Chevrolet 2005 Aveo Assembly instructions

Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . .2
Instrument Panel Cluster . . . . . . . . . . . . . . . . . . .3
Rear Folding Seat . . . . . . . . . . . . . . . . . . . . . . . . .4
Rear Center Safety Belt Operation . . . . . . . . . . .5
Passenger-Side Power Rearview Mirror . . . . . . .5
Audio Systems . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Wiper/Washer Controls . . . . . . . . . . . . . . . . . . . . .8
Power Door Locks and Lockout Protection . . . .8
Remote Keyless Entry and
Content Theft-Deterrent Systems . . . . . . . . . . . .9
Climate Control System . . . . . . . . . . . . . . . . . . . .9
Accessory Power Outlet and
Cigarette Lighter . . . . . . . . . . . . . . . . . . . . . . . . .10
Malfunction Indicator Lamp/
Service Engine Soon . . . . . . . . . . . . . . . . . . . . . .11
Shifting the Automatic Transaxle
into Park or Neutral . . . . . . . . . . . . . . . . . . . . . . .11
Automatic Transaxle Hold Control Mode . . . . .12
Reverse Lockout Feature
(Manual Transaxle) . . . . . . . . . . . . . . . . . . . . . . .12
Opening the Hood . . . . . . . . . . . . . . . . . . . . . . . .13
Roadside Assistance . . . . . . . . . . . . . . . . . . . . .16
My GMLink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Congratulations on your purchase of a Chevrolet Aveo. Please read this information and your Owner Manual
to ensure an outstanding ownership experience. Note that your vehicle may not include all the features
described in this booklet. Place this booklet in your Owner Manual portfolio for easy reference.
Aveo_r4.qxd 6/21/04 12:15 PM Page 1

A. Air Outlet
B. Instrument Panel Cluster
C. Air Outlet
D. Digital Clock and Secondary
Information Center
E. Hazard Warning Flashers Button
F. Air Outlet
G.Instrument Panel Brightness
Control
H. Hood Release
I. Audio System
J. Cupholder
K. Ashtray
L. Cigarette Lighter
M.Climate Control System
N. Glove Box
Getting to Know Your Aveo
2
Instrument Panel
See Section 3 of your Owner Manual.
Aveo_r4.qxd 6/21/04 12:15 PM Page 2

3
See Section 3 of your Owner Manual.
AB
Instrument Panel Cluster
Your vehicle’s instrument panel is
designed to let you know at a glance
how your vehicle is running. You’ll
know how fast you’re going, about
how much fuel you’ve used, and
many other things necessary for
driving safely and economically.
The instrument panel cluster includes
these key features:
A. Tachometer/Fuel Gauge/Coolant
Temperature Gauge
B. Speedometer/Odometer/Trip
Odometer
IMPORTANT: The instrument panel
cluster is designed to let you know
about many important aspects of
your vehicle’s operation. It is impor-
tant to read your Owner Manual and
become familiar with the information
being relayed to you by the lights,
gauges and indicators, as well as
what action can be taken to ensure
safety and to prevent damage.
Aveo_r4.qxd 6/21/04 12:15 PM Page 3

To create more cargo room, the rear
seatback can be folded down:
• Pull up the release knob on top of the
rear seatback (shown above).
• Your vehicle has adjustable head
restraints; push them down all the
way.
• Fold the seatback forward and down.
• Move the safety belts/buckles out
of the space between the seatback
and seatback cushion.
Getting to Know Your Aveo
4
Rear Folding Seat On 5-door model only:
• Pull both release tabs on the rear
side of the seat cushion to release
the rear seat.
• Lift and fold up the seat, and clip the
hook to the head restraint of the front
seat to keep the rear seat secure.
• Store rear safety belts/buckles in the
storage area under the floor mat.
• Reverse the process to return the
seatback to the upright position,
ensuring that the seat cushion and
seatback are securely latched and
that the safety belts/buckles are in
their original position between the
rear seatback and seat cushion.
See Section 1 of your Owner Manual.
Aveo_r4.qxd 6/21/04 12:15 PM Page 4

5
Passenger-Side Power Rearview
Mirror (if equipped)
Your vehicle may be equipped with an
outside power mirror control that adjusts
the passenger-side mirror. The control is
located on the driver door panel, above
the power window buttons. Adjust the
passenger-side mirror by pressing the
edges of the control pad to move the
mirror in the direction that you want it to
go. The ignition must be ON.
See Section 2 of your Owner Manual.
Rear Center Safety Belt
Operation
Your vehicle has a removable safety
belt in the rear center seating position.
To install the rear center safety belt:
• Pull the belt from the retractor.
• Push the latch plate at the end of the
safety belt strap into the buckle with
the black release button until the
mechanism clicks, ensuring that the
strap is not twisted and that the slid-
ing latch plate faces the front of the
vehicle.
• Insert the upper part of the safety belt
into the safety belt guide, ensuring
that the belt is not twisted.
The buckles for the rear center seat belt
are positioned outboard of the left and
right rear passenger’s buckles. The cen-
ter passenger’s seat belt uses two buck-
les. The center passenger’s buckles can
be identified by the black release button
on the left side, and by the word
“CENTER” on the top of the buckle on
the right side. The positions of the
buckles are correct. Please don’t try to
rearrange their position.
See Section 1 of your Owner Manual.
Aveo_r4.qxd 6/21/04 12:15 PM Page 5

Getting to Know Your Aveo
6
Audio Systems
AM/FM Radio (if equipped)
Use the following controls to operate the
system:
( ) (Power)
( ) (Volume)
AM/FM: Press this button to switch
between AM, FM1 and FM2.
( ) (Tune): Turn this knob to tune
stations.
( ) (Scan): Press this knob until
“SCAN” flashes on the display; then
press either the up or down arrow button
to determine the scanning direction.
() (Bass/Treble/Balance/Fade): Press
this button until BAS, TRE, BAL or FAD
appears on the display. Then turn the
volume knob to adjust to your preferred
settings.
Setting Preset Stations
You can preset up to 18 of your favorite
stations (six AM, six FM1 and six FM2)
using the six numbered pushbuttons on
the radio.
AM/FM Radio with CD Player and MP3
(if equipped)
Playing a CD
Insert a CD partway into the slot, label
side up. The player will pull it in and the
player will begin playing. (Note: You can
insert a CD with the ignition off.)
2 RPT (Repeat): Press this button to
repeat the current track. Press the but-
ton again to turn off repeat play.
3 INT (Scan): Press this button to listen
to the first few seconds of each track on
each CD inserted. Press the button
again to stop scanning. The current
track will begin to play.
4 RDM (Random): Press this button to
hear the tracks in random, rather than
sequential, order. Press the button again
to turn off random play.
TRACK (Previous/Next Track): Turn this
knob one notch to go to the start of the
current track or to go to the next track.
The player will continue moving back-
ward or forward through the CD with
each turn of the knob.
Aveo_r4.qxd 6/21/04 12:15 PM Page 6

7
TUN (Forward/Reverse): Press, turn and
hold this knob to fast forward or reverse
through the current track.
AM/FM: Press this button to listen to the
radio when a CD is playing.
CD: Press this button to play a CD when
listening to the radio. Press this button
while a CD is playing to pause the CD.
Press the button again to start playing
the CD.
( ) (Eject): Press this button to eject
a CD.
Playing an MP3
With the ignition on, insert a CD partway
into the slot, label side up. The player
will pull it in. The words “Loading,”
“Filecheck” and “MP3” will appear
sequentially on the display and the play-
er will begin playing.
As each new track starts to play, “F001”
(the track number) and the song name
will appear on the display.
MP3 Controls
All of the CD player functions work the
same while playing an MP3, except for
the following:
5DN (Down): Press this button to go to
the previous directory.
6UP: Press this button to go to the next
directory.
TRACK (Previous/Next File): Turn this
knob one notch to go to the first track in
the previous folder or to go to the next
folder. The player will continue moving
backward or forward through the CD
with each turn of the knob.
DIR (Directory): Press and release this
button to repeat tracks in the current
directory. Press and release this button
twice to repeat the tracks in all of the
directories. Press and release the button
again to turn off repeat play.
See Section 3 of your Owner Manual.
Note: Do not add paper labels to your
CDs, as they could get caught in the
player. Also, do not play 3-inch CDs
without a standard adapter CD. If an
error appears on the player display, see
CD Messages in Section 3 of your
Owner Manual.
Aveo_r4.qxd 6/21/04 12:15 PM Page 7

Getting to Know Your Aveo
8
Wiper/Washer Controls
The lever on the right side of the steer-
ing column operates the front and rear
windshield wipers. Move the lever to the
following positions to operate the front
wipers:
HI (High Speed): Move the lever to this
position to wipe at high speed.
LO (Low Speed): Move the lever to this
position to wipe steadily at slow speed.
INT (Intermittent): Move the lever to this
position to choose a delayed wiping
cycle.
OFF: Move the lever to this position to
turn off the windshield wipers.
To wash the windshield, pull the lever
toward you. When you release it, the
washers will stop, then continue for
several cycles and go to their previous
setting.
Rear Wiper/Washer: Push the lever
away from you to operate the rear wiper.
The wiper operates continuously in the
first position. Push it to the second posi-
tion and washer fluid will spray onto the
rear window.
See Section 3 of your Owner Manual.
Power Door Locks and Lockout
Protection
Your vehicle may have a central door
locking/unlocking system that is activat-
ed from the driver door. When the driver
door is closed, pushing the lock knob
down (shown below) centrally locks all
doors.
To prevent accidental lockouts, this func-
tion will not operate when the driver
door is open, and the driver door itself
will not lock when it is open.
You can also lock or unlock your vehicle
with the ignition key, or by using the
optional Remote Keyless Entry
transmitter. To further prevent lockouts,
the Remote Keyless Entry System will
not lock the driver door if it is open.
However, central locking will lock all
doors if the driver door is closed and
other doors are open.
See Section 2 of your Owner Manual.
Aveo_r4.qxd 6/21/04 12:15 PM Page 8

9
Remote Keyless Entry and
Content Theft-Deterrent
Systems (if equipped)
On equipped vehicles, use the Remote
Keyless Entry System transmitter
(integral to the ignition key) to:
• Unlock the vehicle doors by pressing
the UNLOCK button once.
• Lock the doors and arm the Content
Theft-Deterrent System by pressing
the LOCK button once to lock all
doors.
The Content Theft-Deterrent System will
arm only if you use the remote transmit-
ter or lock the doors with a power lock
switch. It will not arm if you lock the door
with a key. To turn off the alarm, press
the UNLOCK button on the key or
unlock any door with the key.
The remote transmitter’s range is up to
about 20 feet (6 m). If it doesn’t work or
range is reduced, check the:
• Distance — you may be too far away.
• Location — other vehicles or objects
may be blocking the signal.
• Battery in the transmitter (use
replacement battery CR1616).
• Match of the transmitter to the vehicle
(see Owner Manual).
See Section 2 of your Owner Manual.
Climate Control System
Use the following controls to operate
your climate control system:
Air Temperature: Turn the temperature
knob (see “A” above) clockwise or coun-
terclockwise to increase or decrease the
temperature.
Air Conditioning (if equipped): With
the fan turned on, press the air condi-
tioning button (see “B” above) to turn the
A/C on or off.
Fan Knob: Turn the fan control (see “C”
above) clockwise or counterclockwise to
increase or decrease fan speed.
Recirculation: Press this button (see
“D” above) to prevent outside air from
entering the vehicle. If your vehicle has
an air intake lever (base models), move
the lever to choose the recirculation
mode. Note: Extended use of the recir-
culation mode can cause the windows to
fog. If this happens, select the defrost
mode.
Mode Knob: Use this knob (see “E”
above) to direct the flow of air into your
vehicle. Modes include:
(Vent): Directs air to the instrument
panel outlets.
(Bi-Level): Directs half of the airflow
to the instrument panel outlets and the
rest to the floor outlets.
B
C
ADE
Aveo_r4.qxd 6/21/04 12:15 PM Page 9

Getting to Know Your Aveo
10
(Floor): Directs most of the air to the
floor outlets, and, on equipped vehicles,
to the rear outlets as well. (Recirculation
does not work in this mode.)
(Defog): Directs most of the air to
the windshield and the floor outlets and
a small amount to the side window out-
lets. (Recirculation does not work in this
mode.)
To help clear the side windows quickly:
• Select the bi-level mode.
• Select the highest fan speed.
• Select A/C (if equipped).
• Select the temperature.
(Defrost): Directs most air to the
windshield, with some sent to the side
window outlets and floor outlets.
(Recirculation does not work in this
mode.)
(Rear Defogger): Press this button
to turn the rear window defogger on or
off. The heated outside rearview mirrors
on equipped vehicles will activate as
well.
See Section 3 of your Owner Manual.
Accessory Power Outlet and
Cigarette Lighter
Your vehicle has an accessory power
outlet to power accessories such as a
cell phone. It is located next to the park-
ing brake.
To use it, remove the protective cap and
plug in the accessory. Replace the cap
when not in use. (See your Owner
Manual for important safety details.)
The cigarette lighter is located to the
right of the front ashtray. With the igni-
tion key in the ACC or ON position (the
lighter will not operate in the OFF posi-
tion), push the lighter knob in all the way
and release it. When the element is fully
heated, the knob will pop back out
automatically.
See Section 3 of your Owner Manual.
Aveo_r4.qxd 6/21/04 12:15 PM Page 10
