................4
PICK THE BEST .......................................................................................................4
HARDWARESETUP..............................................................................................9
INSTALLING COOLING FAN.....................................................................................10
INSTALLING MEMORY............................................................................................11
STORAGE CONFIGURATION ....................................................................................12
FRONT PANEL CONFIGURATION..............................................................................13
REAR PANEL CONFIGURATION ...............................................................................14
AUDIO CONNECTORS.............................................................................................17
SLOTS...................................................................................................................18
POWER SUPPLY ATTACHMENTS ..............................................................................19
BIOSSETTINGS...................................................................................................20
ZEROSANDONES ..................................................................................................20
MAIN....................................................................................................................20
ADVANCED ...........................................................................................................22
PERIPHERALS ........................................................................................................31
POWER..................................................................................................................37
HWMONITOR ......................................................................................................41
DEFAULTS .............................................................................................................42
EXIT .....................................................................................................................43
機板 BIOS 系統設定.........................................................................................44
介.....................................................................................................................44
按鍵功能 .............................................................................................................44
主選單(MAIN MENU)...........................................................................................45
進階功能設定(ADVANCED)..................................................................................45
整合週邊系統設定(INTEGRATED PERIPHERALS)...................................................45
電源管理設定(POWER MANAGEMENT)................................................................46
電腦硬體監控功能(HARDWARE MONITORING).....................................................46
載入預設值(LOAD DEFAULTS)..............................................................................46
退出選單(EXIT MENU).........................................................................................46
BIOS 정..............................................................................................................48
인화면 .............................................................................................................48
ADVANCED ...........................................................................................................51
PERIPHERALS ........................................................................................................63

POWER..................................................................................................................71
HWMONITOR ......................................................................................................76
DEFAULTS .............................................................................................................77
EXIT .....................................................................................................................78
BIOSSETTINGS...................................................................................................79
DES ZEROSETDESUNS..........................................................................................79
MENU PRINCIPAL ..................................................................................................79
AVANCE ................................................................................................................81
PERIPHERALS (PERIPHERIQUES).............................................................................91
POWER..................................................................................................................97
HWMONITOR ....................................................................................................101
DEFAULTS ...........................................................................................................102
EXIT ...................................................................................................................103
SOFTWARE.........................................................................................................104
NOTE....................................................................................................................106
HOWTOCONTACTCHAINTECH..................................................................107

1
Specifications
CPU:
Supports Socket775 Pentium®4Prescottprocessor
Supports Hyper-ThreadingTechnology
533/800 MHzFSB(FrontSideBus)frequencies
Chipset:
NorthbridgeChipset–Intel®915P
SouthbridgeChipset–Intel®ICH6
I/OController–WinbondW83627THF
HDAduioCodec –RealtekALC880
GbLAN Controller–Marvell®MV8001
DRAMMemory:
Uses eitherDDR400 (PC3200)orDDR333(PC2700)SDRAM
SDRAMmodulesmustbeunbufferedandnon-ECC
Supportedmemorymoduleincrements are256 MB/512 MB/1GB
Totalmemorycapacityis 4GB(see MemoryInstallationsectionformore
details)
Supports Dual-Channeldatabus
PCI-Express BUSSlots:
Provides 1x16 PCIExpress slotwith4GB/s bandwidth(eachdirection)
Provides2x1PCIExpress slotswith250 MB/sbandwidth(each
direction)
AllPCIExpress slots arefullyPCIExpress1.0acompliant
PCI BUSSlots:
Provides 3PCIslots
Contains 33MHz, 32bitPCIinterface, PCI2.3is compliant

2
UniversalSerialBus:
Supports upto8USBports forUSBcompliantinterface devices
SupportsUSB2.0EnhancedHostControllerInterface (EHCI) andUSB
1.1UniversalHostControllerInterface (UHCI)
OnboardIDEController:
Supports UltraATA66/100, DMAandPIOmodes
Supports IDEinterface withCD-ROM
Supports highcapacityharddiskdrives
IDEslotcansupport2IDEdrives
OnboardSATABus:
4SATAIDEslots
SATA1.0compatible
Supports 150 MB/s transferrates
HardwareMonitorFunction:
Monitors CPUFAN/CHASFAN/AUXFANSpeeds
Monitors systemVoltage
HDAudioSoundCodec Onboard:
HDAudio(HighDefinitionAudio)protocolcompliance
CompliantwithAzaliaspecifications
8-channelplaybackcapability
Supports Sony/Philips DigitalInterfaces (S/PDIF)
LAN Controller:
MarvellMV8001 supports Ethernet10/100/1000 Mbit/s connectivity.
I/OController:
Onemulti-modeParallelPortcapableofsupportingthefollowing
specifications:

3
1. Standard&Bi-directionParallelPort
2. EnhancedParallelPort(EPP)
3. ExtendedCapabilities Port(ECP)
Contains oneserialport, 16550 UART
Supports PS/2mice andPS/2keyboards
Supports 360 KB/720 KB/1.2MB/1.44 MB/2.88 MBfloppydiskdrives
BIOS:
Phoenix-Award™BIOS
Supports APM1.2
Supports ACPI2.0powermanagement

4
Introduction
PickTheBest
ThankyouforchoosingChaintechV915Pmotherboard.Beforebuilding
yourownperfectPCandinstallingand configuringitscomponents, you
needtohaveaclearidea ofwhatyoutrulygetbybuyingtheChaintech
V915Pmobo topickthebestcomponentsandenhance theperformance
foryourfleshandblood.
Figure1ChaintechV915PLayout

5
Intel915P
ThisNorthbridgeisalsoknownasthe
MemoryController Hub.Thispartofthe
chipsetprovidesthesystembusinterface,
memorycontroller,PCI-Express interfaceand
hubinterface forI/O.
IntelICH6
ThisSouthbridgeisalsoknownasthe
Input/OutputControllerHub,andcontrolsthesystem'saccesstothe
outsideworld,suchasthePCIbus, USBports, IDEsockets, SerialATA
ports andsoon.
LGA(Land-GridArray)775Socket
AqualityCPUdeservesaqualityhome.Here
iswhereyourvaluableCPUcomfortablysits.
TheLGA775 socket,whichhas775 sensitive
contacts, isonlycompatiblewiththeIntel
processors intheland-775 LGApackage.
MemoryDIMM(DualIn-Line
MemoryModule)Slots1/2/3/4
Theseplacesenableyoutoinstall4upto4GBDDR333/400 SDRAMs.
Improvedcommunicationsbetweenyourmemoryandtheprocessor
shouldalsoimproveperformance.

6
PCI-Express X16
YourPCI-Ex16-basedgraphicscardgoes
here.
PCI-Express X1
YourPCI-Express x1-basedexpansioncards go
here.
PCISlots
Yourexpansioncardsgohere,butbearinmind thatmoreisnot
necessarilybetter.
FDC (FloppyDiskConnector)
Asitsnamesuggests, thisconnectorconnects
toyourfloppydiskdriveviatheFDCcable.
IDEChannel
ThismotherboardprovidesoneIDEchannel
supportingPIOMode0~4,BusMaster,Ultra
ATA66/100.Thatgivesyousupportforup to
twoparallelATAdrives.
SATA(SerialATA)1/2/3/4
YourSATAdevices gohere.

7
BIOS
TheBasicInput/OutSystem(BIOS)contains
thecodetoburnupyourPC,testitandstart
loading anOperatingSystem.
Battery
TheBIOSset-up dataisheldinCMOSRAM,
thanks tothepowertakenfromthis battery.
RearI/Opanel
MostoftheI/Oports willbefoundhere, but
notall.
ATXPower Connectors
TheseconnectorshandlemostofyourPC's and
CPU's powerneeds.
FanConnectors
YourCPU/Chipset/Casefanwillbepoweredfromthesesockets,
respectively.

8
USBConnectors3/4
Thismotherboardhastwoextraportsthatyou
won'tfindontherearI/Opanel.Toaccess
them,youwillneedtorunacablefroma
socketonthemotherboardtoaslotconnector,
whichscrewsintoavacantPCIbackplate.
Alternatively, connecttothefrontofyourPCif
yourcasehas front-mountedports.

9
Hardware Setup
Havingfiguredoutingeneralwhatyouget,thenextjob istobitethe
bulletand buildyourPC
Precautions
WhenintegratingaPentium4processor-basedsystem,besuretotakethe
properelectrostaticdischarge(ESD)precautions. Considerusingground
straps, gloves, ESDmats, orotherprotectivemeasurestoavoiddamaging
theprocessorandotherelectricalcomponentsinthesystem.
Warning
Donottouchsocketsensitivecontacts.
Chaintechassumesnoresponsibilityforthe
potentialdamagescausedbythisactionand
thereforethewarrantyweprovidemaybe
invalid.
InstallingCPU
#1 DisengageLoadLeverbydepressingdownandoutonthehookto
clearretentiontab.RotateLoadLevertofullyopenpositionat
approximately135°
#2 RotateLoadPlatetofullyopenpositionatapproximately100°.
RemoveSocketProtectiveCover.Withlefthandindexfingerand thumb
tosupporttheloadplateedge,engageprotectivecoverfingertabwith
righthandthumbandpeelthecoverfromLGA775 Socketwhilepressing
oncenterofprotectivecovertoassistinremoval.
#3 Locatethetwoorientationkeynotches.
#4 Grasptheprocessorwiththumband indexfinger.(Grasptheedges
withouttheorientationnotches.)Thesockethascutoutsforyourfingers
tofitinto. Carefullyplace thepackageintothesocketbodyusingapurely
verticalmotion. (Tiltingtheprocessorintoplace orshiftingit intoplace
onthesocketcandamagethesensitivesocketcontacts.)
#5 Verifythatpackageiswithinthesocketbodyandproperlymatedto
theorientationkeys

10
#6 Closethesocketby
Installing CoolingFan
.Warning
Forasafetylanding,avoidleavingprongsonhard
surface.
Instructions
Smearthermalgreaseonthetop oftheCPU.
LowertheCPUfanontotheCPU/CPUsocketand
secureitusingtheattachmentsorscrewsprovidedon
thefan.Finally,attachthefanpowercabletothe
CPUFANadapter.Formoredetailsonthis, go to
http://www.intel.com
1. Close theLoadPlate
2. Whilepressingdown lightlyon LoadPlate,engagetheLoadLever.
3. SecureLoadLeverwith LoadPlatetabunderretention tab ofLoad
Lever

11
InstallingMemory
Takegreatcarewhenhandlingand
implementing thememory,becauseit
isnotcheapanymore.Memory
DIMMs will onlygo inoneway,so
don'ttryandforce it.Lineupthe
DIMM andpushdowngently.Then,
whenit'sinplace,lockitinwith
whiteconnectors, as shownontherightimage.
Warning
Thismainboardcontains4memoryslotswhichuse184-pinDDR
SDRAMwithatotalmemorycapacityofupto4GB.Youmustinstall
unbuffered/non-ECC DDR-SDRAMDIMMs witheither256 MB,512
MB,or1GBofmemory.ThesemodulesmustbeeitherDDR400
(PC3200)orDDR333 (PC2700)SDRAM.
Tips
ThismainboardprovidesDual-ChannelfunctionalityforitsDIMM slots.
Enabling Dual-Channelcansignificantlyincreaseyourdataaccess rates.
DIMM1andDIMM2shareonechannel,whileDIMM3andDIMM4
sharethesecondchannel.Enabling Dual-Channelsimplymeanstomake
surethatthetotalmemoryforthetwochannelsisbalanced.Forexample:
Ifyouinstallone256 MBmoduleinDIMM1andoneinDIMM2
(256MBx2=512MB),youmustinstallatotalof512 MBbetween
DIMM3andDIMM4.Inbalancingthememoryonthetwochannels, you
have, ineffect, enabledDual-Channel.

12
StorageConfiguration
Sofarsogood,nowitistimetoinstall thestoragedevicesforyour
mainboard.
FloppyDiskConnector:FDC
Thismainboardprovidesastandardfloppydisk
connector(FDC)thatsupports360K,720K,1.2M,
1.44Mand2.88Mfloppydiskettedrives. This
connectorsupportsthefloppydriveribboncablesprovidedinthe
packaging.
IDE1(PrimaryIDEConnector)
Youcan connect2IDEdevices totheIDE1connector
usingasingleribbon cablewith3connectors(2forthe
drives andonetoconnecttotheboard).Ifyouareconnecting1drive,you
shouldconfigureitastheMasterdevice.Ifyouareconnectingasecond
drive,youmustconfigureitastheSlavedevice (seeyourharddrivemanual
formaster/slave configuration specifics).Ifyouhavean IDECD-ROM
drive,youjustcan attach ittothisconnector.
SATA1-4(SerialATAconnector)
These SATAconnectors(SATA1 –SATA4)support
SerialATA150.EachSATAconnectorcan onlysupport
oneserialATAdevice. Note:Withmoststoragedevices,
thereisapowercablethatyouneedattachtoapowersource (power
supply).

13
FrontPanelConfiguration
SW/LED
HDLED(HardDriveLEDConnector)
ThisconnectorcanbeattachedtoanLEDonthefrontpanelofa
computercase. TheLEDwillflickerduringanydiskactivity.
RST SW(ResetConnector)
ThisconnectorcanbeattachedtoamomentarySPSTswitch.Thisswitch
isnormallyleftopen.Whencloseditwillcausethemainboardtoreset
andrunthePOST(PowerOnSelfTest).
PWR-LED(2-pinPowerLED)
Themainboardprovidesatwo-pinpowerLEDconnector.Ifthereisa
2-pinpowerLEDcableonthefrontpanelofyourcomputercase,youcan
attachittothe2-pinpowerLEDconnector.TheLEDwillilluminate
showingthatthecomputeris poweredon.
PWRON(PowerButton)
Thisconnectorcanbeattachedtoafrontpanelpowerswitch.Theswitch
mustpullthePowerButtonpintogroundforatleast50 mstosignalthe
powersupplytoswitchonoroff(thetimerequiredisduetointernal
debounce circuitryonthesystemboard).Atleasttwosecondsmustpass
beforethepowersupplywillrecognize anotheron/off signal.
PWR-LED(3-PinPower LED)
Thismainboardprovidesa3-pinpowerLEDconnector.
Ifthereisa3-pinpowerLEDcableonthefrontpanelof
acomputercase,youcanattachit tothe3-pinpower
LEDconnector.TheLEDwillilluminateshowingthat
thecomputeris poweredon.

14
SPEAKER(Speaker)
Afrontpanelspeakercanbeattachedtothisconnector.
Thisspeakerisusedforaudiblebeepsduringthebootup
process (PowerOnSelf-Test).Asingle“shortbeep”is
normal, while“irregularbeeps”signalproblems.
RearPanelConfiguration
PS/2Mouse&PS/2KeyboardConnectors:KB/MS
ThismainboardprovidesastandardPS/2mouseconnectorand PS/2
keyboardconnector. Thepinassignments aredescribedbelow:
SerialandParallelInterface Ports
Thismainboardcomeequippedwithoneserialportandoneparallelport.
Pin Assignment Pin Assignment
1 Data 4 +5V(fused)
2 No connect 5 Clock
3 Ground 6 No connect
