SERVICE MANUAL
Published by Sony Techno Create Corporation
Sony Corporation
DAV-TZ215/TZ715
DVD HOME THEATRE SYSTEM
9-893-290-01
2011H33-1
© 2011.08
E Model
Ver. 1.0 2011.08
• DAV-TZ215/TZ715 are composed of following models.
As service manuals are issued for each component model, please
refer to them.
SPECIFICATIONS
COMPONENT MODEL NAME
DAV-TZ215 DAV-TZ715
DVD receiver HBD-TZ215 HBD-TZ715
Front speaker SS-TS102 SS-TS103
Center speaker SS-CT101 SS-CT101
Surround speaker SS-TS102 SS-TS103
Subwoofer SS-WS101 SS-WS102
Packing Contents
• Main unit
• Front speakers (2)
• Center speaker (1)
• Surround speakers (2)
• Subwoofer (1)
• Speaker cords (1 set) (red/white/green/gray/blue)
• Foot pads (1 set)
• Speaker assembly parts for the tall speakers for DAV-TZ715
• Remote commander (remote) (1)
• R6 (size AA) batteries (2)
• FM wire antenna (aerial) (1)
• Video cord (1)
• High Speed HDMI cable (1)
(supplied with certain models/in certain areas only)
• Operating Instructions
• Quick Setup Guide
• Speaker Instruction Guide (DAV-TZ715 only)
General
Power requirements
Latin American models: 110 V - 240 V AC,
50/60 Hz
Other models: 220 V - 240 V AC,
50/60 Hz
Power consumption On: 105 W
Standby: 0.2 W*
* Valid when the system is in the following status:
– “DEMO” is set to “OFF.”
– [CONTROL FOR HDMI] is set to [OFF].
Dimensions (approx.) 430 mm × 67 mm × 335
mm (w/h/d) incl.
projecting parts
Mass (approx.) 3.6 kg
Supported file format
MP3 (MPEG 1 Audio Layer-3)
File Extension: mp3
Bitrate: 32 kbps - 320 kbps
Sampling frequencies: 32/44.1/48 kHz
WMA (USB device only)
File Extension: wma
Bitrate: 48 kbps - 192 kbps
Sampling frequencies: 44.1 kHz
AAC (USB device only)
File Extension: m4a
Bitrate: 48 kbps - 320 kbps
Sampling frequencies: 44.1 kHz
Xvid
File Extension: avi
Video codec: Xvid video
Bitrate: 4.854 Mbps (MAX)
Resolution/Frame rate: 720 × 480 / 30 fps
720 × 576 / 25 fps
Audio codec: MP3
MPEG4
File format: MP4 File Format
File Extension: mp4/m4v
Video codec: MPEG4 Simple Profile
(AVC is not compatible.)
Bitrate: 4 Mbps
Resolution/Frame rate: 720 × 576 / 30 fps
Audio codec: AAC-LC (HE-AAC is not
compatible.)
DRM: Not compatible
Design and specifications are subject to change
without notice.
Standby power consumption 0.2 W.
Halogenated flame retardants are not used in the
certain printed wiring boards.
Over 85% power efficiency of amplifier block is
achieved with the full digital amplifier, S-Master.
– Refer to next page for accessoreis list –

DAV-TZ215/TZ715
2
• Abbreviation
E3 : Middle East & African models
E12 : Indian model
E32 : Latin American model
ACCESSORIES
4-295-622-11 MANUAL, INSTRUCTION (ENGLISH) (E3, E12)
4-295-622-21 MANUAL, INSTRUCTION (FRENCH) (E3)
4-295-622-31 MANUAL, INSTRUCTION (SPANISH) (E32)
4-295-622-41 MANUAL, INSTRUCTION (ARABIC) (E3)
1 1-487-640-11 REMOTE COMMANDER (RM-ADU079)
2 1-754-060-21 ANTENNA (FM) (FM wire antenna (aerial))
3 1-833-579-11 CORD, CONNECTION (Video cord)
4 1-835-855-31 CORD WITH CONNECTOR (HDMI CABLE)
(High Speed HDMI cable) (E32)
5 1-837-582-21 CORD (WITH CONNECTOR) (SPEAKER)
(Speaker cords (1 set: red/white/green/gray/blue))
6 2-639-385-01 FOOT (Foot pads) (4 pieces, 1set)
7 A-1745-154-A BASE (PS) ASSY, STAND (Stand base) (1 piece)
(TZ715)
8 4-162-924-01 FOOT (ST) (1 piece) (TZ715)
9 A-1579-236-A STAND PIPE (S) ASSY (Stand pipe) (1 piece)
(TZ715)
10 4-118-374-01 +PWH TAPTITE 3X8 (ROUNDED END) (1 piece)
(TZ715)
Ref. No. Part No. Description Remark
2
FM wire antenna (aerial) (1)
1
Remote commander
(remote) (1)
4
High Speed HDMI cable∗
(1)
3
Video cord (1)
6
Foot pads (1 set)
5
Speaker cords (1 set)
(red/white/green/gray/blue)
79 10
8
Speaker assembly parts for the tall speakers
For DAV-TZ715
(4)
(4) (16)
∗ The High Speed HDMI cable is
supplied with certain models/in
certain areas only.
or

MEMO
DAV-TZ215/TZ715
3

DAV-TZ215/TZ715
REVISION HISTORY
Checking the version allows you to jump to the revised page.
Also, clicking the version at the top of the revised page allows you to jump to the next revised page.
Ver. Date Description of Revision
1.0 2011.08 New
