Chevrolet Corvette 2023 Assembly instructions

2023
CORVETTE
GETTING TO KNOW YOUR
chevrolet.com
Certain restrictions, precautions, and safety procedures apply to your vehicle.
Please read your Owner’s Manual for complete instructions.
Review this quick reference guide for an overview of some important features in your Chevrolet Corvette.
Some equipment described in this guide may not be included in your vehicle. Contact your dealer for details on
a specific vehicle. All information contained in this guide is based on the latest information available at the time
of printing and is subject to change without notice. More information can be found in your Owner’s Manual and
at chevrolet.com/owners. For easy reference, keep this guide with your Owner’s Manual in your glove box.

2
Manual Shift
Paddles
INSTRUMENT PANEL
Stability Control Off
Low Tire Pressure
Brake System
Antilock Brake System
Stability Control Active
Door Ajar
Cruise Control
PARK
Electric Parking Brake
Charging System
Oil Pressure
Engine Coolant Temperature
Service Electric
Parking Brake
Traction Control Off
Low Fuel
Head-Up
Display
ControlsF
Cruise
Control/
Z-Mode
Buttons
Turn Signal
Lever/Exterior
Lamps Control Windshield
Wipers Lever
Hood Release/
Trunk Release
Buttons
Audio
Favorite
Station
Buttons
Audio
Volume
Buttons
Driver Information
Center/Heated
Steering WheelF/
Voice Recognition
Control Buttons
Steering
Wheel
Adjustment
Control
Electric
Parking
Brake
Switch
Customizable
Instrument
Cluster
Power Folding
MirrorF/Window
Controls
SYMBOLS
Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer
available. See the window label or your dealer regarding the features on an individual vehicle.

3
Infotainment
System
Touchscreen
Engine
Start/Stop
Button
Transmission
Shift Controls
Performance Data Recorder
SD Card SlotF
(in glove box) Glove Box
Button
Read your Owner’s Manual to
learn about the information being
relayed by the lights and gauges
of the instrument cluster.
See Introduction in your
Owner’s Manual.
Driver Mode
Control
Traction Control &
StabiliTrak Off/Front
Lift SystemF/Curb View
CameraFButtons
Transmission Temperature
Airbag Readiness
Check Engine
Driver Seat Belt Reminder
Front Lift System
NFC Bluetooth
Pairing Hotspot
Climate Controls/
Heated & Ventilated
SeatFControls
Accessory
Power Outlet
2
Passenger Seat
Belt Reminder
Security
Lamps On
Reminder
F Optional equipment Some equipment shown may not be included in your vehicle.
Stingray shown

4
REMOTE KEYLESS ENTRY TRANSMITTER (KEY FOB)
X2
Hatch/Trunk Release
Press and release followed by press and
hold to open the hatch/trunk.
Lower Convertible TopF
Press and release the Unlock button
and then press and hold the button
to lower the top.
Press and release the Lock button and
then press and hold the button to
open the engine compartment.
Vehicle Locator/Panic Alarm
Press and release to locate your vehicle.
The horn sounds and lights flash 3 times.
Press and hold to activate the alarm.
Press again to cancel the alarm.
KEY RELEASE
If vehicle power is lost, press the button on
the side of the transmitter to pull out the
key. Use the key to open the door. Pull the
looped cord below the instrument panel to
open the hood for access to the battery.
Lock
Press to lock all doors and
the fuel door. Press again to
fold the power mirrorsF.
Unlock
Press to unlock the driver’s
door and the fuel door only
or all doors, based on vehicle
settings. Press and hold for 3
seconds to open all windows.
To enable automatic mirror foldingF
when using the Lock and Unlock buttons,
go to Settings > Vehicle > Comfort and
Convenience > Remote Mirror Folding.
[
Remote Vehicle Start
Press twice to start the engine from out-
side the vehicle. The turn signal lamps will
flash. After entering the vehicle, turn on
the ignition.
X2
Hood Release
Press and release followed by press and
hold to open the hood.
Note: To change or enable some Remote Keyless Entry settings, go to Settings > Vehicle > Remote Lock,
Unlock, Start.
See Keys, Doors and Windows in your Owner’s Manual.
F Optional equipment Some equipment shown may not be included in your vehicle.
The system enables operation of the doors, hatch/
trunk, and hood without removing the Remote
Keyless Entry transmitter (key fob) from your
pocket or purse. The key fob must be within 3 feet
of the hatch/trunk, hood or door being unlocked.
KEYLESS UNLOCKING
With the key fob within range:
Press the driver’s door handle touchpad (A) to unlock the driver’s door only or all doors.
Press the passenger’s door handle touchpad to unlock all doors.
KEYLESS LOCKING
Press the Lock button on the key fob or interior door panel to lock all doors.
If Passive Locking is turned on in the Settings menu, all doors will lock automatically
after a short delay once all doors are closed.
See Keys, Doors and Windows in your Owner’s Manual.
KEYLESS ACCESS SYSTEM
A

5
KEYLESS ACCESS SYSTEM
PASSIVE LOCKING
To have all doors lock automatically after a short delay when the ignition is off, the
key fob is removed from the vehicle, and all doors are closed, go to Settings > Vehicle
> Remote Lock, Unlock, Start > Passive Door Lock.
To have the driver’s door or all doors unlock
when using the touchpad on the driver’s door
handle, go to Settings > Vehicle > Remote
Lock, Unlock, Start > Passive Door Unlock.
HATCH/TRUNK ACCESS
The vehicle must be in Park.
Press and release followed by press and hold
the
X2
button on the key fob, press and
hold the button on the driver’s door, or
press the touchpad (B) above the license
plate with the vehicle unlocked or, if locked,
with the key fob within range.
When closing the hatch/trunk, set the
decklid into the power latch. The latch will
close automatically.
HOOD ACCESS
The vehicle must be in Park.
Press and release followed by press and hold
the
X2
button on the key fob, press and
hold the button on the driver’s door, or
press the touchpad (C) in the driver-side grille
opening below the headlamp.
When closing the hood, set the hood striker
into the latch and then press on the front
edge of the hood until the latch clicks twice.
Never drive without the hood fully closed.
AUXILIARY DOOR RELEASES
If the vehicle battery is weak or disconnected,
the doors can be opened manually.
From inside the vehicle, pull the driver’s or
passenger’s door release handle (D) on the
floor near each door opening.
From outside the vehicle, use the mechanical
key from the key fob in the key cylinder,
located rearward of the driver’s door handle
in the air inlet (E), to open the driver’s door.
See Keys, Doors and Windows in your Owner’s Manual.
F Optional equipment Some equipment shown may not be included in your vehicle.
E
D
C
B

6
STARTING THE ENGINE/ON
With the transmission in Park, press the
brake pedal and then press the ENGINE
START/STOP button to start the engine. The
green button indicator will illuminate.
Note: If the key fob battery is weak, place the key fob in
the center console rear cupholder to enable the engine
to start. Replace the key fob battery as soon as possible.
STOPPING THE ENGINE/OFF
Shift to Park and then press the ENGINE START/STOP button to turn off the engine.
ACCESSORY MODE
With the engine off and the brake pedal not depressed, press the ENGINE START/
STOP button to place the ignition in accessory mode to operate the radio, windows
and other accessories. The amber button indicator will illuminate.
BATTERY LOCATION
The battery is located under a cover in the underhood compartment. To access the
battery, remove the left- and right-side shields first before removing the cover assembly.
If vehicle power is lost, pull the manual hood release cable twice, located under the left
side of the instrument panel, to open the hood.
BATTERY CHARGERF
If the vehicle is not driven weekly, or the battery is disconnected or drained, use the
optional battery maintainer to charge the battery. To operate the battery maintainer, plug it
into a standard electrical outlet and into the vehicle’s underhood accessory power outlet.
See Vehicle Care in your Owner’s Manual.
WINDOW PROGRAMMING
To provide a tight seal, window indexing automatically lowers the window slightly when
the door is opened and then automatically raises the window when the door is closed.
If battery power is disconnected, program the power windows:
1. Close all doors and start the vehicle.
2. Partially open the window to be programmed and then fully close the window.
Continue to hold up the window switch briefly after the window has closed.
3. Fully open the window. Continue to hold down the window switch briefly after the
window has opened.
Note: The power windows’ express-close feature and the power convertible top
F
will not operate until
the windows are programmed.
See Keys, Doors and Windows in your Owner’s Manual.
KEYLESS (PUSH-BUTTON) START
BATTERY TIPS
The Remote Keyless Entry transmitter (key fob) must be present to start the vehicle.
See Driving and Operating in your Owner’s Manual.
F Optional equipment Some equipment shown may not be included in your vehicle.

7
SEAT ADJUSTMENTS
A. Seat Cushion Adjustment
Move the horizontal control to slide the seat
forward or rearward, and to tilt, raise or lower
the seat.
B. Seatback Adjustment
Move the vertical control to recline or raise the
seatback.
C. Lumbar/Side Bolster Adjustment
F
Press the round control forward or rearward to
adjust the lumbar support, and up or down to adjust the side bolsters.
SET DRIVER’S SEAT MEMORY POSITIONSF
1. With the vehicle On and in Park, adjust the
driver’s seat, power outside mirrors, and
power steering columnFto the desired
positions.
2. Press and release the SET button on the
driver’s door. A beep will sound.
3. Immediately press and hold button 1or 2
until two beeps sound. Use the button that
matches the Driver Information Center welcome message indicating driver 1 or 2. To
identify each Remote Keyless Entry transmitter (key fob), one has a chrome flag and
the other has a black flag.
To store seat and power steering column positions for more clearance when exiting the
vehicle, repeat these steps using the EXIT button instead of button 1or 2.
RECALL DRIVER’S SEAT MEMORY POSITIONSF
Press and hold button 1, 2or EXIT until the set position is reached.
To set the memory/exit positions to be recalled automatically when the ignition is
turned on/off (for exit recall, the driver’s door must be opened), go to Settings >
Vehicle > Seating Position > Seat Entry Memory and Seat Exit Memory.
SET PASSENGER’S SEAT MEMORY POSITIONSF
1. With the vehicle On and in Park, adjust the passenger’s seat to the desired position.
2. Press and release the SET button on the passenger’s door. A beep will sound.
3. Immediately press and hold button 1or 2until two beeps sound.
To store a seat position for more clearance when exiting the vehicle, repeat these steps
using the EXIT button instead of button 1or 2.
To recall a setting, press and hold button 1, 2or EXIT until the set position is
reached.
See Seats and Restraints in your Owner’s Manual.
POWER SEATS
F Optional equipment Some equipment shown may not be included in your vehicle.
CAB

8
LIGHTING
EXTERIOR LAMPS
Rotate the band to operate the exterior lamps.
Off/On
AUTO Automatic Headlamp System
Automatically activates the Daytime Running
Lamps (DRLs) or the headlamps and other
exterior lamps depending on outside light
conditions.
Parking Lamps
Headlamps
INTERIOR LIGHTING
Instrument Brightness Control
Rotate the knob to brighten or dim the
instrument panel lighting during nighttime use.
ENGINE COMPARTMENT LAMPSF
The engine compartment lamps will turn on
briefly when any door is unlocked or opened, or
when the engine compartment is opened.
The lamps will turn off when all doors and the
engine compartment are closed, the doors are
locked, the vehicle begins to move after shifting
out of Park, or the ignition is turned On.
WINDSHIELD WIPERS
Move the lever up/down to activate the wipers.
HI Fast Wipes
LO Slow Wipes
INT Intermittent Wipes
Rotate the band up for more frequent wipes or
down for less frequent wipes.
OFF
1x Single wipe
Washer Fluid
Pull the lever to spray washer fluid on the
windshield.
See Lighting in your Owner’s Manual.
See Instruments and Controls in your Owner’s Manual.
F Optional equipment Some equipment shown may not be included in your vehicle.

9
INFOTAINMENT SYSTEM
NFC Bluetooth Pairing
Hotspot (requires
compatible smartphone)
Power/Volume/
Mute/Unmute
speakers
Additional Page Views:
Swipe to display overview
page or additional pages
(if available)
Applications Tray:
Shortcuts to commonly
used apps
ApplicationsF:
Touch a screen icon to
access an app
Home
Page Views
The infotainment system uses a Bluetooth or USB connection to link to a compatible
device, such as a smartphone or portable audio player, and offers hands-free voice
control. You can use simple gestures on the touchscreen, such as tap, drag and swipe,
tointeract with the system. For assistance, call 1-855-478-7767 or visit
chevrolet.com/support.
MANAGING HOME PAGE ICONS
1. Press the Home button.
2. To enter edit mode, touch and hold the Home page icon to move.
3. Continue holding the icon and drag it to the desired position, and then release.
See Infotainment System in your Owner’s Manual.
Read your Owner’s Manual for important information about using the infotainment system while driving.
F Optional equipment Some equipment shown may not be included in your vehicle.

10
INFOTAINMENT SYSTEM
STORING FAVORITES
Radio stations from all bands (AM, FM or SiriusXM
F
) can be stored in any order. The audio
source options are on the left side of the audio screen.
1. Display the desired radio station.
2. Select the desired page of favorite screen buttons.
3. Touch and hold one of the favorite screen buttons until a beep is heard.
VOICE RECOGNITION
Control the music source, enter a navigation destination
F
, make phone calls hands-free
(after pairing your Bluetooth-enabled phone), and perform other tasks using the natural
voice recognition system.
1. Push the Push to Talk button on the steering wheel.
2. The system will play a prompt.
3. After the prompt, say what you want it to do using natural speech.
Examples: “Call Dave” or “Tune to 99.5 FM.” Say “Help” for assistance.
BLUETOOTH VOICE RECOGNITION
Bluetooth voice recognition allows access to the voice recognition commands on a
paired, compatible mobile phone; e.g. Siri or Google Assistant.
To activate Bluetooth Voice Recognition, press and hold the Push to Talk button
for a few seconds.
APPLE CARPLAY® AND ANDROID AUTO™†
Apple CarPlay or Android Auto capability is available through a compatible phone using
the Apple CarPlay or Android Auto icon on the Home page.
1. Download the Android Auto app to your compatible phone from the Google Play Store.
No app is required for Apple CarPlay.
2. There are two ways to set up device projection:
•Wireless Connection – Connect your phone by pairing it to the in-vehicle Bluetooth
system. Turn on wireless Apple CarPlay or Android Auto in your phone’s settings.
•Wired Connection – Connect your phone to a USB data port using the USB cable
provided with your phone. Aftermarket USB cables may not work.
3. Follow the instructions on the infotainment system and the phone.
4. The Apple CarPlay or Android Auto icon will illuminate when connected. Touch the icon
to have your apps displayed.
To exit Apple CarPlay or Android Auto, press the Home button. To return to Apple
CarPlay or Android Auto, press and hold the Home button.
See Infotainment System in your Owner’s Manual.
F Optional equipment
†Android and Android Auto are trademarks of Google LLC; Apple CarPlay is a trademark of Apple Inc.
User terms and privacy statements apply.
