Operation manual
CHIAYO ELECTRONICS CO.,LTD.
DPRB-600M
DPRB-500M
MP3 recorder & Bluetooth module

1
DPRB-600/500M MP3 recorder & Bluetooth module
Bluetooth receiver section (LEFT)
Linking instruction
1 Turn on the Bluetooth receiver and both
SCAN and LOCK LEDs will flash
alternatively.
2 Activate Bluetooth on your device and
search new external Bluetooth device
named “Bluetooth Speaker”.
3 Once the linking is finished, the LOCK LED
will flash green.
4 Pressing LINK button can cut the
connection.

Digital recorder player section (RIGHT)
remote control
1.LCD display
2.Press to return to previous track, press and
hold to fast reverse.
3.Press to play/pause or stop recording.
(readable formats: mp3, wav and wma)
4.Press to go to next track, press and hold to
fast forward.
5.Press to record.
6.Press to switch repeat modes.
7.Press to stop playing or recording.
8.IR sensor area
9.USB input
10.
USB/SD indicator: The LED flashes green
during playing and red during recording. It
lights red if there is no track to play, lighting
green when playing or recording stops.
11.
SD card input
12.
Power switch/volume control
123
4
Settings Bluetooth
Bluetooth
DEVICES
Bluetooth Speaker
Now Discoverable
...
12
1234
567
8
910
11
1.Power/volume control
2.LINK button
3.LOCK LED
4.SCAN LED

2
Instructions
Operating functions on the panel and the remote
Operating function
On the panel
On the remote
Play/pause
Press
Press
Record
Press to record and or to
stop.
Press to record and or
to stop.
Skip forward
Press
Press
Fast forward
Press and hold
Press and hold
Skip backward
Press
Press
Fast backward
Press and hold
Press and hold
Next folder
-
Press
Previous folder
-
Press
Track select (#0-9)
-
input track number, then press
USB/SD switch
-
Press
Repeat mode switch
(ALL / SINGLE / FOLDER)
Press
Press
Volume control
-
Press or
A-B section play
-
Press to start, again to play
section and again to stop
Delete tracks
-
Press to delete track and again
to confirm your delete
Mute
-
press to mute/recover
Note:
Supports FAT and FAT32 file systems only.
Supports MP3, WAV and WMA music formats only
Record track format :MP3; Bit rate: 128kbps; Sampling frequency: 44kHz
Recordable only when USB/SD is detected.
Record files will be stored in the RECORD folder of USB/SD.
The files will be named as FILE_001, FILE_002, FILE_003…etc.
The name of a deleted track won’t be applied to its next one.
Recordable until FILE_999 appears with LCD displaying “Num Full”.
LCD displays USB FULL or “SD FULL”when insufficient memory left.
LCD displays SD LOCK if the SD is locked.
Don’t remove the USB/SD during the recording process in case the interrupted track might be
damaged.
