Chevrolet Impala Assembly instructions

Review this Quick Reference Guide for an overview of some important features in your Chevrolet Impala.
More detailed information can be found in your Owner Manual. Some optional equipment F described in
this guide may not be included in your vehicle. For easy reference, keep this guide with your Owner Manual
in your glove box.
www.chevrolet.com

2
Electric
Parking
Brake Switch
Instrument Panel
Illumination
Control
Cruise Control/Forward
Collision Alert
F
/Heated
Steering Wheel
F
Buttons
Windshield
Wipers
Lever
Tilt/Telescope
Steering
Wheel Lever
Turn Signal Lever/
Exterior Lamp
Controls
Audio Next/Previous
Favorite Station
Controls (behind
steering wheel)
Trunk Release/
Parking Assist/
Lane Departure
Warning
F
Buttons
INSTRUMENT PANEL
Low Fuel
Door Ajar
Traction Control Off
Engine Coolant
Temperature
Brake System
Cruise Control Set
StabiliTrak Active
StabiliTrak Off
Security
!
Speed Sensitive
Power Steering
Reduced Engine
Power
Parking Assist
2
Passenger Safety
Belt Reminder
Check Engine
Oil Pressure
Audio Volume
Controls (behind
steering wheel)
Phone
Buttons/Driver
Information
Center Controls
Instrument Cluster Symbols

3
Refer to your Owner Manual to learn about the information
being relayed by the lights, gauges and indicators on the
instrument cluster.
See In Brief in your Owner Manual.
Hazard Warning
Flashers Button
Storage
Compartment Open/
Close Button
F
Driver’s
Heated/Cooled
Seat Buttons
F
StabiliTrak
Button
Passenger’s
Heated/Cooled
Seat Buttons
F
Infotainment
System
Climate
Controls
FOptional equipment
Charging System
Safety Belt Reminder
Airbag Readiness
Antilock Brake System
Low Tire Pressure

4
Unlock
Press to unlock the driver’s
door. Press again to unlock
all doors.
Lock
Press to lock all doors.
The driver’s door will
not lock if open.
Vehicle Locator/
Panic Alarm
Press and release to
locate your vehicle. The
turn signal lamps will ash
and the horn will sound.
Press and hold to activate
the alarm. The turn signal
lamps will ash and the horn
will sound until the button is
pressed again or the ignition is turned on.
Trunk
Press and hold to unlock the trunk.
DOOR LOCKS/TRUNK RELEASE
Door Locks
To lock or unlock all doors, press the power door Lock/ Unlock button, located on
the front doors.
Note: Open Power Door Locks in the Vehicle Settings menu to change the lock and unlock settings.
To open a locked door from inside, pull the inside door handle to unlock the door and
then pull the door handle again to open the door.
Trunk Release
To open the trunk, with the vehicle unlocked, press the Trunk Release on the left
side of the instrument panel or press the touchpadFabove the license plate.
See Keys, Doors and Windows in your Owner Manual.
FOptional equipment
Remote Vehicle StartF
Press and release the Lock button and
then press and hold the button to start
the engine from outside the vehicle. After
entering the vehicle, turn the ignition to the
ON position.
• During a remote start, the engine
will run for 10 minutes.
• Press and hold the button to
cancel a remote start.
Note: Open Remote Lock, Unlock, Start
in the Vehicle Settings menu to change
the remote lock, unlock, and remote start
settings.
If the remote start heated seat
option is selected, the heated seat
button indicators do not illuminate
and the temperature performance of the
unoccupied heated seat may be reduced
during the remote start. The heated seat
turns off when the ignition is turned ON.
See Keys, Doors and Windows in your Owner Manual.
REMOTE KEYLESS ENTRY TRANSMITTER (KEY FOB)

5
KEYLESS ACCESS SYSTEMF
KEYLESS ACCESS STARTF
The Keyless Access System enables operation of the doors and ignition without removing
the key fob from a pocket or purse. The key fob must be within three feet of the door being
unlocked or the trunk.
Keyless Unlocking
With the key fob within range:
Press the lock sensor on the driver’s
door handle to unlock the driver’s door;
press it again within ve seconds to unlock
all doors.
Press the lock sensor on a passenger
door handle to unlock all doors.
Press the touchpad above the license
plate to open the trunk. Touchpad included with the Keyless Access System only.
Keyless Locking
With the ignition off, the key fob out of the vehicle, and all doors closed:
Press the lock sensor on any door handle to lock all doors immediately.
If passive locking is turned on, all doors will lock automatically after a short delay once
all doors are closed.
Note: Open Vehicle Settings in the Conguration menu to change the door lock and unlock settings.
See Keys, Doors and Windows in your Owner Manual.
Starting the Engine
With the vehicle in Park or Neutral, press
the brake pedal and then press and hold
the START/STOP button to start the
engine.
Note: The key fob must be in the vehicle to turn
on the ignition. If the key fob battery is weak, place
the key fob in the pocket in the center console to
enable the engine to start. Replace the key fob
battery as soon as possible. The vehicle cannot be
started if the key fob is lost or damaged.
Stopping the Engine
Shift to Park and press the START/STOP button to turn off the engine.
Accessory
With the engine off, press the START/STOP button to place the ignition system in the
accessory position.
See Driving and Operating in your Owner Manual.
FOptional equipment

6
POWER SEATSF
A. Seat Adjustment
Move the front horizontal control to
move the seat forward or rearward, or to
tilt, raise or lower the seat.
B. Seatback Recline Adjustment
Move the vertical control to recline or
raise the seatback.
C. 4-way Lumbar Adjustment
Press the rear control to adjust the
lumbar support.
See Seats and Restraints in your Owner Manual.
Set Memory Positions
1. Adjust the driver’s seat, power outside mirrors and the power steering columnFto the
desired positions.
2. Press and hold the SET button and button 1 at the same time until a beep sounds.
3. Repeat the steps using button 2 for a second driver.
Set Exit Position
1. Adjust the driver’s seat, power outside mirrors and the power steering columnFto the
desired positions.
2. Press and hold the SET button and EXIT button on the driver’s door until a beep
sounds.
Recall Positions
At any time, press and hold button 1, 2 or until the stored position is reached.
Releasing the button before the stored position is reached cancels the recall.
With the vehicle in Park and the ignition ON, press and release button 1, 2 or to
recall the stored position.
Note: Open Comfort and Convenience in the Vehicle Settings menu to change the memory
recall settings.
See Seats and Restraints in your Owner Manual.
TILT/TELESCOPE STEERING WHEEL
MEMORY FEATURESF
FOptional equipment
With the vehicle parked, push down the lever on the left side of the steering column to
adjust the position of the steering wheel. The steering wheel can then be moved up or
down and in or out. Pull up the lever to lock the steering wheel in place.
See Instruments and Controls in your Owner Manual.
A B C

7
FOptional equipment
LIGHTING
Automatic Headlamp System
Rotate the band to activate the
exterior lights.
Off/On
AUTO Automatic Headlamp System
Automatically activates the Daytime
Running Lamps (DRLs) or the headlamps
and other exterior lamps depending on
outside light conditions.
Parking Lamps
Headlamps
Instrument Panel Brightness
Rotate and hold the switch located on the
left side of the instrument panel to adjust
the instrument panel lighting.
See Lighting in your Owner Manual.
Instrument Panel Lighting
AUDIO STEERING WHEEL CONTROLS
Volume (behind steering wheel on the
right side)
Press top or bottom button to adjust the
volume.
Next/Previous Favorite Station
(behind steering wheel on the left side)
Press top or bottom button to go to the
next or previous favorite radio station.
Next/Previous
Press or to go to the previous or next
radio station, track, or le.
Push to Talk
Press to answer an incoming call or to
interact with the audio, Bluetooth, naviga-
tionFor OnStar®system.
End Call/Mute
Press to end or reject a call.
Press to mute the vehicle speakers.
See Instruments and Controls in your Owner Manual.

8
INFOTAINMENT SYSTEM
FOptional equipment
Power/
Volume
RADIO:
Select AM,
FM, XM
F
Applications:
Touch the screen
icon to access
the application
Additional Pages:
Touch to view
additional pages
of applications
HOME
Home page
Storage
compartment
open/close
button
F
MEDIA:
Select the
media source
SEEK:
Previous/Next radio
station, track or le
TUNE/MENU:
Tune radio stations/
Open and select
menus
Eject disc
BACK:
Move back
one level in the
menus
Touchscreen infotainment system shown.
F
The infotainment system controls include the audio system buttons and touchscreen.
Refer to your Owner Manual for important safety information about using the infotainment system
while driving.
Touchscreen Sensitivity
To adjust the touchscreen’s sensitivity, open the Vehicle Settings menu and select Display
> Calibrate Touchscreen.
See Infotainment System in your Owner Manual.
Favorite Pages:
Display pages
of favorite radio
stations

9
INFOTAINMENT SYSTEM
FOptional equipment
Setting the Time
1. Touch Settings on the home page.
2. Touch Time and Date.
3. Touch Set Time.
4. Touch the arrows to adjust the hours, minutes and AM or PM.
5. Touch BACK to exit the menu.
Storing Favorite Stations
Radio stations from all bands (AM, FM or XMF) can be stored, in any order, with ve
stations per page and up to ve pages.
1. Tune in the desired radio station.
2. Touch and hold one of the favorite screen buttons until a beep is heard, indicating it
is stored.
3. Repeat the steps to store another favorite station.
Note: Open Radio in the Vehicle Settings menu to customize the number of favorite screen buttons
available.
Portable Audio Devices
Note: Connect an iPod/iPhone USB cord after
starting the vehicle for optimum performance.
An accessory power outlet, a 3.5mm auxil-
iary input jack, a USB port and an SD card
slotFare located in the center console.
An iPod™, iPhone™, MP3 Player, a
USB ash drive or a USB mass storage
device can be connected to the USB
port. Chevrolet MyLinkFwill read the
device and build a list of voice com-
mands. Search for music on-screen or
by voice commands.
Press the MEDIA button to select a
portable device as the audio source.
See Infotainment System in your Owner Manual.

10
CHEVROLET MYLINKF
MyLink uses a Bluetooth or USB connection to link a smartphone, cell phone, USB ash
drive or portable audio player/iPod™ to the touchscreen infotainment display. MyLink
enables streaming audio through a smartphone and hands-free voice control. Music also
can be played from a USB ash drive.
For assistance with Bluetooth pairing, application downloading and installation, mobile
device compatibility, and operation of the MyLink system, contact Customer Assistance at
1-855-4-SUPPORT (855-478-7767) or visit www.chevrolet.com/mylink.
Voice Recognition
Control the music source and make phone calls hands-free (after pairing your Bluetooth-
enabled phone) using the enhanced voice recognition system.
1. Press the Push to Talk button on the steering wheel.
2. The radio will say “Say a command,” followed by a beep.
3. After the beep, say what you want it to do.
•Phone (using your paired phone):
Example command: “Call Amanda” or “Dial 555-1212”
• MediaMusicDeviceSearch(whenconnectedtoUSBonly):
Example command: “Play artist [name]” or “Play song [name]”
• Radiocontrol:
Example command: “Tune FM 104.3” or “Tune XM Classic Vinyl”
• Help:
Say “Help” for voice recognition assistance
PANDORA®Internet Radio
Listen to personalized radio stations based on favorite artists or genres (a slight delay may
occur when loading a song or changing a station).
Download the Pandora app to your smartphone. Restart the smartphone and sign in to
Pandora.
Create a station on your phone to listen to a customized song list in the vehicle.
Touch the Pandora icon on the touchscreen to access Pandora. A slight delay may
occur when loading a song or changing a station.
Note: Pandora can be played using the Bluetooth connection. However, the Pandora voice
commands will be active only when connected to the USB port.
See Infotainment System in your Owner Manual.
FOptional equipment
