ChargeTech PPL8 User manual

8 Bay Pin Code
Charging Locker (PPL8)
Installation Guide
3.Fix 4 metal pieces
in rectangle pole A
with 12 x M5 screws.
1. Fix rectangle pole
on base plate with 4 x
M8 screws.
2. Fix 4 x rubber foots
on base plate with 4 x
M5 screws.
4. Fix rectangle pole B
on rectangle pole A
with 12 x M5 screws.
5
6
4
5. Fix metal plate on rectangle
pole with 4 x M5 screws.
6. Fix PPL8 on rectangle pole
with 4 x M5 Hex screws.
7. Put extension cord
through rectangle pole.
1
2
3
8.Connect power cord
with the extension cord.
8
7
P1

Ø6mm
1. Fix 2 x L racks on the top of the product by
using 2 x M3 screws.
2. Mark the hole on wall.Drill 2 x Ø6mm holes on
wall according to the Mark.
3.Fix 2 x screw studs in hole.
4. Fix 2 x M4 screws to secure the unit in place.
3.Fix 2 x L racks on the
bottom of the product
by using 2 x M3 screws.
4. Mark the holes on
wall.Drill 2 x Ø6mm
holes on wall according
to the Mark.
Option A: Fix product by the wall Option B: Hang on wall
1
2
3
4
1
1. Drill 2 x Ø6mm holes (Suggest: 1.6m height)
on wall according to the drawing. Fix 2 x screw
studs and 2 x screws on wall(not included).
2. Lift 5mm space for hanging WM10 on wall.
Ø6mm Ø6mm
2
160cm
Ø6mm
4
5
6
3
5. Fix 2 x screw studs in holes.
6. Fix 2 x M4 screws to secure the unit in place.
462 mm
P2

B. Replace Cable
1. Open the control box door with key
provided.
2. Unlock the door by pressing the button
on the lock.
1
2
2
3.Open the cable clip.
4. Unplug USB Cable.
5. Take out the cable through the hole.
3
4
5
1. Mark the holes on floor.
2. Drill 4 x Ø12mm holes on floor
according to the Mark.
3.Bolt the base plate on the ground with
4 x expansion screws.
Option C: Fix product on ground
1
2
3
Ø12mm
P3

C. Emergency
Set up of Admin Password,Press “0” “#” “0” “#” “0” “#”
to enter Admin Mode.
==> Press < 1 >
Factory reset.
==> Press < 2 >
Modify Password.
Admin password:
* * * * * * * *
==>Press < # >
Enter a new
8-digit password
==>Press < # >
The administramo
tor password is
modified success
fully.
☐ 1 ☐ 3 ☐ 5 ☐ 7
☐ 2 ☐ 4 ☐ 6 ☐ 8
☐ 0 Reset All
==> Press < # >
Resetting.....
Please wait a mo
ment.
Factory setting
reset completed.
LCD Displays:
Administrative Mode
Default Password:
88888888
Please change it before
implementing the locker.
!
10.Open the front door by using the key
provided.
11. Hold the angle of the front door by using
the metal stick.
10
11
- Model no.: PPL8
- Input : AC 100 - 240V / 50~60Hz
- Output (per locker box) : 5V/2.4A Max
- Charging Cable (per locker box):
Micro USB Cable + Lightning Cable + Type C Cable
- Dimensions(PPL8 only): 480 x 200 x 668 mm
- Dimensions(PPL8 with Floor Stand): 590 x 280 x 1660mm
- Material (Housing) : Cold Rolled Steel
- To Prevent fire on shock hazard,do not expose the device to rain or
moisture.
- To avoid electric shock, please do not disassemble the device.
- If trouble occurs,immediately disconnected the device from wall socket.
Maintenance
- Wipe the device with a soft dry cloth to prevent dust build up.
- keep the device away from strong volatile solvents or chemicals, such as
thinner, benzene,alcohol, pesticide, rubber or vinyl plastic etc, which may
lead to deterioration or damage to your devices.
F. Specifications
G. Notes on use
Press button
“0”
Reset all boxs
Press
button “1”
Press button “2”
Press button
“1-8”
Reset corresponding
box
D.Reset to factory admin password
Reset to factory
admin password
Specker volume
controller
PCB
Plug in your flash
memory stick with
your video content.
E. Advertising video content
P4
