C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S
1
NOTE: Information shown is correct at time of publication and is subject to change.
2011 Chrysler 200 Convertible
SPECIFICATIONS
The information shown is preliminary and based on data available at the time of publication. All dimensions are in inches
(millimeters) unless otherwise noted. All dimensions are measured at curb weight with standard wheels and tires unless
otherwise noted.
GENERAL INFORMATION
Body Style
Four-door sedan
Assembly Plant
Sterling Heights Assembly, Mich.
EPA Vehicle Class
Mid-size sedan
Introduction Date
January 2011
ENGINE: 2.4-LITER, GASOLINE, DOHC, 16-VALVE, VVT, SMPI I-4
Availability
Standard on 200 Touring
Type and Description
Four-cylinder inline, tuned intake manifold with electronic active charge
motion control valves with dual counter-rotating balance shafts
Displacement
144 cu. in. (2360 cu. cm)
Bore x Stroke
3.46 x 3.82 (88 x 97)
Valve System
Chain-driven DOHC, 16 valves, electronically controlled dual variable-
valve timing (VVT), direct-acting shimless mechanical bucket tappets
Fuel Injection
Sequential, multi-port, electronic, returnless
Construction
High-pressure die-cast aluminum block with dry iron liners, cast-aluminum
cylinder heads, cast-aluminum ladder frame, forged-steel crankshaft
Compression
10.5:1
Power (SAE net, estimated)
173 bhp (129 kW) @ 6,000 rpm (71 bhp/liter)
Torque (SAE net, estimated)
166 lb.-ft. (225 N•m) @ 4,400 rpm
Max. Engine Speed
6,500 rpm (electronically limited)
Fuel Requirement
Unleaded regular, 87 octane (R+M)/2
Oil Capacity
4.5 qt. (4.23L) SAE 5W-20
Coolant Capacity
7.7 qt. (7.3L)
Emission Controls
Single catalytic converter dual heated oxygen sensors and engine
features(a)
Estimated EPA Fuel Economy mpg
(City/Hwy)
18 mpg city/29 mpg highway
(a) Meets Federal Tier 2, Bin 5 emissions requirements and PZEV requirements in California, Massachusetts, New York, Maine,
Vermont, Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington. Meets Euro IV emissions
requirements.
ENGINE: 3.6-LITER, GASOLINE, DOHC, 24-VALVE, SMPI V-6
Availability
Available on 200 Touring. Standard on Limited and S
Type and Description
60-degree bank angle, liquid-cooled, three-plenum intake manifold with
electronically controlled manifold tuning valve and short-runner valves
Displacement
3605 cu. cm
Bore x Stroke
3.78 x 3.28 (96 x 83 mm)

C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S
2
Valve System
DOHC, 24 valves, hydraulic, roller finger followers
Fuel Injection
Sequential, multi-port, electronic
Construction
High-pressure die-cast A380 aluminum block with iron liners and semi-
permanent mold A319 aluminum heads
Compression Ratio
10.2:1
Power (SAE net, estimated)
283 bhp (211 kW) @ 6,400 rpm
Torque (SAE net, estimated)
260 lb.-ft. (353 N•m) @ 4,400 rpm
Max. Engine Speed
6,800 rpm (electronically limited)
Fuel Requirement
Unleaded regular, 87 octane (R+M)/2
Oil Capacity
6 qt. (5.7L) with dry filter SAE 5W30
Coolant Capacity
11.6 qt. (10.98L)
Emission Controls
Dual catalytic converters, four heated oxygen sensors, electronic EGR,
and internal engine features(d)
Estimated EPA Fuel Economy mpg
(City/Hwy)
19 mpg city/29 mpg highway
(d) Meets Federal Tier 2, Bin 5 emission requirements and ULEV II requirements in California, Massachusetts, New York, Maine,
Vermont, Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington. Meets Euro IV emissions
requirements.
TRANSAXLE: 62TE, AUTOMATIC SIX-SPEED OVERDRIVE
Availability
Standard on 200 Touring, Limited and S
Description
Six-speed, adaptive electronic control or Auto Stick driver-interactive
manual control and electronically modulated torque converter clutch
Gear Ratios
1st
4.127
2nd
2.842
3rd
2.283
4th
1.452
5th
1
6th
0.69
Reverse
3.214
Transfer Ratio
0.95
Final Drive Ratio
3.16 w/ 3.6L engine, 3.43 w/ 2.4L engine
Overall Top Gear
2.06 w/ 3.6L engine, 2.24 w/ 2.4L engine
DRIVETRAIN
Front-wheel Drive
Standard with all engines
DIMENSIONS AND CAPACITIES
General
Wheelbase
108.9 (2765)
Track, Front
61.7 (1567)
Track, Rear
62.7 (1594)
Overall Length
194.8 (4947)

C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S
3
Overall Width
72.5 (1842.6)
Overall Height w/Cloth Convertible Top
57.9 (1470)
Overall Height w/Retractable Hard Top
57.8 (1469)
Aero
Cd
.34
Fuel Tank Capacity, gal. (L)
16.9 (64.0)
Towing Capabilities, NAFTA Markets lbs. (kg)(e)
2.4L Auto. Trans
1,000 (450)
3.6L Auto. Trans
1,000 (450)
(e) Maximum frontal area of trailer or boat: 22 square feet 3.6L engine and 11 square feet 2.4L engine.
U.S. Curb Weight, Base Vehicle, lbs. (kg)
2.4L Gasoline Engine
3820 (1733) (200 Touring)
3.6L Gasoline Engine
3977 (1804) (200 Touring)
ACCOMMODATIONS
Seating Capacity - F/R
2/2
EPA Total Interior Passenger Volume,
cu. ft. (cu. m)
88.4 (2.50)
Front
Head Room w/o Sunroof
38.7 (984)
Head Room w/Sunroof
39.0 (992)
Legroom
42.4 (1077)
Shoulder Room
56.4 (1432)
Hip Room
52.7 (1339)
Seat Travel
10.2 (260)
EPA Front Compartment Volume,
cu. ft. (cu. m)
53.6 (1.52)
Rear
Head Room w/Cloth Convertible Top
37.0 (939)
Head Room w/Retractable Hard Top
36.3 (921)
Legroom
33.5 (850)
Shoulder Room
48.5 (1233)
Hip Room
44.2 (1123)
EPA Rear Compartment Volume,
cu. ft. (cu. m)
35.0 (0.99)
Cargo
Trunk Lift-over Height
31.2 (792)
EPA Total Trunk Volume – Top Up
13.1 (0.37)
EPA Total Trunk Volume – Top Down
6.6 (0.19)

C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S
4
BODY/CHASSIS
Layout
Transverse front engine with front-wheel drive
Construction
Steel unibody
SUSPENSION
Front
Independent MacPherson strut, coil spring over gas-charged shock
absorbers, stabilizer bar
Rear
Multi-link independent with coil springs, link-type stabilizer bar, gas-
charged shock absorbers and isolated rear suspension cradle
STEERING
Type
Power rack and pinion
Overall Ratio
16.65:1
Turning Diameter (curb-to-curb)
36.5 ft. (17-in. wheels), 37.7 ft. (18-in. wheels)
Steering Turns (lock-to-lock)
3.3 (17-in. wheels), 3.0 (18-in. wheels)
BRAKES
Power-assist Type
8 x 9 (204 x 230) tandem-diaphragm vacuum
Availability
Standard on Touring, Limited and S models
Front
Size and Type
11.5 x 1.0 (294 x 26) vented rotors with 2.2 (57.0) single-piston floating
caliper
Swept Area (Total Front)
223.5 sq. in. (1442.1 sq. cm)
Rear
Size and Type
10.3 x 0.4 (262 x 10) solid rotor with 1.4 (35.0) single-piston floating
caliper
Swept Area (Total Rear)
138.6 sq. in. (894.6 sq. cm)
Parking Brake Type
Drum-in-hat
Anti-lock Brake System (ABS)
Standard
Electronic Stability Control (ESC)
Standard
Traction Control
Standard
Brake Assist
Standard

C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S
5
WHEELS
Availability
Standard on 200 Touring model
Type and Material
Machined and painted cast-aluminum, Sparkle Silver
Size
17 in. x 6.5 in.
Availability
Standard on 200 Limited model
Type and Material
Polished with Painted Pockets, cast-aluminum, Satin Carbon
Size
18 in. x 7.0 in.
Availability
Standard on 200 S model
Type and Material
Polished with Painted Pockets, cast-aluminum, Gloss Black
Size
18 in. x 7.0 in.
TIRES
Availability
Standard on 200 Touring model
Size and Type
225/55R17, All-season
Model
Michelin Primacy MXV4 Touring
Revs per Mile (km)
778 (1252.0)
Availability
Standard on 200 Limited and S models
Size and Type
P225/50R18, All-season Touring
Model
Goodyear Eagle LS-2 Touring
Revs per Mile (km)
777 (1250.4)
• • •
