Chariot Carriers Cavalier User manual

Owners Manual
www.chariotcarriers.com
cavaliercavalier
cavalier_manual.qx4 3/1/02 1:53 PM Page 1

1
Congratulations for choosing a Chariot Carriers®jogging stroller. We have carefully
constructed your jogging stroller so that its safety and performance meet the highest
standards. With proper care and maintenance, your new Chariot jogging stroller will give
you and your family pleasure for years to come.
Read Chapter 1 carefully before you use your new
Chariot jogging stroller!
• Chapter 1 covers important information concerning safety and jogging stroller care.
• Chapter 2 provides information about periodic maintenance for your Chariot jogging
stroller with the intervals for up eep of specific parts of your jogging stroller under
normal strolling conditions.
• Chapter 3 gives basic instructions for inspection, lubrication, and adjustment of
the individual components on your Chariot jogging stroller, including instructions
for folding the jogging stroller.
If you have any questions after reading this manual, consult your Chariot dealer.
Assembly and initial adjustment of your Chariot jogging stroller
should only be done by an authorized Chariot dealer.
Read Chapters 1 and 2 thoroughly. This will ta e about 35 minutes but will help to
ensure that your Chariot jogging stroller eeps wor ing properly and safely. Use Chapter
3 as a reference guide whenever a part of your jogging stroller needs routine mainte-
nance, as required in the Periodic Maintenance Schedule, or whenever something needs
repair or adjustment between routine maintenance periods.
Some maintenance and repair should only be performed by your Chariot dealer. Any
such service will be indicated in this manual. If you have a question or problem which your
Chariot dealer can’t address, contact us at:
CON RATULATIONS!
Bay F, 6810 - 6th Street S.E.
Calgary, Alberta T2H 2K4
tel: [phone]
fax: [phone]
www.chariotcarriers.com
Than you for buying a Chariot Carrier
and for buying Canadian.

2
page
Chapter 1 uide to Safe Use
Important- Read Before You Use!
Ma e sure your jogging stroller fits properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Ma e sure you are familiar with your jogging stroller . . . . . . . . . . . . . . . . . . . . . . . .4
Jogging stroller folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ma e sure your jogging stroller is in proper wor ing condition . . . . . . . . . . . . . . . .5
Chec that your wheels are straight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Chec your tire inflation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Chec your bra e . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Chec attachment of all wheels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Wal safely. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Ta e care of your jogging stroller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Child safety and restraint system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Chapter 2 Periodic Maintenance
Periodic Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Recommended tools for proper jogging stroller maintenance . . . . . . . . . . . . . . . . .11
Chapter 3 Inspection, Adjustment, and Lubrication
Handlebars. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Fabric and Fasteners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Bra e system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13-14
Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-17
Additional features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Parts List/Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Chariot Carriers Inc. Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
TABLE OF CONTENTS
WARNIN
This manual contains many WARNIN S and Cautions. Read and
understand all of the WARNIN S and Cautions. Failure to assemble
and use this carrier correctly may lead to serious injury or death to
your passenger.

3
I. ENERAL WARNIN !
This manual contains many WARNINGS and Cautions. Read and understand all of the
WARNINGS and Cautions. Failure to assemble and use this carrier correctly may lead to
serious injury or death to your passenger.
• Do not operate the jogging stroller without reading and understanding this manual.
• Passenger must always use seat belts.
• Never leave child unattended in jogging stroller.
• Use wrist safety strap at all times.
• Always use par ing bra e when the jogging stroller is stationary.
• Do not allow any of the child's body, clothing, shoe laces, or toys to come in contact
with moving parts.
• Child must be old enough to sit upright unattended.
• Maximum capacity of jogging stroller is 65 lbs. (30 Kg.) including child and cargo.
• The carrier may become unstable if a parcel bag or rac is attached to the
jogging stroller.
• Care must be ta en when folding and unfolding to prevent finger entrapment.
• Never in-line s ate with the jogging stroller. A serious accident could occur resulting
in serious injury or death.
• Never allow children to push or play with jogging stroller.
Because a jogging stroller is used to transport your child, safety cannot be overemphasized.
This chapter contains suggestions that will help you use your jogging stroller as safely as
possible. Read this entire chapter before you use your new Chariot jogging stroller.
page
Before your first use
Ma e sure your jogging stroller fits properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Ma e sure you are familiar with your jogging stroller . . . . . . . . . . . . . . . . . . . . . . . .4
Jogging Stroller folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Before each use: Checklist
Ma e sure your jogging stroller is in proper wor ing condition. . . . . . . . . . . . . . . .5
Chec that your wheels are straight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Chec your tire inflation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Chec your bra e. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Chec attachment of all wheels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
During each use
Use safely. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Before, during, and after every use
Ta e care of your jogging stroller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Child safety and restraint system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
IMPORTANT! READ BEFORE YOU USE

4
Make sure your jogging stroller fits properly.
The maximum capacity of a Chariot jogging stroller is 30 g (65 lbs) including child and
luggage or other supplies. The child’s head, including any helmet, should not project above
the sunshade assembly (Fig. 2). The child’s feet should not reach the front wheel. Using
the jogging stroller with a child who does not properly fit may cause damage to the
jogging stroller, or possibly injure the child.
The maximum capacity of the rear mesh storage poc et is 1 g (2.2 lbs). Do not overload
the rear storage poc et. Do not attach additional carrying bags or other items to the bac
or handlebars of the jogging stroller. Any additional weight on the bac of the jogging
stroller could ma e it unstable. Additional cargo may be stored in the lower cargo poc et
to a maximum of 3 g (6.6 lbs).
You can also adjust the jogging stroller handlebars to fit the person pushing the jogging
stroller. Read page 12 of this manual before attempting to ma e these adjustments.
BEFORE YOUR FIRST USE
Make sure you are familiar with your jogging stroller.
Familiarize yourself with the use of the mechanisms on this jogging stroller. Practice
adjusting and wal ing the jogging stroller without a child in it before attempting to wal
with a loaded jogging stroller.
ONE
uide for
Safe Use
STROLLER FOLDIN
Your jogging stroller can be folded for easier transportation or more compact
storage. Before storage, always ma e sure the jogging stroller is completely dry.
Storing the jogging stroller when wet or moist will cause rust to form on the
metal parts, and mildew will form on the fabric parts. Care must be ta en when
folding and unfolding the jogging stroller to prevent finger entrapment.
Folding the jogging stroller.
1. Open the bra e quic release lever. Remove the front wheel by moving the
quic release lever to the OPEN position as shown in the Wheels section.
Unscrew the quic release adjusting nut and slip the wheel from the dropouts.
Remove the rear wheels by gently pulling each clip spring open enough that
the axle can be removed from the axle tube (do not force the clip spring past
this point, or you may bend it so that it does not secure the wheel properly).
2. Unsnap the seat anchor from the center bac of the axle.
3. Pull the loc ing tension bar (Fig. 1) into its upper, unloc ed position.
4. Gently fold the handlebar forward, being careful not to catch or pinch any
of the jogging stroller’s fabric parts. (Fig. 2)
5. Fold the wheel struts (Fig. 3) forward.
6. Attach (snap) the par ing bra e strap to the snap on the center bac axle.
Unfolding the jogging stroller.
1. Fold the wheel struts bac .
2. Gently fold the jogging stroller handlebar up and bac .
3. Pull the loc ing tension bar into its lower, loc ed position. Ma ing sure it
snaps into place, and roots against the wheels struts.
4. Reattach the seat anchor strap to the center of the bac axle, it must
strap over the loc ing tension bar and down under the axle.
5. Install the wheels as shown in the Wheels section. Close the bra e quic release.
Fig. 1
Fig. 2
Fig. 3
WARNIN
Failure to secure the locking tension bar into its lower locked position, and connect
the seat anchor strap over the locking tension bar and attach to the centre back
axle, could cause the jogging stroller to collapse causing serious injury.
locking
tension bar

5
Make sure your jogging stroller is in proper working condition.
Spend a few moments before each wal to chec your jogging stroller’s systems against
the following chec list:
Check that your wheels are straight.
Spin each wheel to chec that the rim doesn’t wobble up and down or from side
to side, and that the wheels are centered in the jogging stroller frame and for . To do this,
watch the rim as it passes through the bra e pads, or by the frame. If any wheel fails this
test, ta e your jogging stroller to your Chariot dealer for service.
Check your tire inflation.
Inflate your tires to the air pressure recommended on the tire sidewalls.
Use a hand-operated pump with an appropriate gauge. Gas station hoses inflate the jogging
stroller tires too rapidly and the pressure they indicate is often inaccurate.
Check your brake.
Press the bra e lever to ma e sure that the bra e moves freely and stops the
jogging stroller.
The bra e pads should be adjusted so they are 1 to 2 mm away from the rim when the
bra es are not applied. Bra e pads should be centered on the rim (Fig. 4). If your bra es
are too tight, too loose, or not centered on the rim, refer to the Bra e System section of
Chapter 3.
BEFORE EVERY USE – CHECKLIST
WARNIN
This is not a comprehensive maintenance program. Check the entire jogging
stroller carefully. If you spot a problem, do not use the jogging stroller until it
has been corrected. If you are not certain if your jogging stroller has a problem,
take your jogging stroller to your Chariot dealer.
WARNIN
If your brakes are not working properly, do not place a child in
your jogging stroller. Refer to the Brake System section of Chapter 3
or take your jogging stroller to your Chariot dealer for service.
❐
✓
❐
✓
❐
✓
Pad and rim should be
parallel
Brake pad aligned with
the rim surface
Direction of rim
rotation
Fig. 4
0. - 1mm toe in

Check attachment of all wheels.
This jogging stroller is equipped with quic release wheel
retention mechanisms. The quic release allows the wheel to be
installed and removed without tools. For proper and safe perform-
ance, read and follow these instructions carefully:
1. Chec all wheels of your jogging stroller before each use.
Front wheel.
2. For the front wheel, move the quic release lever to the OPEN position
and set the wheel so it firmly touches the inside of the for ends.
3. With the lever about halfway between the OPEN position and the CLOSED
position (Fig. 5), tighten the quic release adjusting nut on the opposite end of the
quic release axle until finger-tight (Fig. 6).
4. Place the quic release lever in the palm of your hand and move the lever in a motion
as shown in Figure 7. Move the lever into the CLOSED position (Fig. 9). At the halfway
closed position of the quic release lever, you should start to feel some resistance to this
motion.
5. If the lever is moved to the CLOSED position with little or no resistance,
clamping strength is insufficient. Simply return the lever to the OPEN position,
tighten the quic release adjusting nut further and close the lever, testing again for
resistance. When the quic release device is properly tightened, and clamped to the
closed position, the clamping force is adequate to cause metal into metal engagement
(embossing) of the for surfaces.
• Do not tighten the quick release by using the quick release lever
like a wing nut (Fig. 8). This will not result in sufficient force to
hold the wheel in place.
6. Orient the quic release lever so that it does not interfere with any other jogging
stroller part and so that it will not become accidentally snagged by obstacles in the
path of the jogging stroller (Fig. 9).
(continued next page)
6
BEFORE EACH USE – CHECKLIST
OPEN
CLOSED
OPEN
OPEN
OPEN
OPEN
Fig.
Fig. 6 Fig. 7 Fig. 8 Fig. 9
WARNIN
Failure to have wheel quick release retention mechanisms properly adjusted
and closed, may cause loss of control resulting in personal injury. If you have
any questions about the operation of this system, consult your Chariot dealer.
ONE
uide for
Safe Use
❐
✓
OPEN
CLOSED
OPEN
CLOSED

7
X
Rear wheel.
7. Insert the rear hub axle (Fig. 10) into the axle tube (Fig. 11) until the loc ing clip
engages. You should hear a clic as this happens, and the clip spring should sit
against the axle tube.
Test for wheel retention.
8. Do these two tests to ensure that you have adequately performed these
procedures:
• Pic the front of the stroller off of the ground, and give the top of the front tire
a sharp downward blow (Fig. 12). The wheel should not come off, be loose, or move
from side to side. If uncertain, repeat the tightening process, as shown in Steps 2-6
of these instructions.
• With the quic release lever properly adjusted and in a closed position, you will
not be able to rotate the quic release lever in a circular motion parallel to the wheel
(as opposed to the flipping motion used to open and close the quic release lever-
see Fig. 13).
9. For the rear wheel, test for a secure attachment by attempting to pull the rear hub
axle from the axle tube (Fig. 14). You should not be able to pull the axle from the tube.
Fig. 12 Fig. 13
Fig. 11
Fig. 10
Axle tube
Clip
spring
X
Fig. 14

8
USE SAFELY DURIN EVERY USE
Wear a helmet.
An unprotected head is highly susceptible to injury, even from the slightest contact.
Children in a stroller should wear a helmet that is comfortable, fits properly, and meets CPSC
or CE safety testing standards. Helmets should be removed when not riding in the stroller to
avoid entrapment in the straps.
Know and observe your local pedestrian laws.
• Use your jogging stroller defensively (expect the unexpected). Remember: You and your
jogging stroller are hard to see. Many drivers simply are not trained to recognize the rights
and special considerations of a jogging stroller.
Do not use unsafe jogging stroller practices.
While most pedestrian rules can be classified as common sense, it is still necessary to
list a few of the things you should NOT do with a jogging stroller.
• Never leave a child unattended in a jogging stroller. Not even for a moment.
• Do not wal ‘no hands’. Without a firm grip on the handlebars, the slightest road
imperfection could cause the jogging stroller to turn unexpectedly.
• Do not wal with loose objects attached to the handlebars or any other part of the
jogging stroller. They could get caught in the wheel spo es, cause the handlebars to turn
unexpectedly, or in other ways cause loss of control.
• Do not wal while intoxicated or while using medications which might ma e you drowsy.
Jogging strollers require attention to the child in the jogging stroller, and wal ers must be
alert for hazards.
• Do not use the jogging stroller at night or in poor visibility conditions. Other vehicles
may not be able to see the jogging stroller.
• Never push the jogging stroller while wearing in-line or roller s ates. Jogging strollers
are not made for high speeds and even when equipped with bra es, their bra ing system is
not designed to control the weight of the person pushing the jogging stroller.
Do not submerge any bearings of your jogging stroller.
Bearings allow the parts of a jogging stroller to rotate smoothly, and water will ma e
them rust and lose their smoothness. If any bearings on your jogging stroller get
submerged, ta e your jogging stroller to your Chariot dealer for service.
WARNIN
Avoid unsafe practices. Keep the safety of yourself, the child,
and the jogging stroller in mind. Failure to follow these rules may
cause loss of control resulting in personal injury.
ONE
uide for
Safe
Strolling

9
WARNIN
BEFORE, DURIN , OR AFTER EVERY USE
TAKE CARE OF YOUR JO IN STROLLER
Keep your jogging stroller clean.
To eep your jogging stroller in proper wor ing condition, eep it clean. If your jogging
stroller frame or a component is dirty, clean it with a soft damp cloth. If the fabric cover
or seat is dirty, use a soft nylon brush and wash with a solution of water and mild
detergent. Do not use abrasives, solvents, or bleach.
If you hear a grinding or “sandy” noise coming from any bearings, your bearings need
maintenance. Ta e your jogging stroller to your Chariot dealer for service.
Avoid high pressure washing systems, li e those at most car washes. The high pressure
can bypass bearing seals, letting water into the bearings. Water will ma e the bearings
rust and lose their smoothness.
Avoid leaving your jogging stroller out
in the weather.
When not strolling, eep your jogging stroller in a location where it will be protected
from rain, snow, sun, etc. Rain and snow can cause your jogging stroller to corrode. The
ultraviolet radiation from the sun can fade the fabric seat, or crac any rubber or plastic
on the jogging stroller.
Use proper storage for your jogging stroller.
Improper storage is very hard on a jogging stroller. Always completely dry the jogging
stroller before storage to prevent rust and mildew. Before storing your jogging stroller for
an extended period of time, clean and lubricate it. Do not store near electric motors, as
ozone from motors destroys rubber, nylon and paint. Before wal ing with the jogging
stroller again, be certain it is in good wor ing order.
Safely transport your jogging stroller.
Never transport your jogging stroller on the outside of your car. The high wind speed can cause
damage to the jogging stroller.
Protect your jogging stroller from accidental damage.
Par your jogging stroller in a place where it will be out of the way. If you suspect your
jogging stroller has been damaged or tampered with in any way, ensure that there is no
problem, or ta e it to your Chariot dealer for inspection and repair.
Never modify your jogging stroller.
Your jogging stroller’s parts have been carefully designed to meet the strength and function
requirements of normal use. Modifying these parts in any way may ma e your jogging stroller
unsafe.
Any modification of your jogging stroller’s frame, fabric seat, or components means that
your jogging stroller no longer meets our specifications and will therefore void the jogging
stroller’s warranty.
Never modify your jogging stroller in any way, including sanding,
drilling, filing, or by any other technique. Such modifications will
void your warranty, may cause your jogging stroller to fail, and
may contribute to loss of control resulting in personal injury.

10
CHILD SAFETY AND RESTRAINT SYSTEM
The retention system is designed to prevent the child from
falling from the jogging stroller in case of bumps or jolts. The
child must always be belted snugly into the seat when strolling.
To secure the child:
1. Engage the par ing bra e, and test to ma e sure the
jogging stroller cannot roll.
To engage the par ing bra e, press the bra e lever firmly,
engage loc pin, and wrap the par ing bra e strap around the
bra e lever and handlebar, and engage the hoo -and-loop
fastener (Fig. 15) (to undo, unfasten the par ing bra e strap
from the bra e lever).
2. Place crotch strap between legs and adjust so O-ring is centered
at child’s lower chest. (Fig. 16)
3. Thread shoulder harness through O-ring, clip it into buc le over child’s left shoulder,
and tighten by pulling loose end from over child’s right shoulder. (Fig. 16)
4. Fasten lap belt buc le and tighten snugly. (Fig. 16)
5. When you are ready to begin strolling, place one hand through the wrist safety strap
(Fig. 17) and grasp the handlebar. Then disengage the par ing bra e.
Other safety considerations:
Never attempt to place a child in the jogging stroller without first engaging the par ing
bra e. Do not allow the child to eat or drin while in use as they could cho e.
Never leave a child unattended in a jogging stroller. Not even for a moment.
Never push the jogging stroller while wearing in-line or roller s ates. Jogging strollers
are not made for high speeds and even when equipped with bra es, their bra ing system is
not designed to control the weight of the person pushing the jogging stroller.
When in use, periodically monitor the child’s condition in the jogging stroller. While you
are exercising, the child is not. Heat and cold can affect them differently, and periodic
adjustments should be made to eep them safe and comfortable.
Do not place a car seat in the jogging stroller. The child should sit directly in the jogging
stroller seat.
Fig. 1
Fig. 17
WARNIN
Always adjust the shoulder harness and crotch strap so they meet at
child’s lower chest. Adjusting harness and buckles near your child’s neck
could cause serious injury.
Never release the jogging stroller without first engaging the parking
brake. If the jogging stroller rolls inadvertently it could result in serious
personal injury.
ONE
uide for
Safe Use
Shoulder Harness
Lap Belt
O-Ring
Fig. 16

11
TWO
Periodic
Maintenance
PERIODIC MAINTENANCE SCHEDULE
page
Before each use
Chec wheel attachment (all) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Chec tire inflation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Chec tires for wear, replace if necessary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Chec that wheels are straight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Chec bra es . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Weekly
Wipe off your jogging stroller with a damp cloth . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Monthly
Inspect for any loose nuts or bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Inspect bra e cables for wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Chec wheel bearing adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Every 3 months
Inspect and lubricate bra e lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Every year
Re-grease wheel bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Lubricate wheel quic releases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
This maintenance schedule is based on normal usage. If you wal your stroller more
than average, or in rain or snow, service your jogging stroller more often than the
schedule suggests. If any part appears to be malfunctioning, inspect and service it
immediately, or consult your Chariot dealer.
Recommended tools for proper stroller maintenance:
10mm open-end wrench
7/16”, 3/8”, 1/2” open-end wrenches
No. 1 Phillips head screwdriver
5mm Allen Key
Bicycle tire pump with gauge
INSPECTION, ADJUSTMENT, AND LUBRICATION
page
Handlebars. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Fabric and Fasteners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Bra e system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13-14
Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-17
Additional features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

12
THREE
Inspection,
Adjustment
& Lubrication
Introduction
The handlebar assembly is primarily responsible for your ability to steer and control the
jogging stroller.
Adjustment
The handlebar height of your jogging stroller can be adjusted to provide increased
comfort and control. Remove the child from the jogging stroller before ma ing adjust-
ments.
To adjust the handlebar height, move the loc ing tension bar (Fig. 18) to its upper, unloc ed
position. Rotate both bar height adjustment levers (Fig. 19) at the same time to change the
handlebar height. Rotating both levers at the same time helps prevent any jamming. Rotate
forward and down (Fig. 19) for the low bar position, or up and bac (Fig. 20) for the high bar
position.
After adjustment, swing the loc ing tension bar into its lower, loc ed position.
HANDLEBARS
Fig. 18
Locking
tension bar
Fig. 20Fig. 19
FABRIC AND FASTENERS
Introduction
In addition to the other specific parts of your jogging stroller listed in this chapter, your
jogging stroller is comprised of a metal frame with a fabric seat and sunshade. These
structures form the jogging stroller itself.
Inspection
Once a month chec the fabric of the seat and sunshade for wear, tears, or any other
damage.
Once a month chec all the nuts and bolts on the jogging stroller. As a simple function
test, chec that any two parts bolted together do not feel loose, and cannot be moved
from one another. All the threaded fasteners on the jogging stroller use Nyloc nuts,
where a plastic insert prevents loosening of the bolt.
In some cases, the bolt in question needs to allow pivoting of the parts it holds together.
In these cases, you must inspect the bolt to ma e sure there is not undue looseness.
Adjustment
Use the proper tools to tighten any loose bolts. If you are unsure of what constitutes a
loose bolt, ta e your jogging stroller to your Chariot dealer for inspection and repair.
If your jogging stroller has any damaged fabric, repair or replace the damaged part, or
ta e your jogging stroller to your Chariot dealer for service.
Bar height
adjustment lever
Bar height
adjustment lever

THREE
Inspection,
Adjustment
& Lubrication
BRAKE SYSTEM
Introduction
The bra e system allows you to control the speed of your jogging stroller, but is
primarily used as a par ing bra e when desired to prevent the jogging stroller from
moving. The bra e system can be difficult to adjust properly without the proper tools and
training. If you are unsure of the bra e adjustment, or suspect any problem, do not wal
your jogging stroller. Ta e your jogging stroller to your Chariot dealer for service. If you
need more specific information regarding your bra e system, contact your Chariot dealer.
Inspection
Before every wal ma e sure your bra e is wor ing properly. Before every wal chec
that the bra e pads are in proper position (Fig. 21). Your rims are part of the bra ing
system, so eep them clean at all times. Chec that there is no oil, grease, or other dirt
on the rims.
Every month chec your jogging stroller’s bra e cable and housing. Chec the cable for
in s, rust, bro en strands, and frayed ends. Chec the housing for bent ends, cuts,
stretched coils, and wear. Replace any part of your bra e cable or housing which do not
pass inspection.
Every month, inspect your bra e pads for wear. Bra e pads have shallow
grooves in their bra ing surfaces to channel water from the rim. If any of
these grooves are less than 2 mm deep, replace the pads.
Adjustment
Adjust the bra e pads so they are 1.5 mm to 2 mm away from the rim
when the bra es are not applied. This is done by turning the barrel
adjuster on the bra e caliper (Fig. 22). To bring the pads closer to the
rims, turn the adjusting barrel counter-cloc wise. To move the pads away
from the rim, turn the adjusting barrel cloc wise.
If the pads cannot be adjusted close enough to the rim in this manner,
loosen the cable anchor bolt until the cable is loose. Screw the barrel
adjuster all the way in cloc wise. Hold the bra e pads against the rim,
and re-tighten.
To adjust the alignment of the bra e pads, loosen the bra e pad fixing
bolt and align the pad so that the pad surface and the rim surface meet
correctly (Fig. 21).
When adjustment is complete, tighten the pad fixing bolt. After the
bra es are adjusted, test the bra es by applying maximum bra ing force
to the levers. Ensure that the cable does not slip, that the pads close
toward the rim at right angles, and that the pads do not contact the tire.
If you are unsure of the bra e adjustment, or suspect any problem, do
not wal your jogging stroller. Ta e your jogging stroller to your Chariot
dealer for service. It is strongly recommended that adjustment of critical
components such as bra es be done by your Chariot dealer.
Pad and rim should be
parallel
Brake pad aligned with
the rim surface
13
Barrel
adjuster
Cable
anchor
bolt
Pad fixing bolt
Fig. 23
Lever clamp bolt
Fig. 22
Fig. 21
QR

Lubrication
Every 3 months, lubricate your bra e lever pivots and bra e arm fixing pivots with a light
oil. See your Chariot dealer for a recommended oil.
Lubricate bra e cables with a thin layer of synthetic grease or a similar lubricant when
installed.
Cable Installation
To install a bra e cable, note the path of the old cable, loosen the cable anchor bolt and
remove the worn cable. Turn the adjusting barrel on the bra e caliper cloc wise so that
the threads on the adjusting barrel are not exposed above the caliper. Grease the new
cable and reinstall, feeding it along the same path as the old cable. Ma e sure that the
cable’s leaded end is seated properly in the bra e lever body and that the housing is
properly seated in the lever. After threading the cable through the cable anchor bolt,
follow the directions for bra e adjustment in the Inspection and Adjustment sections.
Finally, cut the cable so that no more than 2 inches (51 mm) extends beyond the anchor
bolt. Crimp a metal cap or place a bit of solder on the end of the cable to prevent fraying.
WARNIN
If you are not certain your brakes are working properly, or you if
suspect a problem with your brake cables do not use your jogging
stroller. Refer to the instructions in the appropriate section of this
manual or take your stroller to your Chariot dealer for service.
14

WHEELS
THREE
Inspection,
Adjustment
& Lubrication
Introduction
The wheels allow your jogging stroller to roll down the road smoothly so the
integrity of your jogging stroller wheels is crucial. Their structural soundness and
their relationship to the performance of your bra e are of great importance.
The best maintenance of a wheel is preventative maintenance.
Be aware of the things that can go wrong, so you can stop trouble
before it happens.
Inspection
Before each use, chec that your quic release hub, is in its closed (loc ed) position and
that your wheels are correctly attached. For further information on adjusting quic release
hubs, see the Adjustment section, or consult your Chariot dealer.
Chec that the wheels are straight and round by spinning them. If the rim does not
spin evenly, have your wheel trued by your Chariot dealer.
Ma e sure your tires are inflated to the pressure indicated on the tire sidewalls. Use
a gauge and a bi e pump whenever possible. Avoid filling your tires at gas stations.
Because of the greater pressure and volume of air their pumps release, blowouts are
very possible. Inspect your tires for wear and any other damage. If a tire has any cuts
or separations which go through the tire, ma ing any part of the inner tube visible, or
if any part of the tire casing shows through the tire tread (running surface) replace
the tire.
Ma e sure your rims are clean. Dirty or greasy rims render your bra e ineffective. Wipe
your rims with a clean rag or wash them with soap and water, rinse, and let them air dry.
Every wee , ma e sure that there are no loose, damaged, or bro en spo es. If a wheel is
not in good condition, both the effectiveness of the bra es and the strength of the wheel
are greatly reduced.
Every month, chec that the hub bearings are properly adjusted. Lift the front end of
the jogging stroller off the ground with one hand and attempt to move the rim laterally,
left to right. Loo , feel, and listen for any looseness in the hub bearings. Spin the wheel,
and listen for any grinding or other unusual noises. If the hub feels loose or ma es any
noise, the hub may need an adjustment. Repeat these procedures for the rear wheels.
WARNIN
If there is movement between the axle and the hub, or you suspect the
hub may need an adjustment, do not use your jogging stroller. Take your
jogging stroller to your Chariot dealer for service.
15

Check attachment of all wheels.
This jogging stroller is equipped with quic release wheel retention mechanisms. The
quic release allows the wheel to be installed and removed without tools. For proper and
safe performance, read and follow these instructions carefully:
1. Chec all wheels of your jogging stroller before every use.
Front wheel
2. For the front wheel, move the quic release lever to the OPEN position and
set the wheel so it firmly touches the inside of the for ends.
3. With the lever about halfway between the OPEN position and the CLOSED
position (Fig. 24), tighten the quic release adjusting nut on the opposite end of the
quic release axle until finger-tight (Fig. 25).
4. Place the quic release lever in the palm of your hand and
move the lever in a motion as shown in Figure 26. Move the lever
into the CLOSED position (Fig. 28). At the halfway closed
position of the quic release lever, you should start to feel some
resistance to this motion.
5. If the lever is moved to the CLOSED position with little or
no resistance, clamping strength is insufficient. Simply return the
lever to the OPEN position, tighten the quic release adjusting
nut further and close the lever, testing again for resistance. When
the quic release device is properly tightened, and clamped to the
closed position, the clamping force is adequate to cause metal
into metal engagement (embossing) of the for surfaces.
• Do not tighten the quick release by using the
quick release lever like a wing nut (Fig. 27). This
will not result in sufficient force to hold the
wheel in place.
6. Orient the quic release lever so that it does not
interfere with any other stroller part and so that it will not
become accidentally snagged by obstacles in the path of the
jogging stroller (Fig. 28).
Rear wheel
7. Insert the rear hub axle (Fig. 29) into the axle tube (Fig. 30) until the loc ing
clip engages. You should hear a clic as this happens, and the clip spring should sit
against the axle tube.
Fig. 28
Fig. 29
Hub axle
16
OPEN
CLOSED
OPEN
CLOSED
OPEN
OPEN
OPEN
OPEN
Fig. 24 Fig. 2 Fig. 26 Fig. 27
OPEN
CLOSED

17
WARNIN
Test for wheel retention
8. Do these two tests to ensure that you have adequately
performed these procedures:
• Pic the front of the jogging stroller off of the ground, and give
the top of the front tire a sharp downward blow (Fig. 31). The wheel
should not come off, be loose, or move from side to side. If
uncertain, repeat the tightening process, as shown in Steps 2-6 of
these instructions.
• With the quic release lever properly adjusted and in a closed
position, you will not be able to rotate the quic release lever in a
circular motion parallel to the wheel (as opposed to the flipping
motion used to open and close the quic release lever- see Fig. 32).
9. For the rear wheel, test for a secure attachment by
attempting to pull the rear hub axle from the axle tube (Fig. 33).
You should not be able to pull the axle from the tube.
Lubrication
Lubricate spring clips once a month. Apply a drop of synthetic
lube or a similar light oil where the spring clip pin goes through
the axle tube (Fig. 30).
Regrease wheel bearings every year. This requires special tools
and training, so should only be done by your Chariot dealer.
Lubricate quic releases once a year. Apply several drops of
light oil where the quic release lever rotates in the quic
release body.
Fig. 31
X
Failure to have wheel quick release retention mechanisms properly
adjusted and closed, may cause loss of control resulting in personal
injury. If you have any questions about the operation of this system,
consult your Chariot dealer.
Fig. 32 Fig. 33
X
Axle tube
Clip spring
Fig. 30

ADDITIONAL FEATURES
Adjustable Sunshade
The sunshade on your stroller can be adjusted for convenience or protection of the
child. The sunshade can be pivoted bac on its hinge (Fig. 34).
Reclining seat
The seat bac offers an adjustable angle to the seatbac to enhance comfort. Adjust the
seat bac adjuster buc les (Fig. 34).
Storage
The jogging stroller has on-board storage for the many accessories required for child
maintenance. Loo for the mesh bac bag (Fig. 34), as well as the additional under-seat
bas et. The maximum capacity of the rear mesh storage poc et is 1 g (2.2 lbs). Do not
overload the rear storage poc et. Do not attach additional carrying bags or other items to
the bac or handlebars of the jogging stroller. Any additional weight on the bac of the
jogging stroller could ma e it unstable. Additional cargo may be stored in the lower cargo
poc et to a maximum of 3 g (6.6 lbs).
Tracking adjustment
The jogging stroller can be aligned so it will roll in a straight line. To adjust the trac ing,
move the loc ing tension bar to its upper unloc ed position, rotate one of the barrel
adjusters found at the bottom of the wheel struts (Fig. 36) at the cable insertion point. By
rotating the adjuster, cable tension is changed which aligns the axle tube with the front
wheel.
Seat Anchor Strap
The seat anchor strap is designed to eep the seat in place in the case of a sudden stop.
You must unsnap this strap from the center bac axle before you can fold your jogging
stroller. After up righting the jogging stroller, don't forget to reattach the seat anchor
strap to the centre of the bac axle. It will strap over the loc ing tension bar and down
under the axle. (Fig 37)
Removable Rain Cover
The removable rain cover will attach too your jogging stroller at 5 points (Fig 35). Place
the plastic rain cover over the jogging stroller. Wor ing from the top to bottom start by
attaching the 2 velcro tabs around the upper left and right handle bar corners, then
attach the velcro tabs around the right and left cable restraints, and finish attaching the
rain cover by securing the velcro tabs around the foot bar assembly.
Fig. 34 Fig. 3 Fig. 36 Fig. 37
18
Adjustable
sunshade
reclining seat
two storage
compartments tracking barrel
adjuster
anchor
strap

Parts List - Cavalier ‘01
Part # Part Quantity
A 40100445 Front Sub-Assembly 1
B 50103012 Quic Release S ewer 1
C 50101708 16" Alloy Wheel (Quic Release) 1
D 50101707 16" Alloy Wheel (Hollow Bearing) 2
E 50101304 Clevis Axle 2
F 50103031 Lanyard With Thumbscrew (Trac ing Adj) 2
G 50103030 Small Lanyard 2
H 40202018 Cable Restraint 2
I 40100450 Bac Leg Sub-Assembly 2
J 31100601 Fabric Sunshade 1
K 40101325 Handlebar Sub-Assembly 1
L 50101811 9" Foam Grip 2
M 40202020 Wrist Safety Strap 1
N 40202019 Par ing Bra e Strap 1
O 50103026 Par ing Bra e Kit 1
P 40100801 Sunshade Sub -Assembly 1
Q 30100601 Fabric Body 1
R 31100640 Plastic Rain Cover (Not Shown) 1
S 50200213 Shoulder Harness 1
T 40103033 Foot bar Sub-Assembly 1
U 50101404 1" Round End Cap 4
V 50101003 Axle Securing Peg (Not Shown) 2
19
0N L
K
J
M
P
H
G
I
D
E
F
C
B
U
P
T
Q
S
A
