Challenge T-25LCD User manual

Digital Home Safe
Always Read the Instruction Manual
NEVER LOCK YOUR SPARE OVERRIDE KEYS OR THE INSTRUCTION MANUAL IN THE SAFE.
ONCE THE BATTERIES DEPLETE, YOU WILL NEED TO USE THE KEYS TO OPEN THE SAFE.
SPARE KEYS ARE UNAVAILABLE!
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING THE
OPERATION AND MAINTENANCE OF THE SAFE
COMPLETELY READ AND UNDERSTAND THE MANUAL BEFORE SECURING ITEMS IN THE SAFE
SAVE THIS MANUAL FOR FUTURE REFERENCE
MODELS: T-25LCD

SAFE DIAGRAM
-1-
Locking
knob
LCD (display)
Key lock
cover
(Yellow) #(Green)
Instructions
4 x ‘AA’
batteries
Back-up power supply
Override keys 4 x rawlbolts
Number
pad
Dia.1
NOTE: This safe is NOT re proof.
NOTE: This safe has no cash rating.
CONTENTS
1 X Instruction book
2 X Manual override keys
1 X Backup power supply
1 X Internal mat
4 X ‘AA’ Batteries
4 X Rawlbolts
SPECIFICATION
T-25LCD
SIZE : 35 (w) x 25 (h) x 25 (d) Cm
NET WEIGHT: 9.15Kgs
POWER SUPPLY: 4x ‘AA’ 1.5V Batteries
INTERNAL VOLUME: 21.72 Litre
IMPORTANT INFORMATION
This safe can be programmed with two sets of codes, User and Master. After opening the safe and
installing the batteries you should change the USER and MASTER PINS, from the factories pre-set
codes, for security reasons. You could give the user code to a guest while maintaining the master code.
OPERATING THE SAFE FOR THE FIRST TIME
Use the Manual override key to open the safe.
Remove the plastic key lock cover (dia 1).•
The number under the cover is the key number. Replacement keys are unavailable!•
Insert the override key; turn it anti-clockwise, at the same time turn the locking knob clockwise and pull•
open the safe.
See• BATTERY REPLACEMENT
Keep the safe door open until you have set the PIN code.•
LCD DISPLAY
To hide the numbers from being displayed when entered, Press “#” followed by “• “, then enter your
PIN. “o” will be displayed instead of the number.

-2-
KEY PAD
If you make a mistake when entering the PIN, press “• “, the last digit entered will be deleted.
Each time a button is pressed, a beep will be heard. This is a safety feature so that you will know when•
the safe is being accessed and cannot be switched off.
If you Press “• ”, “ bELL on” will be displayed. This will display the battery power status.
However, there is no function to switch the bELL (beep) off.
PROGRAMMING YOUR PIN NUMBER (personal identication number)
DEFAULT FACTORY USER PIN: 1234 : DEFAULT FACTORY MASTER PIN: 123456
Either of these PIN Codes can be set from 1 to 8 digits.
WE STRONGLY RECOMMEND THAT 4 OR MORE NUMBERS ARE USED AS THE USER CODE AND
6 OR MORE FOR THE MASTER CODE.
Keep PIN codes in a safe place. Do not use personal information like birthdays, telephone numbers etc.
NOTE: The following steps will only change one PIN, either the User or Master PIN based on the PIN
you entered in step 2.
In order to change the other PIN, simply repeat steps above, using the other code at step 2.
Write down your PIN codes so you do not forget it. (any combination of numbers from 4 to 8 digits)
Press “#”1.
Enter the either the User PIN or the Master2.
PIN
Press “#”3.
The safe will beep 3 times and display4.
“OPEN”.
Press “5. ” within 10 seconds.
The LCD will display “--------”.6.
Enter your New User or Master PIN7.
Press”#”8.
The LCD will display”--------”9.
Re-enter your New User or Master PIN.10.
Press “#”11.
The LCD will display “Into” for a few seconds12.
Your new PIN has been set.13.
While the door is open familiarise yourself with the door opening procedure, and leave the door open
untilyouaresatisedthatyoufullyunderstandtheopeningandclosingmethod.Youcanre-setthePIN
at any time by following the above procedure.
RESETTING THE PIN CODE TO THE FACTORY DEFAULTS
PIN CODES (personal identication number)
The safe can be reset back to the factory default PIN codes by
pressing the red button situated on the inside cover of the safe
door (Dia 2).
Open the safe door. Remove the reset button’s security cap by
unscrewing it.
Press the red reset button. The display will show “CLEAr”; all PIN
codes will revert back to the factory default PIN codes.
Pleaseretresetbutton’ssecuritycapforsecurityreasons.
OPENING THE DOOR USING YOUR PIN NUMBER (personal identication number)
Press ”#”•
Enter your PIN (either your user or master PIN code)•
Press “#”•
The safe will beep 3 times and display “OPEN”.•
Turn the locking knob clockwise within 10 seconds and pull the safe door open.•
If the PIN code is entered incorrectly the LCD will display “Error”. Wait for the display to clear and try•
again.
If the voltage of batteries is low the LCD will show “Lo-bAtt”. The batteries must be replaced.
Dia.2
Security cap
covering reset
button

OPENING THE SAFE USING THE OVERRIDE KEY
Use the Manual override key to open the safe.
Remove the plastic key lock cover (dia 3)•
Insert the override key; turn it anti-clockwise, at the same time•
turn the locking knob clockwise and pull open the safe.
BATTERY REPLACEMENT
The digital safe uses four ‘AA’ type batteries (supplied).
Remove the battery cover on the rear of the door (dia 4). Push•
the catch in and pull out the cover.
Install the 4x ‘AA’ batteries supplied (dia.4). Ensure correct•
polarity.
Replace the battery cover.•
The unit will beep, and the display will show “o” travelling from•
one side to the other followed by “ALLrEADY”. The unit is now
ready to be programmed.
Keep the safe door open until you have set the PIN code.•
Press #•
If the voltage of batteries is low, the LCD will show “Lo-bAtt”.•
The batteries must be replaced.
BATTERY PACK
Ifyourbatteriesareat,andyouareunabletondtheoverride
keys, you can use the Battery Pack to power the keyboard.
Fit four 1.5V ‘AA’ batteries in the battery pack. Plug the jack plug
of the pack into the battery backup socket on the panel of the
keypad. (dia.5).
The battery life is approximately one year.
Make a note of the battery replacement date; they should
last approximately one year.
However, we recommend checking the batteries every 6
months just to make sure.
If power is removed from the safe the set PIN code may
reset. If this happens use the factory default Pin codes.
SECURING YOUR SAFE
ADVICE: WE STRONGLY RECOMMEND THAT YOU SECURE
YOUR SAFE TO A WALL OR FLOOR FOR SECURITY
REASONS.
Youmaywishtosecureyoursafetoaxedpartofthehouse(i.e.
stone wall or wooden beam).
This can be achieved by using 2 of the 4 rawlbolts supplied in the
back of the safe or using the 4 rawlbolts in the base of the safe.
Use the holes in the safe to mark where you need to drill. Loosely
attach the rawlbolts onto the safe with the nuts and washers
provided. Hold the safe over the drilled holes and locate the
rawlbolts into these holes (Dia 6). Tighten the nuts from the inside
ofthesafetosecurermly.
Note : The rawlbolts are packed inside the safe
-3-
Dia.3
Dia.4
Dia.5
Dia.6
Back of safe
Wall
Nut & Washer
on the inside of
the safe
Dia.7

-4-
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
1 Can I get a replacement key/
extra key?
Replacement keys are not
available due to security
reasons.
2 The keypad becomes
inoperable
Low or depleted batteries Use override keys or Battery
Pack and replace batteries.
3 My PIN works, however, the
safe won’t open
Low batteries. Will operate the
keypad but not the lock relay.
Use override keys or Battery
Pack and replace batteries.
4 I have lost the keys, battery
pack and forgotten the PIN
number, can I obtain spare key
or battery pack?.
Spare keys are unavailable,
but we can supply you with a
spare battery pack at a small
charge.
5 I am experiencing problems
using the back up key; it is
unable to slide smoothly into
the keyhole.
Spray inside the keyhole with
WD40, leave for a few minutes
and then try again.
6 We recently changed the
batteries in the safe, the safe
has reset the code itself, and
the code I’ve been using is no
longer valid?
If the batteries are completely
depleted for more than a day
then the safe will not retain the
code.
Try the factory default code
or use the override key; then
refer to the user manual to
reset your original code or to
enter a new code.
7 When I enter # the LCD
displays “Lo-bAtt”.
The batteries are depleted. Immediately replace the
batteries.
8ThebatteriesIboughtdon’tt
the safe?
Batteries can vary in size. Try another brand.
9 When I use the override key, I
can’t open the door.
Ensure that you are tuning the
key anti-clockwise, holding it
in that position and then turn
the locking knob clockwise to
release the catch.

IB-T-25LCD-Issue1-04-04-11
HELPLINE
In the unlikely event of a defect occurring please contact our Helpline.
Ofcehours9am–4pm,Monday-Friday.Outsideofcehoursorduringpeaktimesyouwillbe
directed to an
answer phone. Please leave your name, a brief description of your enquiry and your number.
One of our operators will contact you as soon as possible.
Telephone Number 02083 916 767
Alternatively check the Q&A on our website www.hilka.co.uk/faq.php
NOTE:
These important safeguards and instructions cannot cover all possible conditions and situations
that may occur. It must be understood that common sense and caution are factors, which cannot
be built into any product. These factors must be supplied by the person using this product.
