Chard FFC-1B Guide

-1-
-1-
HEAVY DUTY
Features:
- Stainless steel cutting plate
- Heavy duty cast components
- Ergonomically designed cast handle
- Includes four suction cup feet
For your safety and continued enjoyment of this product,
always read the instruction book carefully before using.
Care and Use Guide
FRENCH
FRY CUTTER

-2-
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY.
When using any appliance, basic safety precautions
should always be observed, including the following:
1. READ ALL INSTRUCTIONS.
2. Do not clean using abrasive materials. Damage to unit may occur.
3. Never force any parts or brackets into position.
4. Keep away from moving parts. Moving parts can create pinch points which may
result in serious injury.
5. Make sure all product parts are assembled correctly before use.
6. Place the unit on a rm and stable surface.
7. Ensure that the unit is not placed close to the edge of the table, worktop, etc. where
it can be pushed off or fall.
8. Only use the unit when completely assembled.
9. Do not use any attachments that are not recommended, and don’t use this product
for any other purpose except its intended use.
10. This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the unit by
a person responsible for their safety.
11. Do not use the product if it appears to be damaged.
12. Do not try to repair this product by yourself. Contact Customer Service.
13. Close supervision is required when this product is used near children.
14. KEEP OUT OF REACH OF CHILDREN. Children should be supervised to
ensure that they do not play with this product.
15. Cleaning and user maintenance shall not be done by children without supervision.
16. DO NOT put unit in dishwasher.
CAUTION: The blades are very sharp. NEVER LEAVE CHILDREN
UNATTENDED AROUND UNIT.

-3-
LIST OF COMPONENTS
1. wing nut (Qty: 3)
2. cutter base (Qty: 1)
3. handle (Qty: 1)
4. handle nut (Qty: 2)
5. handle bolt (Qty: 2)
6. 3/8" cutting plate with frame (Qty: 1)
7. 3/8" push plate (Qty: 1)
8. push plate screws (Qty: 2)
9. suction cup feet (Qty: 4)
10. push plate guide (Qty: 1)
10
9
23
6
7
1
8
4 5
OVERVIEW OF COMPONENTS
Please DO NOT return product to the store you purchased it from.
For questions or concerns please contact customer service at
1-800-288-4545 or visit our web site at chardproducts.com.

-4-
PRE-ASSEMBLY
1. Attach four suction cup feet to the base and tighten the suction cup bolts.
2. a. Loosen and remove the two handle bolts from the cutter base.
b. Position the handle correctly, the curve of the handle
should face inwards.
c. Slide both handle bolts through the handle holes,
attach the two handle nuts and tighten.
ASSEMBLING THE CUTTING PLATE:
1. Loosen and remove the three wing nuts on front of blade frame housing.
2. Place the cutting plate on the unit with the cutting side facing the pusher,
re-tighten the wing nuts on the front of the unit.
3. Make sure the push plate fits into the cutting plate properly.
ASSEMBLING THE PUSH PLATE:
1. Loosen and remove the 2 push plate screws.
2. Place the push plate properly so the screw holes align vertically on the
push base.
3. Tighten the push plate screws.
ASSEMBLY INSTRUCTIONS
BEFORE FIRST USE
Take contents out of retail box and dispose of waste properly.
Thoroughly wash parts with warm soapy water and dry completely.

-5-
1. The French Fry Cutter can be mounted and fastened vertically or horizontally on a
sturdy surface. It can also be used on a at sturdy surface using the four suction
cup feet included. Press down rmly to ensure that the unit is stable.
2. When using for a sweet potato or yam, cut in half and insert cut end toward the
cutting blade, this will provide better results.
3. For best results, use a quick and rm motion to press items through the cutting
blades. Be sure to move the arm all the way to the end to ensure a clean cut.
4. Like all foods, fresh produce is the best, be sure to use fresh vegetables in the cutter.
5. For crispier fries, it is recommended to place your fries in boiling water for ve
minutes after cutting them, but prior to frying them. Use caution around boiling water.
6. Load the item to be cut so it is rmly touching the cutting blades. DO NOT load the
item against the push plate. When produce is slightly cut by the blade push
the handle down to complete the cut.
Before storing, hand wash and rinse the unit with hot soapy water. Dry thoroughly
with a clean towel. Make sure the unit is completely dry before storing for long
periods of time.
Before and after each use, hand wash and rinse the unit with hot soapy water.
Dry thoroughly with a clean towel.
Not all components are dishwasher safe, for best results, DO NOT put the unit
in a dishwasher.
HOW TO USE
STORAGE
CARE AND CLEANING

-6-
CHARD FFC-1B / French Fry Cutter
C/O MW
PO Box 237
Two Rivers, WI 54241-0237
LIMITED WARRANTY
Your product is warrantied for one year from date of purchase against all defects in material
and workmanship. Should your product prove defective within one year from date of purchase
or receipt, return the unit, freight prepaid, along with an explanation of the claim. Please
package your product carefully in its original box and packing material to avoid damage in
transit. We are not responsible for any damage caused to the product in return shipment.
Under this limited warranty, we undertake to repair or replace any parts found to be defective
at our sole discretion. This limited warranty is only valid if the product is used solely for
household purposes in accordance with the instructions. This limited warranty is void if the unit
is connected to an unsuitable electrical supply, or dismantled or interfered with in
any way or damaged through misuse.
LIMITATION OF REMEDIES AND DAMAGES: Except for the limited warranty and remedies
expressly stated above, the Metal Ware Corp shall not be liable to you, or to anyone claiming
by or through you, for any obligations or liabilities, including, but not limited to, obligations or
liabilities arising out of breach of contract, breach of warranty, statutory claims, negligence or
other tort or any theory of strict liability, with respect to the product or the Metal Ware Corp’s
acts or omissions or otherwise. Buyer agrees that in no event shall the Metal Ware Corp be
liable for incidental, compensatory, punitive, consequential, indirect, special or other damages.
Warranty does not cover consequential or incidental damages such as property damage and
does not cover Incidental costs and expenses resulting from any breach of this warranty, even
if foreseeable. Some states or provinces do not allow the exclusion or limitations of incidental
or consequential damages, so the above limitation or exclusion may
not apply to you depending on the State or Province of purchase.
We ask that you kindly fill in the details on your warranty card and return it within one week
from date of purchase.
Send warranty card to:
©2019 Metal Ware Corp., P.O. Box 237, Two Rivers, Wi 54241 1-800-288-4545
P/N: 300-02748
www.chardproducts.com
